Q78-ZTEC350CDMA 1X Mobile Phone

C350 CDMA 1X Digital Mobile Phone User Manual Copyright © 2007 by ZTE Corporation All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version: Release 1.0 Date: June 2007 Manual number:056584500373 3 Declaration We, ZTE Corporation, declared that: „ The product is installed with battery separately in the box. The FCC ID label is placed on the mobile phone clearly visible to all persons at the time of purchase. „ The user is cautioned that changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. „ This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. „ Do not attempt to disassemble the mobile phone and battery by yourself. Non-expert handling of the devices may damage them. „ Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific 4 organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age or health. The exposure standard for wireless fixed phoned employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limits set by the FCC are 1.6W/kg. Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting as its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station, the lower the output power. The Highest SAR Values for this model phone when tested for use on the Right cheek were 1.15mW/g. „ Some electronic devices are susceptible to electromagnetic interference sent by phone if inadequately shielded. Please use phone at least 20cm or as far as you can from TV set, radio and other automated office equipement so as to avoid interference. „ For body-worn operation, this phone has been tested and meets FCC RF exposure guidelines when the handset is positioned a minimum of 15 mm from the body without any metal parts in the 5 vicinity of the handset. „ NOTE:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/ TV technician for help. i Content 1 General Information ....................................................... 1 1.1 Welcome.................................................................................... 1 1.2 Security ..................................................................................... 1 1.3 Safety Warnings .............................................................. 2 1.4 Limit Warranty .......................................................................... 5 1.5 Limitation of Liability............................................................... 6 2 Know Your Phone............................................................ 8 2.1 Keypad ................................................................................... 8 2.2 Instruction of Interface Icon .................................................... 11 2.3 Technical Parameters............................................................... 12 2.4 Battery..................................................................................... 12 2.4.1 Remove and Installation of Battery ................................. 12 2.4.2 Charging the Battery........................................................ 13 2.5 Connecting to the Network ..................................................... 15 2.5.1 UIM Card ........................................................................ 15 2.5.2 Insertion and Extraction of UIM Card ............................. 15 2.5.3 Power on/off Phone ......................................................... 16 2.5.4 PIN Code......................................................................... 16 2.5.5 Connecting the Network ............................…

Text truncated - open the document above for the full version.

ZTE Corporation Zhongxing Bldg, Shenzhen Hi-tech Industrial Park Nanshan District, Shenzhen city, GuangDong Province, P.R.China 518057 Tel: 086-021-68895196 Fax: 086-021-50801070 Authorization Letter Date: February 18, 2008 BABT Balfour House Churchfield Road Walton-on-Thames Surrey KT12 2TD Dear Sir or Madam: We, the undersigned, hereby authorize Mr. Zhang Changxin from TUV Product Service Limited, Beijing Branch, Unit 918, Landmark Tower 2, 8 North Dongsanhuan Road,100004 Beijing , act on our behalf, as our agent, in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. I further certify that the applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. Section 862. This authorization shall expire 3 months from original date. If you have any question regarding the authorization, please don’t hesitate to contact with me. Sincerely Royce Wang Title: Product Certification Director

Request of Confidentiality Federal Communications Commission Authorization and Evaluation Division Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying of following product: Product Name: CDMA 1X Digital Mobile Phone Product Model: ZTE C350 FCC ID: Q78-ZTEC350 The following information should be held confidential: All Schematics/block diagrams All Parts list for the above schematic diagram Tune-Up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Royce Wang Title: Product Certification Director ZTE Corporation Zhongxing Bldg, Shenzhen Hi-tech Industrial Park Nanshan District, Shenzhen city, GuangDong Province, P.R.China 518057 Tel: 086-021-68895196 Fax: 086-021-50801070

