RF_160, Issue 02 Declaration of Authorization We Name: ZTE Corporation Address: ZTE Plaza, Hi-tech Park, Nanshan District, City: Shenzhen, Guangdong Country: China Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dongguan Country: China is authorized to apply for Certification of the following product(s), including the signing of 731 form: Product description: Cloud Terminal（microcomputer） Type designation: ZXCLOUD iBOX CT620; ZXCLOUD iBOX CT320 Trademark: ZTE 中兴; ZTE on our behalf. Date: 2013-11-11 City: Shenzhen Name: Royce Wang Function: Product Certification Manager Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 10-AUG-09 RF_501, Issue 5 Page 1 of 1 Company Name: ZTE Corporation Address: ZTE Plaza, Hi-tech Park, Nanshan District, City: Shenzhen, Guangdong Country: China To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: Q78- ZXCLDCT620 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2013-11-11 Name and signature of applicant: Royce Wang Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

CERTIFICATE OF COMPLIANCE Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the Neutron EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Date of Issue Nov. 28, 2013 Equipment Cloud Terminal（microcomputer） Model Name ZXCLOUD iBOX CT620; ZXCLOUD iBOX CT320 Brand Name ZTE中兴; ZTE Applicant ZTE Corporation Address ZTE Plaza, Hi-Tech Park, Nanshan District, Shenzhen, Guangdong, P.R.China Standard(s) FCC Part 15, Subpart B: 2012 ANSI C63.4 -2009 Report(s) NEI-FCCE-1-1311C049 The test data, data evaluation, and equipment configuration contained in our test report(s) above was(were) obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory Neutron Engineering Inc. B1, No.37, Lane 365, Yang Guang St., NeiHu District 114., Taipei, Taiwan TEL：+886-2-2657-3299 FAX：+886-2-2657-3331

Project No.: 1311C049 Page 2 of 38 Neutron Engineering Inc. ZXCLOUD iBOX CT620 Project No.: 1311C049 Page 3 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 4 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 5 of 38 Neutron Engineering Inc. ZXCLOUD iBOX CT320 Project No.: 1311C049 Page 6 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 7 of 38 Neutron Engineering Inc.

Project No.: 1311C049 Page 8 of 38 Neutron Engineering Inc. ZXCLOUD iBOX CT620 Project No.: 1311C049 Page 9 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 10 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 11 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 12 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 13 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 14 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 15 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 16 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 17 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 18 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 19 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 20 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 21 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 22 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 23 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 24 of 38 Neutron Engineering Inc. ZXCLOUD iBOX CT320 Project No.: 1311C049 Page 25 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 26 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 27 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 28 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 29 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 30 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 31 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 32 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 33 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 34 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 35 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 36 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 37 of 38 Neutron Engineering Inc. Project No.: 1311C049 Page 38 of 38 Neutron Engineering Inc.

