QDBLT-23FMP23" LCD TV/MONITER

Test Report No.: GETEC-E3-03-024 FCC Class B Certification APPENDIX H : USER’S MANUAL EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP 500-002D Owner's Manual Model: LT-23FMP 본 제품은 국내에서만 사용할 수 있습니다. 사용설명서를 읽고 난 뒤에는 제품을 사용하는 사람이볼수있는곳에보관해주십시오. 23" Wide LCD Color TV/Monitor 3 2 IMPORTANT SAFETY INSTRUCTIONS Important safeguards for you and your new product Your product has been manufactured and tested with your safety in mind. However, improper use can result in potential electrical shock or fire hazards. To avoid defeating the safeguards that have been built into your new product, please read and observe the following safety points when installing and using your new product, and save them for future reference. Observing the simple precautions discussed in this operating guide can help you get many years of enjoyment and safe operation that are built into your new product. This product complies with all applicable U.S. Federal regulations and voluntary safety standards. 1. Read Instructions All the safety and operating instructions should be read before the product is operated. 2. Follow Instructions All operating and use instructions should e followed. 3. Retain Instructions The safety and operating instructions should be retained for future reference. 4. Heed Warnings All warnings on the product and in the operating instructions should be adhered to. 5. Cleaning Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 6. Water and Moisture Do not use this product near water for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool. 7. Accessories, Carts, and Stands Do not place this product on a slippery or tilted surface, or on an unstable cart, stand, tripod, bracket, or table. The product may slide or fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer. 8. Transporting Product A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn. 9. Attachments Do not use attachments not recommended by the product manufacturer as they may cause hazards. 10. Ventilation Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be locked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer ’s instructions have been adhered to. 11. Power Sources This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions. 12. Power Cord Polarization This product is equipped with a three-wire grounding-type plug, a plug having a third (grounding) pin This plug will only fit into a grounding-type power outlet. . This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug. 13. Power Cord Protection Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product. Warnings IMPORTANT SAFETY INSTRUCTIONS TO PREVENT FIRE OR SHOCK HAZARD DO NOT EXPOSE THE SET TO RAIN OR MOISTURE. NOTE TO CABLE/TV INSTALLER: This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as practical. REGULATORY INFORMATION: This equipment has been tested and found to comply with the limits for a Class B DIGITAL device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential Installation. This equipment generates, uses and can radiate radio frequency energy and, if Not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CAUTION: Do not attempt to modify this product in any way without written authorization. Unauthorized modification could void the user’s authority to operate this product. WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN. WARNING : To reduce the risk of electric shock do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualified …

Text truncated - open the document above for the full version.

Test Report No.: GETEC-E3-03-024 FCC Class B Certification APPENDIX D : BLOCK DIAGRAM EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP u_com & Txt Decoder (6MHz) SDA5550M AuthorCreate DateDoc. Ver. J.H. DO ([email protected])JUN. 13, 20031.0 Front Control Digital Display Processor (14.3MHz) Audio Decoder (18.432MHz) 512K*8 SRAM MX88L285 MSP34x1G Audio AMP(M) LA4282 Vidoe Decoder (20.25MHz) LED IR ARB+/- ARC+/- ARD+/- TUNER1 MAIN LCD CONN (20 pin, LVDS) L/R Out Component-IN Y C CVBS S-video V-IN Auido-L Auido-R EEPROM AT24C16 I2C-0 LT-23F*P Block Diagram K6T4008V1C Spkr-L L-IN R-IN VSP9427B YCbCr KeyD7 [Y,U,V] RGB Switch TDA8601 TXT R,G,B Scart R,G,B [R,G,B] W X G A D-SUB Jack (15 pin) R G B H V DR[7..0] DG[7..0] DB[7..0] LR V-Out L-Out R-Out SYSTEM M/N B/G,I,D/K,M/N B/G,I,D/K,L/L' B/G,I,D/K TAFD-H001F TAFD-M232D TAFD-Z242D TAFD-S212D MODEL 23FMP 23FEP 23FTP 23FLP TUNER 512K*8 Flash Memory 512K*32 SDRAM 512K*32 SDRAM Panel Link Transmitter DS90C383A A/D Converter (DVI) AD9882 D V I DVI Jack (25 pin) R G B H V CVBS SIF AM Spkr-R ARA+/-ACK+/- DR[7..0] DG[7..0] DB[7..0] CLK W986432AH AT29C020 DR[7..0] DG[7..0] DB[7..0]

Test Report No.: GETEC-E3-03-024 FCC Class B Certification APPENDIX F : EXTERNAL PHOTOGRAPHS EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP

Test Report No.: GETEC-E3-03-024 FCC Class B Certification APPENDIX C : ID SAMPLE LABEL & LOCATION EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification LABELLING REQUIREMENTS The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. „ ID Label „ ID Label Location of EUT I.D Label EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP

Test Report No.: GETEC-E3-03-024 FCC Class B Certification APPENDIX G : INTERNAL PHOTOGRAPHS EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP

Test Report No.: GETEC-E3-03-024 FCC Class B Certification CONTENTS 1. SCOPE.........................................................................................................................................................................3 2. INTRODUCTION.....................................................................................................................................................4 3. TEST CONDITIONS & EUT INFORMATION...............................................................................................5 3.1 D ESCRIPTION OF EUT.............................................................................................................................................5 3.2 S UPPORT EQUIPMENT USED.....................................................................................................................................6 4 . DESCRIPTION OF TESTS....................................................................................................................................7 4.1 C ONDUCTED EMISSION............................................................................................................................................7 4.2 R ADIATED EMISSION................................................................................................................................................8 5. CONDUCTED EMISSION.....................................................................................................................................9 5.1 O PERATING ENVIRONMENT.....................................................................................................................................9 5.2 TEST SET-UP.............................................................................................................................................................9 5.3 M EASUREMENT UNCERTAINTY................................................................................................................................9 5.4 LIMIT......................................................................................................................................................................10 5.5 TEST EQUIPMENT USED..........................................................................................................................................10 5.6 T EST DATA FOR POWER LINE CONDUCTED EMISSION............................................................................................11 6. RADIATED EMISSION........................................................................................................................................14 6.1 O PERATING ENVIRONMENT...................................................................................................................................14 6.2 TEST SET-UP...........................................................................................................................................................14 6.3 M EASUREMENT UNCERTAINTY..............................................................................................................................14 6.4 L IMIT......................................................................................................................................................................15 6.5 TEST EQUIPMENT USED..........................................................................................................................................15 6.6 T EST DATA FOR RADIATED EMISSION.....................................................................................................................16 7. ANTENNA POWER CONDUCTION...............................................................................................................21 7.1 O PERATING ENVIRONMENT...................................................................................................................................21 7.2 T EST SET-UP...........................................................................................................................................................21 7.3 TEST EQUIPMENT USED..........................................................................................................................................21 7.4 T EST DATA FOR ANTENNA POWER CONDUCTION...................................................................................................22 8. NOISE FIGURE......................................................................................................................................................25 8.1 O PERATING ENVIRONMENT...................................................................................................................................25 8.2 TEST SET-UP...........................................................................................................................................................25 8.3 T EST EQUIPMENT USED..........................................................................................................................................25 8.4 TEST DATA FOR NOISE FIGURE..............................................................................................................................25 9. SAMPLE CALCULATIONS...............................................................................................................................26 9.1 E XAMPLE 1 :...........................................................................................................................................................26 9.2 EXAMPLE 2 :...........................................................................................................................................................26 10. RECOMMENDATION & CONCLUSION....................................................................................................27 APPENDIX A – ATTESTATION STATEMENT APPENDIX B – PLOTS OF CONDUCTED EMISSIONS APPENDIX C – ID SAMPLE LABEL & LOC…

Text truncated - open the document above for the full version.

