Q78-UF110WCDMA/GSM(GPRS) Dual-Mode Digital Mobil Phone

ZTE-U F110 Mobile Phone User Manual LEGAL INFORMATION Copyright © 2010 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version No. : R1.0 Edition Time : 3 Table of Contents SECURITY ............................... 5 SAFETY PRECAUTIONS ........ 5 RF EXPOSURE ..................... 16 LIMITATION OF LIABILITY ... 18 KEY FUNCTIONS .................. 20 LOCKING AND UNLOCKING THE KEYPAD ........................ 22 INTERFACE ICONS ............... 23 BATTERY .............................. 23 INSERTING THE SIM CARD . 25 INSERTING THE MEMORY CARD .................................... 26 CHARGING THE BATTERY .. 27 POWERING YOUR PHONE ON/OFF ..................................29 WRITING TEXT ......................29 ADDING CONTACT TO THE CONTACTS ............................31 MAKING AND RECEIVING CALLS ....................................32 SENDING AND RECEIVING MESSAGES ...........................33 PROFILES ..............................36 CALL LOG .............................38 SETTING YOUR PHONE ........38 TOOLS ...................................42 MEDIA & ENTERTAINMENT ..44 4 FILE MANAGER .................... 48 BLUETOOTH ......................... 48 BROWSER ............................. 50 5 Security  To protect your mobile phone from illegal use, take the security measures as follows:  Set PIN codes of the SIM card.  Set handset lock code.  Set call restrictions. Safety Precautions This section includes some important information on safe and efficient operation. Please read this information before using the phone. Operational Precautions  Please use your phone properly. When making or receiving a call, please hold your phone as holding a wireline telephone. Make sure that the phone is at least one inch (about two point five centimeters) from your body when transmitting. 6  Do not touch the antenna when the phone is in use. Touching the antenna area affects call quality and may cause the phone to operate at a higher power level than needed.  Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing lights, such as when watching television or playing video games. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your phone or enabling a flashing- light feature on your phone. (The flashing-light feature is not available on all products.)  Keep the phone out of the reach of small children. The phone may cause injury if used as a toy. Precautions While Driving  Please pay attention to the traffic safety. Check the laws and regulations on the use of your phone in the area where you drive. Always obey them. 7  Use hands-free function of the phone, if available.  Pull off the road and park before making or answering a call if conditions require. Precautions for Medical Devices and Facilities  When using your phone near pacemakers, please always keep the phone more than eight inches (about twenty centimeters) from the pacemaker when the phone is switched on. Do not carry the phone in the breast pocket. Use the ear opposite the pacemaker to minimize the potential for interference. Switch off the phone immediately if necessary.  Some phones may interfere with some hearing aids. In the event of such interference, you may consult your hearing aids manufacturer to discuss alternatives.  If you use any other personal medical device, please consult the manufacturer of your device to determine if it is adequately shielded from RF energy. 8  In those facilities with special demand, such as hospital or health care facilities, please pay attention to the restriction on the use of mobile phone. Switch off your phone if required. Mobile Phone  Please use original accessories or accessories approved by the phone manufacturer. Using any unauthorized accessories may affect your mobile phone‟s performance, damage your phone or even cause danger to your body and violate related local regulations about telecom terminals.  Turn off your phone before you clean it. Use a damp or anti-static cloth to clean the phone. Do not use a dry cloth or electrostatically charged cloth. Do not use chemical or abrasive cleaners as these could damage the phone.  As your mobile phone can produce electromagnetic field, do not place it near magnetic items such as computer disks.  Using the phone near electrical appliances such as TV, telephone, radio and personal computer can cause interference. 9  Do not expose your mobile phone to direct sunlight or store it in hot areas. High temperatures can shorten the life of electronic devices.  Keep your phone dry. Any liquid may damage your phone.  Do not drop, knock or harshly treat the phone. Rough handling can break internal circuit boards.  Do not connect the phone with any incompatible enhancement.  Do not attempt to disassemble the mobile phone or battery.  Do not store the phone with flammable or explosive articles.  Do not charge the mobile phone without battery.  Some electronic devices are susceptible to electromagnetic interference sent by phone if inadequately shielded. Please use phone at least 20 cm or as far away as you can from TV set, radio and other automated office equipment so as to avoid electromagnetic interference.  Operating phone may interfere with medical devices like hearing aides and pacemakers, or other medical devices in hospital. Consult a physician or the manufacturer of the medical device before using phone. 10  Be aware of the usage limitation when using phone at places such as oil warehouses, or chemical factories, where there are exp…

Text truncated - open the document above for the full version.

