Q78-ZTEA139GSM DUAL-BAND DIGITAL MOBILE PHONE

ZTE Corporation
GSM DUAL-BAND DIGITAL MOBILE PHONE - FCC ID Q78-ZTEA139 - ZTE Corporation
Click to zoom

Application Details

Equipment Class
PCE - PCS Licensed Transmitter held to ear
Date of Grant
Dec 13, 2007
Application Purpose
Original Equipment
Date of Application
Dec 12, 2007
Equipment Note
GSM DUAL-BAND DIGITAL MOBILE PHONE
Frequency Range
824.20000000 - 848.80000000
Company
ZTE Corporation
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

RF Exposure Info

↗
↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 ZTE CORPORATION ZTE A139 GSM Digital Mobile Phone User Manual 2 Copyright © 2007 by ZTE Corporation All rights reserved. No part of this publication may be exce rpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. ZTE operates a policy of continuous devel opment. We reserve the right to update the technical specifications in this doc ument at any time without prior notice. Release V1.0 Manual number MM DD, 2007 3 GENERAL INFORMATION ....................................................................... 8 W ELCOME .................................................................................................... 8 S ECURITY ..................................................................................................... 8 S AFETY P RECAUTIONS ................................................................................. 9 GETTING STARTED ................................................................................. 17 K EY D EFINITION ........................................................................................ 17 D ISPLAY I NDICATORS ................................................................................. 19 T ECHNICAL P ARAMETERS .......................................................................... 20 B ATTERY .................................................................................................... 21 Removing & Installing the Battery ...............................................21 Charging the Battery .......................................................................22 C ONNECTING TO THE N ETWORK ................................................................ 23 SIM Card .............................................................................................23 Inserting & Removing SIM Card ...................................................24 4 Switch on/off Your Phone ..............................................................24 Connecting to the Network ............................................................24 BASIC OPERATIONS................................................................................ 25 M AKING AND A NSWERING A C ALL ............................................................. 25 C ALL M ENU ............................................................................................... 26 FUNCTION MENU..................................................................................... 27 U SAGE AND S TRUCTURE OF F UNCTION M ENU ........................................... 27 C ALL H ISTORY ........................................................................................... 28 Missed Calls ......................................................................................28 Dialed Calls ........................................................................................28 Received Calls ..................................................................................28 Delete Call Log ..................................................................................28 Call Time .............................................................................................28 Call cost ..............................................................................................28 5 SMS Counter .....................................................................................28 GPRS Counter ...................................................................................28 Auto Quick End .................................................................................28 U SER P ROFILES .......................................................................................... 29 F ILE M ANAGER .......................................................................................... 30 P HONE B OOK ............................................................................................. 30 M ESSAGES ................................................................................................. 31 SMS ......................................................................................................31 MMS .....................................................................................................32 Voicemail ............................................................................................33 Broadcast Message .........................................................................33 M ULTIMEDIA .............................................................................................. 34 Camera ................................................................................................34 Image Viewer .....................................................................................34 Video Recorder .................................................................................34 Video Player .......................................................................................34 6 Audio Player ......................................................................................34 Sound Recorder ................................................................................34 Melody Compose ..............................................................................34 T OOLKIT .................................................................................................... 35 Calendar .............................................................................................35 To Do List ...........................................................................................35 Alarm ...................................................................................................35 World clock ........................................................................................35 Games .................................................................................................35 St…

Text truncated - open the document above for the full version.

