QBTLTK-UP1ULTRASONIC DEVICE

• • • • • • • -

’

* Label Format & Location FCC ID : QBTLTK-UP1 Model No : LTK-UP1 MADE IN KOREA LTK-UP1 FCC Label LTK-UP1 Rear Cas e LTK-UP1 Front Case Note. on the user’s manual. The rest of the necessary descriptions including the below are noted THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS : (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

* Label Format & Location FCC ID : QBTLTK-UP1 Model No : LTK-UP1 MADE IN KOREA LTK-UP1 FCC Label LTK-UP1 Rear Cas e LTK-UP1 Front Case Note. on the user’s manual. The rest of the necessary descriptions including the below are noted THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS : (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: LEE TECHNOLOGY KOREA CO. LTD. Test Report Product Name: ULTRASONIC DEVICE FCC ID: QBTLTK-UP1 Applicant: LEE TECHNOLOGY KOREA CO. LTD. 3RD FL. #499-2 SANG 3-DONG, WONMI-GU BUCHON-CITY KYUNGKI-DO KOREA Date Receipt: 11/2/2005 Date Tested: 12/6/2005 FCC ID: QBTLTK-UP1 REPORT #: L\LEE TECH\2234UT5\2234UT5TestReport.doc COVER SHEET TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: LEE TECHNOLOGY KOREA CO. LTD. TABLE OF CONTENTS APPLICANT: LEE TECHNOLOGY KOREA CO. LTD. FCC ID: QBTLTK-UP1 REPORT CONTAINING: PAGE 1.............TEST EQUIPMENT LIST PAGE 2.............TEST PROCEDURE PAGE 3-4...........RADIATION INTERFERENCE TEST DATA PAGE 5.............OCCUPIED BANDWIDTH PAGE 6.............OCCUPIED BANDWIDTH PLOT PAGE 7.............TEST SET UP PHOTO EXHIBITS INCLUDING: REQUEST FOR CONFIDENTIALITY LETTER BLOCK DIAGRAM SCHEMATIC LABEL SAMPLE LABEL LOCATION PARTS LIST INSTRUCTION MANUAL CIRCUIT DESCRIPTION EXTERNAL PHOTOS INTERNAL PHOTOS TUNING PROCEDURE TEST SET UP PHOTOS FCC ID: QBTLTK-UP1 REPORT #: L\LEE TECH\2234UT5\2234UT5TestReport.doc TABLE OF CONTENTS TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: LEE TECHNOLOGY KOREA CO. LTD. EMC Equipment List Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter OATS TEI N/A N/A Listed 1/13/03 1/12/06 Biconnical Antenna Eaton 94455-1 1096 CAL 8/17/04 8/17/06 Biconnical Antenna Electro- Metrics BIA-25 1171 CAL 4/29/05 4/29/07 Blue Tower Quasi-Peak Adapter HP 85650A 2811A01279 CAL 4/13/05 4/13/07 Blue Tower RF Preselector HP 85685A 2926A00983 CAL 8/3/05 8/3/07 Blue Tower Spectrum Analyzer HP 8568B 2928A04729 2848A18049 CAL 4/13/05 4/13/07 LISN Electro- Metrics ANS-25/2 2604 CAL 8/27/04 8/27/06 LISN Electro- Metrics EM-7820 2682 CAL 4/28/05 4/28/07 Loop Antenna Electro Mechanics 6512 N/A N/A N/A FCC ID: QBTLTK-UP1 REPORT #: L\LEE TECH\2234UT5\2234UT5TestReport.doc Page 1 of 6 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: LEE TECHNOLOGY KOREA CO. LTD. TEST PROCEDURES GENERAL: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-2003 using a HEWLETT PACKARD spectrum analyzer with a pre-selector. In the frequency range 10 kHz to 30 MHz the RBW was 10 kHz and from 30-1000 MHz the RBW of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100 kHz and the video bandwidth was 300 kHz. The ambient temperature of the UUT was &tempr& with a humidity of &humr&. FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBuV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Pre-selector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) METER READING + ACF = FS 33 20 dBuV + 10.36 dB = 30.36 dBuV/m @ 3m ANSI C63.4-2003 Section 8.2.1 MEASUREMENT PROCEDURES: The EUT was placed on a non-conducting table 80 cm above the ground plane with the EUT located in the center of the table. With the antenna vertical a preliminary scan was done at 1 meters distance, the EUT was moved to a 3.0-meter distance and the antenna height varied and also placed in a horizontal position. The frequency was scanned from 9.0 kHz to 1.0 GHz. When an emission was found, the table was rotated to produce the maximum signal strength. The EUT was measured in three (3) orthogonal planes. The unit was measured at TIMCO ENGINEERING, INC. located at 849 N.W. State Road 45 Newberry, Florida 32669. FCC ID: QBTLTK-UP1 REPORT #: L\LEE TECH\2234UT5\2234UT5TestReport.doc Page 2 of 6 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: LEE TECHNOLOGY KOREA CO. LTD. APPLICANT: LEE TECHNOLOGY KOREA CO., LTD. FCC ID: QBTLTK-UP1 NAME OF TEST: RADIATION INTERFERENCE RULES PART NO.: 15.109(a) and 15.209 REQUIREMENTS: CARRIER FREQUENCY WILL NOT EXCEED 2400/F (kHz) AT 300 METERS OUT-OF-BAND EMISSIONS SHALL NOT EXCEED THE LEVEL OF THE FUNDAMENTAL. 9 to 490 KHz: 2400/F (kHz) uV/m @ 300 METERS 490 to 1705 KHz: 24000/F (kHz) uV/m @ 30 METERS 1705 to 30 MHz: 29.54 dBuV/M @ 30 METERS 30 to 88 MHz: 40.00 dBuV/M @ 3 METERS 88 to 216 MHz: 43.50 dBuV/M 216 to 960 MHz: 46.02 dBuV/M ABOVE 960 MHz: 54.00 dBuV/M TEST CONFIGURATION: The INTENTIONAL RADIATOR was connected to an ignition switch and a harness simulator cable box. The device was tested in both transmitting modes. TEST DATA: The Measured Signal level was at or below noise floor. The spectrum was scanned from 10 kHz to 1000 MHz and no emissions were found. TEST PROCEDURE: The procedure used was ANSI C63.4-2003 Section 8.2. The frequency was scanned from 9.0 kHz to 1.0 GHz. When an emission was found, the table was rotated to produce the maximum signal strength. The EUT was measured in three (3) orthogonal planes. The unit was measured at TIMCO ENGINEERING, INC. located at 849 N.W. State Road 45 Newberry, Florida 32669. TEST RESULTS: THE UNIT DOES MEET THE FCC REQUIREMENTS. PERFORMED BY: JOE SCOGLIO DATE: 12/6/05 FCC ID: QBTLTK-UP1 REPORT #: L\LEE TECH\2234UT5\2234UT5TestReport.doc Page 3 of 6 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: …