内部公开 内部公开内部公开 内部公开▲ 本文中的所有信息归中兴通讯股份有限公司所有，未经允许，不得外传 第 1 / 1 页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China Date: Dec 24,2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC(Telecommunication Metrology Center of MII) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Royce Wang ZTE CORPORATION Tel ：0755-26770345 Fax：0755-26770347 E-Mail：[email protected]

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Jan 25, 2011 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: Q78-UF110 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

external photo Mobile Phone Mobile Phone Battery Battery Headset

Q78-UF110, label placement

internal photos Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly 内部公开Internal Use Only▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> All Rights reserved, No Spreading abroad without Permission of ZTE 第1页 手机主天线 77mm 0.5mm 蓝牙天线 PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

Report No.: RZA1012-2056SAR01R1 TESTING No. L2264 OET 65 TEST REPORT Product Name WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Model ZTE-U F110 FCC ID Q78-UF110 Client ZTE Corporation TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1012-2056SAR01R1 Page 2 of 149 GENERAL SUMMARY Product Name WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Model ZTE-U F110 FCC ID Q78-UF110 Report No. RZA1012-2056SAR01R1 Client ZTE Corporation Manufacturer ZTE Corporation Reference Standard(s) IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radiofrequency Electromagnetic Fields, 3 kHz to 300 GHz. IEEE Std 1528™-2003: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. SUPPLEMENT C Edition 01-01 to OET BULLETIN 65 Edition 97-01 June 2001 including DA 02-1438, published June 2002: Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields Additional Information for Evaluation Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radiofrequency Emissions. Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards. General Judgment: Pass (Stamp) Date of issue: January 20 th , 2011 Comment The test result only responds to the measured sample. Approved by Yang Weizhong Revised by Ling Minbao Performed by Li Siyuan TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1012-2056SAR01R1 Page 3 of 149 TABLE OF CONTENT 1. General Information ..................................................................................................................... 5 1.1. Notes of the Test Report.......................................................................................................5 1.2. Testing Laboratory ................................................................................................................ 5 1.3. Applicant Information ............................................................................................................ 6 1.4. Manufacturer Information ...................................................................................................... 6 1.5. Information of EUT................................................................................................................ 7 1.6. The Maximum SAR 1g Values and Conducted Power of each tested band ........................... 8 1.7. Test Date .............................................................................................................................. 9 2. Operational Conditions during Test ............................................................................................ 10 2.1. General Description of Test Procedures............................................................................. 10 2.2. GSM Test Configuration ...................................................................................................... 10 2.3. WCDMA Test Configuration ................................................................................................ 11 2.3.1. Output Power Verification ............................................................................................ 11 2.3.2. Head SAR Measurements ........................................................................................... 11 2.3.3. Body SAR Measurements ........................................................................................... 11 2.4. Test Positions...................................................................................................................... 11 2.4.1. Against Phantom Head ................................................................................................ 11 2.4.2. Body Worn Configuration............................................................................................. 11 3. SAR Measurements System Configuration ................................................................................ 12 3.1. SAR Measurement Set-up .................................................................................................. 12 3.2. DASY5 E-field Probe System ............................................................................................. 13 3.2.1. EX3DV4 Probe Specification ....................................................................................... 13 3.2.2. E-field Probe Calibration .............................................................................................. 14 3.3. Other Test Equipment .........................................................................................................14 3.3.1. Device Holder for Transmitters .................................................................................... 14 3.3.2. Phantom...................................................................................................................... 15 3.4. Scanning Procedure........................................................................................................... 15 3.5. Data Storage and Evaluation .............................................................................................. 17 3.5.1. Data Storage................................................................................................................ 17 3.5.2. Data Evaluation by SEMCAD ...................................................................................... 17 3.6. System Check..................................................................................................................... 20 3.7. Equivalent Tissues ..............................................................................................................21 4. Laboratory Environment...................…

Text truncated - open the document above for the full version.

