Q78-LIGHTV9CTablet PC

V9C User Manual ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: (86) 755 26779999 URL: http://www.zte.com.cn E-mail: [email protected] LEGAL INFORMATION Copyright © 2010 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version No. : R1.0 Edition Time : Manual No. : Contents For Your Safety ..................................................................................................................... 1 Product Safety Information ............................................................................................... 1 RF Exposure ...................................................................................................................... 1 General Statement on RF Energy.................................................................................. 1 Specific Absorption Rate (SAR) ................................................................................... 1 Body-worn Operation ................................................................................................... 2 Limiting Exposure to Radio Frequency (RF) Fields ..................................................... 3 Regulatory Information ................................................................................................. 3 Distraction ......................................................................................................................... 3 Driving .......................................................................................................................... 3 Operating Machinery .................................................................................................... 3 Product Handling .............................................................................................................. 3 General Statement on Handling and Use ...................................................................... 3 Small Children .............................................................................................................. 4 Demagnetization ........................................................................................................... 4 Electrostatic Discharge (ESD) ...................................................................................... 4 Air Bags ........................................................................................................................ 4 Seizures/Blackouts ........................................................................................................ 4 Repetitive Motion Injuries ............................................................................................ 4 Emergency Calls ........................................................................................................... 4 Loud Noise .................................................................................................................... 4 Device Heating .............................................................................................................. 4 Electrical Safety ................................................................................................................ 5 Accessories.................................................................................................................... 5 Connection to a Car....................................................................................................... 5 Faulty and Damaged Products ...................................................................................... 5 Interference ....................................................................................................................... 5 General Statement on Interference ................................................................................ 5 Pacemakers.................................................................................................................... 5 Hearing Aids ................................................................................................................. 5 Medical Devices ............................................................................................................ 5 Hospitals........................................................................................................................ 5 Aircraft .......................................................................................................................... 5 Interference in Cars ....................................................................................................... 6 Explosive Environments ................................................................................................... 6 Petrol Stations and Explosive Atmospheres ................................................................. 6 Blasting Caps and Areas ............................................................................................... 6 Getting Started ...................................................................................................................... 7 Overview ........................................................................................................................... 7 Key Definition................................................................................................................... 7 Starting Up ........................................................................................................................ 8 How to slot your SIM/memory card ............................................................................. 8 How to pop in your battery …

Text truncated - open the document above for the full version.

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Oct 8, 2011 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC(Telecommunication Metrology Center of MII) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Oct 8, 2011 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: Q78-LIGHTV9C To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

Q78-LIGHTV9C external photo Battery Battery Charger Label of Charger Headset Data cable

Q78-LIGHTV9C, label placement

Q78-LIGHTV9C internal photos

No.2011TAR476 Page 1 of 16 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2011TAR476 for ZTE Corporation Tablet PC Model Name: V9C FCC ID : Q78-LIGHTV9C with Hardware Version: d49a Software Version: GB_V9_GENERICV1.0.0B07 Issued Date: 2011-09-14 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633 , Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.2011TAR476 Page 2 of 16 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ............................................................................................................... 3 1.1. TESTING LOCATION ........................................................................................................... 3 1.2. TESTING ENVIRONMENT ................................................................................................... 3 1.3. PROJECT DATA ................................................................................................................... 3 1.4. SIGNATURE .......................................................................................................................... 3 2. CLIENT INFORMATION ........................................................................................................... 4 2.1. APPLICANT INFORMATION ................................................................................................ 4 2.2. MANUFACTURER INFORMATION ...................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT .......................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 4. REFERENCE DOCUMENTS .................................................................................................... 6 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 6 5. LABORATORY ENVIRONMENT .............................................................................................. 7 6. SUMMARY OF TEST RESULTS .............................................................................................. 8 7. TEST EQUIPMENTS UTILIZED ............................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 10 No.2011TAR476 Page 3 of 16 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Aug. 31, 2011 Testing End Date: Sep. 5, 2011 1.4. Signature Qu Pengfei (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2011TAR476 Page 4 of 16 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: ZTE Corporation Address /Post: #68 Zijin Hua Road, Nanjing, Jiangsu Province, P. R. China City: Nan Jing Postal Code: 210012 Country: China Telephone: +86-25-52878232 Fax: +86-25-68897541 2.2. Manufacturer Information Company Name: ZTE Corporation Address /Post: #68 Zijin Hua Road, Nanjing, Jiangsu Province, P. R. China City: Nan Jing Postal Code: 210012 Country: China Telephone: +86-25-52878232 Fax: +86-25-68897541 No.2011TAR476 Page 5 of 16 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description Tablet PC Model Name V9C FCC ID Q78-LIGHTV9C Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.7VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 355912040854528 d49a GB_V9_GENERICV1.0.0B07 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Battery 10021012280793208 AE2 Travel charger / AE3 USB cable / AE1 Model Li3734T42P3h1286049 Manufacturer ZTE Capacitance 3400mAh Nominal Voltage 3.7V AE2 Model STC-A22O50I1500M5 Manufacturer RUIDE Length of DC line 122cm AE3 Model / Manufacturer ZTE Length of DC line 120cm *AE ID: is used to identify the test sample in the lab internally. No.2011TAR476 Page 6 of 16 ©Copyright. All rights reserved by TMC Beijing. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version FCC Part 15, Subpart B Radio frequency devices July 10, 2008 Edition ANSI C63.4 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 2003 No.2011TAR476 Page 7 of 16 ©Copyright. All rights reserved by TMC Beijing. 5. LABORATORY ENVIRONMENT Semi-anecho…

Text truncated - open the document above for the full version.

V9C FCC test setup photo 1． Radiated Spurious Emission 2． Conducted Emission(Charging) 3． Conducted Emission(USB) 4． Radiated Emission(Charging) 5． Radiated Emission(USB) 6. part15C
