Q78-ZTEMF212HSUPA mini PCI-E Modem

1 ZTE MODEM Mobile Connection User Manual 2 1 Software Installation 1.1 Installation Instruction The following installation interface will show how to install the software.  Recommend you to exit other programs, and then click “Next”. 3  Read the agreement carefully. If you agree, choose “I accept the terms of the license agreement”, and then click “Next”.  Select the folder that you want to install the software by 4 pressing “Change”, and then click “Next”.  The system show the installation progress, wait a minute and the following screen will show up:  Click “Finish” to complete the installation. 5 Note：If you have problems with installation after the upper operation, please contact the service provider. After the installation, select the “Start → Programs” and there will be a “MODEM Mobile Connection” program group，which includes “MODEM Mobile Connection” and “MODEM Uninstall”. There will be a Shortcut icon like below on the desktop. 1.2 Run the Application Software After the modem is correctly connected, click the “Start → Programs → MODEM Mobile Connection →MODEM Mobile Connection” menu on the laptop or desktop PC to run the application software. Or double click the shortcut icon, to run the application software. After modem initialized, main interface appears. When the standby icon appears in the taskbar, the modem can work properly. 1.3 Software Uninstall  Close the application program before the software uninstalls.  Click “Start→ Programs→ MODEM Mobile Connection 6 → MODEM Uninstall” menu on the laptop or desktop PC.  Click “Yes” according to the indication, then the system begins to uninstall programs.  Click “Finish” to complete the application software uninstall. 7 2 Functions & Operation 2.1 Interface introduction 2.1.1 Main Interface The starting screen of the Device software is shown as the following: The whole interface is divided into three parts. Related functions can be executed by operation in the related areas. 1. Function button area: There will show various function button icons. Select different function button and it will carry out corresponding operation. 8 Internet: Connect to the Internet. Short Message (SMS): Send SMS or read SMS. PhoneBook: Save and view the different information of the contacts. Settings: Set normal relative information for the modem. Help: Show the help information. 2. System information area: Show the system status and different kinds of tips. Icon Explanations The icon indicates the network signal intensity. There are 6 stages from none to the strongest. The icon indicates there are new SMS at present. The icon indicates the current status of Internet connection is not connected. The icon indicates the current status of Internet connection is already connected. Letter “P” means supporting packet-switch （P）service, letter “C” means supporting circuit-switch（C） service. SIM/USIM card is in status of roaming. 9 Icon Explanations The icon indicates insert status of the modem. Green means it has been inserted into the computer. The icon indicates insert status of the modem. Red means it has not been inserted into the computer. The icon indicates insert status of the modem. Yellow means it has been inserted into the computer but in offline status. The icon indicates insert status of the SIM/USIM card to the modem. Green means the card has been inserted. The icon indicates insert status of the SIM/USIM card to the modem. Red means it has not been inserted. The icon indicates the current network type, i.e. EDGE or GPRS, HSDPA/HSUPA service. Name of the current service provider. View related information for your internet operation, such as, user name, start time, disconnect time, duration, data received and data sent. 3. User Area: Show the man-computer interaction information under various conditions. 10 2.1.2 Description of Mini Icons When click the mini button, the software will minimize as an icon on the system taskbar. If connected to the Internet, the minimized software won’t influence the download of data or receiving SMS. When the application window is minimized, the system icons will display on the taskbar. Double click the icon to resize the display. 1. Taskbar Icons Description： The Device has been inserted into the computer. The Device is not inserted into the computer. The Device is offline. UIM/SIM card is not inserted. No network signal. There is a new message. The Device is ready to connect to Internet. The Internet is already connected. 2. The uses of Tray Icons： Right Click the tray icons, the following menu will appear: 11 Device Offline/ Device Online: Pause/reusing the working of the modem. If connected Internet, you need disconnect the Internet first, and then select the Device Offline. Factory Settings: Restore all the settings to the original values in the Device. This operation just affects the settings in the Device and do not change any software settings in the laptop or desktop PC. Help: Enter the Device software help. About: View the information of the application software and hardware versions. Exit: Close the software and stop the modem from working. 2.2 Connecting Internet You can browse web pages after you have accessed to Internet with the help of modem, you can also receive SMS when surfing in the Internet. 1. Connect to the Internet: Click the Internet icon. Then the system will ask you “Connect to ?”. Select “Connect”. 12 When connected, there is a status bar in the bottom of the user area which shows “State: connected to ...”, and the user area will show data amount, connected time and so on. Then you can access Internet and receive email etc through network. 13 You can click “Disconnect” to stop the connection when the “Connect” 'button becomes “Disconnect” button, 2. Internet connection records: Click “Internet connection records” to check the log of Internet connection history. 14 2.3 SMS Note: To ensure that the Short Message can be used properly, at first, you should setup the correct Short Mess…

