FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 48 of 410 6 RF EXPOSURE Applicable standard: FCC §2.1091 §1.1037 Limit According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. Limits for Maximum Permissible Exposure (MPE) Test Data Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S = EIRP/ 4!R² Where: S = power density EIRP= equivalent isotropically radiated power=ERP+2.15dB R = distance to the center of radiation of the antenna= [(ERP+2.15dB)/4!S] 1/2 According to §27.50 , the effective radiated power (ERP) of base transmitters and cellular repeaters must not exceed 1000 Watts. Frequency 2690MHz is between 1500MHz and 100,000MHz, and the Maximum S=1mW/cm 2 ð R=4.22m. This equipment should be installed and operated with minimum distance 4.22m between the radiator& your body. Test Result: pass

FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 1 of 410 FCC MEASUREMENT AND TEST REPORT For ZTE Corporation ZTE Plaza, Hi-tech Park, Nanshan District, Shenzhen, Guangdong, China 518057 FCC ID: Q78-R8882S2600 May 30, 2014 This Report Concerns: Original Report Equipment Type: LTE Remote Radio Unit Test Engineer: Bloom Report No.: RF20140041RP Test Date: May 1 – May 30, 2014 Reviewed By: Xie Yuming Prepared By: ZTETS Corporation ZTE Plaza, Hi-tech Park, Nanshan District, Shenzhen, Guangdong, China 518057, P.R.China Tel: +86-755-26770000 Fax: +86-755-26771999 Note: The test report is specially limited to the above company and this particular sample only. It may not be duplicated without prior written consent of ZTE Corporation. This report must not be used by the client to claim product certification 、approval 、or endorsement by any agency of the US Government. FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 2 of 410 1 TABLE OF CONTENTS 1 TABLE OF CONTENTS ............................................................................................................................................ 2 2 GENERAL INFORMATION ....................................................................................................................................... 4 Product Description for Equipment Under Test (EUT) .......................................................................................... 4 Objective ...................................................................................................................................................................... 4 Related Submittal(s)/Grant(s) ................................................................................................................................... 5 Test Methodology ....................................................................................................................................................... 5 Test Facility .................................................................................................................................................................. 5 3 SYSTEM TEST CONFIGURATION ......................................................................................................................... 6 Description of Test Configuration ............................................................................................................................. 6 4 SUMMARY OF TEST RESULTS ............................................................................................................................. 7 5 TRANSMITTER OUTPUT POWER ........................................................................................................................ 8 Applicable Standard：FCC §2.1046, §27.50 ......................................................................................................... 8 Test Equipment List and Details ............................................................................................................................... 8 Test Procedure ............................................................................................................................................................ 8 Environmental Conditions ......................................................................................................................................... 8 Test Result: Pass ........................................................................................................................................................ 9 Test Mode: Transmitting LTE ................................................................................................................................. 9 Test Data: ..................................................................................................................................................................... 9 6 RF EXPOSURE ............................................................................................................................................................. 48 Applicable standard: FCC §2.1091 §1.1037 ........................................................................................................ 48 Limit ............................................................................................................................................................................ 48 Test Data .................................................................................................................................................................... 48 Test Result: pass .......................................................................................................................................................... 48 7 MODULATION CHARACTERISTIC ........................................................................................................................... 49 Applicable Standard: FCC §2.1047 .................................................................................................................... 49 Test Equipment List and Details ............................................................................................................................. 49 Test Procedure .......................................................................................................................................................... 49 Test Data Environmental Conditions ..................................................................................................................... 49 Test Result: Pass ...................................................................................................................................................... 49 Test Mode: Transmitting LTE .................................................................................................................................. 49 Test Data: ....................................................................................…

Text truncated - open the document above for the full version.

FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 41 of 410 15M+15M -Port 2 –carry2-2682.5MHz Channel Bandwidth :20M+20M Port Carry1 Center Freq. (MHz) Carry1 Max output Power in dBm Carry2 Center Freq. (MHz) Carry2 Max output Power in dBm Max output Power in dBm 1 2630 41.83 2650 41.49 44.71 2645 41.77 2665 41.42 44.62 2660 41.99 2680 41.41 44.73 2 2630 41.86 2650 41.51 44.70 2645 41.76 2665 41.42 44.61 2660 41.97 2680 41.40 44.71 20M+20M -Port 1 –carry1-2630MHz FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 42 of 410 20M+20M -Port 1 –carry2-2650MHz 20M+20M -Port 1 –carry1-2645MHz FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 43 of 410 20M+20M -Port 1 –carry2-2665MHz 20M+20M -Port 1 –carry1-2660MHz FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 44 of 410 20M+20M -Port 1 –carry2-2680MHz 20M+20M -Port 2 –carry1-2630MHz FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 45 of 410 20M+20M -Port 2 –carry2-2650MHz 20M+20M -Port 2 –carry1-2645MHz FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 46 of 410 20M+20M -Port 2 –carry2-2665MHz 20M+20M -Port 2 –carry1-2660MHz FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 47 of 410 20M+20M -Port 2 –carry2-2680MHz FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 48 of 410 6 RF EXPOSURE Applicable standard: FCC §2.1091 §1.1037 Limit According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. Limits for Maximum Permissible Exposure (MPE) Test Data Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S = EIRP/ 4лR² Where: S = power density EIRP= equivalent isotropically radiated power=ERP+2.15dB R = distance to the center of radiation of the antenna= [(ERP+2.15dB)/4лS] 1/2 According to §27.50 , the effective radiated power (ERP) of base transmitters and cellular repeaters must not exceed 1000 Watts. Frequency 2690MHz is between 1500MHz and 100,000MHz, and the Maximum S=1mW/cm 2  R=4.22m. This equipment should be installed and operated with minimum distance 4.22m between the radiator& your body. Test Result: pass FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 49 of 410 7 MODULATION CHARACTERISTIC Applicable Standard: FCC §2.1047 Test Equipment List and Details Manufacturer Description Model Serial Number Calibration Date Calibration Due Date Agilent MXA Series Spectrum Analyzer N9030A MY49431143 2013.06.18 2014.06.18 DTS DTS 40dB Attenuator DTS100-40-3-1 09112005 2013.07.19 2014.07.19 Silverline Silverline RF Cable SLA18-NMN1T 100311-04-0001 N/A N/A *statement of traceability: ZTE Corporation Reliability Testing Center attest that all calibration have been performed per the NVLAP requirements , traceable to NIST. Test Procedure LTE digital mode is used by EUT. Test Data Environmental Conditions Temperature: 20 °C Relative Humidity: 53 % ATM Pressure: 1009 mbar Test Result: Pass Test Mode: Transmitting LTE FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 50 of 410 Test Data: Single Carrier: Channel Bandwidth :5M Port Frequency (MHz) Test mode EVM 1 2622.5 TM2.0 1.815 TM3.1 6.246 TM3.2 7.656 TM3.3 14.328 2655 TM2.0 1.888 TM3.1 6.302 TM3.2 7.661 TM3.3 14.294 2687.5 TM2.0 2.366 TM3.1 6.233 TM3.2 7.666 TM3.3 14.345 2 2622.5 TM2.0 1.907 TM3.1 6.226 TM3.2 7.653 TM3.3 14.050 2655 TM2.0 1.711 TM3.1 6.245 TM3.2 7.654 TM3.3 14.298 2687.5 TM2.0 2.496 TM3.1 6.243 TM3.2 7.671 TM3.3 14.289 5M -Port 1 -2622.5MHz-TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 51 of 410 5M -Port 1 -2622.5MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 52 of 410 5M -Port 1 -2622.5MHz -TM3.2 5M -Port 1 -2622.5MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 53 of 410 5M -Port 1 -2655MHz-TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 54 of 410 5M -Port 1 -2655MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 55 of 410 5M -Port 1 -2655MHz -TM3.2 5M -Port 1 -2655MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 56 of 410 5M -Port 1 -2687.5MHz-TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 57 of 410 5M -Port 1 -2687.5MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 58 of 410 5M -Port 1 -2687.5MHz -TM3.2 5M -Port 1 -2687.5MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 59 of 410 5M -Port 2-2622.5MHz -TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 60 of 410 5M -Port 2 -2622.5MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 61 of 410 5M -Port 2 -2622.5MHz -TM3.2 5M -Port 2 -2622.5MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 62 of 410 5M -Port 2 -2655MHz -TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 63 of 410 5M -Port 2 -2655MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 64 of 410 5M -Port 2 -2655MHz -TM3.2 5M -Port 2 -2655MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 65 of 410 5M -Port 2 -2687.5MHz -TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 66 of 410 5M -Port 2 -2687.5MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 67 of 410 5M -Port 2 -2687.5MHz -TM3.2 5M -Port 2 -2687.5MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 68 of 410 Channel Bandwidth :10M Port Frequency (MHz) Test mode EVM 1 2625 TM2.0 2.467 TM3.1 6.385 TM3.2 7.699 TM3.3 10.314 2655 TM2.0 1.664 TM3.1 6.307 TM3.2 7.674 TM3.3 10.304 2685 TM2.0 1.640 TM3.1 6.294 TM3.2 7.672 TM3.3 10.318 2 2625 TM2.0 1.799 TM3.1 6.324 TM3.2 7.688 TM3.3 10.310 2655 TM2.0 1.690 TM3.1 6.370 TM3.2 7.689 TM3.3 10.316 2685 TM2.0 1.852 TM3.1 6.346 FCC ID: Q78-…

Text truncated - open the document above for the full version.

FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 81 of 410 10M -Port 2 -2655MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 82 of 410 10M -Port 2 -2655MHz -TM3.2 10M -Port 2 -2655MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 83 of 410 10M -Port 2 -2685MHz -TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 84 of 410 10M -Port 2 -2685MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 85 of 410 10M -Port 2 -2685MHz -TM3.2 10M -Port 2 -2685MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 86 of 410 Channel Bandwidth :15M Port Frequency (MHz) Test mode EVM 1 2627.5 TM2.0 1.860 TM3.1 6.045 TM3.2 8.662 TM3.3 9.963 2655 TM2.0 1.608 TM3.1 6.044 TM3.2 8.579 TM3.3 9.979 2682.5 TM2.0 2.112 TM3.1 6.036 TM3.2 8.505 TM3.3 9.965 2 2627.5 TM2.0 1.918 TM3.1 6.071 TM3.2 8.488 TM3.3 9.976 2655 TM2.0 1.836 TM3.1 6.048 TM3.2 8.494 TM3.3 9.982 2682.5 TM2.0 2.164 TM3.1 6.099 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 87 of 410 TM3.2 8.507 TM3.3 9.993 15M -Port 1 -2627.5MHz-TM2.0 15M -Port 1 -2627.5MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 88 of 410 15M -Port 1 -2627.5MHz -TM3.2 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 89 of 410 15M -Port 1 -2627.5MHz -TM3.3 15M -Port 1 -2655MHz-TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 90 of 410 15M -Port 1 -2655MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 91 of 410 15M -Port 1 -2655MHz -TM3.2 15M -Port 1 -2655MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 92 of 410 15M -Port 1 -2682.5MHz-TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 93 of 410 15M -Port 1 -2682.5MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 94 of 410 15M -Port 1 -2682.5MHz -TM3.2 15M -Port 1 -2682.5MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 95 of 410 15M -Port 2-2627.5MHz -TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 96 of 410 15M -Port 2 -2627.5MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 97 of 410 15M -Port 2 -2627.5MHz -TM3.2 15M -Port 2 -2627.5MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 98 of 410 15M -Port 2 -2655MHz -TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 99 of 410 15M -Port 2 -2655MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 100 of 410 15M -Port 2 -2655MHz -TM3.2 15M -Port 2 -2655MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 101 of 410 15M -Port 2 -2682.5MHz -TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 102 of 410 15M -Port 2 -2682.5MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 103 of 410 15M -Port 2 -2682.5MHz -TM3.2 15M -Port 2 -2682.5MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 104 of 410 Channel Bandwidth :20M Port Frequency (MHz) Test mode EVM 1 2630 TM2.0 1.702 TM3.1 6.305 TM3.2 7.803 TM3.3 10.497 2655 TM2.0 1.949 TM3.1 6.312 TM3.2 7.763 TM3.3 10.487 2680 TM2.0 1.844 TM3.1 6.303 TM3.2 7.812 TM3.3 10.510 2 2630 TM2.0 1.639 TM3.1 6.299 TM3.2 7.839 TM3.3 10.497 2655 TM2.0 2.039 TM3.1 6.319 TM3.2 7.783 TM3.3 10.500 2680 TM2.0 1.563 TM3.1 6.317 TM3.2 7.816 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 105 of 410 TM3.3 10.529 20M -Port 1 -2630MHz-TM2.0 20M -Port 1 -2630MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 106 of 410 20M -Port 1 -2630MHz -TM3.2 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 107 of 410 20M -Port 1 -2630MHz -TM3.3 20M -Port 1 -2655MHz-TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 108 of 410 20M -Port 1 -2655MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 109 of 410 20M -Port 1 -2655MHz -TM3.2 20M -Port 1 -2655MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 110 of 410 20M -Port 1 -2680MHz-TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 111 of 410 20M -Port 1 -2680MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 112 of 410 20M -Port 1 -2680MHz -TM3.2 