Q78-ZTEMF30Wireless Access Terminal

1 ZTE MF30 Global Mobile Hotspot User Manual 2 WELCOME Thank you for choosing the ZTE MF30 Global Mobile Hotspot (hereinafter referred to as “Wireless Router"). To get the most from your router and to keep it in the best condition please read this manual carefully. The pictures, symbols and contents in this manual are for reference only. They might not be completely identical with your router. ZTE operates a policy of continuous development. We reserve the right to update the technical specifications in this document at any time without prior notice. 3 Glossary AC: Alternating Current APN: Access Point Name DC: Direct Current DHCP: Dynamic Host Control Protocol DNS: Domain Name System (or Service or Server) EDGE: Enhanced Data GSM Evolution Ethernet: A frame-based computer networking technology for local area networks (LANs) GSM: Global System for Mobile Communications GPRS: General Packet Radio Service HSDPA: High Speed Downlink Packet Access HSUPA: High Speed Uplink Packet Access IP: Internet Protocol LAN: Local Area Network LED: Light - emitting Diode MHz: Megahertz MTU: Maximum Transmission Unit PDP: Packet Data Protocol PIN: Personal Identification Number PPP: Point to Point Protocol PSTN: Public Switched Telephony Network PUK: PIN Unlocking Key RSSI: Radio Signal Strength Indicator 4 RF: Radio Frequency (U)SIM: Subscriber Identification Module WCDMA: Wideband CDMA (Code-Division Multiple Access) WEP: Wired Equivalent Privacy WLAN: Wireless LAN WPA-PSK: Wi-Fi Protected Access–PreShared Key CM Software: Connection management software UI: User interface 5 Content 1 General Information .................................................................................... 7 1.1 Safety Precautions .................................................................... 7 1.2 Declaration ................................................................................ 8 1.3 Cleaning and Maintaining .......................................................... 8 1.4 Limited Warranty ....................................................................... 9 1.5 Limitation of Liability ................................................................ 10 2 Getting started ........................................................................................... 11 2.1 Parts Supplied ......................................................................... 11 2.2 Router Appearance ................................................................. 11 2.3 Work mode .............................................................................. 12 2.4 Installation ............................................................................... 13 2.5 About the (U)SIM Card ............................................................ 15 3 Modem mode .............................................................................................. 16 3.1 Software Installation ................................................................ 16 3.2 Run the Application Software ................................................... 18 3.3 Software Uninstall.................................................................... 18 3.4 Functions & Operation ............................................................. 20 3.4.1 Interface introduction ................................................................. 20 3.4.2 Internet ....................................................................................... 22 3.4.3 SMS ........................................................................................... 23 3.4.4 Phonebook ................................................................................. 26 6 3.4.5 Settings ...................................................................................... 28 3.4.6 Data Records .............................................................................. 38 3.4.7 microSD card ............................................................................. 39 4 AP mode ..................................................................................................... 40 4.1 Preparation .............................................................................. 40 4.2 Settings ................................................................................... 41 4.2.1 Login .......................................................................................... 41 4.2.2 Quick Setup................................................................................ 42 4.2.3 WAN Connection ....................................................................... 45 4.2.4 3G Settings ................................................................................. 45 4.2.5 Router ........................................................................................ 48 4.2.6 Wi-Fi Setting.............................................................................. 49 4.2.7 Firewall ...................................................................................... 54 4.2.8 Advanced ................................................................................... 57 4.3 Logout ..................................................................................... 59 4.4 Disconnecting from the Internet ............................................... 60 5 Troubleshooting ......................................................................................... 61 6 Technical Parameters ................................................................................ 65 7 1 General Information 1.1 Safety Precautions Some electronic devices may be susceptible to electromagnetic interference. Locate the router away from TV set, radio and other electronic equipment to avoid electromagnetic interference. The router may interfere with medical devices like hearing aids and pacemakers. Consult a physician or the manufacturer of the medical device before using the router. Please keep yourself at least 20 centimeters away from router. Do not use your router in dangerous envi…

Text truncated - open the document above for the full version.