Text truncated - open the document above for the full version.

秘密▲ <本文中的所有信息均为中兴通讯股份有限公司内部信息，不得向外传播。> Antenna Test Report 1. 3D Gain Frequency （MHz） 3D Gain Data （dBi） 824 -1.60 880 -0.86 894 0.11 960 -0.25 1710 -1.20 1880 1.12 1920 1.21 1990 0.78 2170 -2.10 2. Pattern XY Plane 秘密▲ <本文中的所有信息均为中兴通讯股份有限公司内部信息，不得向外传播。> XZ Plane YZ Plane ~~~~~~END~~~~~~

内部公开 内部公开内部公开 内部公开▲ 本文中的所有信息归中兴通讯股份有限公司所有，未经允许，不得外传 第 1 / 1 页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China Date: Oct 12,2009 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC(Telecommunication Metrology Center of MII) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pur suant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Royce Wang ZTE CORPORATION Tel：0755-26770345 Fa x：0755-26770347 E- Mail：[email protected]

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Oct. 22, 2010 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: Q78-ZTEMF212 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

内部公开Internal Use Only▲ <以上所有信息均为中兴通讯股份有限公司所有，不得外传> All Rights reserved, No Spreading abroad without Permission of ZTE 第1页 ZTE CORPOARTION 2010-10-20 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality request for FCC ID: Q78- ZTEMF212 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 days:  External Photos  Internal Photos  Test Setup Photos  User’s Manual The applicant also acknowledges that they will also provide appropriate notice to ATCB should either of the following occur: a) if the applicant requires additional 45 day extension periods they will notify ATCB with a new request letter at least 7 days prior to the short-term confidentiality expiration date - [Note: up to a maximum of 3 extensions only are allowed], or b) immediately notify ATCB in the event the information regarding the product or the product is made available to the public. ATCB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, Royce Wang CERTIFICATION MANAGER ZTE CORPORATION

ZTE Corporation Zhongxing Bldg, Shenzhen Hi-tech Industrial Park Nanshan District, Shenzhen city, GuangDong Province, P.R.China 518057 Tel: 086-021-68895196 Fax: 086-021-50801070 Module Characteristics Declaration We declare that our GSM/GPRS/EDGE/WCDMA/HSDPA/HSUPA Module product Product Model: MF212 (FCC ID: Q78-ZTEMF212) has the following module characteristics: Item 1 2 3 4 5 6 7 8 Requirements Have its own RF shielding Have buffered modulation/data inputs (if such inputs are provided) Have it own power supply regulation Meet the antenna requirements of Section 15.203 Be tested in a stand-alone configuration, i.e. the antenna, AC or DC power and data input/output lines must be connected to the module but, the module must not be inside another case during testing Be labeled with its own FCC ID number, and if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. The modular transmitter is manufactured so that the user cannot influence the operation of the transmitter that will operate outside of the scope of the regulations. Address compliance with the commission’s RF exposure limits Sections 1.1310 and 2.1093. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF exposure compliance in accordance with Section 15.247(b)(4). EUT Device is equipped with Metal shielding to cover RF section. Refer to external and internal photos All inputs to the modules are buffered through logic or microprocessor inputs. Internal 1.8V and 2.8V regulator IFA Antenna on the module insert to mother board Device is tested in a test fixture in a standalone configuration FCC ID label format will be included in the filling. System ID label will by displayed on the host system Refer to “User Manual” Exhibit MPE calculation is provided to demonstrate RF compliance for mobile modular approval. Signed: Name: Royce Wang Title: Product Certification Director Date: Oct 27, 2010

