Q78-V970TWCDMA/GSM (GPRS) Dual-Mode Digital Mobile Phone

1 LEGAL INFORMATION Copyright © 2012 ZTE CORPORATION. All rights reserved. No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. ZTE Corporation reserves the right to correct typographical errors, misprints or update specifications in this guide without prior notice. The Bluetooth ® trademark and logos are owned by the Bluetooth SIG, Inc. and any use of such trademarks by ZTE Corporation is under license. Other trademarks and trade names are the property of their respective owners. The phone is manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. We offer self-service for our smart terminal device users. Please visit ZTE official website (at www.zte.com.cn) for more information on self-service and supported product models. Information subject to the website. Version No.: R1.0 Edition Time: 2012.09 2 What’s Inside Getting Started ............................................................................ 9 Your Phone at a Glance ........................................................... 9 Knowing the Keys................................................................ 10 Installing the SIM Card, microSD Card, and Battery ................ 11 Charging the Battery ............................................................ 14 Powering On/Off ................................................................. 15 Locking/Unlocking the Screen and Keys ................................ 15 Using the Touch Screen ........................................................ 16 Getting to Know the Home Screen ......................................... 17 Personalizing ............................................................................. 19 Changing the System Language ............................................. 19 Setting the Date and Time ..................................................... 19 Changing Ringtone and Notification Sound ............................ 19 Adjusting Volumes ............................................................... 20 Applying New Wallpapers .................................................... 21 Changing Screen Brightness .................................................. 21 Protecting Your Phone with Screen Locks ............................... 22 Protecting Your Phone with Encryption .................................. 23 Knowing the Basics ................................................................... 25 Monitoring the Phone Status ................................................. 25 Managing Notifications ........................................................ 26 3 Managing Shortcuts and Widgets ........................................... 28 Rearranging the Favorites Tray .............................................. 29 Entering Text ....................................................................... 29 Editing Text ......................................................................... 32 Opening and Switching apps ................................................. 33 Connecting to Networks and Devices .......................................... 34 Connecting to Mobile Networks ............................................ 34 Connecting to Wi-Fi ............................................................. 35 Connecting to Bluetooth Devices ........................................... 37 Connecting to Your Computer via USB .................................. 39 Sharing Your Mobile Data Connection.................................... 40 Connecting to Virtual Private Networks .................................. 42 Phone Calls ................................................................................ 45 Placing and Ending Calls ...................................................... 45 Answering or Rejecting Calls ................................................ 46 Working with the Call Log .................................................... 46 Calling Your Contacts ........................................................... 48 Checking Voicemail .............................................................. 49 Using Options During a Call.................................................. 49 Managing Multi-Party Calls .................................................. 50 Adjusting Your Call Settings ................................................. 51 People ........................................................................................ 57 Opening Your Contact List .................................................... 57 Adding a New Contact .......................................................... 58 Setting Up Your Own Profile ................................................. 58 4 Importing, Exporting, and Sharing Contacts ............................ 58 Working with Favorite Contacts ............................................ 60 Working with Groups ........................................................... 61 Searching for a Contact ........................................................ 63 Editing Contacts .................................................................. 63 Accounts ................................................................................... 64 Adding or Removing Accounts .............................................. 64 Configuring Account Sync .................................................... 65 Email ........................................................................................ 67 Set Up the First Email Account .............................................. 67 Checking Your Emails .......................................................... 68 Responding to an Email ........................................................ 68 Writing and Sending an Email ............................................... 70 Adding a Signature to Your Emails .........................…

Text truncated - open the document above for the full version.

内部公开▲ 本文中的所有信息归中兴通讯股份有限公司所有，未经允许，不得外传 第 1 / 1 页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China Date: Nov.19,2012 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Tejet is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Royce Wang ZTE CORPORATION Tel：0755-26770345 Fax：0755-26770347 E-Mail：[email protected]

内部公开▲ 本文中的所有信息归中兴通讯股份有限公司所有，未经允许，不得外传 第 1 / 1 页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China Date: Nov.19,2012 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: Q78-V970T To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Royce Wang ZTE CORPORATION Tel：0755-26770345 Fax：0755-26770347 E-Mail：[email protected]

内部公开Internal Use Only▲ ZTE Plaza, Hi-tech Park, Nanshan District, Zhangjiang High-Tech Park, Pudong 0755-26770345 Request for Supercede TO: Federal Communication Commission Please kindly be notified that we, ZTE Corporation herein request to supercede the FCC ID: Q78-V970T for the following reason: 1. The client don’t want issue any document with the photos in public. Revised the SAR report to remove the photos of EUT to meet FCC’s STC requirement. 2. Revised the Label location to remove the photo of EUT. Please kindly permit the supercede. Thank you. Sincerely, Name / Title: zhihui wang / Certificate Manager Company: ZTE Corporation Tel: 0755-26770345 Email: [email protected]