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: May 7, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC(Telecommunication Metrology Center of MII) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: May 7, 2010 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: Q78-ZTEMF30 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

MF30 external photo Battery Battery Charger Label of Charger

MF30, label placement

MF30 internal photos Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly Mobile phone Disassembly

RF exposure requirements – ZTE MF30 Dear Reviewer, The maximum measured power output is GSM 850:33.04dBm GSM 1900:30.93dBm UMTS 850: 22.24dBm UMTS 1900: 22.85dBm 802.11b/g: 19.50dBm the maximum antenna gain for integral antenna is GSM 850:-1.1dBi GSM 1900:1.9dBi UMTS 850: -1.1dBi UMTS 1900: 1.9dBi 802.11b/g: 1.2dBi The maximum permissible exposure is defined in 47 CFR 1.1310 with 1 mW/cm². The Transmitter is using external antennas that operate at 20 cm or more from nearby persons. The maximum permitted level is calculated using the general equation: S = P’ / 4R² GSM 850: P’ = 33.04dBm+(-1.1dBi)=31.94dBm=1563mW GSM1900: P’ = 30.93dBm+ 1.9dBi=32.83dBm=1918mW UMTS850: P’ = 22.24dBm+(-1.1dBi)=21.14dBm=130mW UMTS1900: P’ = 22.85dBm+1.9dBi =24.75dBm=298mW 802.11b/g: P’ = 19.50dBm+1.2dBi =20.7dBm=117mW R = 20cm = 3.1416 Solving for S, the power density at 20 cm is GSM 850: 0.310mW/cm² GSM1900: 0.381mW/cm² UMTS850: 0.025mW/cm² UMTS1900: 0.059mW/cm² 802.11b/g: 0.023mW/cm² For simultaneous transmission, maximum value is GSM1900+802.11b/g=0.381mW/cm²+0.023mW/cm²=0.404mW/cm² So the limit is kept. Best Regard. 2010-05-05 Zhang Hao Telecommunication Metrology Center of MIIT No 52 Huayuanbei Road, Haidian District Beijing P.R.China 100191

No.2010TAR152 Page1 of 16 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2010TAR152 for ZTE Corporation Wireless Access Terminal Model Name: MF30 FCC ID: Q78-ZTEMF30 with Hardware Version: dg6A Software Version: EN_ZTE_MF30V1.0.0B04 Issued Date: May 5th, 2010 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633 , Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.2010TAR152 Page2 of 16 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ............................................................................................................... 3 1.1. TESTING LOCATION ........................................................................................................... 3 1.2. TESTING ENVIRONMENT ................................................................................................... 3 1.3. PROJECT DATA ................................................................................................................... 3 1.4. SIGNATURE .......................................................................................................................... 3 2. CLIENT INFORMATION ........................................................................................................... 4 2.1. APPLICANT INFORMATION ................................................................................................ 4 2.2. MANUFACTURER INFORMATION ...................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT .......................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 4. REFERENCE DOCUMENTS .................................................................................................... 6 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 6 5. LABORATORY ENVIRONMENT .............................................................................................. 7 6. SUMMARY OF TEST RESULTS .............................................................................................. 8 7. TEST EQUIPMENTS UTILIZED ............................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 10 No.2010TAR152 Page3 of 16 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing,P.R.China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304793 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Mar 15,2010 Testing End Date: Mar 16,2010 1.4. Signature Zi Xiaogang (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2010TAR152 Page4 of 16 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China City: Shenzhen Postal Code: 518057 Country: China Telephone: +86-21-68897541 Fax: +86-21-50801070 2.2. Manufacturer Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China City: Shenzhen Postal Code: 518057 Country: China Telephone: +86-21-68897541 Fax: +86-21-50801070 No.2010TAR152 Page5 of 16 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description Wireless Access Terminal Model Name MF30 FCC ID Q78-ZTEMF30 Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.8VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MII of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version N05 359995030000218 dg6A EN_ZTE_MF30V1.0.0B04 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Battery / AE2 Travel Adapter / AE1 Model Li3715T42P3h654251 Manufacturer ZTE CORPORATION Capacitance 1500mAh Nominal Voltage 3.7V AE2 Model STC-A22O50I700USBA-Z Manufacturer RUIDE Length of DC line 120cm *AE ID: is used to identify the test sample in the lab internally. No.2010TAR152 Page6 of 16 ©Copyright. All rights reserved by TMC Beijing. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version FCC Part 15, Subpart B Radio frequency devices July 10, 2008 Edition ANSI C63.4 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 2009 No.2010TAR152 Page7 of 16 ©Copyright. All rights reserved by TMC Beiji…

Text truncated - open the document above for the full version.

MF30 FCC test setup photo 1． Radiated Spurious Emission 2． Conducted Emission(Charging) 3． Conducted Emission(USB) 4． Radiated Emission(Charging) 5． Radiated Emission(USB) 6. part15C
