FCC ID: QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 1/2 ATTACHMENT C: BLOCK DIAGRAM(S) FCC ID: QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 2/2 nBody-EP MCU wi t h USB interface DATA MEMORY AMP/ Fi l t er Loadcel l A/ D Conver t er Di spl ay (LED) Po wer Ma n a g e me n t U S B PC USB bus power <Legend> Si g nal Li ne Po wer Li ne Dat a Bus Cl oc k : 6MHz

FCC ID : QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 1/5 AT TA CH MEN T B. - EXTERNAL PHOTOS - FCC ID : QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 2/5 FCC ID : QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 3/5 FCC ID : QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 4/5 FCC ID : QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 5/5

FCC ID : QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 1/3 ATTACHMENT A. - ID LABEL INFORMATION AND LOCATION PHOTOS FCC ID : QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 2/3 1.1 ID Label Information Following is a copy of the label that will be placed on the rear side of the cabinet. Figure 3.1 PRODUCT LABEL Both the FCC ID and compliance statement are included in the product label Model NO : nBody-EP Type No : Scales FCC ID : QD8NB-2 Serial No : This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Including interference that may cause undesired operation. “ Product complies with DHHS Rules-21 CFR subchapter J-applicable at date of manufacture #19 Ganap-ri Gwangjuk-Myoun Yangju-gun Gyeonggi-do, Seoul Korea MADE IN KOREA FCC ID : QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 3/3 1.2 Label Location Photos The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) LABEL LOCATION

FCC ID : QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 1/4 ATTACHMENT F. - INTERNAL PHOTOS - FCC ID : QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 2/4 FCC ID : QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 3/4 FCC ID : QD8NB-2 REPORT NO. : HCT-F03-0708 HYUNDAI C–TECH 4/4

HYUNDAI CALIBRATION & CERTIFICATION TECH. CO., LTD. Product Compliance Division, EMC Team SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNKI-DO, 467-701, KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 CERTIFICATION Rule Part(s): Equipment Class: Standard(s): EUT Type: Model(s): Port/Connector(s) This equipment has been shown to be in compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-1992 (Grant Notes: #19, #28). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report prepared by : Ki-Soo Kim Manager of EMC Tech. Part  HYUNDAI CALIBRATION & CERTIFICATION TECH. CO., LTD.  1/ 19 QD8NB-2 nBody-EP/ Scales Manufacture; CAS Corporation. #19 Ganap-ri Gwangjuk-Myoun Yangju-gun Gyeonggi-do, Seoul Korea CAS FRN : 0007-1276-16 Date of Issue : JULY 22, 2003 Test Report No.: HCT-F03-0708 Test Site: HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. HCT FRN : 0005-8664-21 FCC ID : MODEL / TYPE : Part 15 & 2 FCC Class B Peripheral Device (JBP) FCC Class B: 2001 (CISPR 22:1998) Scales nBody-EP USB Port FCC ID : QD8NB-2 REPORT NO. : HCT-F3-0708 HYUNDAI C–TECH 2/19 TABLE OF CONTENTS PAGE REPORT COVER 1 TABLE OF CONTENTS 2 1.1 SCOPE 3 2.1 INTRODUCTION (SITE DESCRIPTION) 4 3.1 PRODUCTION INFORMATION 5 4.1 DESCRIPTION OF TESTS (CONDUCTED) 6 4.2 DESCRIPTION OF TESTS (RADIATED) 7 5.1 LIST OF SUPPORT EQUIPMENT 8-9 6.1 TEST DATA (CONDUCTED) 10-14 7.1 TEST DATA (RADIATED) 15 8.1 SMPLE CALCULATIONS 16 9.1 TEST EQUIPMENT 17 10.1 TEST SOFTWARE USED 18 11.1 CONCLUSION 19 ATTACHMENT A: FCC ID LABEL & LOCATION ATTACHMENT B: EXTERNAL PHOTOGRAPHS ATTACHMENT C: BLOCK DIAGRAM(S) ATTACHMENT D: TEST SETUP PHOTOGRAPHS ATTACHMENT E: USER’S MANUAL ATTACHMENT F: INTERNAL PHOTOGRAPHS FCC ID : QD8NB-2 REPORT NO. : HCT-F3-0708 HYUNDAI C–TECH 3/19 MEASUREMENT REPORT 1.1 SCOPE Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. • FCC ID : QD8NB-2 • Equipment Class: FCC Class B Peripheral Device (JBP) • EUT Type: Scales • Model(s): nBody-EP • Cable(s): Unshielded • Rule Part(s): FCC Part 15 Subpart B • Test Procedure(s): ANSI C63.4 (1992) • Dates of Tests: June 30, 2003 ~ July 3, 2003 • Place of Tests: 254-1,MAEKOK-RI,HOBUP-MYUN,ICHON-SI,KYOUNGKI-DO,467-701,KOREA Applicant Name: Address: CAS Corporation #19 ganap-ri Gwangjuk-Myoun Yangju-gun Gyeonggi-do, Seoul Korea FCC ID : QD8NB-2 REPORT NO. : HCT-F3-0708 HYUNDAI C–TECH 4/19 2.1 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSIC63.4-1992) was used in determining radiated and conducted emissions emanating from CAS Corporation. Scales FCC ID: QD8NB-2 The open area test site and conducted measurement facility used to collect the radiated data are located at the 254-1, MAEKOK-RI,HOBUP-MYUN,ICHON-SI,KYOUNGKI-DO, 467-701,KOREA. The site is constructed in conformance with the requirements of ANSI C63.4and CISPR Publication 22. Detailed description of test facility was submitted to the Commission and accepted dated July 24,2000 (Confirmation Number: EA90661) FCC ID : QD8NB-2 REPORT NO. : HCT-F3-0708 HYUNDAI C–TECH 5/19 3.1 PRODUCT INFORMATION (Equipment Description) Equipment Under Test (EUT) is the CAS Corporation. ( Model : nBody-EP) Scales FCC ID : QD8NB-2 Port(s)/Input Connector(s): USB Port Cable(s): Unshielded Dimensions (W×H×D): 420x510x112mm(W×H×D) Weight (Net):12.5Kg FCC ID : QD8NB-2 REPORT NO. : HCT-F3-0708 HYUNDAI C–TECH 6/19 4.1 Description of Tests(Conducted) (Power line Conducted RFI (150kHz- 30MHz) ) The power line conducted RFI measurements were performed according to CISPR 22. The EUT was placed on a non-conducting 1.0 by 1.5 meter table which is 0.8 meters in height and 0.40 meters away from the vertical wall of the shielded enclosure. Power to the EUT is provided through a Rohde & Schwarz 50 Ω / 50 uH Line Impedance Stabilization Network (LISN) and the support equipment through a separate Solar 50 Ω / 50 uH Line- Conducted Test Facility LISN. Sufficient time for the EUT, support equipment, and test equipment were allowed in order for them to warm up to their normal operating condition. The RF output of the LISN was connected to the spectrum analyzer to determine the frequency producing the maximum EME. The spectrum was scanned from 150kHz to 30 MHz. Each maximum EME was measured using an EMI receiver. The detector function of the receiver was set to CISPR quasi- peak and average mode with the bandwidth set to 9 kHz. Each emission was maximized consistent with the typical applications by varying the configuration of the test sample. Interface cables were connected to the available interface ports of the test unit. The effect of varying the position of cables was investigated to find the configuration that produces maximum Diagram emission. Excess cable lengths were bundled at the centre with 30- 40cm. in length. The worst-case configuration is noted in the test report and the photographs are attached. Each EME reported was calibrated using the Rohde & Schwarz SMX signal generator and are listed on Table 1. RFI Conducted FCC Class B RFI CONDUCTED FCC CLASS B Limits dB(uV/m) CISPR 22 CLASS B Limits dB(uV/m) Freq. Range FCC Class B Quasi-Peak CISPR 22 Quasi-Peak CISPR 22 Average 150kHz - 0.5MHz 48* 66-56** 56-46** 0.5MHz - 5MHz 48 56 46 5MHz - 30MHz 48 60 50 *FCC Class B limits starts from 450kHz **Limits decreases linearly with…
