Q78-WP658GSM Wireless Phone

1 GSM Wireless Phone User Guide ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: (86) 755 26779999 URL: http://www.zte.com.cn E-mail: [email protected] Manual No. : 079584500000 2 LEGAL INFORMATION Copyright © 2011 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. 3 C h a p t e r 1 Know Your Phone C h a p t e r 2 Key Instruction Key Description 1. MENU/SELECT • Enter main menu. • Select or confirm options in menus. 2. Number • Use these keys to enter numbers and characters. 3. # , * • Perform different functions under different conditions. 6 10 LCD Screen 5 4 3 2 8 7 1 9 4 Key Description 4.Scrolling • Press these keys to scroll cursor to the left, right, up or down when inputting characters or selecting items. • Default functions in standby mode are set in Settings menu. 5. EXT PWR • Lights up when the phone is connected to external power outlet. 6. NAMES/CLR/BACK • In standby mode, press this key to enter right-bottom submenu on the screen. • Press this key to erase character(s) while editing text. • Press this key to return to the previous page during menu navigation. 7.MESSAGE • This is the shortcut key to enter message menu in standby mode. 8. EXIT • End an active call or reject calls. • Power on/power off the phone. 9. CALL/REDIAL • Make a call or answer an incoming call. • In standby mode, press this key to enter recent Outgoing calls list. 10.HANDS-FREE • If you are using the handset to call and want to transfer the call to the speakerphone, press this key and hang up the handset to put conversation on the speakerphone. • Press this key to end a hands-free call. Notes: In this manual, “press” a key means to press the key once, “h 5 old” a key means to press the key for 2 or 3 seconds. C h a p t e r 3 Interface Icons Icon DescriptionIconDescription Signal strength New message (blinks when memory is full) Silent Divert always Power indicator Alarm clock Roaming Keypad lock New voice mail C h a p t e r 4 Installation 1. Handset Connect phone and handset via the phone cord. 2. External power adapter Plug the external power adapter to the external AC socket. 3. SIM card Always switch the phone off before removing or inserting SIM card. Open the bottom cover of the battery. Remove the battery, slide the SIM card into the SIM card slot. Make sure that the contact area of 6 the card is facing down, and the beveled corner matches with the SIM card slot. Put in the battery and install the bottom cover. C h a p t e r 5 How to Power on/off ‹ To power on the phone, connect phone and external power outlet with the power adapter and then hold Exit key for about three seconds. ‹ To power off the phone, hold the Exit key till the phone is powered off. Notes: It is strongly recommended to connect the phone to external power outlet, and use internal battery to power your phone only when external power fails or is not available. The phone will charge the internal battery automatically when it is connected to external power outlet. C h a p t e r 6 How to Make a Call There are two methods for making a call. „ The first method: 1. Pick up the handset or press the HANDS-FREE key. 2. Enter the phone number, press CALL/REDIAL key to make the call. „ The second method: Enter the number or select recipient’s number from Phonebook, or press CALL/REDIAL key to select a number from the recent calls list, then press CALL/REDIAL key to make the call. Notes: Add the international prefix, country code and area code (without the leading 0) before the number when making an international call. 7 C h a p t e r 7 Voice Mail Before using voice mail, please contact service provider to confirm that the voicemail has been activated. The system automatically sends a message to your phone to inform you that there is a new voice mail. Read the message and then dial voice mailbox number to listen to your voice mail. To read or send your voice mail quickly, you set the voice mailbox number first. Pick up the handset or press HANDS-FREE key, and then hold “1” key to dial voice mailbox number. In standby mode, you can also hold “1” key directly to dial voice mailbox number. C h a p t e r 8 Message Select Short Message in Menu, and press Select. • Select New message to write message text, select Accept to send or save the message. • Select Inbox to view messages received. • Select Outbox to view the sent messages. • Select Draftbox to view draft messages. • Select Voice mail to listen to your voice mail messages, or set the voice mailbox number. • Select Message settings to make some necessary short message settings. C h a p t e r 9 Phone Code Phone code could prevent your phone from unauthorized use. The default phone code is 1234. Change it to your own as soon as possible. 8 If you change the default phone code to a new one, remember it or place it at secure place. C h a p t e r 10 PIN1 Code and PUK Code • PIN1 code (SIM password): PIN1 code could prevent your SIM card from illegal use. When PIN1 code is enabled, you should enter the PIN1 code when powering on the phone again. Change the default PIN1 code to your own as soon as possible. • PUK code: The SIM card will be locked if you enter a wrong PIN1 code consecutively for several times. To unlock, you need PUK code. Notes: PIN1 code and PUK code may be offered together with the SIM card. If not, contact your service provider. C h a p t e r 11 Text Input Operation Method Input letters “ABC”, “Abc” or “abc”, press corresponding letter key till the letter appears. Input digits “123”, press the Number keys to input the digits you want directly. Input words “Eng”, press the Number k…

Text truncated - open the document above for the full version.
