Q78-UV760WCDMA/GSM (GPRS) Dual-Mode Digital Mobile Phone

1 ZTE-U V760 WCDMA/GSM Mobile Phone User Manual 2 LEGAL INFORMATION Copyright © 2012 ZTE CORPORATION. All rights reserved. No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. ZTE Corporation reserves the right to make modifications on print errors or update specifications in this guide without prior notice. Version No.: R1.0 Edition Time: 20120201 3 Contents Basic Knowledge ..................................................... 8 Introduction ...................................................................... 8 Your Safety ............................................................... 8 Operational Precautions .................................................. 8 Distraction ...................................................................... 12 Driving ...................................................................... 12 Operating Machinery ................................................ 12 Product Handling ........................................................... 13 General Statement on Handling and Use ................. 13 Small Children .......................................................... 15 Demagnetization ...................................................... 15 Electrostatic Discharge (ESD) .................................. 15 Antenna .................................................................... 15 Air Bags .................................................................... 15 Seizures/ Blackouts .................................................. 16 Repetitive Motion Injuries ......................................... 16 Emergency Calls ...................................................... 16 Loud Noise ............................................................... 16 Precautions for Electrical Devices ................................. 17 Interference .................................................................... 17 General Statement on Interface ............................... 17 Pacemakers ............................................................. 17 Hearing Aids ............................................................. 17 Medical Devices ....................................................... 18 4 Hospitals .................................................................. 18 Aircraft ...................................................................... 18 Interference in Cars ................................................. 19 Explosive Environments ................................................ 19 Battery Use .................................................................... 19 Getting Start ........................................................... 21 Overview ....................................................................... 21 Keys Explained .............................................................. 21 Starting up ..................................................................... 22 Installing the SIM/microSD Card and Battery .......... 22 Removing the Battery and SIM/microSD Card ........ 24 Charging the Battery ................................................ 24 Switching Your Phone On/Off ....................................... 25 Setting Up Your Phone for the First Time ................ 25 Switching to Sleep Mode ......................................... 26 Waking Up Your Phone ........................................... 26 Getting Around Your Phone .......................................... 27 Touch Control .......................................................... 27 Home Screen ........................................................... 27 Status and Notification Icons ................................... 28 Using the Notification Panel ..................................... 29 Phone Calls ............................................................ 30 Making Calls .................................................................. 30 Calling from the Phone ............................................ 30 Calling from Your Contacts ...................................... 30 5 Calling from Your Call History .................................. 31 Calling from a Text Message .................................... 31 Receiving Calls .............................................................. 31 Answering a Call ...................................................... 31 Muting a Call ............................................................ 32 Turning the Speakerphone On/Off ........................... 32 Ending a Call ............................................................ 32 Contacts ................................................................. 32 Creating a Contact ......................................................... 32 Searching for a Contact ................................................. 33 Messaging .............................................................. 33 The Message Box .......................................................... 33 Sending an Message ..................................................... 33 Message Settings .......................................................... 34 Touch Input Settings ...................................................... 34 Getting Connected to the Internet ........................ 35 Adding a New Network Connection ............................... 35 Turning On Wi-Fi............................................................ 35 Connecting to a Wi-Fi Network ...................................... 36 Checking the Wi-Fi Network Status ............................... 36 Using the Phone as a Modem ....................................... 36 Enabling USB tethering ............................................ 37 Disabling USB tethering ........................................... 37 Enabling the Wi-Fi Hotspot ....................................... 37 Disabling the Wi-Fi Hotspot .......…

Text truncated - open the document above for the full version.

ZTE CORPORATION Declaration As the applicant of the below model, [ZTE Corporation] declares that the product, [Q78-UV760] [ ZTE Corporation] ZTE U V760 North America edition is limited using channel 1-11. This limited operation can be only set by software and was done before the product down from the product line. All the products for North America marketing were embedded this limited before shipping. Customers have no way to choose the channel 12 & 13. Limited by local law regulations, version for North America does not have region selection option. Date:2012-3-27 Company: ZTE Corporation Address: ZTE R&D Center()Nanjing),No.6 hua shen avenue, Yu Hua Tai District, Nanjing,P.R.China Tel: +86-25-52878723 Fax: +86-21-68896835

