Q78-MF668AHSPA+ USB Stick

1 ZTE MF668A HSPA+ USB Modem User Manual 2 Contents 1 Modem Introduction ........................................................ 4 1.1 Introduction .......................................................................................... 4 1.2 Warning and Notice .............................................................................. 4 1.3 Applicability Scope ............................................................................... 6 1.4 System requirements ........................................................................... 6 1.5 Functions .............................................................................................. 7 1.6 Specification ......................................................................................... 7 2 Installation ........................................................................ 8 2.1 Outline and Parts ................................................................................. 8 2.2 Hardware Installation ........................................................................... 8 2.3 Software Installation ........................................................................... 10 2.4 Run the Application Software ............................................................. 14 2.5 Hardware Uninstall ............................................................................. 15 2.6 Software Uninstall .............................................................................. 15 3 Functions & Operation .................................................. 18 3.1 Interface introduction .......................................................................... 18 3.1.1 Main Interface ......................................................................... 18 3.1.2 Description of Mini Icons ......................................................... 19 3.2 Connecting to the Internet .................................................................. 20 3.3 SMS .................................................................................................... 21 3.3.1 Check SMS ............................................................................. 22 3.3.2 Create a new message ........................................................... 23 3.3.3 The SMS box operating guide ................................................ 25 3.4 Phonebook ......................................................................................... 25 3.5 Settings .............................................................................................. 27 3.5.1 Connection settings ................................................................ 28 3.5.2 Selection settings .................................................................... 30 3.5.3 Preference settings ................................................................. 30 3.5.4 SMS Settings .......................................................................... 31 3.5.5 Sound settings ........................................................................ 32 3.5.6 Security settings ...................................................................... 32 3 3.5.7 System settings ....................................................................... 33 3.5.8 Update settings ....................................................................... 33 3.6 Data record ........................................................................................ 34 3.7 MicroSD card ..................................................................................... 34 3.8 Help .................................................................................................... 34 4 FAQ ................................................................................. 35 4 1 Modem Introduction 1.1 Introduction Thank you for purchasing ZTE MF668A HSPA+ USB Modem. To guarantee that the modem is always in its best condition, please read this manual carefully and keep it for further use. The pictures, symbols and contents in this manual are just for your reference. They might not be completely identical with your modem. ZTE operates a policy of continuous development and reserves the right to update the technical specifications in this document at any time without prior notice. The ZTE MF668A HSPA+ USB Modem is a type of multi-mode, 3G modem, suitable for GSM/GPRS/EDGE/UMTS/HSDPA/HSUPA/HSPA+ networks. W ith a USB interface connecting to a laptop or a desktop PC, it integrates the functionality of a modem and a mobile phone (SMS and phonebook), combining mobile communication with internet perfectly. While connected to the mobile network, it can help you get SMS, data service and will help you break away from the limit of time and space, and realize wireless communication at any moment everywhere. 1.2 Warning and Notice To the owner  The use of electronic transmitting devices is forbidden in aircraft, at petrol stations and in hospitals. Please observe and obey all warning signs and switch off your modem in these conditions.  Operating USB modem may interfere with medical devices like hearing aides and pacemakers.  Be aware of warning signs in places such as oil refineries or chemical factories where there are explosive gases or explosive products being processed.  Store the USB modem out of the reach of children. The USB modem may cause injury if used as a toy or may be damaged by rough play or moisture.  Do not open the cover and touch the metallic (U)SIM bracket when the modem is working. Otherwise, you may get a burn. Modem  The USB modem must only be used with a PC that is certified to IEC 60950-1 (or equivalent) or a PC that has a power supply that is certified to IEC 60950-1 (or equivalent) or a PC that is powered by an internal battery and that has no connection to mains power. 5  Only use original accessories supplied by the manufacturer. Using unauthorised accessories may invalidate your warranty.  Avoid using the USB modem near or inside metallic structures …

Text truncated - open the document above for the full version.

内部公开 内部公开内部公开 内部公开▲ 本文中的所有信息归中兴通讯股份有限公司所有，未经允许，不得外传 第 1 / 1 页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China Date: Oct 12,2009 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC(Telecommunication Metrology Center of MII) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pur suant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Royce Wang ZTE CORPORATION Tel：0755-26770345 Fa x：0755-26770347 E- Mail：[email protected]

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Feb. 6, 2011 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: Q78-MF668A To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

MF668A External Photos:

Label

MF668A Internal Photos:

©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2011TAR047 for ZTE Corporation HSPA+ USB Stick Model Name: MF668A FCC ID : Q78-MF668A with Hardware Version: d32A Software Version: BD_MF668AV1.0.0B02 Issued Date: 2011-01-28 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633 , Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.2011TAR047 Page 2 of 14 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ............................................................................................................... 3 1.1. TESTING LOCATION ........................................................................................................... 3 1.2. TESTING ENVIRONMENT ................................................................................................... 3 1.3. PROJECT DATA ................................................................................................................... 3 1.4. SIGNATURE .......................................................................................................................... 3 2. CLIENT INFORMATION ........................................................................................................... 4 2.1. APPLICANT INFORMATION ................................................................................................ 4 2.2. MANUFACTURER INFORMATION ...................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT .......................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 4. REFERENCE DOCUMENTS .................................................................................................... 6 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 6 5. LABORATORY ENVIRONMENT .............................................................................................. 7 6. SUMMARY OF TEST RESULTS .............................................................................................. 8 7. TEST EQUIPMENTS UTILIZED ............................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 10 No.2011TAR047 Page 3 of 14 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Jan 11, 2011 Testing End Date: Jan 15, 2011 1.4. Signature Qu Pengfei (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2011TAR047 Page 4 of 14 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China City: Shenzhen Postal Code: 518057 Country: China Telephone: +86-21-68897541 Fax: +86-21-50801070 2.2. Manufacturer Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China City: Shenzhen Postal Code: 518057 Country: China Telephone: +86-21-68897541 Fax: +86-21-50801070 No.2011TAR047 Page 5 of 14 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description HSPA+ USB Stick Model Name MF668A FCC ID Q78-MF668A Extreme vol. Limits 4.8VDC to 5.2VDC (nominal: 5.0VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MII of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version N01 86485100000001 d32A BD_MF668AV1.0.0B02 *EUT ID: is used to identify the test sample in the lab internally. No.2011TAR047 Page 6 of 14 ©Copyright. All rights reserved by TMC Beijing. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version FCC Part 15, Subpart B Radio frequency devices July 10, 2008 Edition ANSI C63.4 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 2003 No.2011TAR047 Page 7 of 14 ©Copyright. All rights reserved by TMC Beijing. 5. LABORATORY ENVIRONMENT Semi-anechoic chamber (23 meters×17meters×10meters) did not exceed following limits along the EMC testing: Temperature Min. = 15 °C, Max. = 30 °C Relative humidity Min. = 30 %, Max. = 60 % Shielding effectiveness > 110 dB Electrical insulation > 10 k Ground system resistance < 0.5  Normalised site attenuation (NSA) < ±3.2 dB, 10 m distance, from 30 to 1000 MHz Uniformity of field strength Between 0 and 6 dB, from 80 to 2000 MHz Control room did not exce…

Text truncated - open the document above for the full version.

FCC ID: Q78-MF668A Test Set up photos: Part22/24 RSE: Part15B CE1: Part15B CE2: Part15B RE1: Part15B RE2:
