QFPTGP78ABTrackbox

BENEFON TRACKBOX 2.1 Operating Instructions Publication number: YZ2655-0 All rights reserved. © Benefon Oyj, 2004. 2 FCC/INDUSTRY CANADA NOTICE This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: - This device may not cause harmful interference. - This device must accept any interference received, including interference that may cause undesired operation. CERTIFICATION INFORMATION - FCC ID: QFPTGP78AB - IC: 4350ATGP78AB Information in this manual is subject to change without notice. BENEFON reserves the right to change or improve their products and to make changes in the content without obligation to notify any person or organization of such changes or improvements. BENEFON is not responsible for any loss of data, income or any consequential damage whatsoever caused. Manufacturer: Benefon Oyj, P.O. Box 84, 24101 Salo, Finland Web site: www.benefon.com NOTE: Before you start using the device, carefully read through the device documentation: Installation Guide and Operating Instructions, especially Important safety information at the end of this manual. 3 CONTENTS PART A: CONFIGURING SETTINGS FOR THE TRACKBOX ............................................................7 MPTP MESSAGES AND REMOTE CONFIGURATION (OTA)................................... 7 THE BENEFON CONFIGURATOR SOFTWARE FOR TRACKBOX .......................................... 8 Connecting the Trackbox to the Benefon Configurator................................................. 8 THE CONFIGURATION PORT.............................................................. 9 Loading settings from the Trackbox to the software ............................................................ 10 Saving settings in a computer disk ........................... 10 Changing default mobile phone ................................ 11 Transferring settings from the software to the Trackbox ........................................... 11 Disconnecting the Trackbox from the software........................................................ 12 ACTIVATING NEW FEATURES......................................... 12 SHORT MESSAGES .......................................................... 13 Reading and editing existing messages ................... 13 Deleting a short message .......................................... 13 Writing and sending a short message ...................... 14 PHONE BOOKS ................................................................. 15 Editing and adding an entry....................................... 15 Deleting entries........................................................... 15 Arranging entries ........................................................15 Moving and copying entries.......................................16 USER SETTINGS ...............................................................16 Phone time and date ...................................................16 Activity timer ...............................................................16 SETTING THE ACTIVITY TIMER.......................................................... 17 Message settings ........................................................17 SMS SERVICE NUMBER...................................................................... 17 MESSAGE TYPE................................................................................... 18 MESSAGE VALIDITY TIME .................................................................. 18 Port and audio settings ..............................................18 AUTOMATIC ANSWER......................................................................... 18 DATA PORT ACTIVITY......................................................................... 19 AUDIO.................................................................................................... 19 VISIBLE MODE ..................................................................................... 19 Settings during battery loading .................................20 GPS OPERATING MODE ..................................................................... 20 GSM ACTIVATION ................................................................................ 20 GPS settings...............................................................20 GPS OPERATING MODE ..................................................................... 20 NMEA OUTPUT..................................................................................... 21 ASSISTED GPS (AGPS) ....................................................................... 21 TELEMATIC SETTINGS .....................................................22 Tracking settings ........................................................22 TRACKING ............................................................................................ 23 AREA TRACKING ................................................................................. 24 DEFAULT BEHAVIOUR FOR LOCATION REQUEST ......................... 25 REAL TIME TRACKING........................................................................ 25 General telematic settings .........................................26 SERVICE CENTER NUMBER............................................................... 27 4 LIST OF ALLOWED CALLERS............................................................. 27 PROTOCOL SETTINGS ........................................................................ 27 Authorized numbers .................................................. 29 Notifications ............................................................... 30 POOR SATELLITE COVERAGE........................................................... 30 NOTIFY SERVICE CENTER OF BATTERY STATUS .......................... 30 I/O SETTINGS ................................................................... 31 Emergency settings ................................................... 31 EMERGENCY CONFIRMATION ........................................................... 32 EMERGENCY CALL CYCLE MODE.........…

Text truncated - open the document above for the full version.

BENEFON OYJPostal addressTelephone+358-2-77 400 P.O.Box 84Telefax+358-2-733 2633 FIN-24101 SALODomicile: SALO Trade reg. No. 415.722 BENEFON TRACKBOX TGP78AB LABEL LOCATION: The label is located underneath the turnable GPS antenna which can be upturned at any time by hand for displaying the label.

MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE ! BALTIMORE, MARYLAND 21230-3432 ! PHONE (410) 354-3300 ! FAX (410) 354-3313 The Nation’s First Licensed Nationally Recognized Testing Laboratory September 8, 2004 Benefon Oyj Meriniitynkatu 11 24101 Salo Finland Dear Petri Aarnio, Enclosed is the EMC test report for compliance testing of the Benefon Oyj, Benefon Trackbox. The Benefon Oyj, Benefon Trackbox was tested to the requirements of the FCC Certification rules under Title 47 of the CFR Part 24 Subpart E for Broadband PCS Devices. Thank you for using the services of MET Laboratories, Inc. If you have any questions regarding these results or if MET can be of further service to you, please feel free to contact me. Sincerely yours, MET LABORATORIES, INC. Christina M. Karlhoff Documentation Department Reference: (\Benefon Oyj\ EMC15743A-FCC) Certificates and reports shall not be reproduced except in full, without the written permission of MET Laboratories, Inc. While use of the National Voluntary Laboratory Accreditation Program (NVLAP) letters or the NVLAP Logo, the Standards Council of Canada Logo, or the Nationally Recognized Testing Laboratory (NRTL) Letters in this report reflects MET Accreditation under these programs, these letters, logo, or statements do not claim product endorsement by NVLAP or any Agency of the U.S. Government. DOC-EMC709 9/2/2004 MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE ! BALTIMORE, MARYLAND 21230-3432 ! PHONE (410) 354-3300 ! FAX (410) 354-3313 DOC-EMC709 9/2/2004 Electromagnetic Compatibility Criteria Test Report For the Benefon Oyj Benefon Trackbox Tested under FCC Certification Rules Title 47 of the CFR, Part 24 Subpart E for Broadband PCS Devices MET Report: 15743A-FCC September 8, 2004 Prepared For: Benefon Oyj Meriniitynkatu 11 24101 Salo Finland Prepared By: MET Laboratories, Inc. Baltimore, MD 21230 Benefon Oyj Benefon Trackbox FCC ID: QFPTGP78AB CFR Title 47 Part 24 Subpart E MET Report: EMC15743A-FCC © 2004, MET Laboratories, Inc. Page i of v DOC-EMC709 9/2/2004 Electromagnetic Compatibility Criteria Test Report For the Benefon Oyj Benefon Trackbox Tested Under FCC Certification Rules Title 47 of the CFR, Part 24 Subpart E for Broadband PCS Devices Kevin A. Mehaffey Christina M. Karlhoff Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 24 Subpart E of the FCC Rules under normal use and maintenance. Liming Xu Electromagnetic Compatibility Lab Benefon Oyj Benefon Trackbox FCC ID: QFPTGP78AB CFR Title 47 Part 24 Subpart E MET Report: EMC15743A-FCC © 2004, MET Laboratories, Inc. Page ii of v DOC-EMC709 9/2/2004 Report Status Sheet Revision Report Date Reason for Revision & September 8, 2004 Initial Issue. Benefon Oyj Benefon Trackbox FCC ID: QFPTGP78AB CFR Title 47 Part 24 Subpart E MET Report: EMC15743A-FCC © 2004, MET Laboratories, Inc. Page iii of v DOC-EMC709 9/2/2004 Table of Contents 1. Requirements Summary .................................................................................................................................................1 2. Equipment Configuration...............................................................................................................................................2 2.1. Overview....................................................................................................................................................................2 2.2. Test Site .....................................................................................................................................................................3 2.3. Description of Test Sample ........................................................................................................................................3 2.4. Mode of Operation .....................................................................................................................................................5 2.5. Modifications .............................................................................................................................................................5 2.5.1. Modifications to EUT .............................................................................................................................5 2.5.2. Modifications to Test Standard ...............................................................................................................5 2.6. Disposition of EUT ....................................................................................................................................................5 3. Electromagnetic Compatibility Criteria for Broadband PCS Devices (Part 24 Subpart E) ...................................6 3.1. RF Power Output .......................................................................................................................................................6 3.2. Modulation Characteristics ......................................................................................................................................12 3.3. Occupied Bandwidth ................................................................................................................................................14 3.4. Spurious Emissions ......................................................................................................................…

Text truncated - open the document above for the full version.

DOC-FCC007-4C 2/19/04 Page 1 of 1 FCC GRANT OF EQUIPMENT AUTHORIZATION APPLICATION ALL RULE PARTS OTHER THAN 11, 15, AND 18 (PLEASE COMPLETE QUESTIONAIRE) 1. Type or types of emissions____________________________________________________________________ 2. Frequency Range: Transmitter: 1850.2 - 1909.8 Receiver: 1930.2 - 1989.8 3. Range of operating power values or specific operating power levels, and description of any means provided for variation of operating power Transmitter output: +30 dBm - 0 dBm, in 2 dB steps. 4. Maximum power rating as defined in the applicable rule part(s): Transmitter output: 1W 5. dc voltages applied to and dc currents into the several elements of the final radio frequency amplifying device for normal operation over the power range Operating voltage of the device (in-build charger): 10 – 30 V. Radio part: maximum operating voltage is 5.2 V, minimum voltage 3.3 V. Nominal voltage 4.0 V. Maximum current 700 mA.
