Q78-ZTEMF631HSDPA USB MODEM

MF631 USB Modem Quick Guide ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: (86) 755 26779999 URL: http://www.zte.com.cn E-mail: [email protected] LEGAL INFORMATION Copyright © 2010 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version No. : R1.0 Edition Time : Manual No. : Confidential and Proprietary Information of ZTE CORPORATION 1 C h a p t e r 1 Quick Guide Introduction The ZTE USB modem is a multi-mode USB modem, working in HSUPA/HSDPA/WCDMA/EDGE/GPRS/GSM networks. With USB interface connecting to a laptop or a desktop PC, it integrates the functionality of a modem and a mobile phone (SMS), and combines mobile communication with Internet perfectly. It supports data and SMS services through the mobile phone network, enabling you to communicate anytime and anywhere. Specification The following table shows the specification of your device. Interface Type USB 2.0 high speed Systems supported Supports most types of laptop and desktop PC. Operating systems supported Windows XP, Vista, Windows 7 MAC 10.4 or above Functions SMS service, Data service, Applications management, support microSD card, etc. Network Standards HSUPA/HSDPA/WCDMA/EDGE/GPRS/GSM Transmission speed (Max) HSUPA: 5.76Mbps UL HSDPA: 7.2Mbps DL Temperature Storage: -40°C ~ +80°C Operation:-10°C ~ +55°C Dimension 76mm×24.5mm×10mm Weight About 25g microSD capability Support up to 32GB microSD card Notes: microSD is a trademark of SD Card Association. Getting to know your device The following figure shows the appearance of the MF631. It is only for your reference. The actual product may be different. MF631 Quick Guide 2 Confidential and Proprietary Information of ZTE CORPORATION 1. Indicator 2. Front Cover 3. USB Connector 4. microSD card slot 5. SIM/USIM card slot Hardware Installation 1. Put finger on the bottom finger grip, and then lift the cover of the modem to release and remove. Notes: Do not open the cover rudely so as to avoid the damage of the cover. 2. Insert the SIM/USIM card into the SIM/USIM card slot. Insert the SIM/USIM card with the metal contact area facing downwards into the slot, shown as the following picture. MF631 Quick Guide Confidential and Proprietary Information of ZTE CORPORATION 3 3. Insert the microSD card into the microSD card slot. Insert your microSD card into the microSD card slot, shown as the following picture. Notes: This modem only supports microSD card. 4. Put the cover of the modem flatly upon the body of modem. Direct the cover towards the locking catches on the sides of the modem and push the cover of the modem to lock the cover into its place. 5. Connect the Modem to your laptop or desktop PC.  Rotate the USB connector and plug the USB connector into your computer’s USB port. Make sure that it is tightly inserted. MF631 Quick Guide 4 Confidential and Proprietary Information of ZTE CORPORATION  The OS automatically detects and recognizes new hardware and starts the installation wizard. Software Installation Guide On different operating systems, the installation procedures may be difference. Follow the system prompts during operation. For Windows OS Your system will start the software setup process automatically when you connect the modem to your computer correctly. Follow the system prompts to complete the software installation. Notes: If the system does not launch installation automatically, you can run the installation program in path of My Computer > ZTEMODEM. For Mac OS The system will automatically display a ZTEMODEM CD-ROM icon on the desktop, when you connect the modem to your computer correctly. Double click the installation software package in the ZTEMODEM, and follow the system prompts to complete the software installation. Safe removal from your system Please close the application software, and then you can pull out the USB Modem safely. How to use your modem Various icons are presented to enable quick operation of the following functions: Connect Connect to the Internet. SMS Click New button, enter recipient’s number and content, and then click Send to send new message. MF631 Quick Guide Confidential and Proprietary Information of ZTE CORPORATION 5 Phonebook Click New to fill in a new contact person and contact details. Settings Set the configuration for the USB modem. Data records Show the connection information. Warning and Notice To the owner • Some electronic devices are susceptible to electromagnetic interference sent by modem if inadequately shielded, such as the electronic system of vehicles. Please consult the manufacturer of the device before using the modem if necessary. • Operating of laptop and desktop PCs and the modem may interfere with medical devices like hearing aids and pacemakers. Please always keep them more than 20 centimeters away from such medical devices when they are turned on. Turn the modem off if necessary. Consult a physician or the manufacturer of the medical device before using the modem. • Be aware of the usage limitation when using a modem at places such as oil warehouses or chemical factories, where there are explosive gases or explosive products being processed. Turn off your modem if required. • The use of electronic transmitting devices is forbidden in aircrafts, at petrol stations and in hospitals. Please observe and obey all warning signs and switch off your modem in these conditions. • Do not touch the inner antenna area if not necessary. Otherwise it will affect your modem’s performance. • Store the modem out of the reach of little children. The modem may cause injury if used as a toy. • Do not touch the metallic parts of the m…

Text truncated - open the document above for the full version.