Cover Letter(s)

FCC Authorization Date: 200 7-11-16 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We ZTE CORPORATION , the undersigned, Hereby authorizes Shanghai Morlab Communication Technology Co.,Ltd to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Shanghai Morlab Communication Technology Co.,Ltd on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Li dezi Nov. 16 2007 ZTE CORPORATION

Cover Letter(s)

Nov. 16, 2007 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we, ZTE CORPORATION, hereby request confidential treatment of information accompanying this Application ( FCC ID: Q78-ZTEA139) as outlined below: Exhibit Type File Name Block Diagram, ZTE A139 Block Diagram.pdf Schematics ZTE A139 SCH.pdf Operational Description ZTE A139 operational description.pdf Parts List ZTE A139 PART_LIST.pdf Tune Up Info ZTE A139 Tune-up.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to us, ZTE CORPORATION, and provide unjustified benefits to its competitors. We, ZTE CORPORATION, understand that pursuant to Rule 0.457, disclosure of this Application (FCC ID: Q78-ZTEA139) and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, Li dezi Nov. 16 2007 ZTE CORPORATION

External Photos

External photos

ID Label/Location Info

GSM Dual-band GPRS Digital Mobile Phone ZTE中兴 MODEL: ZTE A139 GSM Dual-band Digital Mobile Phone FCC ID:Q78-ZTEA139 IMEI NO: 351756020000107 ZTE CORPORATION ZTE中兴 MODEL: ZTE A139 GSM Dual-band Digital Mobile Phone FCC ID:Q78-ZTEA139 IMEI NO: 351756020000115 ZTE CORPORATION ZTE中兴 MODEL: ZTE A139 GSM Dual-band Digital Mobile Phone FCC ID:Q78-ZTEA139 IMEI NO: 351756020000123 ZTE CORPORATION ZTE中兴 MODEL: ZTE A139 GSM Dual-band Digital Mobile Phone FCC ID:Q78-ZTEA139 IMEI NO: 351756020000131 ZTE CORPORATION

ID Label/Location Info

30 Nov 2007 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: Q78-ZTEA139 Dear Sirs: ZTE CORPORATION requests acceptance of the labeling proposal described below for cell phone bearing FCC identifier Q78-ZTEA139. The subject cell phone are compact handheld models as shown in figure 1, authorized under 47CFR Part 24/22 for GSM mobile services. Figure 1. Because the majority of the cell phone housing is composed of display, speaker, operating controls, and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, ZTE CORPORATION proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. Figure 2. The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), ZTE CORPORATION will add the FCC identifier " Q78-ZTEA139" to the outside of the consumer "gift box" packaging. Thank you for your attention to this matter. Sincerely, Li dezi 30 Nov 2007