Test Report No.: GETEC-E3-03-024 FCC Class B Certification 6. Radiated Emission 6.1 Operating environment Temperature : 25°C Relative humidity : 70 % 6.2 Test set-up A preliminary scan with peak mode was performed in the semi anechoic chamber and found frequency for open area test site. The formal radiated emission was measured at 3m-distance open area test site. The EUT was placed on a non-conductive turntable approximately 0.8 meters above the ground plane. The turntable with EUT was rotated 360°, and the antenna was varied in height between 1.0 and 4.0 meters in order to determine the maximum emission levels. This procedure was performed for both horizontal and vertical polarization of the receiving antenna. 6.3 Measurement uncertainty The measurement uncertainty was calculated in accordance with ISO “Guide to the expression of uncertainty in measurement”. The measurement uncertainty was given with a confidence of 95%. Probability Uncertainty (dB) Distribution Biconical Ant. Log-periodic Ant. Contribution 3m 10m 3m 10m Ambient signal Antenna factor calibration Normal (k=2) 1.00 1.00 1.00 1.00 Receiver specification Rectangular 1.00 1.00 1.00 1.00 Antenna directivity Rectangular 0.50 0.00 3.00 0.50 Antenna phase center variation Rectangular 0.00 0.00 1.00 0.20 Antenna factor frequency interpolation Rectangular 0.25 0.25 0.25 0.25 Measure distance variation Rectangular 0.60 0.40 0.60 0.40 Site imperfections Rectangular 2.83 -2.94 -1.96 -2.96 Mismatch Receiver VRC : Γl= 0.09 U-shaped 0.33 0.33 0.33 0.33 Antenna VRC : Γg= 0.43 (Bi) 0.23 (Lp) -0.35 -0.35 -0.18 -0.18 Uncertainty limits 20log(1± Γl Γg) System repeatability Std Deviation 0.07 0.05 0.06 0.10 Cable loss calibration Normal (k=2) 0.20 0.20 0.20 0.20 Combined standard uncertainty Uc(y) Normal 1.88 1.90 2.33 1.94 -1.88 -1.90 -2.32 -1.93 Extended uncertainty U Normal (k=2) 3.77 3.80 4.65 3.87 -3.77 -3.80 -4.63 -3.85 EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Page 14 of 27 Test Report No.: GETEC-E3-03-024 FCC Class B Certification 6.4 Limit Frequency (MHz) FCC Limit @ 3m. Quasi-Peak dB (μV/m) FCC Limit @ 10m. Quasi-Peak dB (μV/m) CISPR Limit @ 10m. Quasi-Peak dB (μV/m) 30 – 88 40.0 29.5 30.0 88 – 216 43.5 33.0 30.0 216 – 230 46.0 35.6 30.0 230 – 960 46.0 35.6 37.0 960 – 1000 54.0 43.5 37.0 > 1000 54.0 43.5 No Specified limit *Limit extrapolated 20dB / decade 6.5 Test equipment used Model Number Manufacturer Description Serial Number Calibrated Date „ - ESI Rohde & Schwarz EMI test receiver 830482/010 12. 12. 2002 „ - ESCS30 Rohde & Schwarz EMI test receiver 839809/003 12. 12. 2002 „ - HK116 Rohde & Schwarz Biconical antenna 836239/007 12. 18. 2002 „ - HL223 Rohde & Schwarz Log-periodic antenna 835998/004 12. 20. 2002 „ - BBHA9120D Schwarzbeck horn antenna 207 02. 27. 2002 „ - 8449B Agilent Pre-Amplifier 3008A01828 Verification „ - 54200 FLUKE TV Signal generator 831011 02. 07. 2003 „ - HD100 HD GmbH Position Controller 100/692/01 NCR „ - DS415S HD GmbH Turntable 415/657/01 NCR „ - MA240 HD GmbH Antenna Mast 240/565/01 NCR EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Page 15 of 27 Test Report No.: GETEC-E3-03-024 FCC Class B Certification 6.6 Test data for radiated emission -. Test Date : July 08, 2003 -. Resolution bandwidth : 120kHz / 1MHz -. Frequency range : 30MHz ~ 2000MHz -. Detector mode : 30MHZ ~1000MHz : Quasi-peak detector mode 1000MHz ~ 2000MHz : Average detector mode 6.6.1 PC Mode ♦ Test resolution: 1024*768/85Hz (Analog) Frequency (MHz) Reading (dBuV) Ant. Pol. (H/V) Ant. Factor(dB/m) Cable Loss Emission Level(dBuV/m) Limits (dBuV/m) Margin (dB) 64.66 25.1 H 7.85 2.27 35.2 40.0 4.8 65.88 24.8 V 7.81 2.29 34.9 40.0 5.1 139.74 12.7 H 11.72 3.20 27.6 43.5 15.9 141.6 11.7 V 11.80 3.22 26.7 43.5 16.8 157.49 19.5 V 12.35 3.37 35.2 43.5 8.3 195.67 16.7 H 13.82 3.76 34.3 43.5 9.2 417 12.2 H 15.93 5.54 33.7 46.0 12.3 468.02 19.1 H 16.78 5.94 41.8 46.0 4.2 625.04 4.8 H 19.46 6.85 31.1 46.0 14.9 693 13.7 H 20.35 7.26 41.3 46.0 4.7 782.68 11.7 H 20.53 7.80 40.0 46.0 6.0 944.98 6.7 H 21.83 8.77 37.3 46.0 8.7 Above 1GHz 1106.97 16.3 V 24.47 4.83 45.6 54.0 8.4 1344.46 7.7 V 25.09 5.34 38.1 54.0 15.9 1660.42 7 V 24.86 6.45 38.3 54.0 15.7 Note: “H”: Horizontal, “V”: Vertical EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Page 16 of 27 Test Report No.: GETEC-E3-03-024 FCC Class B Certification ♦ Test resolution: 1024*768/85Hz (Digital) Frequency (MHz) Reading (dBuV) Ant. Pol. (H/V) Ant. Factor(dB/m) Cable Loss Emission Level(dBuV/m) Limits (dBuV/m) Margin (dB) 65.23 25.7 V 7.83 2.28 35.8 40.0 4.2 128.88 13.3 V 11.34 3.15 27.8 43.5 15.7 130.45 18.3 H 11.39 3.16 32.8 43.5 10.7 131.26 18 H 11.42 3.16 32.6 43.5 10.9 139.98 13.3 H 11.73 3.20 28.2 43.5 15.3 195.67 12.2 H 13.82 3.76 29.8 43.5 13.7 468.02 16.3 H 16.78 5.94 39.0 46.0 7.0 682.5 11.5 H 20.16 7.20 38.9 46.0 7.1 700.02 10.5 H 20.48 7.30 38.3 46.0 7.7 782.68 10.9 H 20.53 7.80 38.2 46.0 6.8 787.48 12.7 H 20.64 7.82 41.2 46.0 4.8 984.34 11.2 H 22.76 9.01 43.0 54.0 11.0 Above 1GHz 1106.98 16.4 V 24.47 4.83 45.7 54.0 8.3 1181.38 13.6 V 24.73 5.13 43.5 54.0 10.5 1344.28 9.9 V 25.09 5.34 40.3 54.0 13.7 1575 8.6 V 24.85 6.19 39.6 54.0 14.4 1660.47 7.9 V 24.86 6.45 39.2 54.0 14.8 1968.64 6.2 H 25.93 7.56 39.7 54.0 14.3 Note: “H”: Horizontal, “V”: Vertical EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Page 17 of 27 Test Report No.: GETEC-E3-03-024 FCC Class B Certification 6.6.2 TV Mode ♦ Radiated Emission due to the local oscillator Fundamental frequency Band Ch. NO. Ch. Frequency (MHz) HarmonicsMeasuring Frequency(MHz) Emission Level(dBuV/m) Limits (dBuV/m) Margin (dB) 2 55.25 1 101.0 - 43.5 << 3 61.25 1 107.0 - 43.5 << 4 67.25 1 113.0 - 43.5 << 5 77.25 1 123.0 - 43.5 << 6 83.25 1 129.0 - 43.5 << 7 175.25 1 221.0 - 46.0 << 8 181.25 1 227.0 30.15 46.0 15.85 9 187.25 1 233.0 - 46.0 << 10 193.25 1 239.0 - 46.0 << 11 199.25 1 245.0 - 46.0 << 12 205.25 1 251.0 25.52 46.0 20.48 VHF 13 211.25 1 257.0 23.86 46.0 22.14 14 471.25 1 517.0 - 46.0 << 19 501.25 1 547.0 - 46.0 << 24 531.25…

