RF_160, Issue 02 Declaration of Authorization We Name: ZTE Corporation Address: ZTE Plaza, Hi-tech Park, Nanshan District, City: Shenzhen, Guangdong Country: China Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: Neutron Engineering, Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dongguan Country: China is authorized to apply for Certification of the following product(s): Product description: VDSL CPE Type designation: ZXHN H368C Trademark: ZTE on our behalf. Date: 2012-06-20 City: Shenzhen, Guangdong Name: Royce Wang Function: Product Certification Manager Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 10-AUG-09 RF_501, Issue 5 Page 1 of 1 Company Name: ZTE Corporation Address: ZTE Plaza, Hi-tech Park, Nanshan District, City: Shenzhen, Guangdong Country: China To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: Q78-ZXHNH368CV1 Reference number: ZXHN H368C Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2012-06-20 Name and signature of applicant: Royce Wang Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

CERTIFICATE OF COMPLIANCE Ref No.: NEI-FCCE-1-1205C276 Date of Issue: Jun. 20, 2012 Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the Neutron EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment VDSL CPE Model Name ZXHN H368C Brand Name ZTE Applicant ZTE Corporation Address ZTE Plaza, Hi-tech Park, Nanshan District, Shenzhen, Guangdong, China Measurement ANSI C63.4 (2009) Method The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCE-1-1205C276) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory Neutron Engineering Inc. B1, No.37, Lane 365, Yang Guang St., NeiHu District 114., Taipei, Taiwan TEL：+886-2-2657-3299 FAX：+886-2-2657-3331

Neutron Engineering Inc. Project No.: 1205C276 Page 2 of 12 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 3 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 3 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 4 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 4 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 5 of 12 1205C276

Label Location

Neutron Engineering Inc. Project No.: 1205C276 Page 6 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 6 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 7 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 7 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 8 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 8 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 9 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 9 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 10 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 10 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 11 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 11 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 12 of 12 1205C276 1205C276 Neutron Engineering Inc. Project No.: 1205C276 Page 12 of 12 1205C276 1205C276

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: Q78-ZXHNH368CV1 Project No. : 1205C276 Equipment : VDSL CPE Model : ZXHN H368C Applicant : ZTE Corporation Address : ZTE Plaza, Hi-tech Park, Nanshan District, Shenzhen, Guangdong, China According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Ant. Brand name Model Name Antenna TypeConnector Gain (dBi) 0 ARISTOTLE L14 DIPOLE Dipole N/A 2.2 1 ARISTOTLE PCB038 PCB N/A 5.1 Note: The antenna of EUT could be rotated, but the Antenna Polarity vertical is max. The EUT incorporates a MIMO function. Physically, the EUT provides two completed transmitters and two receivers (2T2R). all transmit signals are completely uncorrelated, then, , that is Directional gain=6.9; So,the out power limit is 30-6.9+6=29.1; and power density limit is 8-6.9+6=7.1 Operating Mode TX Mode 1TX 2TX 802.11b V (ANT1) - 802.11g V (ANT1) - 802.11n(20MHz) - V (ANT0 & ANT1) 802.11n(40MHz) - V (ANT0 & ANT1) Neutron Engineering Inc. TEST RESULTS EUT： VDSL CPE Model Name ： ZXHN H368C Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX B MODE /CH01, CH06, CH11-ANT 1 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5.1 3.2359 25.64 366.4376 0.236020851 Complies 5.1 3.2359 25.68 369.8282 0.238204721 Complies 5.1 3.2359 25.67 368.9776 0.237656871 Complies EUT： VDSL CPE Model Name ： ZXHN H368C Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX G MODE /CH01, CH06, CH11-ANT 1 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5.1 3.2359 24.83 304.0885 0.195862081 Complies 5.1 3.2359 24.87 306.9022 0.197674371 Complies 5.1 3.2359 24.92 310.4560 0.199963331 Complies EUT： VDSL CPE Model Name ： ZXHN H368C Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-20M MODE /CH01, CH06, CH11 - ANT 0 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2.2 1.6596 23.45 221.3095 0.073105551 Complies 2.2 1.6596 23.12 205.1162 0.067756411 Complies 2.2 1.6596 23.08 203.2357 0.067135211 Complies Neutron Engineering Inc. EUT： VDSL CPE Model Name ： ZXHN H368C Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-20M MODE /CH01, CH06, CH11 - ANT 1 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5.1 3.2359 23.02 200.4472 0.129107171 Complies 5.1 3.2359 23.01 199.9862 0.128810231 Complies 5.1 3.2359 22.98 198.6095 0.127923511 Complies EUT： VDSL CPE Model Name ： ZXHN H368C Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-20M MODE /CH01, CH06, CH11 – ANT0+ ANT 1 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 6.9 4.8978 26.25 421.6965 0.411102741 Complies 6.9 4.8978 26.08 405.5085 0.395321441 Complies 6.9 4.8978 26.04 401.7908 0.391697111 Complies EUT： VDSL CPE Model Name ： ZXHN H368C Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-40M MODE /CH03, CH06, CH09 - ANT 0 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 2.2 1.6596 23.04 201.3724 0.066519711 Complies 2.2 1.6596 22.89 194.5360 0.064261431 Complies 2.2 1.6596 22.85 192.7525 0.063672281 Complies Neutron Engineering Inc. EUT： VDSL CPE Model Name ： ZXHN H368C Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-40M MODE /CH03, CH06, CH09 - ANT 1 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 5.1 3.2359 22.32 170.6082 0.109888031 Complies 5.1 3.2359 22.23 167.1091 0.107634221 Complies 5.1 3.2359 22.16 164.4372 0.105913271 Complies EUT： VDSL CPE Model Name ： ZXHN H368C Temperature： 25 °C Relative Humidity： 60 % Pressure： 1012 hPa Test Voltage ： AC 120V/60Hz Test Mode ： TX N-40M MODE /CH03, CH06, CH09 - ANT 0+ANT 1 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 6.9 4.8978 25.71 372.3917 0.363036561 Complies 6.9 4.8978 25.58 361.4099 0.352330601 Complies 6.9 4.8978 25.53 357.2728 0.348297511 Complies