ZTE CORPORATION Declaration As the applicant of the below model, [ZTE Corporation] declares that the product, [Q78-UV760] [ ZTE Corporation] In the block diagram, MT6620 actually have 5G and FM transmitters but these are not used in U V760. The hardware support 5G WIFI but software do not. We do not connect FM transmitters in hardware. Date:2012-4-13 Company: ZTE Corporation Address: ZTE R&D Center()Nanjing),No.6 hua shen avenue, Yu Hua Tai District, Nanjing,P.R.China Tel: +86-25-52878723 Fax: +86-21-68896835

内部公开▲ 本文中的所有信息归中兴通讯股份有限公司所有，未经允许，不得外传 第 1 / 1 页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China Date: Mar 16,2012 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Shanghai Tejet Communications Technology Co.,Ltd.is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Royce Wang ZTE CORPORATION Tel：0755-26770345 Fax：0755-26770347 E-Mail：[email protected]

内部公开▲ 本文中的所有信息归中兴通讯股份有限公司所有，未经允许，不得外传 第 1 / 1 页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China Date: Mar 16,2012 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: Q78-UV760 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Royce Wang ZTE CORPORATION Tel：0755-26770345 Fax：0755-26770347 E-Mail：[email protected]

Label Location

No.2012TAR122 Page 1 of 16 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2012TAR122 for ZTE Corporation WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Model Name: ZTE-U V760 FCC ID : Q78-ZTEUV760 with Hardware Version: WMAB Software Version: CN-ZTE-B18S-P173A10V1.0.0 Issued Date: 2012-03-20 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633 , Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.2012TAR122 Page 2 of 16 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ............................................................................................................... 3 1.1. TESTING LOCATION ........................................................................................................... 3 1.2. TESTING ENVIRONMENT ................................................................................................... 3 1.3. PROJECT DATA ................................................................................................................... 3 1.4. SIGNATURE .......................................................................................................................... 3 2. CLIENT INFORMATION ........................................................................................................... 4 2.1. APPLICANT INFORMATION ................................................................................................ 4 2.2. MANUFACTURER INFORMATION ...................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT .......................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 4. REFERENCE DOCUMENTS .................................................................................................... 6 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 6 5. LABORATORY ENVIRONMENT .............................................................................................. 7 6. SUMMARY OF TEST RESULTS .............................................................................................. 8 7. TEST EQUIPMENTS UTILIZED ............................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 10 No.2012TAR122 Page 3 of 16 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Mar 01, 2012 Testing End Date: Mar 01, 2012 1.4. Signature Liu Baodian (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2012TAR122 Page 4 of 16 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: ZTE Corporation Address /Post: #68 Zijin Hua Road, Nanjing, Jiangsu Province, P. R. China City: Nan Jing Postal Code: 210012 Country: China Telephone: +86-25-52878232 Fax: +86-25-68897541 2.2. Manufacturer Information Company Name: ZTE Corporation Address /Post: #68 Zijin Hua Road, Nanjing, Jiangsu Province, P. R. China City: Nan Jing Postal Code: 210012 Country: China Telephone: +86-25-52878232 Fax: +86-25-68897541 No.2012TAR122 Page 5 of 16 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Model Name ZTE-U V760 FCC ID Q78-ZTEUV760 Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.7VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MII of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 868215000121264 WMAB CN-ZTE-B18S-P173A10V1.0.0 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Battery / AE2 Travel Adapter / AE3 USB Cable / AE1 Model Li3713T42P3h415266-H Manufacturer ZTE Capacitance 1350mAh Nominal Voltage 3.7V AE2 Model STC-A22O50I700USBA-Z Manufacturer RUIDE Length of DC line / AE3 Model / Manufacturer ZTE Length of headset line 120cm *AE ID: is used to identify the test sample in the lab internally. No.2012TAR122 Page 6 of 16 ©Copyright. All rights reserved by TMC Beijing. 3.4. General Description Equipment Under Test (EUT) is a model of WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone with integrated antenna. It supports GSM 900/1800/850/1900 bands and WCDMA Band I/VIII. It has MP3, Camera, FM radio, USB memory, Bluetooth, Wi-Fi（802.11b/g/n）and GPS functions. It also supports GPRS function with multi-slots class 12 and EDGE clss12. It consists of normal options: Lithium B…

Text truncated - open the document above for the full version.

RSE RE‐15B‐U CE RE‐15B‐C USB_CE RE‐15C