Q78-ZTEC350 External Photo

Q78-ZTEC350 Internal Photo

1 CDMA Handset Technical specification ZTE C350 Prepared by ____Dingling __ Verified by _____________ Approved by _____________ ZTE Corporation <The information contained in this file is solely property of ZTE Corporation. Recipients are obligated to maintain secrecy and are not permitted to disclose it to others.> 2 Revision History Date Version Name Description of Change 2006-10-25 V1.0 Dingling First Draft 2008-1-17 V1.1 Daiye Update Parameters CDMA Handset Specification – ZTE C350 3 Table of Contents 1. Product Picture................................................................................................................ 4 2. General Specifications .................................................................................................... 4 3. Main Functions ...............................................................................................................5 4. Electric Performance....................................................................................................... 6 5. Battery and Charger ........................................................................................................ 6 6. Standard Delivery Unit ................................................................................................... 7 7. Reference standards ........................................................................................................ 7 CDMA Handset Specification – ZTE C350 4 1. Product Picture This is a general version picture of this product. Logo and silk print on mechanical parts, Key pad, etc. may be different to different projects. 2. General Specifications Items C350 CDMA2000 1X Handset Remark Protocol CDMA 2000 1x Release 0 back compatible with IS-95A/B Chipset QSC6010 Frequency TX: 824MHz～849MHz RX: 869MHz～894MHz CDMA Cellular Dimension 88mm46mm16mm Weight 72g(including battery) LCD CSTN65K 128 * 128 pixels Memory 64M Flash16M SRAM CDMA Handset Specification – ZTE C350 5 Vocoder 8K EVRC4GV Keypad 21 keys including 4 way navigation key Vibrator Built-in Vibrator Earphone Support Travel Charger Input: 100V～240V AC Output: 5.0VDC 700mA Battery 670mAh / Li-Ion Antenna Internal Color CSTN 65K 3. Main Functions Items Description Remark Mobile Originate Call Support Mobile Terminate Call Support Caller number display Support Call Forward Network support required Call waiting Network support required Recent Calls 40 Incoming calls 40 Outgoing calls 40 Missed calls Ringer 32 Poly, 31 types(20*Incoming Calls+6*SMS+5 self recorded) Vibrator Support Voice Language Chinese/English, Sending SMS 100 SMS in OutBox Receiving SMS 100 SMS in InBox SMS SMS length 160 English characters Maximum Phonebook Group Names Support 500*3 Including 3 phone numbers Input Zi Support Security PIN Support PINPIN change Calculator Support Alarm Support (1 alarm) Game Support Extra Stopwatch Support OTASP/OTAPA Support Akey Support Brew Option Voice Recording Support Speaker Phone Support Other Functions FM NA CDMA Handset Specification – ZTE C350 6 4. Electric Performance Item Design spec. Mode of Communication CDMA TX: 824 ~ 849MHz Basic Operating Frequency Range (Edge frequency) RX: 869 ~ 894MHz TX: 824 ~ 835MHz Ratified Operating Frequency Range (Edge frequency) RX: 869 ~ 880MHz Frequency Step 30kHz TX / RX separation 45MHz TX: 824.64 ~ 848.37MHz Interval 30KHz, 792 Channels Interval 30KHz, 625 Channels Channeling (Center frequency) RX: 869.64 ~ 893.37MHz Interval 30KHz, 792 Channels TX: OQPSK Type of Modulation RX: QPSK Occupied Bandwidth 1.25MHz Frequency Tolerance ±300Hz Receive Sensitivity -104dBm (FER0.5%) As in Figure, The module uses QSC6010 single chip platform .The o audio parts such as speaker, receiver, headset and microphone. The QSC6010 module is the core of system. The module has the interface of LCD and KEYPAD. And manages the system power and battery charging. 5. Battery and Charger Items Remark Type Lithium Voltage 3.7V (working voltage) Capacity 670mAh Battery Standby Time 80~160 Hours CDMA Handset Specification – ZTE C350 7 Talking Time 2~4 Hours Type Travel Charger Input Voltage AC 100V~240V Input Frequency 47Hz63Hz Output Voltage DC 5V Charger Output Current 700mA 6. Standard Delivery Unit Items Quantity(PCS) Handset 1 Battery (670mAh) 1 Travel Charger 1 Pretty Box 1 User Manual 1 7. Reference standards TIA/EIA/IS-2000.1 Introduction to cdma2000 Standards for Spread Spectrum System TIA/EIA/IS-2000.2 Physical Layer Standard for cdma2000 Spread Spectrum System TIA/EIA/IS-2000.3 Medium Access Control (MAC) Standard for cdma2000 spectrum System TIA/EIA/IS-2000.4 Signaling Layer 2 Standard for cdma2000 Spread Spectrum Systems TIA/EIA/IS-2000.5 Upper Layer(Layer 3) Signaling Standard for cdma2000 spread Spectrum Systems TIA/EIA/IS-2000.6 Analog Signaling Standard for cdma2000 Spread Spectrum Systems 3GPP2 TSG-C4.1 Recommended Minimum Performance Standards for cdma2000 Spread Spectrum Mobile Stations TIA/EIA/IS707.A Data Service Option for Spread Spectrum Systems TIA/EIA/IS707.A.2 Data Service Options for Spread Spectrum systems: Radio link Protocol 3GPP2 C.S0023-0 Removable User Identity Module for Spread Spectrum Systems TIA/EIA/IS-683 Over-the-Air Service Provisioning of Mobile Stations in Wideband Spectrum Cellular Systems

