Q78-Z431WCDMA/GSM(GPRS) Dual-Mode Digital Mobile Phone

Z431 User Manual ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: (0086) 755 26779999 Website: http://www.zte.com.cn E-mail: [email protected] LEGAL INFORMATION Copyright © 2011 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version No. : R1.0 Edition Time: Feb, 2011 Manual No. : 07958450XXXX Contents Getting Started ...................................................................................................................... 1 Removing the Back Cover ................................................................................................ 1 Battery ............................................................................................................................... 1 SIM and Memory Cards .................................................................................................... 1 Charging Your Phone ....................................................................................................... 2 Powering Phone On/Off .................................................................................................... 3 Getting to Know Your Phone ........................................................................................... 4 Key Functions ................................................................................................................... 4 Idle Mode .......................................................................................................................... 5 Indicators and Icons .......................................................................................................... 5 Main Menu ........................................................................................................................ 6 Entering Text ........................................................................................................................ 8 Calls ...................................................................................................................................... 9 Making a Voice Call ......................................................................................................... 9 Using the Address Book ................................................................................................... 9 Using Call Options ............................................................................................................ 9 Receiving Calls ................................................................................................................. 9 Adjusting the Volume ....................................................................................................... 9 Using Call History ............................................................................................................ 9 Messages ............................................................................................................................. 10 Type of Messages............................................................................................................ 10 SMS and MMS ............................................................................................................... 10 Voice Mail....................................................................................................................... 10 Using Message Options .................................................................................................. 11 Message Settings ............................................................................................................. 11 Using Message Templates .............................................................................................. 11 Mobile Email....................................................................................................................... 12 Address Book ...................................................................................................................... 14 AT&T Address Book ...................................................................................................... 14 Adding Contact ............................................................................................................... 14 Searching Contact ........................................................................................................... 14 Setting Speed Dial ........................................................................................................... 14 Making a Speed Dial ....................................................................................................... 15 Using Address Book Entry Options ................................................................................ 15 Bluetooth ............................................................................................................................. 16 Enabling Bluetooth ......................................................................................................... 16 My Devices ..................................................................................................................... 16 Sending Data ................................................................................................................... 16 Receiving Data ................................................................................................................ 17 Mobile Web......................................................................................................................... 18 Using the att.net Homepage ...........................................................…

Text truncated - open the document above for the full version.

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Oct 8, 2011 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC(Telecommunication Metrology Center of MII) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Oct 8, 2011 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: Q78-LIGHTV9C To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected] Q78-Z431

内部公开Internal Use Only▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> All Rights reserved, No Spreading abroad without Permission of ZTE 第1页 ZTE CORPOARTION 2011-4-18 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality request for FCC ID: Q78-ZTEMF206A Here ZTE CORPORATION request to continue STC for FCC ID: Q78-ZTEMF206A. Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 135 days:  External Photos  Internal Photos  Test Setup Photos  User’s Manual The applicant also acknowledges that they will also provide appropriate notice to ATCB should either of the following occur: a) if the applicant requires additional 135 day extension periods they will notify ATCB with a new request letter at least 7 days prior to the short-term confidentiality expiration date - [Note: up to a maximum of 3 extensions only are allowed], or b) immediately notify ACB in the event the information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04 -1705. Sincerely, Royce Wang CERTIFICATION MANAGER ZTE CORPORATION Q78-Z431 2011-11-11 Federal Communications Commission

label placement lael

No.2011TAR487 Page 1 of 16 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2011TAR487 for ZTE Corporation WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Model Name: Z431 FCC ID : Q78-Z431 with Hardware Version: w5yB Software Version: 1.0.0 Issued Date: 2011-10-09 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633 , Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.2011TAR487 Page 2 of 16 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ............................................................................................................... 3 1.1. TESTING LOCATION ........................................................................................................... 3 1.2. TESTING ENVIRONMENT ................................................................................................... 3 1.3. PROJECT DATA ................................................................................................................... 3 1.4. SIGNATURE .......................................................................................................................... 3 2. CLIENT INFORMATION ........................................................................................................... 4 2.1. APPLICANT INFORMATION ................................................................................................ 4 2.2. MANUFACTURER INFORMATION ...................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT .......................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 4. REFERENCE DOCUMENTS .................................................................................................... 6 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 6 5. LABORATORY ENVIRONMENT .............................................................................................. 7 6. SUMMARY OF TEST RESULTS .............................................................................................. 8 7. TEST EQUIPMENTS UTILIZED ............................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 10 No.2011TAR487 Page 3 of 16 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Sep. 6, 2011 Testing End Date: Sep. 27, 2011 1.4. Signature Qu Pengfei (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2011TAR487 Page 4 of 16 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: ZTE Corporation Address /Post: #68 Zijin Hua Road, Nanjing, Jiangsu Province, P. R. China City: Nan Jing Postal Code: 210012 Country: China Telephone: +86-25-52878232 Fax: +86-25-68897541 2.2. Manufacturer Information Company Name: ZTE Corporation Address /Post: #68 Zijin Hua Road, Nanjing, Jiangsu Province, P. R. China City: Nan Jing Postal Code: 210012 Country: China Telephone: +86-25-52878232 Fax: +86-25-68897541 No.2011TAR487 Page 5 of 16 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description WCDMA/GSM（GPRS） Dual-Mode Digital Mobile Phone Model Name Z431 FCC ID Q78-Z431 Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.7VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 861080000001537 w5yB 1.0.0 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Battery 60101103250202069 AE2 Battery 60101103250202698 AE3 Travel charger / AE4 USB cable / AE1, AE2 Model Li3710T42P3h483757 Manufacturer ZTE Capacitance 1000mAh Nominal Voltage 3.7V AE3 Model STC-A22O50I700M5-C Manufacturer DOKOCOM Length of DC line 184cm AE4 Model / Manufacturer ZTE Length of DC line 120cm *AE ID: is used to identify the test sample in the lab internally. No.2011TAR487 Page 6 of 16 ©Copyright. All rights reserved by TMC Beijing. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version FCC Part 15, Subpart B Radio frequency devices July 10, 2008 Edition ANSI C63.4 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 2003 No.2011TAR487 Page 7 of 16 ©Copyright. Al…