External Photos

Model：MF212 Made in China FCC IDQ78-ZTEMF212 IMEI: 865160000000279

Internal Photos:

RF exposure requirements – ZTE MF212 Dear Reviewer, The maximum measured power output is GSM 850:32.99dBm GSM 1900:30.37dBm WCDMA850: 23.73dBm WCDMA 1900: 23.01dBm the maximum antenna gain for integral antenna is GSM 850:-1.0dBi GSM 1900:1.2dBi WCDMA850: -1.0dBi WCDMA 1900: 1.2dBi The maximum permissible exposure is defined in 47 CFR 1.1310 with 1 mW/cm². The Transmitter is using external antennas that operate at 20 cm or more from nearby persons. The maximum permitted level is calculated using the general equation: S = P’ / 4πR² GSM 850: P’ = 32.99dBm+(-1.0dBi)=31.99dBm=1581.2mW GSM1900: P’ = 30.37dBm+ 1.2dBi=31.57dBm=1435.5mW WCDMA850: P’ = 23.73dBm+(-1.0dBi)=22.73dBm=187.5mW WCDMA1900: P’ = 23.01dBm+1.2dBi =24.21dBm=263.6mW R = 20cm π = 3.1416 Solving for S, the power density at 20 cm is GSM 850: 0.315mW/cm² GSM1900: 0.286mW/cm² UMTS850: 0.037mW/cm² UMTS1900: 0.052mW/cm² So the limit is kept. Best Regard. 2010-10-21 Yin Feng Telecommunication Metrology Center of MIIT Shouxiang Science Building, No 51, Xueyuan Road, Haidian District, Beijing, P.R.China 100191

TEST REPORT No. 2010TAR417 for ZTE CORPORATION HSUPA mini PCI-E Modem Model Name: MF212 FCC ID : Q78-ZTEMF212 with Hardware Version: P678A1-2.0.0 Software Version: BD_P678A1V1.0.2B07_FCC Issued Date: Oct 29th, 2010 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology 3/F Shou Xiang Technology Building, No.51 Xueyuan Road, Hai Dian District, Beijing, P. R. China,100191. Tel:+86(0)10-62304633-2604, Fax:+86(0)10-62304793, Email:[email protected], web: www.emcite.com No.2010TAR417 Page2 of 62 CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION .................................................................................................................... 3 1.2. TESTING ENVIRONMENT ........................................................................................................... 3 1.3. PROJECT DATA .............................................................................................................................. 3 1.4. SIGNATURE ..................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ....................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ..................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .................................... 5 3.3. GENERAL DESCRIPTION ............................................................................................................ 5 4. REFERENCE DOCUMENTS ............................................................................................................. 5 4.1. REFERENCE DOCUMENTS FOR TESTING ............................................................................. 5 5. LABORATORY ENVIRONMENT ..................................................................................................... 6 6. SUMMARY OF TEST RESULTS ....................................................................................................... 7 7. TEST EQUIPMENTS UTILIZED ...................................................................................................... 8 ANNEX A: MEASUREMENT RESULTS .................................................................................................. 9 A.1 OUTPUT POWER (§22.913(A)/§24.232(B)) ................................................................................. 9 A.2 EMISSION LIMT (§2.1051/§24.238) .......................................................................................... 15 A.3 FREQUENCY STABILITY (§2.1055/§24.235) ........................................................................... 20 A.4 OCCUPIED BANDWIDTH (§2.1049(H)(I)) ................................................................................. 22 A.5 EMISSION BANDWIDTH (§22.917(B)/§24.238(B)) .................................................................. 34 A.6 BAND EDGE COMPLIANCE (§22.917(B)/§24.238(B)) ............................................................. 46 A.7 CONDUCTED SPURIOUS EMISSION (§2.1057/§22.917/§24.238) ........................................... 52 No.2010TAR417 Page3 of 62 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: 3/F Shou Xiang Technology Building, No.51 Xueyuan Road, Hai Dian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304793 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Sep 27,2010 Testing End Date: Oct 29,2010 1.4. Signature Zi Xiaogang (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2010TAR417 Page4 of 62 2. Client Information 2.1. Applicant Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China City: Shenzhen Postal Code: 518057 Country: China Telephone: 0086 21 68895196 Fax: 0086 21 61460600 2.2. Manufacturer Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China City: Shenzhen Postal Code: 518057 Country: China Telephone: 0086 21 68895196 Fax: 0086 21 61460600 No.2010TAR417 Page5 of 62 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description HSUPA mini PCI-E Modem Model Name MF212 FCC ID Q78-ZTEMF212 Frequency GSM 850MHz; PCS 1900MHz; EGSM900; DCS1800; WCDMA Band I WCDMA Band II; WCDMA Band V Antenna Internal Power supply USB Output power 27.69 dBm maximum ERP measured for GSM850 Extreme vol. Limits 4.8VDC to 5.2VDC (nominal: 5VDC) Extreme temp. Tolerance -30°C to +50°C Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identifi…