内部公开Internal Use Only▲ Date: December 28, 2012 Office of Engineering and Technology Federal Communication Commission 7435 Oakland Mills Road Columbia, MID 21046-1609 Subject : SHORT-TERM Confidentiality request for FCC ID: Q78-V970T To Whom It May Concern, __ZTE Corporation __(the applicant) attests that none of the products certified under FCC ID: Q78- V970T has been marketed in the U.S. since the certification was granted on 24/December/2012 and acknowledges that the requested exhibits for SHORT-TERM Confidentiality below have been viewable to the public since 24/December/2012. Pursuant to Section 0.457 (d)(1)(ii) and 0.459 of 47CFR, the applicant requests the following documents contained in this application be temporarily withheld from public disclosure for a period of 180 days: Type of Confidentiality Requested Exhibit Short Term External Photos Short Term Internal Photos Short Term Test Setup Photos Short Term User’s Manual ZTE Corporation (the applicant) also acknowledges that they will also provide appropriate notice to ACB should either of the following occur: a) If the applicatnt requires aditional 180 days extension periods they will notify ACB with a new request letter at least 7 days prior to the short-term confidentiality expiration date – or b) Immediately notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents above for public disclosure pursuant to the FCC Public Notice. Name / Title: zhihui wang / Certificate Manager Company name: ZTE Corporation Tel: 0755-26770345 E-mail: [email protected]

External Photos:

Label Location:

Internal Photos:

No.2012EEB00405-EMC Page 1 of 15 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2012EEB00405-EMC For ZTE Corporation WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Model Name: V970T Marketing Name: V970T FCC ID: Q78-V970T with Hardware Version: weyA Software Version: TMO_US_P943EV1.0.0B02 Issued Date: 2012-12-21 Test Laboratory: FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633-2678 , Fax:+86(0)10-62304633-2504 Email:[email protected]. www.emcite.com No.2012EEB00405-EMC Page 2 of 15 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION .................................................................................................................... 3 1.2. TESTING ENVIRONMENT ........................................................................................................... 3 1.3. PROJECT DATA .............................................................................................................................. 3 1.4. SIGNATURE ..................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ....................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ..................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ....................................... 5 3.4. EUT SET-UPS ................................................................................................................................... 5 4. REFERENCE DOCUMENTS ............................................................................................................. 6 4.1. REFERENCE DOCUMENTS FOR TESTING ............................................................................. 6 5. LABORATORY ENVIRONMENT ..................................................................................................... 7 6. SUMMARY OF TEST RESULTS ....................................................................................................... 8 7. TEST EQUIPMENTS UTILIZED ...................................................................................................... 8 ANNEX A: MEASUREMENT RESULTS .................................................................................................. 9 No.2012EEB00405-EMC Page 4 of 15 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: ZTE Corporation Address /Post: ZTE Plaza, Hi-tech Park, Nanshan District City: Shenzhen, Guangdong Postal Code: 518057 Country: China Telephone: +86-21-68897541 Fax: +86-21-50801070 2.2. Manufacturer Information Company Name: ZTE Corporation Address /Post: ZTE Plaza, Hi-tech Park, Nanshan District City: Shenzhen, Guangdong Postal Code: 518057 Country: China Telephone: +86-21-68897541 Fax: +86-21-50801070 No.2012EEB00405-EMC Page 5 of 15 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Model Name V970T Marketing Name V970T FCC ID Q78-V970T 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 867820010003773 weyA TMO_US_P943EV1.0.0B02 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test . AE ID* Description SN AE1 Battery / AE2 Travel charger / AE3 USB cable / AE1 Model Li3716T42P3h594650 Manufacturer ZTE Corporation Capacitance 1650mAh Nominal voltage 3.7V AE2 Model STC-A51-Z Manufacturer RUIDE Length of cable 123cm AE3 Model / Manufacturer / Length of cable / *AE ID: is used to identify the test sample in the lab internally. 3.4. EUT set-ups EUT set-up No. Combination of EUT and AE Remarks Set.1 EUT1+ AE1 + AE2 Charging mode Set.2 EUT1+ AE1 + AE3 USB mode No.2012EEB00405-EMC Page 6 of 15 ©Copyright. All rights reserved by TMC Beijing. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version FCC Part 15, Subpart B Radio frequency devices 10-1-2011 Edition ANSI C63.4 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 2003 No.2012EEB00405-EMC Page 7 of 15 ©Copyright. All rights reserved by TMC Beijing. 5. LABORATORY ENVIRONMENT Semi-anechoic chamber (11.20 meters×6.10meters×5.60meters) did not exceed following limits along the EMC testing: Temperature Min. = 15 °C, Max. = 30 °C Relative humidity Min. = 35 %, Max. = 70 % Shielding effectiveness > 110 dB Electrical insulation > 2M Ground system resistance < 0.5  Normalised site attenuation (NSA) < ±3.5 dB, 3 m distance, from 30 to 1000 MHz Uniformity of field strength Between 0 and 6 dB, from 80 to 3000 …