DAT-P-174/04-00 NO.L0447 Registration No.612767 CONFORMANCE TEST REPORT FOR HUMAN EXPOSURE TO ELECTROMAGNETIC FIELDS Report No. : SRMC2008-H024- E0003 Product Name: CDMA Digital Mobile Phone Product Model: ZTE C350 Manufacture: ZTE Corporation Specification: FCC OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01) FCC ID : Q78-ZTEC350 The State Radio Monitoring Center, Equipment Testing Division The State Radio Spectrum Monitoring and Testing Center No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 The State Radio Monitoring Center, Equipment Testing Division Num：SRMC2008-H024-E0003 The State Radio Spectrum Monitoring and Testing Center Tel: 86-10-68009202 68009203 fax:86-10-68009195 68009205 Page 1 of 54 Tables of Contents 1. General information ......................................................................................................................3 1.1 Notes of the test report........................................................................................................3 1.2 Information about the testing laboratory...........................................................................3 1.3 Applicant’s details.................................................................................................................3 1.4 Manufacturer’s details..........................................................................................................3 1.5 Application details.................................................................................................................4 1.6 Information of Test Sample.................................................................................................4 1.7 Auxiliary Equipment (AE)....................................................................................................4 1.8 Reference Specification.......................................................................................................5 2．Subject of Investigation ..............................................................................................................6 2.1 The IEEE Standard C95.1 and the FCC Exposure Criteria...........................................6 2.2 Distinction Between Exposed Population, Duration of Exposure and Frequencies...7 2.3 Distinction between Maximum Permissible Exposure and SAR Limits........................7 2.4 SAR Limit...............................................................................................................................8 3 The FCC Measurement Procedure .................................................................................................8 3.1 General Requirements.........................................................................................................8 3.2 Phantom specifications (shell and liquid)..........................................................................9 3.3 Specifications of the SAR measurement equipment.......................................................9 3.4 Scanning system specifications.......................................................................................10 3.5 Mobile phone holder specifications.................................................................................10 4. Measurement preparation............................................................................................................10 4.1 General preparation...........................................................................................................10 4.2Simplified performance checking......................................................................................10 4.3 Preparation of the mobile phone under test................................................................... 11 4.4 Position of the mobile phone in relation to the phantom.............................................. 11 4.5Tests to be performed.........................................................................................................12 5. The Measurement system........................................................................................................12 5.1 DASY4 Information............................................................................................................12 5.2Test Equipments:.................................................................................................................14 5.3 Uncertainty Assessment....................................................................................................15 6. Test Results .................................................................................................................................16 6.1Test Environment:...............................................................................................................16 6.2Test Method and Procedure...............................................................................................16 6.3Test Configuration................................................................................................................17 6.4Test Results..........................................................................................................................17 7. Appendix .....................................................................................................................................19 7.1 Administrative Data............................................................................................................19 7.2 Device under Test and Test Conditions...........................................................................19 7.3 Tissue Recipes...................................................................................................................21 7.4 Material Parameters...........................................................................................................22 7.5Setup for System Performance Check................................................…

Text truncated - open the document above for the full version.