Internal Photos

Internal photos

RF Exposure Info

Report No: SH07110011S01 Page 3 of 77 Contents 1. GENERAL CONDITIONS 2. ADMINISTRATIVE DATA 2.1. Identification of the Responsible Testing Laboratory 2.2. Identification of the Responsible Testing Location(s) 2.3. Organization Item 2.4. Identification of Applicant 2.5. Identification of Manufacture 3. EQUIPMENT UNDER TEST (EUT) 3.1. Identification of the Equipment under Test 3.2. Identification of all used Test Sample of the Equipment under Test 4. OPERATIONAL CONDITIONS DURING TEST 4.1. Schematic Test Configuration 4.2. SAR Measurement System 5. CHARACTERISTICS OF THE TEST 5.1. Applicable Limit Regulations 5.2. Applicable Measurement Standards 6. LABORATORY ENVIRONMENT 7. TEST RESULTS 7.1. Dielectric Performance 7.2. Summary of Measurement Results 7.3. Conclusion 8. MEASUREMENT UNCERTAINTY 9. MAIN TEST INSTRUMENTS This Test Report consists of the following Annexes: Annex A: Accreditation Certificate Annex B: Test Layout Annex C: Sample Photographs Annex D: Graph Test Results Annex E: System Performance Check Data Report No: SH07110011S01 Page 4 of 77 1.GENERAL CONDITIONS 1.1 This report only refers to the item that has undergone the test. 1.2 This report standalone does not constitute or imply by its own an approval of the product by the certification Bodies or competent Authorities. 1.3 This document is only valid if complete; no partial reproduction can be made without written approval of Shenzhen Morlab Communications Technology Co., Ltd. 1.4 This report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of Shenzhen Morlab Communications Technology Co., Ltd. and the Accreditation Bodies, if it applies. Report No: SH07110011S01 Page 5 of 77 2. Administrative Date 2.1. Identification of the Responsible Testing Laboratory Company Name: Shenzhen Morlab Communications Technology Co.,Ltd. Department: Testing Department Address: 3Fl, Electronic Testing Building, ShaHe Road, NanShan District, Shenzhen, P. R. China Telephone: +86 755 86130268 Fax: +86 755 86130218 Responsible Test Lab Managers: Mr. Shu Luan 2.2. Identification of the Responsible Testing Location(s) Company Name: Shenzhen Electronic Product Quality Testing Center Morlab Laboratory Address: 3Fl, Electronic Testing Building, ShaHe Road, NanShan District, Shenzhen, P. R. China 2.3. Organization Item Morlab Report No.: SH07110011S01 Morlab Project Leader: Mr. Yang Jinhua Morlab Responsible for Accreditation scope: Mr. Shu Luan Start of Testing: 2007-11-17 End of Testing: 2007-11-17 2.4. Identification of Applicant Company Name: ZTE CORPORATION Address: Zhongxing Bldg, Hi-Tech Park, NanShan, Shenzhen, P.R.China Contact person: Li.dz Telephone: +86-021-68895196 Fax: +86-021-50801070 2.5. Identification of Manufacture Company Name: ZTE CORPORATION Address: Zhongxing Bldg, Hi-Tech Park, NanShan, Shenzhen, P.R.China Contact person: Li.dz Telephone: +86-021-68895196 Fax: +86-021-50801070 Notes: This data is based on the information offered by the applicant. Report No: SH07110011S01 Page 6 of 77 3. Equipment Under Test (EUT) 3.1. Identification of the Equipment under Test Brand Name: ZTE中兴 Type Name: ZTE A139 Marking Name: ZTE A139 Test frequency Cellular 850MHz PCS 1900MHz Development Stage Identical prototype Accessories Charger, Battery Battery Model ZTE A139 Battery specification 3.7V 770 mAh Antenna type Integrated Operation mode Call established Modulation mode GMSK General description: Max. Power(EIRP) 0.023W Cellular 850MHz 0.290W PCS 1900MHz 3.2. Identification of all used Test Sample of the Equipment under Test EUT Code Serial Number Hardware Version Software Version IMEI SH07110011A01 N.A. G4rA SE-VE-MOVISTAR- P103C2V1.0.0B01 000000000000000 NOTE: 1. The EUT consists of Hand Telephone Set and normal options: Charger, Lithium Battery as listed above. 2. Please refer to Appendix C for the photographs of the EUT. For a more detailed features description of the EUT, please refer to its User’s Manual. Report No: SH07110011S01 Page 7 of 77 4 OPERATIONAL CONDITIONS DURING TEST 4.1 Schematic Test Configuration During SAR test, EUT is in Traffic Mode (Channel Allocated) at Normal Voltage Condition. A communication link is set up with a System Simulator (SS) by air link, and a call is established. The TCH is allocated to 0, 62 and 124 respectively in the case of GSM 900 MHz, or to 512, 700 and 885 respectively in the case of PCS 1800 MHz. The EUT is commanded to operate at maximum transmitting power. The EUT shall use its internal transmitter. The antenna(s), battery and accessories shall be those specified by the manufacturer. The EUT battery must be fully charged and checked periodically during the test to ascertain uniform power output. If a wireless link is used, the antenna connected to the output of the base station simulator shall be placed at least 50 cm away from the handset. The signal transmitted by the simulator to the antenna feeding point shall be lower than the output power level of the handset by at least 35 dB. 4.2 SAR Measurement System The SAR measurement system being used is the COMOSAR Test Bench, which consists of a Figure1. SAR Lab Test Measurement Set-up KUKA 6-axis robot arm and controller, Antennessa probe with no amplifier and SAM phantom. The system is controlled remotely from a PC, which contains the software to control most of the bench devices and stores measurement data. The software also displays the data obtained from test scans, Report No: SH07110011S01 Page 8 of 77 and determines the averaged SAR values (averaging region 1 gram or 10 gram) for compliance testing. In operation, the system first does an area (2D) scan at a fixed depth within the liquid from the inside wall of the phantom. When the maximum SAR point has been found, the system will then carry out a 3D scan centered at that point to determine volume averaged SAR level. 4.2.1 Robot system specification The robot is used to articulate the probe to programmed positions inside the ph…

Text truncated - open the document above for the full version.