Text truncated - open the document above for the full version.

Test Report No.: GETEC-E3-03-024 FCC Class B Certification APPENDIX B : PLOTS OF CONDUCTED EMISSIONS EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification -. PC Mode „ Test Mode: 1024*768 / 85Hz (Analog) < Hot line > < Neutral line > EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification „ Test Mode: 1024*768 / 85Hz (Digital) < Hot line > < Neutral line > EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification „ Test Mode: 800*600 / 85Hz (Analog) < Hot line > < Neutral line > EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification „ Test Mode: 640*480 / 85Hz (Analog) < Hot line > < Neutral line > EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification -. TV Mode < Hot line > < Neutral line > EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification -. DVD Mode < Hot line > < Neutral line > EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP

Test Report No.: GETEC-E3-03-024 FCC Class B Certification APPENDIX E : TEST SET UP PHOTOGRAPHS EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification -. PC Mode „ Conducted Test Picture (Front) „ Conducted Test Picture (Rear) EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification „ Radiated Test Picture (Front) „ Radiated Test Picture (Rear) EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification -. TV Mode „ Conducted Test Picture (Front) „ Conducted Test Picture (Rear) EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification „ Radiated Test Picture (Front) „ Radiated Test Picture (Rear) EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification -. DVD Mode „ Conducted Test Picture (Front) „ Conducted Test Picture (Rear) EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP Test Report No.: GETEC-E3-03-024 FCC Class B Certification „ Radiated Test Picture (Front) „ Radiated Test Picture (Rear) EUT Type: 23” LCD TV/Monitor FCC ID : QDBLT-23FMP
