QB8LT3GMicrowave Outdoor Unit

DragonWave Inc.

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Oct 14, 2014
Application Purpose: Original Equipment
Date of Application: Sep 21, 2014
Equipment Note: Microwave Outdoor Unit
Frequency Range: 3670.00000000 - 3680.00000000
Company: DragonWave Inc.
Country: Canada

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Harmony Lite, R1.1 Product Description Revision 1, Updated in September, 2014 Document Number: PM-000157-01-EN 2 NOTICE This document contains DragonWave proprietary information. Use, disclosure, copying or distribution of any part of the information contained herein, beyond that for which it was originally furnished, requires the written permission of DragonWave Inc. The information in this document is subject to change without notice and relates only to the product defined in the introduction of this document. DragonWave intends that information contained herein is, to the best of its knowledge, correct and accurate. However, any/all liabilities associated with the use or accuracy of the information contained herein must be defined in a separate agreement between DragonWave and the customer/user. Copyright © DragonWave Inc. 2014. All rights reserved. 3 Table of Contents Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 1.1What’s New in This Release? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 1.2Changes History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 1.3Scope of The Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 1.4Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 1.5FCC & IC RF Exposure Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 1.6Waste Electrical and Electronic Equipment (WEEE) . . . . . . . . . . . . . . . 10 1.7RoHS Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 1.8CE Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 2Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 2.1Available Bandwidth and Modulation . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 2.2Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 2.2.1Small Cell Backhaul in Non-line-of-sight (NLOS) Environment . . . . . . . 13 2.2.2Rural Backhaul . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 2.2.3Public Safety and Vertical Applications . . . . . . . . . . . . . . . . . . . . . . . . . 14 2.3Environmental Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 3Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 3.1Main Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 3.2Adaptive Coding and Modulation (ACM) . . . . . . . . . . . . . . . . . . . . . . . . 15 3.3Transmit Power Control (TPC). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 3.42x2 Multiple-input and Multiple-output (2x2 MIMO) . . . . . . . . . . . . . . . . 16 3.5Dynamic Frequency Selection (DFS). . . . . . . . . . . . . . . . . . . . . . . . . . . 17 3.6Dynamic Channel Selection (DCS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 3.7Retransmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 3.8Configurable Uplink/Downlink Ratio. . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 3.9Quality of Service (QoS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 3.9.1Priority Determination (Classification) . . . . . . . . . . . . . . . . . . . . . . . . . . 20 3.9.2Scheduling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 3.9.3CoS Queue and Egress Port Rate Limiting (Shaping). . . . . . . . . . . . . . 22 3.10Power over Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 3.10.1P+E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 3.10.2PoE+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 3.11Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 3.12Co-site Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 3.13OFDM Modulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 3.14Low-density Parity Check (LDPC) Encoding . . . . . . . . . . . . . . . . . . . . . 29 3.15LLDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 3.16Radio Port Performance Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 3.17Adaptive Noise Immunity (ANI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 4Mechanical Structure and Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 4.1Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 4.2Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 4 4.2.1P+E In (Eth 1) Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 4.2.2P+E Out (Eth 2) Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 4.2.3PoE+ In Interface (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 4.2.4Internal Interface (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 4.2.5RF Interface (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 4.2.6RSSI/EVM Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 5Product Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . …

Text truncated - open the document above for the full version.

Attestation Statements

Tuesday, September 16, 2014 DragonWave Inc. 600-411 Legget Drive, Ottawa, ON, Canada K2K 3C9 (t) 613.599.9991 (f) 613.599.4225 www.dragonwaveinc.com FCC ID: QB8LT3G Product Name: Microwave Outdoor Unit Product Model: Harmony Lite 3GHz CFR 47: Telecommunications Section 2.1033 c 9 This letter is pursuant to Section 2.1033(c), Tune-up procedure over the power range, or at specific operating power levels. Harmony Lite 3GHz system does not need any Tune-up procedure over the power range, or at specific operating power levels when operating in the band 3650-3700MHz. If you have any questions, please contact the undersigned. Date this 16 Day of September _ _ 2014____ ___ By: Jerry Potera _ Signature Printed Title: ___ Regulatory Approvals____ __ Telephone: _____613.599.9991 ______ _____ Applicant of: ___ DragonWave Inc. _____ ___

