QE870820TX27R/C CAR

- Open the lock on both side of RC Car. - Extend the bag to make it stand. - Open the zipper of bag. - Place enough ice inside the bag. - Place 6 cans or bottle drink inside the ice and let’s the ice cool down the drink. - Turn on the RC Car. - There are 4 buttons on transmitter: forward, backward, left turn, right turn. - Drive the RC Car to where you want! - When the ice melts, pour the wate out of the bag and refill ice. © 2008 INTERACTIVE TOY CONCEPTS (HK) LTD. WARNING: Take out all of the Cans or Bottle of Drink before you pour the water out of the bag. User Guide Important battery information. This product is required (not included) with 6 x C cells for the RC Car and 1 x 9V battery for transmitter. Battery Replacement Remove battery compartment cover to replace batteries, unscrew where necessary. Replace batteries with 6 x C cells for the RC Car and 1 x 9V battery for transmitter. Please make sure that battery cover is securely fastened and screwed into place where necessary. Batteries are to be removed and replaced by an adult. Remove exhausted batteries from the unit and dispose of respnsibly. Do not incinerate. Non-rechargeable batteries are not to be recharged. Different types of batteries or new and used batteries are not to be mixed. Only batteries of the same or equivalent type as recommended are to be used. Batteries are to be inserted with the correct polarity as indicated inside the battery compartment. The supply terminals are not to be short-circuited. Please retain this information for future reference. INSTRUCTION MANUAL Forward Right Turn Left Turn Backward Lock On/Off Zipper RC Car Bag Strap Forward Left Turn Right Turn Backward Moving Direction

FCC ID: QE870820TX27 POWER OF ATTORNEY Jan.23, 2008 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Services (Hongkong) Co., Ltd. (Philo Zhong) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Services (Hongkong) Co., Ltd. (Philo Zhong) on our behalf shall have the same effect as acts of our own. This authorization expires on Jan.22, 2009. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, Interactive Toy Concepts (HK) Ltd., are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Interactive Toy Concepts (HK) Ltd. ------------------------------- Virginia Yeung General Manager

EUT - Front View EUT - Back View

FCC ID Label Sample for Model: R/C Car FCC ID: QE870820TX27 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID Label This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The Label must not be a stick-on paper. The Label on these products must be permanently affixed to the product and readily visible at the time of purchase and must last the expected lifetime of the equipment not be readily detachable. Proposed Label Location on EUT EUT Bottom View/proposed FCC Mark Location FCC ID: QE870820TX27 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference,

PCB- Front View PCB- Back View

Circuit Description Circuit Description When the control key is pressed,A encode signal from U2 is transmitted. Q2 and crystal for osilator,Q1 is rf amp modulation encode signal for rf, signal through filter send by antenna. Antenna and grond circuitry This unit make use an extenal antenna，This antenna is inductively coupled. This unit relies on the ground trace of the printed circuit board.No external ground is provided. energry is supplied by 6pcs aa alkaline battery. Background The device described herein a wirless(RF)TOY car CONTROLLER TRANSMITTER For use with the toy aeroplane controlled receiver.It has only one channel of Operation which the usermay choose only.And is used to send button-status dataform The controller to a wireless receiver connected with motors. Typical opeartion Typical opeartion would innolve the user turning on the unit to the toy game when turned on,The unit comes up on the default channel and transmits a continuously steam data.The user can not，At will .Change to any other of the predefined channel. Configuration The transmitted rf circutiry consists of a crystal controlled oscillator, Follow by rf amplifier & filter and antenna.Tha main characteristics Of this configuration are shown as below: Frequency ranges 27.145MHZ Occupied bandwidth(-26db) <100KHZ MAX Frequency stability +/- 20PPM Modulation method AM Output power 80DBuv/m Reference oscillator A 27.145MHZ crystal oscillator is used to generate ths reference frequency It has a stability of +/-20ppm Amplifier Ths Oscillator is followed by amplifiers.These final output is 80dbuv/m max Microcontroller The tx system iscontrolled by a encode ic running with <300khz Oscillator

FCC TEST REPORT Page 1 of 22 FCC ID : QE870820TX27 Applicant : Interactive Toy Concepts(HK) Ltd. 7/F.,Eu Yan San Tower, 11-15 Chatham Road South, TST, Kowloon, Hong Kong Equipment Under Test (EUT) : Product description : R/C Car Model No. : R/C Car Standards : FCC 15 Subpart C Paragraph 15.227 Date of Test : Jan.23, 2008 Test Engineer : Tiger Su Reviewed By : PERPARED BY: Waltek Services (Shenzhen) Co., Ltd. 8C,West Tower, Aidi Building, No.5003 Binhe Rd, Futian District, Shenzhen518045, Guangdong, China. Tel: 86-755-83551033 Fax: 86-755-83552400 Interactive Toy Concepts(HK) Ltd. FCC ID: QE870820TX27 Page 2 of 22 2 Contents Page 1 COVER PAGE..........................................................................................................................................................1 2 CONTENTS ..............................................................................................................................................................2 3 TEST SUMMARY....................................................................................................................................................4 4 GENERAL INFORMATION..................................................................................................................................5 4.1 CLIENT INFORMATION............................................................................................................................................5 4.2 GENERAL DESCRIPTION OF E.U.T...........................................................................................................................5 4.3 DETAILS OF E.U.T. .................................................................................................................................................5 4.4 DESCRIPTION OF SUPPORT UNITS...........................................................................................................................5 4.5 STANDARDS APPLICABLE FOR TESTING..................................................................................................................5 4.6 TEST FACILITY........................................................................................................................................................6 4.7 TEST LOCATION......................................................................................................................................................6 5 EQUIPMENT USED DURING TEST ...................................................................................................................7 6 CONDUCTED EMISSION TEST ..........................................................................................................................8 6.1 TEST EQUIPMENT....................................................................................................................................................8 6.2 TEST PROCEDURE...................................................................................................................................................8 6.3 CONDUCTED TEST SETUP.......................................................................................................................................9 6.4 EUT OPERATING CONDITION.................................................................................................................................9 6.5 CONDUCTED EMISSION LIMITS.............................................................................................................................10 6.6 CONDUCTED EMISSION TEST RESULT...................................................................................................................10 7 RADIATION EMISSION TEST...........................................................................................................................11 7.1 TEST EQUIPMENT..................................................................................................................................................11 7.2 MEASUREMENT UNCERTAINTY.............................................................................................................................11 7.3 TEST PROCEDURE.................................................................................................................................................11 7.4 RADIATED TEST SETUP.........................................................................................................................................12 7.5 SPECTRUM ANALYZER SETUP...............................................................................................................................13 7.6 CORRECTED AMPLITUDE & MARGIN CALCULATION............................................................................................13 7.7 SUMMARY OF TEST RESULTS................................................................................................................................13 7.8 EUT OPERATING CONDITION...............................................................................................................................14 7.9 RADIATED EMISSIONS LIMIT.................................................................................................................................14 7.10 RADIATED EMISSIONS TEST RESULT................................................................................................................15 7.11 RADIATED EMISSION TEST DATA.....................................................................................................................15 8 OCCUPIED BANDWIDTH ..................................................................................................................................17 8.1 TEST PROCEDURE.................................................................................................................................................17 9 PHOTOGRAPHS OF TESTING..........................................................................................…

Text truncated - open the document above for the full version.

Radiation Emission Test View