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1205C276 Page 1 of 132 FCC Radio Test Report FCC ID: Q78-ZXHNH368CV1 This report concerns (check one) : Original Grant Class II Change Issued Date : Jun. 20, 2012 Project No. : 1205C276 Equipment : VDSL CPE Model Name : ZXHN H368C Applicant : ZTE Corporation Address : ZTE Plaza, Hi-tech Park, Nanshan District, Shenzhen, Guangdong, China Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Jun. 04, 2012 Date of Test: Jun. 04, 2012 ~ Jun. 15, 2012 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1205C276 Page 2 of 132 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutronshall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1205C276 Page 3 of 132 Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 19 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 23 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 25 5 . BANDWIDTH TEST 73 5.1 APPLIED PROCEDURES / LIMIT 73 5.1.1 MEASUREMENT INSTRUMENTS LIST 73 5.1.2 TEST PROCEDURE 73 5.1.3 DEVIATION FROM STANDARD 73 5.1.4 TEST SETUP 73 5.1.5 EUT OPERATION CONDITIONS 73 5.1.6 TEST RESULTS 74 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1205C276 Page 4 of 132 Table of Contents Page 6 . MAXIMUM OUTPUT POWER TEST 82 6.1 APPLIED PROCEDURES / LIMIT 82 6.1.1 MEASUREMENT INSTRUMENTS LIST 82 6.1.2 TEST PROCEDURE 82 6.1.3 DEVIATION FROM STANDARD 82 6.1.4 TEST SETUP 82 6.1.5 EUT OPERATION CONDITIONS 82 6.1.6 TEST RESULTS 83 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 87 7.1 APPLIED PROCEDURES / LIMIT 87 7.1.1 MEASUREMENT INSTRUMENTS LIST 87 7.1.2 TEST PROCEDURE 87 7.1.3 DEVIATION FROM STANDARD 87 7.1.4 TEST SETUP 87 7.1.5 EUT OPERATION CONDITIONS 87 7.1.6 TEST RESULTS 88 8 . POWER SPECTRAL DENSITY TEST 118 8.1 APPLIED PROCEDURES / LIMIT 118 8.1.1 MEASUREMENT INSTRUMENTS LIST 118 8.1.2 TEST PROCEDURE 118 8.1.3 DEVIATION FROM STANDARD 118 8.1.4 TEST SETUP 118 8.1.5 EUT OPERATION CONDITIONS 118 8.1.6 TEST RESULTS 119 9 . EUT TEST PHOTO 131 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1205C276 Page 5 of 132 1. CERTIFICATION E q u i p m e n t : VDSL CPE Brand Name : ZTE Model Name : ZXHN H368C A p p l i c a n t : ZTE Corporation Date of Test : Jun. 04, 2012 ~ Jun. 15, 2012 T e s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1205C276) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1205C276 Page 6 of 132 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious EmissionPASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(b)(3) Peak Output Power PASS 15.209/15.205 Radiated Spurious Emission PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this test report (2) The test follows FCC KDB Publication No,558074(Measurement Guidelines of DTS) Neutron Engineering Inc. Report No.: NEI-FCCP-1-1205C276 Page 7 of 132 2.1 TEST FACILITY The test facilities used…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1205C276 Page 131 of 132 9. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1205C276 Page 131 of 132 9. EUT TEST PHOTO Conducted Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1205C276 Page 132 of 132 Radiated Measurement Photos Neutron Engineering Inc. Report No.: NEI-FCCP-1-1205C276 Page 132 of 132 Radiated Measurement Photos