Cover Letter(s)

DragonWave Inc. 600-411 Legget Drive, Kanata ON K2K 3C9, CANADA Authorization Letter TUV SUD BABT TCB/FCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Dear Sir or Madam, We, (Name: DragonWave Inc.; Address: 600-411 Legget Drive, Kanata ON K2K 3C9, CANADA), hereby authorize Mr. Yuanjie He from TUV Product Service Limited, Beijing Branch, Unit 918, Landmark Tower 2, 8 North Dongsanhuan Road, 100004 Beijing to act as our agent in all matters relating to IC and FCC (I further certify that the applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. Section 862.) applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 09-10-2015. Sincerely, Name: Jerry Potera Title: Regulatory Approvals Sign: Date: 11 September 2014

Cover Letter(s)

DragonWave Inc. 600-411 Legget Drive, Ottawa, ON, Canada K2K 3C9 (t) 613.599.9991 (f) 613.599.4225 www.dragonwaveinc.com ____________________________________________________________________________________________________ Request of Confidentiality 16 September 2014 TÜV SÜD BABT Octagon House Concorde Way, Segensworth North Fareham, Hampshire, PO15 5RL United Kingdom Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules and RSP100 Paragraph 10, we, (DragonWave Inc.) hereby requests confidential treatment of information accompanying this application of the following product: Product Name: Microwave Outdoor Unit Model: Harmony Lite 3GHz FCC ID: QB8LT3G IC: 4679A-LT3G The following information should be held confidential: (1) Operational description (2) Tune-up procedure; (3) Circuit Schematics; (4) Block diagram; (5) Components list; The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Exhibits/Items which are not here are allowed to be published. Yours sincerely, Company Officer: Jerry Potera Telephone Number: 613.599.9991 Email: [email protected]

Cover Letter(s)

External Photos

Photo Documentation Manufacturer: DragonWave Inc. 1 of 12 Product: Microwave outdoor Unit Model: Harmony Lite 3GHz Photo 1. Top view Photo 2. Front view Photo Documentation Manufacturer: DragonWave Inc. 2 of 12 Product: Microwave outdoor Unit Model: Harmony Lite 3GHz Photo 3. Side view of left side Photo 4. Rear View Photo Documentation Manufacturer: DragonWave Inc. 3 of 12 Product: Microwave outdoor Unit Model: Harmony Lite 3GHz Photo 5. Side View of right side Photo 6. Bottom View Photo Documentation Manufacturer: DragonWave Inc. 4 of 12 Product: Microwave outdoor Unit Model: Harmony Lite 3GHz Photo 7. Conncetor View Photo 8. Glands View Photo Documentation Manufacturer: DragonWave Inc. 5 of 12 Product: Microwave outdoor Unit Model: Harmony Lite 3GHz Photo 9. Connector View Photo 10. Earthing terminal View Photo Documentation Manufacturer: DragonWave Inc. 6 of 12 Product: Microwave outdoor Unit Model: Harmony Lite 3GHz Photo11. EUT with Antenna MT–384022/SVH/A Front Photo 12 EUT with Antenna MT–384022/SVH/A Back Photo Documentation Manufacturer: DragonWave Inc. 7 of 12 Product: Microwave outdoor Unit Model: Harmony Lite 3GHz Photo 13 EUT with Antenna MT–385006/SVH/A Front Photo 14 EUT with Antenna MT–385006/SVH/A Back Photo Documentation Manufacturer: DragonWave Inc. 8 of 12 Product: Microwave outdoor Unit Model: Harmony Lite 3GHz Photo 15 Antenna MT–405042/NVH/D Front Photo 16 EUT with Antenna MT–405042/NVH/D Back Photo Documentation Manufacturer: DragonWave Inc. 9 of 12 Product: Microwave outdoor Unit Model: Harmony Lite 3GHz Photo 17 Internal view Photo 18 Internal view Photo Documentation Manufacturer: DragonWave Inc. 10 of 12 Product: Microwave outdoor Unit Model: Harmony Lite 3GHz Photo 19 View of RF daughter card Photo 20 View of RF daughter card Photo Documentation Manufacturer: DragonWave Inc. 11 of 12 Product: Microwave outdoor Unit Model: Harmony Lite 3GHz Photo 21 View of LcmBH Board Photo 22 View of LcmBH Board Photo Documentation Manufacturer: DragonWave Inc. 12 of 12 Product: Microwave outdoor Unit Model: Harmony Lite 3GHz Photo 24 View of PoE+ daughter card Photo 25 View of PoE+ daughter card

