MF180A HSDPA USB Stick Quick Guide ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 LEGAL INFORMATION Copyright © 2011 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version No. : R1.0 Confidential and Proprietary Information of ZTE CORPORATION 1 Introduction The ZTE USB Stick is a multi-mode USB Stick, working in HSDPA/WCDMA/EDGE/GPRS/GSM networks. With USB interface connecting to a laptop or a desktop PC, it integrates the functionality of a modem and a mobile phone (SMS), and combines mobile communication with Internet perfectly. It supports data and SMS services through the mobile phone network, enabling you to communicate anytime and anywhere. MF180A Quick Guide 2 Confidential and Proprietary Information of ZTE CORPORATION Specification The following table shows the specification of your device. Interface Type USB 2.0 HIGH SPEED Systems supported Supports most types of laptop and desktop PC. Operating systems supported Windows XP(SP2 or later), Vista(32bit or 64bit), Windows 7 MAC(1 0.4 or later) Functions SMS service, Data service, Applications management, supports microSD card, etc. Network Standards HSDPA/WCDMA/EDGE/GPRS/GSM Transmission speed (Max) HSDPA: 3.6Mbps DL WCDMA CS: 64kbps UL/DL WCDMA PS: 384kbps UL/DL Temperature Storage: -40°C ~ +80°C Operation:-10°C ~ +60°C Dimension 78mm×27mm×11mm(without cap) Weight About 26g microSD capacity Up to 32GByte Notes: microSD is a trademark of SD Card Association. MF180A Quick Guide Confidential and Proprietary Information of ZTE CORPORATION 3 Getting to know your device The following figure shows the appearance of the MF180A. It is only for your reference. The actual product may be different. 1. Indicator 2. Front Cover 3. USB Connector 4. SIM/USIM card slot 5. microSD card slot MF180A Quick Guide 4 Confidential and Proprietary Information of ZTE CORPORATION Hardware Installation 1. Put finger on the bottom finger grip, and then lift the front cover of the modem to release and remove. Notes: Do not open the front cover rudely to avoid the damage of the front cover. 2. Insert the SIM/USIM card and microSD card. Insert the SIM/USIM card with the metal contact area facing downwards into the slot, and then insert the microSD card, shown as the following picture. Notes: The modem only supports microSD card. 3. Close the front cover as shown in the following picture. 4. Connect the Modem to your laptop or desktop PC.  Plug the USB connector into your computer’s USB port and make sure that it is tightly inserted. MF180A Quick Guide Confidential and Proprietary Information of ZTE CORPORATION 5  The OS will automatically recognize the new hardware and start the installation wizard. MF180A Quick Guide 6 Confidential and Proprietary Information of ZTE CORPORATION Warning and Notice To the owner • Some electronic devices are susceptible to electromagnetic interference sent by modem if inadequately shielded, such as the electronic system of vehicles. Please consult the manufacturer of the device before using the modem if necessary. • Operating of laptop and desktop PCs and the modem may interfere with medical devices like hearing aids and pacemakers. Please always keep them more than 20 centimeters away from such medical devices when they are turned on. Turn the modem off if necessary. Consult a physician or the manufacturer of the medical device before using the modem. • Be aware of the usage limitation when using a modem at places such as oil warehouses or chemical factories, where there are explosive gases or explosive products being processed. Turn off your modem if required. • The use of electronic transmitting devices is forbidden in aircrafts, at petrol stations and in hospitals. Please observe and obey all warning signs and switch off your modem in these conditions. • Do not touch the inner antenna area if not necessary. Otherwise it will affect your modem’s performance. • Store the modem out of the reach of little children. The modem may cause injury if used as a toy. • Do not touch the metallic parts of the modem so as to avoid a burn, when the modem is working. Using your USB Stick • Please use original accessories or accessories that are authorized. Using any unauthorized accessories may affect your modem’s performance, and violate related national regulations about telecom terminals. • Avoid using the modem near or inside metallic structures or establishments that can emit electromagnetic waves. Otherwise it may influence signal reception. • The modem is not waterproof. Please keep it dry and store in a shady and cool place. • Do not use the modem immediately after a sudden temperature change. In such case, it will produce dew inside and outside the modem, so don’t use it until it becomes dry. • Handle the modem carefully. Do not drop, bend or strike it. Otherwise the modem will be damaged. • No dismantling by non-professionals and only qualified technicians can undertake repair work. • Operating temperature range of -10°C ~ +60°C and humidity range of 5% ~ 95% are recommended. Limited Warranty • This warranty does not apply to defects or errors in the Product caused by: i. Reasonable abrasion. ii. End User’s failure to follow ZTE’s installation, operation or maintenance instructions or procedures. iii. End User’s mishandling, misuse, negligence, or improper installation, disassembly, storage, servicing or operation of the Product. iv. Modifications or repairs not made by ZTE or a ZTE-certified individual. v. Power failures, surges, fire, flood, accidents, actions of third parties or other events outside ZTE’s reasonable control. vi. Us…
