QBT-LT2005WWATCH PAGER

WATCH TYPE PAGER (LT2005W) OPERATION MANUAL www.leetek.org [email protected] Lee Technology Korea.Co.,Ltd(LEETEK) 3 rd #499-2 Sang3dong, Wonmi-gu, Puchon-city, kyunggi-do, Korea T:82-32-324-9838/9 F:82-32-324-9840 FCC ID : QBT-LT2005W Trade Name : WATCH PAGER Model No. : LT2005W THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS : (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. NOTE:THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USERS AUTHORITY TO OPERATE THE EQUIPMENT. WATCH-TYPE PAGER 1. PICTURE 2. SPEC z 12 Segment Display z 1.5V AAA Battery Included z 2 Button Switch (Top Button, Side Button) z Vibe Alert z Maximum 12 Table Number Can Be Stored. 3. POWER ON/OFF 1) ON – Press the side Button for more than 5 seconds, and then it will be turned on. 2) OFF – Press the side button for more than 5 seconds, and then it will be turned off. 4. Time Setup 1) If you want to enter the Time Setting Mode, insert the battery. And then, you can automatically enter to the Time Setting Mode. 2) To change the number of the hour or the minute, press the side button. 3) Press the top button, to change the location of the edit bar from the hour to the minute. 4) It will be automatically exited to the initial screen after 3 seconds without any input. 5. Enter Table Setting Mode z To enter the Table Setting Mode, press the Top Button about 2 seconds. And then it will enter the Table Setting Mode. 6. Alert Mode z When the message is received, the vibration works for 15 seconds. If you push the button, the vibration will be stopped. 7. Message Reading 1) If you press the Side Button, “Call” is displayed. 2) The received message will be displayed if you push the Side Button once more. 8. Erase Message z To delete the message, make the display screen indicating the table number. z Then press the Side Button 3 seconds. The corresponding message will be erased. 9. Battery Information and Replacement 1) Watch-Typed Pager is designed to use a single AAA alkaline battery. 2) To replace the battery, do the following. - Slide the locking switch to the unlock position. - Take out the battery over. - Remove the old battery and insert a new AAA battery in the direction shown on the battery compartment. - Slide the battery cover back on the pager and slide the battery lock switch to the locked position. GuestCall Troubleshooting Charge light will not come on a. Make sure there is power to the outlet b. Try changing the position of the coasters on the stack. Make sure they are seated properly with the numbers facing front. c. Using a damp rag, clean metal contacts on coaster that will not light d. Check all connections on charger bases. If only one stack of coasters will not light on the charger, There is probably a bad connection. Move wires and be sure they are all plugged into back of black coaster charger. If you try all this and the coaster charging light will not come on you most likely have a blown power supply. No range on coaster pagers a. Be sure transmitter is not near any large metal objects, fire walls, etc. b. Be sure antenna is connected properly and not broken. Coasters are not paging or paging in a manner you did not program Review Coaster modes and enter the code for the mode you would like. It probably has changed. Coasters are not answering the page or acting strange Make sure the Coaster has a full charge. Before you call, try some of the following suggestion *Remember that the capability of your system will be affected by: Foil backed wallboard, Metal mesh, wire reinforced glass, metal sheeting, large mirrors, suspended ceilings, lift shafts etc. These can all reflect and thereby reduce the signaling capability of the transmitter. A little forethought prior to installation, coupled with a few tests, can normally avoid most of these problems. 1.Read through the manual. Answers to most questions can be found there. A trouble shooting section further assists you in diagnosing the problem. 2. IMPORTANT NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help . The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. Warning: Changes or modifications made to this equipment not expressly approved by LEETEK may void the FCC authorization to operate this equipment. 3. CAUTION : Never use any cleaner other than alcohol for the maintenance of this equipment. Organic solvent su…

Text truncated - open the document above for the full version.

Tel. : 82-32-324-9838 Fax. : 82-32-324-9840 July 6, 2007 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: QBT-LT2005W Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Diagram(s) QBT-LT2005W - Schematics.pdf Part List QBT-LT2005W - Part List.pdf Block Diagram QBT-LT2005W - Block Diagram.pdf Circuit Description QBT-LT2005W - Circuit Description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, LEETEK(Lee Technology Korea.,Co. Ltd)/Director

Model Name : LT2005W FCC ID : QBT-LT2005W Voltage Input: DC1.5V AAA MADE IN KOREA FCC Label Position ’ THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS : (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. (copy of marking place)

Model Name : LT2005W FCC ID : QBT-LT2005W Voltage Input: DC1.5V AAA MADE IN KOREA FCC Label Position ’ THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS : (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. (copy of marking place)

THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LT2005W REPORT #:THRU-707001 COVER SHEET Test Report Product Name: Watch Pager(Receiver) FCCID: QBT-LT2005W Applicant: Lee Technology Korea Co., Ltd. 3 rd FL #499-2 Sang 3-dong, Wonmi-gu, Bucheon-city, Kyungki-do, KOREA Date Receipt: 07/11/2007 Date Tested: 07/12/2007 THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LT2005W REPORT #:THRU-707001 TABLE OF CONTENTS APPLICANT: Lee Technology Korea Co., Ltd. FCCID: QBT-LT2005W TABLE OF CONTENTS FOR A RECEIVER REPORT PAGE 1........ TEST EQUIPMENT LIST PAGE 2........ TEST PROCEDURE PAGE 3-6...... RADIATED EMISSIONS TEST DATA PAGE 7-9.... POWERLINE CONDUCTED EMISSIONS THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LT2005W REPORT #:THRU-707001 1 of 7 EMC Equipment List No Description Manufacturer Model No. Serial No. Due Cal. 1 Test Receiver Rohde & Schwarz ESHS 10 825832/014 2007.08.25 2 Test Receiver Rohde & Schwarz ESVS 10 826008/014 2008.06.12 3 Spectrum Analyzer Hewlett Packard 8566B 2311A02394 2008.06.13 4 Spectrum Display Hewlett Packard 85662A 2542A12429 2008.06.13 5 Quasi-peak Adapter Hewlett Packard 85650A 2521A00887 2008.06.13 6 RF Preselector Hewlett Packard 85685A 2648A00504 2008.06.13 7 Preamplifer Hewlett Packard 8449B 3008A00375 2007.04.23 8 Preamplifer Hewlett Packard 8447F 3113A05367 2007.05.09 9 Preamplifer Hewlett Packard 8447F 2805A02570 2008.05.28 10 Preamplifer A.H. Systems PAM-0118 164 2008.05.08 11 Biconical Antenna Eaton Corp. 94455-1 0977 2008.04.01 12 Biconical Antenna EMCO 3104C 9111-2468 2008.06.07 13 Log Periodic Antenna EMCO 3146 2051 2008.05.11 14 Horn Antenna A.H. Systems SAS-571 414 2008.03.17 15 Loop Antenna Rohde & Schwarz HFH2-Z2.335.4711.52 826532/006 2009.01.31 16 Dipole Antenna Rohde & Schwarz VHAP 574 2007.12.12 17 Dipole Antenna Rohde & Schwarz VHAP 575 2007.12.12 18 Dipole Antenna Rohde & Schwarz UHAP 546 2007.12.12 19 Dipole Antenna Rohde & Schwarz UHAP 547 2007.12.12 20 Signal Generator Rohde & Schwarz SMX 825459/030 2007.06.15 21 Spectrum Monitor Rohde & Schwarz EZM 862304/007 None 22 Panorama Monitor Rohde & Schwarz EPN 883707/207 None 23 Spectrum Analyzer Advantest Corp. R3261C 61720208 2008.06.12 24 LISN EMCO 3825/2 9111-1912 2007.12.12 25 LISN Kyoritsu KNW-242 8-923-2 2008.05.23 26 Plotter Hewlett Packard 7475A 2210A02802 None 27 Modulation Analyzer Hewlett Packard 8901B 3438A05094 2008.05.25 28 Waveform Generator Hewlett Packard 33120A US3400119 0 2008.05.21 29 Audio analyzer Hewlett Packard 8903B 3011A12915 2008.05.21 30 Temperature & Humidity Chamber TABAI EZPEC CORP.MC711P 112000492 2006.08.27 31 Antenna Mast EMCO 1070-3 9109-1617 None THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LT2005W REPORT #:THRU-707001 2 of 7 32 Turn Table EMCO 1080-1,2 9203-1762 None 33 Positioning Controller EMCO 1090 9111-1054 34 Antenna Power Supply Rohde & Schwarz HZ-9 920127 None 35 Pulse Limiter Rohde & Schwarz ESH3-Z2 881052 None 36 Coaxial Take-up Reel EMCO 100817 9109-1684 None THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LT2005W REPORT #:THRU-707001 3 of 7 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in full without the written approval of of THRU &ENGINEERING. Shielded interface cables were used in all cases except for cables connecting to the telephone line and the power cords. A test program was run which simulated a normal data transmission on a network. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-2003 using a HEWLETT PACKARD spectrum analyzer with a preselector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100 kHz and the video bandwidth was 300 kHz. The ambient temperature of the UUT was 28.5C with a humidity of 60%. FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBuV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) METER READING + ACF = FS 33 20 dBuV + 10.36 dB = 30.36 dBuV/m @ 3m ANSI STANDARD C63.4-2003 10.1.7 MEASUREMENT PROCEDURES: The unit under test was placed on a table 80 cm high and with dimensions of 1m by 1.5m. The table used for radiated measurements is capable of continuous rotation. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and vertical planes. The situation was similar for the conducted measurement except that the table did not rotate. The EUT was setup as described in ANSIC63.4-2003 10.1.7 with the EUT 40 cm from the vertical ground wall. THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LT2005W REPORT #:THRU-707001 4 of 7 APPLICANT: Lee Technology Korea Co., Ltd. FCCID: QBT-LT2005W NAME OF TEST: RADIATION INTERFERENCE RULES PART NUMBER:…

Text truncated - open the document above for the full version.

THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LT2005W REPORT #:THRU-707001 THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LT2005W REPORT #:THRU-707001 THRU Lab & Engineering. 477-6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea T820318835092F820318835169 email [email protected] APPLICANT: Lee Technology Korea Co., Ltd. FCCID #: QBT-LT2005W REPORT #:THRU-707001