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: Q78-ZXCLDCT620 Project No. : 1311C049 Equipment : Cloud Terminal(microcomputer) Model : ZXCLOUD iBOX CT620; ZXCLOUD iBOX CT320 Applicant : ZTE Corporation Address : ZTE Plaza, Hi-Tech Park, Nanshan District, Shenzhen, Guangdong, P.R. China According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna Ant. Brand Model Name Antenna TypeConnector Gain (dBi) Note 1 Hispeed Q-B1-0294 Dipole N/A 4.54 TX/RX Neutron Engineering Inc. TEST RESULTS EUT： Cloud Terminal (microcomputer) Model Name ： ZXCLOUD iBOX CT620 Temperature： 24 °C Relative Humidity： 60 % Pressure： 1016 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX B MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 4.54 2.8445 19.04 80.1678 0.045388971 Complies 4.54 2.8445 20.04 100.9253 0.057141331 Complies 4.54 2.8445 19.23 83.7529 0.047418781 Complies EUT： Cloud Terminal (microcomputer) Model Name ： ZXCLOUD iBOX CT620 Temperature： 24 °C Relative Humidity： 60 % Pressure： 1016 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX G MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 4.54 2.8445 22.5 177.8279 0.100681661 Complies 4.54 2.8445 22.25 167.8804 0.095049621 Complies 4.54 2.8445 22.36 172.1869 0.097487821 Complies Neutron Engineering Inc. EUT： Cloud Terminal (microcomputer) Model Name ： ZXCLOUD iBOX CT620 Temperature： 24 °C Relative Humidity： 60 % Pressure： 1016 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-20M MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 4.54 2.8445 23.18 207.9697 0.117747141 Complies 4.54 2.8445 23.24 210.8628 0.119385171 Complies 4.54 2.8445 23.79 239.3316 0.135503461 Complies EUT： Cloud Terminal (microcomputer) Model Name ： ZXCLOUD iBOX CT620 Temperature： 24 °C Relative Humidity： 60 % Pressure： 1016 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-40M MODE /CH03, CH06, CH09 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 4.54 2.8445 23.59 228.5599 0.129404801 Complies 4.54 2.8445 23.62 230.1442 0.130301791 Complies 4.54 2.8445 23.47 222.3310 0.125878161 Complies Note: the calculation distance is 20cm.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1311C049 Page 1 of 124 FCC Radio Test Report FCC ID: Q78-ZXCLDCT620 This report concerns (check one): Original Grant Class II Change Issued Date : Nov. 27, 2013 Project No. : 1311C049 Equipment : Cloud Terminal(microcomputer) Model Name : ZXCLOUD iBOX CT620; ZXCLOUD iBOX CT320 Applicant : ZTE Corporation Address : ZTE Plaza, Hi-Tech Park, Nanshan District, Shenzhen, Guangdong, P.R.China Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Nov. 07, 2013 Date of Test: Nov. 07, 2013~ Nov. 26, 2013 Testing Engineer : ( David Mao) Technical Manager : (Leo Hung) Authorized Signatory: (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL: 0769-8318-3000 FAX: 0769-8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1311C049 Page 2 of 124 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1311C049 Page 3 of 124 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 15 4.1.3 TEST PROCEDURE 16 4.1.4 DEVIATION FROM TEST STANDARD 16 4.1.5 TEST SETUP 16 4.1.6 EUT OPERATING CONDITIONS 16 4.1.7 TEST RESULTS 17 4.2 RADIATED EMISSION MEASUREMENT 20 4.2.1 RADIATED EMISSION LIMITS 20 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 21 4.2.3 TEST PROCEDURE 21 4.2.4 DEVIATION FROM TEST STANDARD 21 4.2.5 TEST SETUP 22 4.2.6 EUT OPERATING CONDITIONS 23 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 24 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 31 5 . BANDWIDTH TEST 79 5.1 APPLIED PROCEDURES / LIMIT 79 5.1.1 MEASUREMENT INSTRUMENTS LIST 79 5.1.2 TEST PROCEDURE 79 5.1.3 DEVIATION FROM STANDARD 79 5.1.4 TEST SETUP 79 5.1.5 EUT OPERATION CONDITIONS 79 5.1.6 TEST RESULTS 80 6 . MAXIMUM OUTPUT POWER TEST 88 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1311C049 Page 4 of 124 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 88 6.1.1 MEASUREMENT INSTRUMENTS LIST 88 6.1.2 TEST PROCEDURE 88 6.1.3 DEVIATION FROM STANDARD 88 6.1.4 TEST SETUP 88 6.1.5 EUT OPERATION CONDITIONS 88 6.1.6 TEST RESULTS 89 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 91 7.1 APPLIED PROCEDURES / LIMIT 91 7.1.1 MEASUREMENT INSTRUMENTS LIST 91 7.1.2 TEST PROCEDURE 91 7.1.3 DEVIATION FROM STANDARD 91 7.1.4 TEST SETUP 91 7.1.5 EUT OPERATION CONDITIONS 91 7.1.6 TEST RESULTS 92 8 . POWER SPECTRAL DENSITY TEST 112 8.1 APPLIED PROCEDURES / LIMIT 112 8.1.1 MEASUREMENT INSTRUMENTS LIST 112 8.1.2 TEST PROCEDURE 112 8.1.3 DEVIATION FROM STANDARD 112 8.1.4 TEST SETUP 112 8.1.5 EUT OPERATION CONDITIONS 112 8.1.6 TEST RESULTS 113 9 . EUT TEST PHOTO 121 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1311C049 Page 5 of 124 REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FCCP-1-1311C049 Original Issue. Nov. 27, 2013 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1311C049 Page 6 of 124 1. CERTIFICATION Equipment : Cloud Terminal(microcomputer) Brand Name : ZTE中兴;ZTE Model Name : ZXCLOUD iBOX CT620; ZXCLOUD iBOX CT320 Applicant : ZTE Corporation Manufacture : ZTE Corporation Address : ZTE Plaza, Hi-Tech Park, Nanshan District, Shenzhen, Guangdong, P.R.China Factory : ZTE Corporation Address ZTE Plaza, Hi-Tech Park, Nanshan District, Shenzhen, Guangdong, P.R.China Date of Test : Nov. 07, 2013~ Nov. 26, 2013 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part15(2012), Subpart C(15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1311C049) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1311C049 Page 7 of 124 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): Applied Standard(s): FCC Part15 (15.247) , Subpart C Standard(s) Section Test Item Judgment Remark 15.207 Conducted Emission…