ID Label/Location Info

Harmony Lite 3.xGHz Product Label: FCC/IC Label

Internal Photos

RF Exposure Info

Document 57014125 Report 02 Issue 1September 2014 Report On RF Exposure Estimation of the DragonWave Inc. Microwave Outdoor Unit Harmony Lite 3GHz (3650 – 3700MHz) In accordance with FCC CFR 47 Part 90Z and Industry Canada RSS-102: Issue 4 COMMERCIAL-IN-CONFIDENCE FCC ID: QB8LT3G IC ID: 4679A-LT3G TÜV SÜD Certification and Testing (China) Co., Ltd. Beijing Branch Unit 918, Landmark Tower 2, No.8 North Dongsanhuan Road, Beijing 100004, P.R. China Tel: +86-10 6590 6186. W ebsite:www.tuv-sud.cn CO MME RCI AL-IN-CO NFI DE NCE Document 57014125 Report 02 Issue 1Page 1 of 3 COMMERCIAL-IN-CONFIDENCE REPORT ONRF Exposure Estimationof the DragonWave Inc. Microwave Outdoor Unit Harmony Lite 3GHz Document 57014125 Report 02 Issue 1 September 2014 PREPARED FORDragonWave Inc. 600-411 Legget Drive, Kanata ON, K2K 3C9, CANADA PREPAREDBY Y He Test Engineer APPROVED BY CZhang Test Engineer DATED12 September 2014 ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47: Part 1, 2, 90Z and Industry Canada RSS-102. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineer(s); Y He C Zhang COMMERCIAL-IN-CONFIDENCE Document 57014125 Report 02 Issue 1 Page 2 of 3 RF Exposure Measurement 1Introduction This document was prepared to analyze the expected level of Radiofrequency Radiation Exposure caused by the radio transmission equipment Microwave Outdoor Unit Harmony Lite 3GHz belonging to DragonWave Inc. 2Limits and Guidelines on Maximum Permissible Exposure (MPE) Based on Section FCC Part 1.1307(b) and Industry Canada RSS-102 requirements for environmental impact of human exposure to radio-frequency (RF) radiation, according to the RF Exposure Procedures and Equipment Authorization Policies, a device may be used in exposure condition with no restrictions when output power is 60/f (GHz) mW as specified in the following table: Limits for Maximum Permissible Exposure Exposure CategoryLimit General Population1.0mW/cm 2 or 10W /m 2 NOTE: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or cannot exercise control over their exposure. 3Calculation of Output Power threshold In accordance with FCC 47 CFR Part 2.1091 and Industry Canada RSS-102. Below method describes a theoretical approach to compare the output power of the Microwave Outdoor Unit Harmony Lite 3GHz based on a typical configuration device. 3.1 Typical Configuration Microwave Outdoor Unit Harmony Lite 3GHz supports frequency band of 3650 - 3700MHz. It supports BPSK, QPSK, 16QAM and 64QAM modulation with channel bandwidth 20MHz and 40MHz. Document 57014125 Report 02 Issue 1 Page 3 of 3 3.2 Antennas and Technical Description 20MHz OBW Max. output power at antenna connector(dBm)-total Modulation Type Bottom (3660MHz) Middle (3675MHz) Top (3690MHz) BPSK21.5121.3720.80 QPSK21.5221.6320.82 16QAM21.5321.4120.81 64QAM21.4921.3820.80 Transmitter frequency band3650MHz - 3700MHz Number of antenna ports2ports(2*2MIMO) Antenna MT–384022/SVH/AGain14.5 Antenna MT–385006/SVH/AGain19.5 Antenna MT–405042/NVH/DGain21.0 40MHz OBW Max. output power at antenna connector(dBm)-total Modulation Type Bottom (3670MHz) Middle (3675MHz) Top (3680MHz) BPSK24.2724.1724.13 QPSK24.2524.2124.11 16QAM24.2724.2024.09 64QAM24.2724.2024.09 Transmitter frequency band3650MHz - 3700MHz Number of antenna ports2 ports(2*2MIMO) Antenna MT–384022/SVH/AGain14.5 Antenna MT–385006/SVH/AGain19.5 Antenna MT–405042/NVH/DGain21.0 3.3 Calculation result The maximum measured antenna conducted power,P max =24.27dBm The antenna gain,G max =21dBi, So, the maximum EIRP power= P+G max =45.27dBm,or 33.651W The limit for Maximum Permissible Exposure (MPE) for transmitter at3.7GHz is 10W/m 2 The power density is related to EIRP with the equation: S = EIRP/4ʌD 2 , which equal to 10=33.651/4ʌD 2 , thusD=0.5175m The minimum safe separation distance D= 0.5175m.

