Q78-ZTEWP850CDMA 1X Wireless Phone

ZTE WP850 CDMA Wireless Phone User Guide ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: (86) 755 26779999 URL: http://www.zte.com.cn E-mail: [email protected] LEGAL INFORMATION Copyright © 2012 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version No. : R1.2 Edition Time : 2012.05.25 Confidential and Proprietary Information of ZTE CORPORATION 1 C h a p t e r 1 Know Your Phone There are two ZTE WP850 models. One needs UIM card inserted in, the other does not need. Section or function marked with “★” is only available to the model with UIM card. Otherwise, it is available to both models. 2 LCD Screen 4 7 9 3 8 1 Earpiece 10 5 6 11 Confidential and Proprietary Information of ZTE CORPORATION 2 C h a p t e r 2 Key Instruction Key Description 1, 3, 8: Scrolling keys (Up/Down/Left/Right key) „ Press these keys to scroll cursor to the left, right, up or down when inputting characters or selecting items. 2: Left select key „ Enter main menu. „ Select or confirm options in menu. „ Enter the left-bottom menu. 4: CALL/REDIAL key „ Make a call or answer an incoming call. „ In standby mode, press this key to enter recent calls list. 5: Number keys „ Input numbers and characters. 6, 11: * key, # key „ Perform different functions under different conditions. 7: Right select key „ Enter righ t-bottom submenu on the screen. „ Erase character(s) while editing text. „ Return to the previous page during menu navigation. 9: End key „ End an active call or reject a call. „ Hold this key to Power on/Power off the phone. „ Exit from any interface to standby mode. 10: OK key „ Confirm the commands and options selected. „ Confirm the characters inputting. Notes: In this guide, “press” a key means to press the key once, “hold” a key means to press the key for 2 or 3 seconds. Confidential and Proprietary Information of ZTE CORPORATION 3 C h a p t e r 3 Interface Icons Icon Description Icon Description Signal strength New message Silent Roaming Power indicator Alarm clock Confidential and Proprietary Information of ZTE CORPORATION 4 C h a p t e r 4 Installation 1. Charge the battery z Connect the desk charger and external AC socket via power adapter. z Put the phone on the desk charger. The charge spring of the desk charger should be inserted in the apertures at the bottom of the phone. z Meanwhile, power indicator in the upper-right corner of the display blinks, indicating the charging is in progress. While charging in power-off mode, the display only shows the charge indicator. If the battery is completely flat, it may take a while before the charge indicator appears on the display. z When the power indicator on the screen stops blinking, the charging is completed. The normal charging time is 4 hours. In the process of charging, it is a normal phenomenon that the battery, phone and charger get hot. z After the completion of charging, disconnect the charger from the phone and AC socket. Note： „ When charging the battery, place the phone in an environment with good ventilation and temperature between 0°C～＋45°C. Make sure to use the charger offered by the phone manufacturer. Using unauthorized charger may cause danger and violate the guarantee articles. „ When the phone is automatically switched off or indicates power shortage, charge the battery in time. „ The standby time and the talk time of the phone are based on ideal working environment. In practice, the working time of battery varies with network condition, working environment and application methods. 2. ★UIM Card z Power off the phone and remove other external power. z Take off the back cover and remove the battery of the phone. z Insert UIM card into UIM card slot in the phone or pull out UIM card out of slot. z Direct the back cover towards the locking catches on the both sides of the phone and push the back cover of the phone upward to lock the cover into its place. Confidential and Proprietary Information of ZTE CORPORATION 5 C h a p t e r 5 How to Power On/Off ‹ Hold the End key to power on the phone. ‹ When the phone is powered on, hold the End key to power off the phone. Confidential and Proprietary Information of ZTE CORPORATION 6 C h a p t e r 6 How to Make a Call 1. Enter the telephone number. Add the international prefix, country code and area code (without the leading 0) before the number when making an international call. 2. Press the CALL/REDIAL key to make the call. Note: If required, hold the 0 key for the international prefix “+”, or input international prefix e.g. “00” directly. Confidential and Proprietary Information of ZTE CORPORATION 7 C h a p t e r 7 Message Select Menu→Messages. • Select New Message to create new message: key in receiver’s phone number or press OK key to select from Contacts list, press Down key to input message text, Press OK key to send the message. • Select Inbox to view messages received. • Select Drafts to view draft you saved. • Select Outbox to view the stored messages. • Select Sent to view the sent messages. • Select Message Settings to set the message configuration. • Select Message Template to view or edit the default text. • Select Delete Message to erase certain messages. • Select Memory Status to view the memory information of message box. Confidential and Proprietary Information of ZTE CORPORATION 8 C h a p t e r 8 Phone Code Phone code could prevent your phone from illegal using. The default handset password is 0000. Change it to your own phone password as soon as possible. Notes: Remember the handset password, otherwise some service expense may happen. Confidential and Proprietary Information of ZTE …

Text truncated - open the document above for the full version.