20M -Port 1 -2680MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 113 of 410 20M -Port 2-2630MHz -TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 114 of 410 20M -Port 2 -2630MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 115 of 410 20M -Port 2 -2630MHz -TM3.2 20M -Port 2 -2630MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 116 of 410 20M -Port 2 -2655MHz -TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 117 of 410 20M -Port 2 -2655MHz -TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 118 of 410 20M -Port 2 -2655MHz -TM3.2 20M -Port 2 -2655MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 119 of 410 20M -Port 2 -2680MHz -TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 120 of 410 20M -Port 2 -2680MHz -TM3.1

FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 121 of 410 20M -Port 2 -2680MHz -TM3.2 20M -Port 2 -2680MHz -TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 122 of 410 Double Carrier: Channel Bandwidth :10M+10M Port Center Frequency (MHz) Test mode EVM 1 2640 2625 TM2 1.482 2655 1.819 2625 TM3.1 6.271 2655 6.308 2625 TM3.2 7.623 2655 7.667 2625 TM3.3 10.153 2655 10.138 2655 2640 TM2 1.382 2670 1.561 2640 TM3.1 6.283 2670 6.321 2640 TM3.2 7.700 2670 7.730 2640 TM3.3 10.148 2670 10.133 2670 2655 TM2 1.370 2685 1.420 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 123 of 410 2655 TM3.1 6.330 2685 6.342 2655 TM3.2 7.664 2685 7.677 2655 TM3.3 10.166 2685 10.138 2 2640 2625 TM2 1.649 2655 1.692 2625 TM3.1 6.295 2655 6.360 2625 TM3.2 7.643 2655 7.679 2625 TM3.3 10.181 2655 10.157 2655 2640 TM2 1.371 2670 1.318 2640 TM3.1 6.332 2670 6.349 2640 TM3.2 7.688 2670 7.669 2640 TM3.3 10.169 2670 10.137 2670 2655 TM2 1.533 2685 1.368 2655 TM3.1 6.336 2685 6.349 2655 TM3.2 7.681 2685 7.658 2655 TM3.3 10.190 2685 10.110 10M+10M -Port 1 –2625M-TM2 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 124 of 410 10M+10M -Port 1 –2655M-TM2 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 125 of 410 10M+10M -Port 1 –2625M-TM3.1 10M+10M -Port 1 –2655M-TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 126 of 410 10M+10M -Port 1 –2625M-TM3.2 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 127 of 410 10M+10M -Port 1 –2655M-TM3.2 10M+10M -Port 1 –2625M-TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 128 of 410 10M+10M -Port 1 –2655M-TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 129 of 410 10M+10M -Port 1 –2640M-TM2.0 10M+10M -Port 1 –2670M-TM2.0 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 130 of 410 10M+10M -Port 1 –2640M-TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 131 of 410 10M+10M -Port 1 –2670M-TM3.1 10M+10M -Port 1 –2640M-TM3.2 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 132 of 410 10M+10M -Port 1 –2670M-TM3.2 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 133 of 410 10M+10M -Port 1 –2640M-TM3.3 10M+10M -Port 1 –2670M-TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 134 of 410 10M+10M -Port 1 –2655M-TM2 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 135 of 410 10M+10M -Port 1 –2685M-TM2 10M+10M -Port 1 –2655M-TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 136 of 410 10M+10M -Port 1 –2685M-TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 137 of 410 10M+10M -Port 1 –2655M-TM3.2 10M+10M -Port 1 –2685M-TM3.2 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 138 of 410 10M+10M -Port 1 –2655M-TM3.3 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 139 of 410 10M+10M -Port 1 –2685M-TM3.3 10M+10M -Port 2 –2625M-TM2 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 140 of 410 10M+10M -Port 2 –2655M-TM2 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Page 141 of 410 10M+10M -Port 2 –2625M-TM3.1 10M+10M -Port 2 –2655M-TM3.1 FCC ID: Q78-R8882S2600 FCC PART 27 TYPE APPROVAL Report Pa…