RF Exposure Info

Report No: SH07110011S01 Page 3 of 77 Contents 1. GENERAL CONDITIONS 2. ADMINISTRATIVE DATA 2.1. Identification of the Responsible Testing Laboratory 2.2. Identification of the Responsible Testing Location(s) 2.3. Organization Item 2.4. Identification of Applicant 2.5. Identification of Manufacture 3. EQUIPMENT UNDER TEST (EUT) 3.1. Identification of the Equipment under Test 3.2. Identification of all used Test Sample of the Equipment under Test 4. OPERATIONAL CONDITIONS DURING TEST 4.1. Schematic Test Configuration 4.2. SAR Measurement System 5. CHARACTERISTICS OF THE TEST 5.1. Applicable Limit Regulations 5.2. Applicable Measurement Standards 6. LABORATORY ENVIRONMENT 7. TEST RESULTS 7.1. Dielectric Performance 7.2. Summary of Measurement Results 7.3. Conclusion 8. MEASUREMENT UNCERTAINTY 9. MAIN TEST INSTRUMENTS This Test Report consists of the following Annexes: Annex A: Accreditation Certificate Annex B: Test Layout Annex C: Sample Photographs Annex D: Graph Test Results Annex E: System Performance Check Data Report No: SH07110011S01 Page 4 of 77 1.GENERAL CONDITIONS 1.1 This report only refers to the item that has undergone the test. 1.2 This report standalone does not constitute or imply by its own an approval of the product by the certification Bodies or competent Authorities. 1.3 This document is only valid if complete; no partial reproduction can be made without written approval of Shenzhen Morlab Communications Technology Co., Ltd. 1.4 This report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of Shenzhen Morlab Communications Technology Co., Ltd. and the Accreditation Bodies, if it applies. Report No: SH07110011S01 Page 5 of 77 2. Administrative Date 2.1. Identification of the Responsible Testing Laboratory Company Name: Shenzhen Morlab Communications Technology Co.,Ltd. Department: Testing Department Address: 3Fl, Electronic Testing Building, ShaHe Road, NanShan District, Shenzhen, P. R. China Telephone: +86 755 86130268 Fax: +86 755 86130218 Responsible Test Lab Managers: Mr. Shu Luan 2.2. Identification of the Responsible Testing Location(s) Company Name: Shenzhen Electronic Product Quality Testing Center Morlab Laboratory Address: 3Fl, Electronic Testing Building, ShaHe Road, NanShan District, Shenzhen, P. R. China 2.3. Organization Item Morlab Report No.: SH07110011S01 Morlab Project Leader: Mr. Yang Jinhua Morlab Responsible for Accreditation scope: Mr. Shu Luan Start of Testing: 2007-11-17 End of Testing: 2007-11-17 2.4. Identification of Applicant Company Name: ZTE CORPORATION Address: Zhongxing Bldg, Hi-Tech Park, NanShan, Shenzhen, P.R.China Contact person: Li.dz Telephone: +86-021-68895196 Fax: +86-021-50801070 2.5. Identification of Manufacture Company Name: ZTE CORPORATION Address: Zhongxing Bldg, Hi-Tech Park, NanShan, Shenzhen, P.R.China Contact person: Li.dz Telephone: +86-021-68895196 Fax: +86-021-50801070 Notes: This data is based on the information offered by the applicant. Report No: SH07110011S01 Page 6 of 77 3. Equipment Under Test (EUT) 3.1. Identification of the Equipment under Test Brand Name: ZTE中兴 Type Name: ZTE A139 Marking Name: ZTE A139 Test frequency Cellular 850MHz PCS 1900MHz Development Stage Identical prototype Accessories Charger, Battery Battery Model ZTE A139 Battery specification 3.7V 770 mAh Antenna type Integrated Operation mode Call established Modulation mode GMSK General description: Max. Power(EIRP) 0.023W Cellular 850MHz 0.290W PCS 1900MHz 3.2. Identification of all used Test Sample of the Equipment under Test EUT Code Serial Number Hardware Version Software Version IMEI SH07110011A01 N.A. G4rA SE-VE-MOVISTAR- P103C2V1.0.0B01 000000000000000 NOTE: 1. The EUT consists of Hand Telephone Set and normal options: Charger, Lithium Battery as listed above. 2. Please refer to Appendix C for the photographs of the EUT. For a more detailed features description of the EUT, please refer to its User’s Manual. Report No: SH07110011S01 Page 7 of 77 4 OPERATIONAL CONDITIONS DURING TEST 4.1 Schematic Test Configuration During SAR test, EUT is in Traffic Mode (Channel Allocated) at Normal Voltage Condition. A communication link is set up with a System Simulator (SS) by air link, and a call is established. The TCH is allocated to 0, 62 and 124 respectively in the case of GSM 900 MHz, or to 512, 700 and 885 respectively in the case of PCS 1800 MHz. The EUT is commanded to operate at maximum transmitting power. The EUT shall use its internal transmitter. The antenna(s), battery and accessories shall be those specified by the manufacturer. The EUT battery must be fully charged and checked periodically during the test to ascertain uniform power output. If a wireless link is used, the antenna connected to the output of the base station simulator shall be placed at least 50 cm away from the handset. The signal transmitted by the simulator to the antenna feeding point shall be lower than the output power level of the handset by at least 35 dB. 4.2 SAR Measurement System The SAR measurement system being used is the COMOSAR Test Bench, which consists of a Figure1. SAR Lab Test Measurement Set-up KUKA 6-axis robot arm and controller, Antennessa probe with no amplifier and SAM phantom. The system is controlled remotely from a PC, which contains the software to control most of the bench devices and stores measurement data. The software also displays the data obtained from test scans, Report No: SH07110011S01 Page 8 of 77 and determines the averaged SAR values (averaging region 1 gram or 10 gram) for compliance testing. In operation, the system first does an area (2D) scan at a fixed depth within the liquid from the inside wall of the phantom. When the maximum SAR point has been found, the system will then carry out a 3D scan centered at that point to determine volume averaged SAR level. 4.2.1 Robot system specification The robot is used to articulate the probe to programmed positions inside the ph…