Request of Confidentiality Federal Communications Commission Authorization and Evaluation Division Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying of following product: Product Name: CDMA 1X Wireless Phone Product Model: ZTE WP850 FCC ID: Q78-ZTEWP850 The following information should be held confidential: All Schematics/block diagrams All Parts list for the above schematic diagram Tune-Up Procedure Operational description and technical overview of product The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Royce Wang Title: Product Certification Director ZTE Corporation Zhongxing Bldg, Shenzhen Hi-tech Industrial Park Nanshan District, Shenzhen city, GuangDong Province, P.R.China 518057 Tel: 086-021-68895196 Fax: 086-021-50801070

Q78-ZTEWP850 External Photo Battery Ni3607T30P3S473211 Charger STC-A22O50U5-A Charger STC-A22O50U5-A Headset HMZ1-OMTP-3.5

Q78-ZTEWP850 Internal Photo

D-PL-12111-01-01 CNAS L0447 Registration No.910917 CONFORMANCE TEST REPORT FOR HUMAN EXPOSURE TO ELECTROMAGNETIC FIELDS Report No.: SRTC2012-H024-E0051 Product Name: CDMA 1X Wireless Phone Product Model: ZTE WP850 Applicant: ZTE Corporation Manufacturer: ZTE Corporation Specification: FCC OET Bulletin 65 (Edition 97-01) Supplement C (Edition 01-01) FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 1 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC Executive Summary Test report no.: SRTC2012-H024-E0051 Product Model: ZTE WP850 Date of test: 2012.08.18 Date of report: 2012.08.19 Laboratory: The State Radio_monitoring_center Testing Center (SRTC) Test has been Carried out in accordance with: 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices FCC OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01) Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields RSS-102 Evaluation Procedure for Mobile and Portable Radio Transmitters with Respect to Health Canada’s Safety Code 6 for Exposure of Humans to Radio Frequency Fields IEEE 1528 - 2003 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Technique Documentation:The documentation of the testing performed on the tested devices is archived for 5 years at SRTC Result summary: Mode CH/f(MHz) Powerposition Limit (mW/g)/1g Measured (mW/g) Result 800MHz SO55 RC3 full rate 777/848.31 23.62Left hand Cheek1.6 1.370 PASS This Test Report Is Issued by: Mr. Song Qizhu Director of the test lab Checked by: Mr. Wang Junfeng Deputy director of the test lab Tested by: Mr. Mei Haowen Test engineer Issued date: 2012.09.04 No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 2 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC Tables of Contents 1. General information ...................................................................................................................... 4 1.1 Notes of the test report ........................................................................................................ 4 1.2 Information about the testing laboratory ........................................................................... 4 1.3 Applicant’s details ................................................................................................................. 4 1.4 Manufacturer’s details .......................................................................................................... 4 1.5 Application details ................................................................................................................. 5 1.6 Maximum Results ................................................................................................................. 5 2. DESCRIPTION OF THE DEVICE UNDER TEST ..................................................................... 6 2.1 Description of the Antenna .................................................................................................. 6 2.2 Picture of the EUT ................................................................................................................ 6 2.3 Test Positions for the Device under test ............................................................................ 6 2.4 Picture to demonstrate the required liquid depth ............................................................. 7 2.5 Reference Specification ....................................................................................................... 8 2.6 The IEEE Standard C95.1 and the FCC Exposure Criteria ........................................... 8 2.7 Distinction Between Exposed Population, Duration of Exposure and Frequencies ... 8 2.8 Distinction between Maximum Permissible Exposure and SAR Limits ........................ 9 2.9 SAR Limit ............................................................................................................................... 9 3. The FCC Measurement Procedure .............................................................................................. 10 3.1 General Requirements ....................................................................................................... 10 3.2 Phantom specifications (shell and liquid)........................................................................ 10 3.3 Specifications of the SAR measurement equipment ..................................................... 11 3.4 Scanning system specifications ....................................................................................... 11 3.5 Mobile phone holder specifications ................................................................................. 12 4. Measurement preparation ............................................................................................................ 12 4.1 General preparation ........................................................................................................... 12 4.2 Simplified performance checking ..................................................................................... 12 4.3 Preparation of the mobile phone under test ................................................................... 12 4.4 Position of the mobile phone in relation to the phantom .............................................. 13 4.5 Tests to be performed ........................................................................................................ 14 5. The Measurement system ...............................................................................…

Text truncated - open the document above for the full version.