Test Report

Document 57014125 Report 01 Issue 2September 2014 Report On FCC and Industry Canada Testing of the DragonWave Inc. Microwave Outdoor Unit Harmony Lite 3GHz (3650 – 3700MHz) In accordance with FCC CFR 47 Part 90Z and Industry Canada RSS-197: Issue 1 COMMERCIAL-IN-CONFIDENCE FCC ID: QB8LT3G IC ID: 4679A-LT3G TÜV SÜD Certification and Testing (China) Co., Ltd. Beijing Branch Unit 918, Landmark Tower 2, No.8 North Dongsanhuan Road, Beijing 100004, P.R. China Tel: +86-10 6590 6186. W ebsite:www.tuv-sud.cn CO MME RCI AL-IN-CO NFI DE NCE Document 57014125 Report 01 Issue 2Page 1 of 66 COMMERCIAL-IN-CONFIDENCE REPORT ONFCCand Industry CanadaTesting of the DragonWave Inc. Microwave Outdoor Unit Harmony Lite 3GHz Document 57014125 Report 01 Issue 2 September 2014 PREPARED FORDragonWave Inc. 600-411 Legget Drive, Kanata ON, K2K 3C9, CANADA PREPARED BY Y He Test Engineer APPROVED BY CZhang Test Manager DATED16 September 2014 This report has been up-issued to Issue 2 tosupplyIC MODELNUMBERin Clause 1.4. ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47: Part 90Z and Industry Canada RSS-197. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineer(s); Y He C Zhang COMMERCIAL-IN-CONFIDENCE Document 57014125 Report 01 Issue 2Page 2 of 66 COMMERCIAL-IN-CONFIDENCE CONTENTS SectionPage No 1REPORT SUMMARY .............................................................................................................. 3 1.1Report Details .......................................................................................................................... 4 1.2Brief Summary of Results ........................................................................................................ 5 1.3Configuration Description ......................................................................................................... 6 1.4Declaration of Build Status ....................................................................................................... 7 1.5Product Information ................................................................................................................. 8 1.6Test Conditions........................................................................................................................ 9 1.7Deviations From the Standard.................................................................................................. 9 1.8Modification Record ................................................................................................................. 9 1.9Alternative Test Site................................................................................................................. 9 2TEST DETAILS ..................................................................................................................... 10 2.1Transmitter Output Power, PSD and E.I.R.P .......................................................................... 11 2.2Occupied Bandwidth .............................................................................................................. 15 2.3Emission Masks..................................................................................................................... 29 2.4Conducted Spurious Emissions ............................................................................................. 38 2.5Radiated Spurious Emissions ................................................................................................ 