DAT-P-174/04-00 CNAS L0447 Registration No.612767 1 TEST REPORT Report No.: SRMC2008-H024-E0002 Product Name: CDMA Digital Mobile Phone Product Model: ZTE C350 Manufacture: ZTE Corporation Specification: FCC Part22, Part 2, Part 15 FCC ID: Q78-ZTEC350 The State Radio Monitoring Center, Equipment Testing Division The State Radio Spectrum Monitoring and Testing Center No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 The State Radio Monitoring Center, Equipment Testing Division No.: SRMC2008-H024-E0002 The State Radio Spectrum Monitoring and Testing Center Tel: 86-10-68009202 68009203 fax:86-10-68009195 68009205 Page 2 of 28 CONTENTS 1．General information ................................................................................ 3 1.1 Notes of the test report...................................................................................................3 1.2 Information about the testing laboratory.......................................................................3 1.3 Applicant’s details............................................................................................................3 1.4 Manufacturer’s details.....................................................................................................3 1.5 Application details............................................................................................................4 1.6 Reference specification...................................................................................................4 1.7 Information of EUT..........................................................................................................4 1.7.1 General information..............................................................................................4 1.7.2 EUT details............................................................................................................5 1.7.3 Auxiliary equipment details..................................................................................5 2. Test information: ....................................................................................... 6 2.1 Summary of the test results:..........................................................................................6 2.2 Test result..........................................................................................................................7 2.2.1 RF Power Output –FCC Part2.1046..................................................................7 2.2.2 Effective Radiated Power-FCC Part22.913......................................................8 2.2.3 Occupied Bandwidth-FCC Part2.1049............................................................10 2.2.4 Spurious Emissions at antenna terminals-FCC Part2.1051/22.917...........13 2.2.5 Band Edges Compliance-FCC Part2.1051/22.917.......................................16 2.2.6 Frequency Stability-FCC Part2.1055/Part22.355..........................................18 2.2.7 Radiated Spurious Emissions-FCC Part2.1053/22.917................................19 2.2.8 Conducted Emissions-FCC Part15.107..........................................................23 2.2.9 Radiated Emissions-FCC Part15.109.............................................................25 2.3. List of test equipments.................................................................................................27 Appendix................................................................................................................................28 The State Radio Monitoring Center, Equipment Testing Division No.: SRMC2008-H024-E0002 The State Radio Spectrum Monitoring and Testing Center Tel: 86-10-68009202 68009203 fax:86-10-68009195 68009205 Page 3 of 28 1．General information 1.1 Notes of the test report The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written permission of The State Radio Monitoring Center. The test results relate only to individual items of the samples which have been tested. 1.2 Information about the testing laboratory Company： The State Radio Monitoring Center, Equipment Testing Division The State Radio Spectrum Monitoring and Testing Center Address： No.80 Beilishi Road, Xicheng District, Beijing China City: Beijing Country or Region: China Contacted person: Wang Junfeng Tel +86 10 68009181 +86 10 68009202 Fax: +86 10 68009195 +86 10 68009205 Email: [email protected] 1.3 Applicant’s details Company: ZTE Corporation Address： Zhongxing Bldg, High-Tech Park, Nan Shan City: ShenZhen City, GuangDong Country or Region: P.R.China Grantee Code: Q78 Contacted person: DangYingchun Tel: + (86) 29 8872 3843 Fax: + (86) 29 8872 3829 Email: [email protected] 1.4 Manufacturer’s details Company: ZTE Corporation Address： Zhongxing Bldg, High-Tech Park, Nan Shan City: ShenZhen City, GuangDong Country or Region: P.R.China Grantee Code: Q78 Contacted person: DangYingchun Tel: + (86) 29 8872 3843 Fax: + (86) 29 8872 3829 Email: [email protected] The State Radio Monitoring Center, Equipment Testing Division No.: SRMC2008-H024-E0002 The State Radio Spectrum Monitoring and Testing Center Tel: 86-10-68009202 68009203 fax:86-10-68009195 68009205 Page 4 of 28 1.5 Application details Date of receipt of application: 21 th Jan. 2008 Date of receipt of test sample: 21 th Jan. 2008 Date of test: 22 th Jan. 2008 to 14 th Feb. 2008 1.6 Reference specification FCC Part22, Part 2, Part 15 1.7 Information of EUT 1.7.1 General information Name of EUT CDMA Digital Mobile Phone FCC ID Q78-ZTEC350 Frequency range Tx:824~849MHz Rx:869~894MHz Rated output power 23.0dBm Modulation type OQPSK Duplex mode FDD Duplex spacing: 45MHz Antenna type Fixed Internal Power Supply Battery or charger Rated Power Supply Voltage 3.7V Extreme Temperature -30°C~+50°C The State Radio Monitoring Center, Equipment Testing Division No.: SRMC2008-H024-E0002 The State Radio Spectrum…

Text truncated - open the document above for the full version.

DAT-P-174/04-00 CNAS L0447 Registration No.612767 Appendix1 TEST SETUP Report No.: SRMC2008-H024-E0002 Product Name: CDMA Digital Mobile Phone Product Model: ZTE C350 Manufacture: ZTE Corporation Specification: FCC Part22, Part 2, Part 15 FCC ID: Q78-ZTEC350 The State Radio Monitoring Center, Equipment Testing Division The State Radio Spectrum Monitoring and Testing Center No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 The State Radio Monitoring Center, Equipment Testing Division No.: SRMC2008-H024-E0002 The State Radio Spectrum Monitoring and Testing Center Tel: 86-10-68009202 68009203 fax:86-10-68009195 68009205 Page 2 of 3 Pic 1 Conducted Emissions Test Setup The State Radio Monitoring Center, Equipment Testing Division No.: SRMC2008-H024-E0002 The State Radio Spectrum Monitoring and Testing Center Tel: 86-10-68009202 68009203 fax:86-10-68009195 68009205 Page 3 of 3 Pic 2 Radiated Spurious Emissions Test Setup Pic 3 Radiated Emissions Test Setup