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Sep 19, 2010 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC(Telecommunication Metrology Center of MII) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

内部公开▲ 本文所有信息为中兴通讯股份有限公司内部信息，未经允许，不得外传 第1页，共1页 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Date: Sep 19, 2010 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: Q78-ZTEMF631 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely yours, Royce Wang ZTE CORPORATION Tel: 0755-26770345 Fax: 0755-26770347 E-Mail: [email protected]

MF631 external photo

MF631, label placement

MF631 internal photos

TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 85 of 131 ANNEX D: Probe Calibration Certificate (SN: 3677) TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 86 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 87 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 88 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 89 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 90 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 91 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 92 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 93 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 94 of 131 ANNEX E: Probe Calibration Certificate (SN:3661) TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 95 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 96 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 97 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 98 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 99 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 100 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 101 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 102 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 103 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 104 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 105 of 131 ANNEX F: D835V2 Dipole Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 106 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 107 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 108 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 109 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 110 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 111 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 112 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 113 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 114 of 131 ANNEX G: D1900V2 Dipole Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 115 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 116 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 117 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 118 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 119 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 120 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 121 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 122 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 123 of 131 ANNEX H: DAE4 Calibration Certificate TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 124 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 125 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 126 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 127 of 131 TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 128 of 131 ANNEX I: The EUT Appearances and Test Configuration Picture 5: Constituents of the EUT TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 129 of 131 Picture 6: Test position 1 Picture 7: Test position 2 5mm 5mm TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 130 of 131 Picture 8: Test Position 3 Picture 9: Test Position 4 5mm 5mm TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 131 of 131 Picture 10: Test Position 5

Report No.: RZA2010-1302-R1 TESTING No. L2264 OET 65 TEST REPORT Product Name HSDPA USB MODEM Model MF631 FCC ID Q78-ZTEMF631 Client ZTE CORPORATION TA Technology (Shanghai) Co., Ltd. GENERAL SUMMARY Product Name HSDPA USB MODEM Model MF631 FCC ID Q78-ZTEMF631 Report No. RZA2010-1302-R1 Client ZTE CORPORATION Manufacturer ZTE CORPORATION Reference Standard(s) IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. SUPPLEMENT C Edition 01-01 to OET BULLETIN 65 Edition 97-01 June 2001 including DA 02-1438, published June 2002: Evaluating Compliance with FCC Guidelines for Human Exposure to Radio frequency Electromagnetic Fields Additional Information for Evaluation Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radio frequency Emissions. 447498 D02 SAR Procedures for Dongle Xmtr v02: SAR Measurement Procedures for USB Dongle Transmitters. Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards. General Judgment: Pass (Stamp) Date of issue: September 30 th , 2010 Comment The test result only responds to the measured sample. Approved by Yang Weizhong Revised by Ling Minbao Performed by Xue Chaofeng TA Technology (Shanghai) Co., Ltd. Test Report Report No. RZA2010-1302-R1 Page 3 of 131 TABLE OF CONTENT 1. General Information ........................................................................................................................ 5 1.1. Notes of the Test Report.......................................................................................................... 5 1.2. Testing Laboratory ................................................................................................................... 5 1.3. Applicant Information ............................................................................................................... 6 1.4. Manufacturer Information ......................................................................................................... 6 1.5. Information of EUT................................................................................................................... 7 1.6. The Maximum SAR 1g Values and Conducted Power of Each Tested Band............................. 8 1.7. Test Date ................................................................................................................................. 8 2. Operational Conditions during Test ................................................................................................. 9 2.1. General Description of Test Procedures .................................................................................. 9 2.2. GSM Test Configuration ........................................................................................................... 9 2.3. WCDMA Test Configuration ................................................................................................... 10 2.4. HSDPA Test Configuration ..................................................................................................... 10 2.5. HSUPA Test Configuration ..................................................................................................... 12 2.6. Position of Module in Portable Devices.................................................................................. 14 2.7. Picture of Host Product .......................................................................................................... 15 3. SAR Measurements System Configuration ................................................................................... 17 3.1. SAR Measurement Set-up .....................................................................................................17 3.2. DASY5 E-field Probe System ................................................................................................ 18 3.2.1. EX3DV4 Probe Specification .......................................................................................... 18 3.2.2. E-field Probe Calibration ................................................................................................. 19 3.3. Other Test Equipment ............................................................................................................19 3.3.1. Device Holder for Transmitters ....................................................................................... 19 3.3.2. Phantom .........................................................................................................................20 3.4. Scanning Procedure ..............................................................................................................20 3.5. Data Storage and Evaluation ................................................................................................. 22 3.5.1. Data Storage...................................................................................................................22 3.5.2. Data Evaluation by SEMCAD ......................................................................................... 22 3.6. System Check........................................................................................................................ 25 3.7. Equivalent Tissues ................................................................................................................. 26 4. Laboratory Environment................................................................................................................ 26 5. Characteristics of the Test ............................................................................................................. 27 5.1. Applicable Limit Regulations .................................................................................................. 27 5.2. Applicable Measurement Standards.…