Text truncated - open the document above for the full version.

TEST REPORT No. 2010TAR418 for ZTE CORPORATION HSUPA mini PCI-E Modem Model Name: MF212 FCC ID : Q78-ZTEMF212 with Hardware Version: P678A1-2.0.0 Software Version: BD_P678A1V1.0.2B07_FCC Issued Date: Oct 29th, 2010 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology 3/F Shou Xiang Technology Building, No.51 Xueyuan Road, Hai Dian District, Beijing, P. R. China,100191. Tel:+86(0)10-62304633-2604, Fax:+86(0)10-62304793, Email:[email protected], web: www.emcite.com No.2010TAR418 Page2 of 39 CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION .................................................................................................................... 3 1.2. TESTING ENVIRONMENT ........................................................................................................... 3 1.3. PROJECT DATA .............................................................................................................................. 3 1.4. SIGNATURE ..................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ....................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ..................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .................................... 5 3.3. GENERAL DESCRIPTION ............................................................................................................ 5 4. REFERENCE DOCUMENTS ............................................................................................................. 6 4.1. REFERENCE DOCUMENTS FOR TESTING ............................................................................. 6 5. LABORATORY ENVIRONMENT ..................................................................................................... 7 6. SUMMARY OF TEST RESULTS ....................................................................................................... 8 7. TEST EQUIPMENTS UTILIZED ...................................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ................................................................................................ 10 A.1 OUTPUT POWER (§22.913(A)/§24.232(B)) ............................................................................... 10 A.2 EMISSION LIMT (§2.1051/§24.238) .......................................................................................... 14 A.3 FREQUENCY STABILITY (§2.1055/§24.235) ........................................................................... 19 A.4 OCCUPIED BANDWIDTH (§2.1049(H)(I)) ................................................................................. 21 A.5 EMISSION BANDWIDTH (§22.917(B)/§24.238(B)) .................................................................. 25 A.6 BAND EDGE COMPLIANCE (§22.917(B)/§24.238(B)) ............................................................. 29 A.7 CONDUCTED SPURIOUS EMISSION (§2.1057/§22.917/§24.238) ........................................... 31 No.2010TAR418 Page3 of 39 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: 3/F Shou Xiang Technology Building, No.51 Xueyuan Road, Hai Dian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304793 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Sep 27,2010 Testing End Date: Oct 29,2010 1.4. Signature Zi Xiaogang (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2010TAR418 Page4 of 39 2. Client Information 2.1. Applicant Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China City: Shenzhen Postal Code: 518057 Country: China Telephone: 0086 21 68895196 Fax: 0086 21 61460600 2.2. Manufacturer Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China City: Shenzhen Postal Code: 518057 Country: China Telephone: 0086 21 68895196 Fax: 0086 21 61460600 No.2010TAR418 Page5 of 39 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description HSUPA mini PCI-E Modem Model Name MF212 FCC ID Q78-ZTEMF212 Frequency GSM 850MHz; PCS 1900MHz; EGSM900; DCS1800; WCDMA Band I WCDMA Band II; WCDMA Band V Antenna Internal Power supply USB Output power 21.35 dBm maximum EIRP measured for UMTS1900 Extreme vol. Limits 4.8VDC to 5.2VDC (nominal: 5VDC) Extreme temp. Tolerance -30°C to +50°C Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identif…

Text truncated - open the document above for the full version.

Part2224_Test Setup Photos