Text truncated - open the document above for the full version.

Test Report

Report No.: SZ07110073E01 Page 2 of 15 TABLE OF CONTENTS 1. TEST CERTIFICATION ...........................................................................................................3 2. GENERAL INFORMATION ....................................................................................................4 2.1 EUT Description .........................................................................................................................4 2.2 Test Standards and Results ........................................................................................................5 2.3 Facilities and Accreditations ......................................................................................................6 2.3.1 Facilities ....................................................................................................................................6 2.3.2 Test Environment Conditions....................................................................................................6 3. TEST CONDITIONS SETTING...............................................................................................7 3.1 Test Mode ....................................................................................................................................7 3.2 Test Setup and Equipments List................................................................................................8 3.2.1 Conducted Emission..................................................................................................................8 3.2.2 Radiated Emission.....................................................................................................................9 4. 47 CFR PART 15B REQUIREMENTS ..................................................................................10 4.1 Conducted Emission .................................................................................................................10 4.1.1 Requirement ............................................................................................................................10 4.1.2 Test Description ......................................................................................................................10 4.1.3 Test Result ...............................................................................................................................10 4.2 Radiated Emission ....................................................................................................................13 4.2.1 Requirement ............................................................................................................................13 4.2.2 Test Description ......................................................................................................................13 4.2.3 Test Result ...............................................................................................................................13 Report No.: SZ07110073E01 Page 4 of 15 2. GENERAL INFORMATION 2.1 EUT Description EUT Type ....................... GSM Dual-band Digital Mobile Phone Model Name................... ZTEA139 Serial No. ....................... (n.a, marked #1 by test site) IMEI ............................... 135790246811220 Hardware Version........... G4rA Software Version ............ SE-VE-MOVISTAR-P103C2V1.0.0B01 Modulation Type ............ GMSK Power Supply ................. Battery Model Name: ZTE A139 Brand name: Capacitance: 770mAh Rated voltage: 3.7V Manufacturer: ZTE CORPORATION Manufacturer Address: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Ancillary Equipment 1 ... AC Adapter (Charger for Battery) Model Name: SCT-A22O50U8-C Brand Name: Serial No.: (n.a. marked #1 by test site) Rated Input: 100-240V, 0.2A,50-60Hz Rated Output: 5V, 700mA Manufacturer: RUIDE ELECTRONICAL INDUSTRIAL CO.,LTD Manufacturer Address: 2nd floor,Block 2,MinQi Scientific Zone, HongHuaLing, XiLi, Nanshan District, Shenzhen, China. Wire Length: 115cm Note 1: The EUT is a GSM/GPRS Wireless telephone; it supports GSM 850MHz, 1900MHz. GSM 850MHz, 1900MHz and GPRS model are tested in this report. Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ07110073E01 Page 5 of 15 2.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart B: No. Identity Document Title 1 47 CFR Part 15 (10-1-05 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section Description Result Test date 1 15.107 Conducted Emission PASS 2007-11-22 2 15.109 Radiated Emission PASS 2007-11-22 NOTE: The tests were performed according to the method of measurements prescribed in ANSI C63.4 2003. Report No.: SZ07110073E01 Page 6 of 15 2.3 Facilities and Accreditations 2.3.1 Facilities Shenzhen Electronic Product Quality Testing Center Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L1659. All measurement facilities used to collect the measurement data are located at Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen 518055 CHINA. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 2.3.2 Test Environment Conditions During the measurement, the environmental conditions were within the listed ranges: Temperature (°C): 20 - 25 Relative Humidity (%): 40 - 60 Atmospheric Pressure (kPa): 96 Report No.: SZ07110073E01 Page 7 of 15 3. TEST CONDITIONS SETTING 3.1 Te s t M o d e During the measurement, there are four Test Modes that will be tested in Conducted Emission and Radiated Emission. These test modes are show…

Text truncated - open the document above for the full version.

Test Report

Report No.: SZ07110073E02 Page 2 of 44 TABLE OF CONTENTS 1. TEST CERTIFICATION ...........................................................................................................4 2. GENERAL INFORMATION ....................................................................................................5 2.1 EUT Description .........................................................................................................................5 2.2 Test Standards and Results ........................................................................................................7 2.3 Facilities and Accreditations ......................................................................................................8 2.3.1 Facilities ....................................................................................................................................8 2.3.2 Test Environment Conditions....................................................................................................8 3. 47 CFR PART 2, PART 22H REQUIREMENTS ....................................................................9 3.1 Frequencies..................................................................................................................................9 3.1.1 Requirement ..............................................................................................................................9 3.1.2 Test Description ........................................................................................................................9 3.1.3 Test Result ...............................................................................................................................10 3.…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Cary Kong(Product Certification Manager)
[email protected]0086-755-26777740Fax: 0086-755-26770347

Test Firm

ShenZhen Electronic Product Quality Testing CenterXingsun Lin
[email protected]86-755-26703698Fax: 86-755-26627238

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
222H824.2 MHz - 848.8 MHz290.00 mW300KGXW85 Hz
Confidentiality
Long Term
Grant Notes
Power listed is EIRP for Part 24 and ERP for Part 22. SAR compliance for body-worn operations is restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.5 cm separation between the device, including its antenna, and the user's body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values are: Part 22 - Body-worn: 0.39W/kg; Head: 0.72 W/kg and Part 24 - Body-worn: 0.29 W/kg; Head: 0.94 W/kg This filing is only applicable for 1900 MHz PCS operations.