No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 48 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC APPENDIX D: RELEVANT PAGES FROM DAE REPORT(S) No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 49 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 50 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 51 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 52 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 53 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 54 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 55 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC APPENDIX E: RELEVANT PAGES FROM DIPOLE VALIDATION KIT REPORT(S) No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 56 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 57 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 58 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 59 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 60 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 61 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC No.: SRTC2012-H024-E0051 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 62 of 62 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC

D-PL-12111-01-01 CNAS L0447 Registration No.910917 TEST REPORT Report No.: SRTC2012-H024-E0048 Product Name: CDMA 1X Wireless Phone Product Model: ZTE WP850 Applicant: ZTE Corporation Manufacturer: ZTE Corporation Specification: FCC Part 22H, Part 2 (October 1, 2009 edition) FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 No.: SRTC2012-H024-E0048 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 2 of 27 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC CONTENTS 1. General information .................................................................................. 3 1.1 Notes of the test report ................................................................................................... 3 1.2 Information about the testing laboratory ....................................................................... 3 1.3 Applicant’s details ............................................................................................................ 3 1.4 Manufacturer’s details ..................................................................................................... 3 1.5 Application details ............................................................................................................ 4 1.6 Reference specification ................................................................................................... 4 1.7 Information of EUT .......................................................................................................... 4 1.7.1 General information .............................................................................................. 4 1.7.2 EUT details ............................................................................................................ 5 1.7.3 Auxiliary equipment details .................................................................................. 5 2. Test information ........................................................................................ 6 2.1 Summary of the test results............................................................................................ 6 2.2 Test result .......................................................................................................................... 7 2.2.1 RF Power Output-FCC Part2.1046 .................................................................... 7 2.2.2 Effective Radiated Power-FCC Part22.913(a) ................................................. 8 2.2.3 Occupied Bandwidth-FCC Part2.1049 ............................................................ 10 2.2.4 Emission Bandwidth-FCC Part22.917(b) ........................................................ 13 2.2.5 Spurious Emissions at antenna terminal-FCC Part2.1051/22.917(a) ......... 14 2.2.6 Band Edges Compliance-FCC Part2.1051/22.917(a) ................................... 20 2.2.7 Frequency Stability-FCC Part2.1055/22.355 .................................................. 22 2.2.8 Radiated Spurious Emissions-FCC Part2.1053/22.917(a) ........................... 23 2.3. List of test equipments ................................................................................................. 26 Appendix .................................................................................................... 27 No.: SRTC2012-H024-E0048 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 3 of 27 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC 1. General information 1.1 Notes of the test report The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written permission of The State Radio_monitoring_center Testing Center (SRTC). The test results relate only to individual items of the samples which have been tested. 1.2 Information about the testing laboratory Company: The State Radio_monitoring_center Testing Center (SRTC) Address: No.80 Beilishi Road, Xicheng District, Beijing China City: Beijing Country or Region: China Contacted person: Wang Junfeng Tel: +86 10 68009181 +86 10 68009202 Fax: +86 10 68009195 +86 10 68009205 Email: [email protected] / [email protected] 1.3 Applicant’s details Company: ZTE Corporation Address: ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park, Nanshan District, 518057 City: Shenzhen Country or Region: P.R.China Grantee Code: Q78 Contacted person: Min Zhang Tel: +86-021-68897541 Fax: +86-021-50801070 Email: [email protected] 1.4 Manufacturer’s details Company: ZTE Corporation Address: Zhongxing Bldg, Hi-Tech Park, NanShan District, 518057 City: Shenzhen Country or Region: P.R.China Contacted person: Li Dezi Tel: +86-021-68895196 Fax: +86-021-50801070 Email: [email protected] No.: SRTC2012-H024-E0048 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 4 of 27 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC 1.5 Application details Date of reception of test sample: 1 st Aug 2012 Date of test: 2 nd Aug 2012 to 21 st Aug 2012 1.6 Reference specification FCC Part 22H, Part 2 (October 1, 2009 edition) 1.7 Information of EUT 1.7.1 General information Name of EUT CDMA 1X Wireless Phone FCC ID Q78-ZTEWP850 Frequency range Tx:824~849MHz Rx:869~894MHz Rated output power 23.0dBm Modulation type OQPSK Emission Designator 1M25F9W Duplex mode FDD Duplex spacing 45MHz Supported test mode RC1/SO2, RC1/SO55, RC3/SO2, RC3/SO55 Antenna type Fixed Internal Power Supply Battery or charger Rated Power Supply Voltage 3.7V Extreme Temperature Lowest: -30°C Highest: +50°C Extreme Voltage Minimum: 3.4V Maximum: 4.2V HW Version fe1A SW Version TTSL_WP850V1.0.0B01 No.: SRTC2012-H024-E0048 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 5 of 27 Tel: 86-1…

Text truncated - open the document above for the full version.

D-PL-12111-01-01 CNAS L0447 Registration No.910917 Appendix1 TEST SETUP Report No.: SRTC2012-H024-E0048 Product Name: CDMA 1X Wireless Phone Product Model: ZTE WP850 Applicant: ZTE Corporation Manufacturer: ZTE Corporation Specification: FCC Part 22H, Part 2 (October 1, 2009 edition) FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 No.: SRTC2012-H024-E0048 FCC ID: Q78-ZTEWP850 The State Radio_monitoring_center Testing Center (SRTC) Page number: 2 of 2 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC Appendix1 Test Setup Radiated Spurious Emissions Test setup