Text truncated - open the document above for the full version.

No.2010TAR372 Page1 of 71 TEST REPORT No. 2010TAR372 for ZTE CORPORATION HSDPA USB MODEM Model Name: MF631 FCC ID : Q78-ZTEMF631 with Hardware Version: dg1B Software Version: BD_MF631F3V1.0.0B01 Issued Date: 2010-09-07 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology Shou Xiang Technology Building, No.51 Xueyuan Road, Hai Dian District, Beijing, P. R. China,100191. Tel:+86(0)10-62304633, Fax:+86(0)10-62304793, Email:[email protected], web: www.emcite.com No.2010TAR372 Page2 of 71 CONTENTS 1. TEST LABORATORY ............................................................................................................... 3 1.1. TESTING LOCATION ............................................................................................................... 3 1.2. TESTING ENVIRONMENT ....................................................................................................... 3 1.3. PROJECT DATA ....................................................................................................................... 3 1.4. SIGNATURE ............................................................................................................................. 3 2. CLIENT INFORMATION ........................................................................................................... 4 2.1. APPLICANT INFORMATION ................................................................................................... 4 2.2. MANUFACTURER INFORMATION ......................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT ............................................................................................................................. 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ....................................... 5 3.3. GENERAL DESCRIPTION ....................................................................................................... 5 4. REFERENCE DOCUMENTS .................................................................................................... 6 4.1. REFERENCE DOCUMENTS FOR TESTING .......................................................................... 6 5. LABORATORY ENVIRONMENT .............................................................................................. 7 6. SUMMARY OF TEST RESULTS .............................................................................................. 8 7. TEST EQUIPMENTS UTILIZED ............................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 10 A.1 OUTPUT POWER .............................................................................................................. 10 A.2 EMISSION LIMT ................................................................................................................. 15 A.3 FREQUENCY STABILITY .................................................................................................. 29 A.4 OCCUPIED BANDWIDTH ................................................................................................ 31 A.5 EMISSION BANDWIDTH .................................................................................................. 43 A.6 BAND EDGE COMPLIANCE .............................................................................................. 55 A.7 CONDUCTED SPURIOUS EMISSION .............................................................................. 61 No.2010TAR372 Page3 of 71 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: Shou Xiang Technology Building, No.51 Xueyuan Road, Hai Dian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304793 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: 2010-08-10 Testing End Date: 2010-09-07 1.4. Signature Zi Xiaogang (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2010TAR372 Page4 of 71 2. Client Information 2.1. Applicant Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Contact Li Dezi Email: [email protected] Telephone: 0086 21 68895196 Fax: 0086 21 61460600 2.2. Manufacturer Information Company Name: ZTE CORPORATION Address /Post: ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, 518057, P.R.China Contact Li Dezi Email: [email protected] Telephone: 0086 21 68895196 Fax: 0086 21 61460600 No.2010TAR372 Page5 of 71 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description HSDPA USB MODEM Model Name MF631 FCC ID Q78-ZTEMF631 Frequency GSM 850MHz; PCS 1900MHz; WCDMA Band II,V Antenna Internal Power supply USB Output power 25.58 dBm maximum EIRP measured for GSM1900 Extreme vol. Limits 4.8VDC to 5.2VDC (nominal: 5.0VDC) Extreme temp. Tolerance -30°C to +50°C Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version N02 / dg1B BD_MF631F3V1.0.0B01 *EUT ID: is used to identify the t…
