QBT-LB7001SLIM PAGER

SLIM VIBE ONLY PAGER INSTRUCTIONAL MANUAL LEE Technology Korea Co., Ltd. 1. To Turn Pager ON Press the button for more than 3 seconds at the side of pager 2. To Turn pager OFF Press the button for more than 5 seconds at the side of pager 3. To stop the alert Press the button shortly at the side of pager 4. Program-mining page alert mode Pager will light up to tell you that they have received new message and pager will alert with the programmed alert type when receive a message Alert Type Description 9292 Vibe only 9797 Flash only 9898 Vibe, Flash and Beep 9696 Vibe and Flash 9595 Flash and Beep 9393 Turn out of range OFF 9494 Turn out of range ON 99 Sleep 9090 8 sec (alert time)-flash once 9091 15 sec (alert time)-flash two times 9092 30 sec(alert time)-flash three times 9093 60 sec (alert time) )-flash once I need to send some transmitter in for repair - What do I do? Within warranty period / Covered by our Product-Care Program: Ship malfunctioning components to the following address: 3 rd FL, #499-2 Sang 3-dong, Wonmi-gu, Puchon-city, Kyunggi-do, Korea Tel: 82-32-678-8605 Fax: 82-32-324-9840 1. Pack the components securely 2. Enclose a note with a brief description of the problem 3. Include a business card 4. Ship the equipment in a traceable manner for your protection. (ie UPS ). 5. Insure the shipment for replacement value. There are no charges for repaired equipment within the warranty period, or if covered by Product-Care, other than your shipping costs. We will pay shipping one way back to you. (Shipping by the courier service is available at an additional charge on request) Out of warranty items will be repaired and sent back C.O.D. Hints and Tips Training is the key to success with a paging system. Orientating your entire staff and training your host staff on the use of the paging system is key to the success of the system. WARRANTY LeeTek warrants this product against any defects that are due to faulty material or workmanship for a one- year period after the original date of consumer purchase. This warranty does not include damage to the product resulting from accident, misuse or improper electrical connection. Power supplies are warranted for 60 days. We recommend the use of a surge protector with all equipment. If this product should become defective within the warranty period, we will repair or replace with equivalent product, free of charge. We will return your product, transportation charges prepaid standard shipping mode, provided the product is shipped prepaid to: LEETEK, 3 rd FL #499-2 Sang 3-dong, Wonmi-gu, Puchon-city, Kyunggi-do, KOREA No return will be received without prior authorization and the proper RMA # posted to the outside of the shipping container. This warranty gives you specific legal rights and you may also have rights which vary from state to state. As a part of the general host training program, time must be set aside to teach new hires about the use and care of the paging system. Be certain staff members understand the importance of asking for the transmitter back after work. Benefits of a VISUAL paging system Staff members are alerted thru the pager and know to quickly close the tab of a guest to help speed table turns. FCC NOTICE NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. LEE Technology Korea Co., Ltd. THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

E-Mail : [email protected] www.leetek.org Tel. : 82-32-324-9838 Fax. : 82-32-324-9840 March 10, 2008 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: QBT-LB7001 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Diagram(s) QBT-LB7001 SCHEMATIC DIAGRAM.PDF Part List QBT-LB7001 PART LIST.PDF Block Diagram QBT-LB7001 BLOCK DIAGRAM.PDF Circuit Description QBT-LB7001 CIRCUIT DESCRIPTION.PDF PCB Layout QBT-LB7001 PCBLAYOUT.PDF The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, LEETEK(Lee Technology Korea.,Co. Ltd)/Director

THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LB7001 REPORT #:THRU-803001 COVER SHEET Test Report Product Name: SLIM VIBE ONLY PAGER(Receiver) FCCID: QBT-LB7001 Applicant: Lee Technology Korea Co., Ltd. 3 rd FL #499-2 Sang 3-dong, Wonmi-gu, Bucheon-city, Kyungki-do, KOREA Date Receipt: 03/05/2008 Date Tested: 03/06/2008 THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LB7001 REPORT #:THRU-803001 TABLE OF CONTENTS APPLICANT: Lee Technology Korea Co., Ltd. FCCID: QBT-LB7001 TABLE OF CONTENTS FOR A RECEIVER REPORT PAGE 1........ TEST EQUIPMENT LIST PAGE 2........ TEST PROCEDURE PAGE 3-6...... RADIATED EMISSIONS TEST DATA PAGE 7-9.... POWERLINE CONDUCTED EMISSIONS THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LB7001 REPORT #:THRU-803001 1 of 9 EMC Equipment List No Description Manufacturer Model No. Serial No. Due Cal. Used 1 Test Receiver Rohde & SchwarzESHS 10 862970/018 2008.05.01 2 Test Receiver Rohde & SchwarzESVS 10 826008/014 2008.06.12 3 Spectrum AnalyzerHewlett Packard 8566B 2311A02394 2008.06.13 4 Spectrum DisplayHewlett Packard 85662A 2542A12429 2008.06.13 5 Quasi-peak AdapterHewlett Packard 85650A 2521A00887 2008.06.13 6 RF Preselector Hewlett Packard 85685A 2648A00504 2008.06.13 7 Preamplifer Hewlett Packard 8447F 2805A02570 2008.05.28 8 Preamplifer A.H. Systems PAM-0118 164 2008.05.08 9 Biconical AntennaEaton Corp. 94455-1 0977 2008.04.01 10 Biconical AntennaEMCO 3104C 9111-2468 2008.06.07 11 Log Periodic Antenn EMCO 3146 2051 2008.05.11 12 Horn Antenna A.H. Systems SAS-571 414 2008.03.17 13 Loop Antenna Rohde & Schwarz HFH2-Z2.335.4711.5 2 826532/006 2009.01.31 14 Dipole Antenna Rohde & SchwarzVHAP 574 2008.12.12 15 Dipole Antenna Rohde & SchwarzVHAP 575 2008.12.12 16 Dipole Antenna Rohde & SchwarzUHAP 546 2008.12.12 17 Dipole Antenna Rohde & SchwarzUHAP 547 2008.12.12 18 Signal Generator Hewlett Packard 8673D 2708A00448 2008.06.12 19 Spectrum AnalyzerAdvantest Corp. R3261C 61720208 2008.06.12 20 LISN EMCO 3825/2 9111-1912 2008.12.12 21 LISN Kyoritsu KNW-242 8-923-2 2009.05.23 22 Modulation Analyzer Hewlett Packard 8901B 3438A05094 2008.05.25 THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LB7001 REPORT #:THRU-803001 2 of 9 23 Waveform Generato Hewlett Packard 33120A US34001190 2008.05.21 24 Audio analyzer Hewlett Packard 8903B 3011A12915 2008.05.21 25 Digital OscilloscopeTektronix TDS 340A B012287 2008.06.13 THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LB7001 REPORT #:THRU-803001 3 of 9 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in full without the written approval of of THRU &ENGINEERING. Shielded interface cables were used in all cases except for cables connecting to the telephone line and the power cords. A test program was run which simulated a normal data transmission on a network. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-2003 using a HEWLETT PACKARD spectrum analyzer with a preselector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100 kHz and the video bandwidth was 300 kHz. The ambient temperature of the UUT was 7.1°C with a humidity of 65%. FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBuV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) METER READING + ACF = FS 33 20 dBuV + 10.36 dB = 30.36 dBuV/m @ 3m ANSI STANDARD C63.4-2003 10.1.7 MEASUREMENT PROCEDURES: The unit under test was placed on a table 80 cm high and with dimensions of 1m by 1.5m. The table used for radiated measurements is capable of continuous rotation. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and vertical planes. The situation was similar for the conducted measurement except that the table did not rotate. The EUT was setup as described in ANSIC63.4-2003 10.1.7 with the EUT 40 cm from the vertical ground wall. THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LB7001 REPORT #:THRU-803001 4 of 9 APPLICANT: Lee Technology Korea Co., Ltd. FCCID: QBT-LB7001 NAME OF TEST: RADIATION INTERFERENCE RULES PART NUMBER: 15.109,15.33(b)(3) REQUIREMENTS: 30 to 88 MHz: 40.0 dBuV/M @ 3 METERS 88 to 216 MHz: 43.5 dBuV/M 216 to 960 MHz: 46.0 dBuV/M ABOVE 960 MHz: 54.0 dBuV/M TEST RESULTS: A search was made of the spectrum from 30 to 1000 MHz and the measurements indicate that the unit DOES meet the FCC requirements. TEST DATA: * Tuning Frequency : 450.3750MHz No Emission Frequency (MHz) Meter Reading dBuV/m Ant. Polaritry Correction Factor dB Cable Loss dB Field Strength (dBuv/m) Margin (dBuv) Limit (dBuv/m) 1 48.30 15.4 H 11.2 1.0 27.6 -12.4 40.0 2 95.60 13.6 H 10.9 1.6 26.0 -17.5 43.5 3 143.60 10.4 V 15.7 2.1…
