Q78-ZTEMF60Wireless Access Terminal

Confidential and Proprietary Information of ZTE CORPORATION 1 ZTE MF60 3G Global Mobile Hotspot User Manual ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: (86) 755 26779999 URL: http://www.zte.com.cn E-mail: [email protected] Confidential and Proprietary Information of ZTE CORPORATION 2 LEGAL INFORMATION Copyright © 2010 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version No. : R Edition Time : Manual No. : Confidential and Proprietary Information of ZTE CORPORATION 3 Contents Getting Started ...................................................................................................................... 5 Device Appearance ........................................................................................................... 5 Indicators ........................................................................................................................... 6 Hardware Installation ........................................................................................................ 6 Inserting SIM Card and Battery .................................................................................... 6 Inserting microSD Card ................................................................................................ 7 Switching On/Off Your Device .................................................................................... 8 Charging Your Device .................................................................................................. 8 microSD Card ................................................................................................................... 9 About SIM Card ................................................................................................................ 9 Working Mode .................................................................................................................... 10 USB Mode....................................................................................................................... 10 Wi-Fi Mode ..................................................................................................................... 13 Mixed Mode .................................................................................................................... 14 Operation and Function ....................................................................................................... 15 Preparation ...................................................................................................................... 15 Establish a connection between your device and the client ............................................ 15 Access the Internet .......................................................................................................... 16 Access the WebGUI Configuration Page........................................................................ 16 Login ............................................................................................................................... 17 Quick Setup ..................................................................................................................... 19 Settings ............................................................................................................................ 21 3G Settings .................................................................................................................. 21 Wi-Fi Settings ............................................................................................................. 24 Firewall ....................................................................................................................... 27 Advanced .................................................................................................................... 30 Phonebook ....................................................................................................................... 33 Adding new contact .................................................................................................... 33 Confidential and Proprietary Information of ZTE CORPORATION 4 Operation in native ...................................................................................................... 33 Operation in SIM Card ................................................................................................ 34 SMS ................................................................................................................................. 34 Configing SMS ........................................................................................................... 34 Sending new SMS ....................................................................................................... 35 Operation in native ...................................................................................................... 35 Operation in SIM Card ................................................................................................ 36 WAN Connection ............................................................................................................ 36 Usage of WPS ................................................................................................................. 37 Logout ............................................................................................................................. 37 Disconnecting from the Internet ..................................................................................... 37 Sleep Mode .............................................…

Text truncated - open the document above for the full version.

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Dec 7, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC(Telecommunication Metrology Center of MII) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Dec 7, 2010 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: Q78-ZTEMF60 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

MF60 external photo Battery Battery Charger Label of Charger

MF60, label placement

MF60 internal photos

©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2010TAR473 for ZTE CORPORATION Wireless Modem and Router Model Name: MF60 FCC ID: Q78-ZTEMF60 With Hardware Version: di3C Software Version: BD_MF60V1.0.0B09 Issued Date: Dec 9, 2010 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633 , Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.2010TAR473 Page2 of 16 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ............................................................................................................... 3 1.1. TESTING LOCATION ........................................................................................................... 3 1.2. TESTING ENVIRONMENT ................................................................................................... 3 1.3. PROJECT DATA ................................................................................................................... 3 1.4. SIGNATURE .......................................................................................................................... 3 2. CLIENT INFORMATION ........................................................................................................... 4 2.1. APPLICANT INFORMATION ................................................................................................ 4 2.2. MANUFACTURER INFORMATION ...................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT .......................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 4. REFERENCE DOCUMENTS .................................................................................................... 6 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 6 5. LABORATORY ENVIRONMENT .............................................................................................. 7 6. SUMMARY OF TEST RESULTS .............................................................................................. 8 7. TEST EQUIPMENTS UTILIZED ............................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 10 No.2010TAR473 Page3 of 16 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing,P.R.China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Nov 22,2010 Testing End Date: Nov 25,2010 1.4. Signature Zi Xiaogang (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2010TAR473 Page4 of 16 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China City: Shenzhen Postal Code: 518057 Country: China Telephone: +86-21-68897541 Fax: +86-21-50801070 2.2. Manufacturer Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park,Nanshan District,Shenzhen, Guangdong, 518057, P.R.China City: Shenzhen Postal Code: 518057 Country: China Telephone: +86-21-68897541 Fax: +86-21-50801070 No.2010TAR473 Page5 of 16 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description Wireless Modem and Router Model Name MF60 FCC ID Q78-ZTEMF60 Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.7VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MII of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version N04 / di3C BD_MF60V1.0.0B09 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Battery / AE2 Travel Adapter / AE1 Model Li3715T42P3h654251 Manufacturer ZTE Capacitance 1500mAh Nominal Voltage 3.7V AE2 Model STC-A22O50I700USBA-Z Manufacturer RUIDE Length of DC line 180cm *AE ID: is used to identify the test sample in the lab internally. No.2010TAR473 Page6 of 16 ©Copyright. All rights reserved by TMC Beijing. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version FCC Part 15, Subpart B Radio frequency devices July 10, 2008 Edition ANSI C63.4 Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 2003 No.2010TAR473 Page7 of 16 ©Copyright. All rights reserved by TMC Beijing. 5. LABORATORY ENVIRONMENT Semi-anechoic chamber (23 mete…

Text truncated - open the document above for the full version.

MF60 FCC test setup photo 1． Radiated Spurious Emission 2． Conducted Emission(Charging) 3． Conducted Emission(USB) 4． Radiated Emission(Charging) 5． Radiated Emission(USB) 6. part15C
