Q78MF193HSUPA USB Stick

MF193 USB Modem Quick Guide ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: +86-755-26779999 URL: http://www.zte.com.cn E-mail: [email protected] LEGAL INFORMATION Copyright © 2011 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version No. : R1.0 Edition Time : Mar.22,2011 Manual No. : Confidential and Proprietary Information of ZTE CORPORATION 1 C h a p t e r 1 Quick Guide Introduction The ZTE USB modem is a multi-mode USB modem, working in HSUPA/HSDPA/WCDMA/EDGE/GPRS/GSM networks. With USB interface connecting to a laptop or a desktop PC, it integrates the functionality of a modem and a mobile phone (SMS), and combines mobile communication with Internet perfectly. It supports data and SMS services through the mobile phone network, enabling you to communicate anytime and anywhere. Specification The following table shows the specification of your device. Interface Type USB 2.0 HIGH SPEED Systems supported Supports most types of laptop and desktop PC. Operating systems supported Windows XP(SP2 and later), Vista, Windows 7 MAC 10.4, 10.5, 10.6 Functions SMS service, Data service, Applications management, support microSD card, etc. Network Standards HSUPA/HSDPA/WCDMA/EDGE/GPRS/GSM Transmission speed (Max) HSUPA: 5.76 Mbps UL HSDPA: 7.2 Mbps DL Temperature Storage: -40 °C ~ +80 °C Operation:-10 °C ~ +60 °C Dimension 76.5 mm × 27.2 mm × 10.5 mm (with cap) Weight About 21g microSD capability Support up to 32 GB microSD card Notes: microSD is a trademark of SD Card Association. Getting to Know Your Device The following figure shows the appearance of the MF193. It is only for your reference. The actual product may be different. Quick Guide 2 Confidential and Proprietary Information of ZTE CORPORATION 1. Front Cover 2. Modem Cap 3. Indicator 4. microSD card slot 5. SIM/USIM card slot 6. USB Connector Installing Hardware 1. Press and push the back-cover of the phone down to release and remove it. Notes: Do not open the front cover rudely so as to avoid the damage of the front cover. 2. Insert the SIM/USIM card into the SIM/USIM card slot. Quick Guide Confidential and Proprietary Information of ZTE CORPORATION 3 Notes: Insert the SIM/USIM card into the slot with the metal contact area facing downwards, and then push SIM/USIM card as far as possible, as shown in the following picture. 3. Insert the microSD card into the microSD card slot, as shown in the following picture. Notes: This modem only supports microSD card. 4. Put the front cover of the modem upon the body of modem. Direct the front cover towards the locking catches on the sides of the modem and push the front cover to lock it into place. Quick Guide 4 Confidential and Proprietary Information of ZTE CORPORATION 5. Connect the Modem to your laptop or desktop PC. i. Plug the USB connector into your computer’s USB port and make sure that it is tightly inserted. ii. The OS automatically detects and recognizes new hardware and starts the installation wizard. Software Installation Guide On different operating systems, the installation procedures may be difference. Follow the system prompts during operation. For Windows OS Your system will start the software setup process automatically when you connect the modem to your computer correctly. Follow the system prompts to complete the software installation. Notes: If the system does not launch installation automatically, you can run the installation program in path of My Computer > ZTEMODEM. For Mac OS The system will automatically display a ZTEMODEM CD-ROM icon on the desktop, when you connect the modem to your computer correctly. Double click the installation software package in the ZTEMODEM, and follow the system prompts to complete the software installation. Safe Removal from Your System Please close the application software, and then you can pull out the USB Modem safely. How to Use Your Modem Various icons are presented to enable quick operation of the following functions: Connect Connect to the Internet. Quick Guide Confidential and Proprietary Information of ZTE CORPORATION 5 SMS Click New button, enter recipient’s number and content, and then click Send to send new message. Phonebook Click New to fill in a new contact person and contact details. Settings Set the configuration for the USB modem. Data records Show the connection information. Warning and Notice To the Owner •Some electronic devices are susceptible to electromagnetic interference sent by modem if inadequately shielded, such as the electronic system of vehicles. Please consult the manufacturer of the device before using the modem if necessary. •Operating the modem may interfere with medical devices like hearing aids and pacemakers. Please always keep them more than 20 centimeters away from such medical devices when they are turned on. Turn the modem off if necessary. Consult a physician or the manufacturer of the medical device before using the modem. •Be aware of the usage limitation when using a modem at places such as oil warehouses or chemical factories, where there are explosive gases or explosive products being processed. Turn off your modem if required. •The use of electronic transmitting devices is forbidden in aircrafts, at petrol stations and in hospitals. Please observe and obey all warning signs and switch off your modem in these conditions. •Do not touch the inner antenna area if not necessary. Otherwise it will affect your modem’s performance. •Store the modem out of the reach of little children. The modem may cause injury if used as a toy. •Do not touch the metallic parts of the modem so as to avoid a burn, when…

Text truncated - open the document above for the full version.