TEST REPORT No. 2011TAR005 for ZTE Corporation WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Model Name: ZTE-U F110 FCC ID: Q78-UF110 with Hardware Version: gadA Software Version: CESF-CN-ZTE8-P168A20V1.0.0 Issued Date: Jan 17, 2011 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology 3/F Shou Xiang Technology Building, No.51 Xueyuan Road, Hai Dian District, Beijing, P. R. China,100191. Tel:+86(0)10-62304633-2604, Fax:+86(0)10-62304793, Email:[email protected], web: www.emcite.com No.2011TAR005 Page2 of 57 CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION .................................................................................................................... 3 1.2. TESTING ENVIRONMENT ........................................................................................................... 3 1.3. PROJECT DATA .............................................................................................................................. 3 1.4. SIGNATURE ..................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ....................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ..................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ....................................... 5 3.4. GENERAL DESCRIPTION ............................................................................................................ 6 4. REFERENCE DOCUMENTS ............................................................................................................. 6 4.1. REFERENCE DOCUMENTS FOR TESTING ............................................................................. 6 5. LABORATORY ENVIRONMENT ..................................................................................................... 7 6. SUMMARY OF TEST RESULTS ....................................................................................................... 8 7. TEST EQUIPMENTS UTILIZED ...................................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ................................................................................................ 10 A.1 OUTPUT POWER (§22.913(A)/§24.232(B)) ............................................................................... 10 A.2 EMISSION LIMT (§2.1051/§24.238) .......................................................................................... 16 A.3 CONDUCTED EMISSION (§15.107§15.207) ............................................................................. 21 A.4 FREQUENCY STABILITY (§2.1055/§24.235) ........................................................................... 25 A.5 OCCUPIED BANDWIDTH (§2.1049(H)(I)) ................................................................................. 27 A.6 EMISSION BANDWIDTH (§22.917(B)/§24.238(B)) .................................................................. 35 A.7 BAND EDGE COMPLIANCE (§22.917(B)/§24.238(B)) ............................................................. 43 A.8 CONDUCTED SPURIOUS EMISSION (§2.1057/§22.917/§24.238) .......................................... 47 No.2011TAR005 Page3 of 57 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: 3/F Shou Xiang Technology Building, No.51 Xueyuan Road, Hai Dian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304793 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: 2010-12-20 Testing End Date: 2011-01-17 1.4. Signature Zi Xiaogang (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2011TAR005 Page4 of 57 2. Client Information 2.1. Applicant Information Company Name: ZTE Corporation Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China City: Shenzhen Postal Code: 518057 Country: China Telephone: 0086 21 68895196 Fax: 0086 21 61460600 2.2. Manufacturer Information Company Name: ZTE Corporation Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China City: Shenzhen Postal Code: 518057 Country: China Telephone: 0086 21 68895196 Fax: 0086 21 61460600 No.2011TAR005 Page5 of 57 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Model Name ZTE-U F110 FCC ID Q78-UF110 Frequency GSM 850MHz; PCS 1900MHz; EGSM900; DCS1800; WCDMA Band II; WCDMA Band V Antenna Internal Power supply Battery or Charger (AC Adaptor) Output power 30.31 dBm maximum EIRP measured for GSM1900 Extreme vol. Limits 3.5VDC to 4.2…

Text truncated - open the document above for the full version.

F110 FCC test setup photo 1． Radiated Spurious Emission 2． Conducted Emission(Charging) 3． Conducted Emission(USB) 4． Radiated Emission(Charging) 5． Radiated Emission(USB) 6. part15C

TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1012-2056SAR01R1 Page 145 of 149 ANNEX H: The EUT Appearances and Test Configuration a: EUT b: Battery Picture 6: Constituents of EUT TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1012-2056SAR01R1 Page 146 of 149 Picture 7: Left Hand Touch Cheek Position Picture 8: Left Hand Tilt 15 Degree Position TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1012-2056SAR01R1 Page 147 of 149 Picture 9: Right Hand Touch Cheek Position Picture 10: Right Hand Tilt 15 Degree Position TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1012-2056SAR01R1 Page 148 of 149 Picture 11: Body, The EUT display towards ground, the distance from handset to the bottom of the Phantom is 15mm Picture 12: Body, The EUT display towards phantom, the distance from handset to the bottom of the Phantom is 15mm 15mm 15mm TA Technology (Shanghai) Co., Ltd. Test Report Report No.: RZA1012-2056SAR01R1 Page 149 of 149 Picture 13: Body with earphone, The EUT display towards ground, the distance from handset to the bottom of the Phantom is 15mm Picture 14: Body with earphone, The EUT display towards phantom, the distance from handset to the bottom of the Phantom is 15mm 15mm 15mm