53 2.6Frequency Stability ................................................................................................................ 59 3TEST EQUIPMENT USED..................................................................................................... 61 3.1Test Equipment Used ............................................................................................................ 62 3.2Measurement Uncertainty ...................................................................................................... 64 4DISCLAIMERS AND COPYRIGHT ........................................................................................ 65 4.1Disclaimers and Copyright ..................................................................................................... 66 COMMERCIAL-IN-CONFIDENCE Document 57014125 Report 01 Issue 2Page 3 of 66 COMMERCIAL-IN-CONFIDENCE SECTION 1 REPORT SUMMARY FCC and Industry Canada Testing of the DragonWave Inc. Microwave Outdoor Unit Harmony Lite 3GHz COMMERCIAL-IN-CONFIDENCE Document 57014125 Report 01 Issue 2Page 4 of 66 COMMERCIAL-IN-CONFIDENCE 1.1REPORT DETAILS The information contained in this report is intended to show verification of the DragonWave Inc. Microwave Outdoor Unit Harmony Lite 3GHz to the requirements of FCC CFR 47 Part 90Z and Industry Canada RSS-197. Testing was carried out in support of an application for Grant of Equipment Authorisation in the name of Microwave Outdoor Unit Harmony Lite 3GHz. ManufacturerDragonWave Inc. Address600-411 Legget Drive, Kanata ON,K2K 3C9, CANADA Product NameMicrowave Outdoor Unit Product TypeHarmony Lite 3GHz Serial Number(s)F1003GHA0140 Software Version1.6.23 Hardware VersionRev A Test Specification/Issue/DateFCC CFR 47 Part 90Z: 2013 Industry Canada RSS-197 Issue 1: 2010 Start of Test13 August 2014 Finish of Test27 August 2014 Name of Engineer(s)Yuanjie He Related Document(s) ANSI C63.4: 2009 ANSI/TIA-603-C-2004 FCC CFR 47 Part 2: 2013 Industry Canada RSS-Gen Issue 3: 2010 Industry Canada SRSP-303.65 Issue 2: 2010 COMMERCIAL-IN-CONFIDENCE Document 57014125 Report 01 Issue 2Page 5 of 66 COMMERCIAL-IN-CONFIDENCE 1.2BRIEF SUMMARY OF RESULTS A brief summary of results for each configuration, in accordance with FCC CFR 47 Part 90Z and Industry Canada RSS-197 is shown below. Section Sp…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: QB8LT3G IC ID: 4679A-LT3G DragonWave Inc. Microwave Outdoor Unit Harmony Lite 3GHz 2014 Not to be reproduced, except in its entirety,Page 1 of 2 without the Permission of TÜV SÜD Product Service LtdReference: 57014125 PHOTOGRAPHS OF TEST SET UP FCC ID: QB8LT3G IC ID: 4679A-LT3G DragonWave Inc. Microwave Outdoor Unit Harmony Lite 3GHz 2014 Not to be reproduced, except in its entirety,Page 2 of 2 without the Permission of TÜV SÜD Product Service LtdReference: 57014125 Radiated Emissions

Contact Information

Applicant

Jerry Potera(Regulatory Approvals)

[email protected]613-599-9991Fax: 613-599-4265

Test Firm

The State Radio_Monitoring_Center Testing (SRTC)Junfeng Wang

[email protected]861068009181Fax: 861068009208

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	9	3.67 GHz - 3.68 GHz	33.65 W	40M0D7W	0.94 ppm

Confidentiality

Long Term

Grant Notes

Output Power is EIRP. External antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures with a separation distance of at least 80.4 cm from all persons. RF exposure compliance for these external antennas is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-locating requirements of 1.1307 (b)(3).