ZTE Corporation Authorization Letter BABT Forsyth House Churchfield Road Walton-on-Thames Surrey KT12 2TD Dear Sir or Madam: We, the undersigned, hereby authorize Ms. Chen Jie from TUV Product Service Limited, Beijing Branch. 9 th Landmark Tower 2, 8 North Dongsanhuan Road, 100004 Beijing, act on our behalf, as our agent, in all matters relating to applications for Product Name: HSUPA USB Stick Product Model: MF193authorization, including the signing of all documents relating to these matters. This authorization shall expire 3 months from original date. If you have any question regarding the authorization, please don’t hesitate to contact with me. Sincerely Signature: Name:Royce Wang Title: Product Certification Director Date: 2011.08.08

ZTE Corporation Confidentiality Letter BABT Forsyth House Churchfield Road Walton-on-Thames Surrey KT12 2TD Dear Sir or Madam: The Applicant hereby requests confidential treatment of information accompanying of following product: Product Name: HSUPA USB Stick Product Model: MF193 The following information should be held confidential: All Schematics/block diagrams All Bill of materials Operational description and Technical description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Signature: Name:Royce Wang Title: Product Certification Director Date: 2011.08.08

Annex A External Photos Front Back Side A Side B Side C Side D Top USB connector side

Annex B Internal Photos EUT photo without SIM card cover Enclosures Antenna Position The antenna located 18 mm from the top end. PCB frond side with shield PCB front side without shield PCB back side with shield PCB back side without shield

China Telecommunication Technology Labs. ® TEST REPORT REPORT NUMBER: I11GC5267-FCC-PART15B ON Type of Equipment: HSUPA USB Stick Type of Designation: MF193 Manufacturer: ZTE CORPORATION ACCORDING TO Part 15B: Radio Frequency Devices, Oct 1, 2009 China Telecommunication Technology Labs. Month date, year May, 25, 2011 Signature Ma Xin Director FCC Parts 15B Equipment: MF193 REPORT NO.: I11GC5267-FCC-PART15B Address：11 YUE TAN NAN JIE, BEIJING, P.R.C,100045 Tel:+86 10 68094053 FAX:+86 10 68011404 Web:http://www.chinattl.com Page 2 of 18 China Telecommunication Technology Labs. ® FCC ID: Q78-MF193 Report Date: 2011-05-25 Test Firm Name: China Telecommunication Technology Labs Registration Number: 840587 Statement The measurements shown in this report were made in accordance with the procedures described on test pages. All reported tests were carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47 Parts 15B. The sample tested was found to comply with the requirements defined in the applied rules. FCC Parts 15B Equipment: MF193 REPORT NO.: I11GC5267-FCC-PART15B Address：11 YUE TAN NAN JIE, BEIJING, P.R.C,100045 Tel:+86 10 68094053 FAX:+86 10 68011404 Web:http://www.chinattl.com Page 3 of 18 China Telecommunication Technology Labs. ® CONTENTS 1 GENERAL INFORMATION ............................................................................................................. 4 1.1 NOTES ............................................................................................................................................. 4 1.2 TESTERS .......................................................................................................................................... 5 1.3 TESTING LABORATORY INFORMATION ............................................................................................. 6 1.4 DETAILS OF APPLICANT OR MANUFACTURER ................................................................................... 7 2 TEST ITEM ......................................................................................................................................... 8 2.1 GENERAL INFORMATION .................................................................................................................. 8 2.2 OUTLINE OF EUT ............................................................................................................................ 8 2.3 MODIFICATIONS INCORPORATED IN EUT ......................................................................................... 8 2.4 EQUIPMENT CONFIGURATION .......................................................................................................... 8 2.5 OTHER INFORMATION ...................................................................................................................... 8 3 SUMMARY OF TEST RESULTS ...................................................................................................... 9 4 TEST RESULTS ................................................................................................................................ 10 4.1 RADIATED EMISSION ..................................................................................................................... 10 4.2 CONDUCTED EMISSION .................................................................................................................. 13 ANNEX A EXTERNAL PHOTOS ...................................................................................................... 16 ANNEX B INTERNAL PHOTOS ....................................................................................................... 17 ANNEX C DEVIATIONS FROM PRESCRIBED TEST METHODS ............................................ 18 FCC Parts 15B Equipment: MF193 REPORT NO.: I11GC5267-FCC-PART15B Address：11 YUE TAN NAN JIE, BEIJING, P.R.C,100045 Tel:+86 10 68094053 FAX:+86 10 68011404 Web:http://www.chinattl.com Page 4 of 18 China Telecommunication Technology Labs. ® 1 General Information 1.1 Notes All reported tests were carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47 Parts 15B. The test results of this test report relate exclusively to the item(s) tested as specified in section 2. The following deviation from, additions to, or exclusions from the test specifications have been made. See Annex C. China Telecommunication Technology Labs.(CTTL) authorizes the applicant or manufacturer (see section 1.4) to reproduce this report provided, and the test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of CTTL Mr. Ma Xin. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. CTTL accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. FCC Parts 15B Equipment: MF193 REPORT NO.: I11GC5267-FCC-PART15B Address：11 YUE TAN NAN JIE, BEIJING, P.R.C,100045 Tel:+86 10 68094053 FAX:+86 10 68011404 Web:http://www.chinattl.com Page 5 of 18 China Telecommunication Technology Labs. ® 1.2 Testers Name: Pan Yang Position: Engineer Department: Department of EMC test Signature: Editor of this test report: Name: Yuan Yuan Position: Engineer Department: Department of EMC test Date: 2011-05-25 Signature: Technical responsibility for area of testing: Name: Zou Dongyi Position: Manager Department: Department of EMC test Date: 2011-05-25 Signature: FCC Parts 15B Equipment: MF193 REPORT NO.: I11GC5267-FCC-PART15B Address：11 YUE TAN NAN JIE, BEIJING, P.R.C,100045 Tel:+86 10 68094053 FAX:+86 10 68011404 Web:http://www.chinattl.com Page 6 of 18 China Telecommunication Technology Labs. ® 1.3 Testing Laboratory information 1.3.1 Location Name: China Telecommunication Technology Labs. Address: No. 11, Yue Tan Nan Jie, Xi Cheng District BEIJING P. R. CHINA, 100083 Tel: +86…
