QFPTGP80EGGSM Mobile phone

TWIG DISCOVERY User’s Manual BY BENEFON Publication number YZ3000-01 All rights reseved. © Benefon Oyj, 2006 2 Correct disposal of this product: The mo- bile phone should not be disposed with household or other commercial wastes. Remove the battery from the phone and dispose it according to local battery recycling laws. •The device is designed for use on the E-GSM900/ DCS 1800/ PCS 1900 MHZ Tri Band networks. You can use the device in all countries where the GSM network operators have a roaming contract with your network operator. •The device also includes integrated high-performance 12-channel GPS receiver. The unique combination of GPS and GSM equipment in this device enables innovative new features, such as personal navigation, route planning, as well as support and user interface for secondary emergency aid feature. In order to function properly, some of these features may require third-party services. BENEFON is not responsible for such services, their existence, functio- nality or compatibility with BENEFON products. •Information in this User ́s manual is subject to change without notice. BENEFON reserves the right to change or improve their products and to make changes in the content without obligation to notify any person or organization of such changes or improvements. BENEFON is not responsible for any loss of data, income or any consequential damage whatsoever caused. Some of the features described in this guide may be optional and intended to be pur- chased separately. For details, please contact your dealer. •For more information, details and descriptions, including phone configuration and assortment of chargers and accessories, please visit the web site: www.benefon.com, or contact your BENEFON dealer. •BENEFON warrants its products to be free of defects in material or workmanship when leaving the factory. A war- ranty certificate with the date of purchase is enclosed in the delivery. For details, see the warranty certificate. •Hereby, Benefon Oyj declares that this mobile phone, type TGP80EG, is in compliance with the essential require- ments and other relevant provisions of Directive 1999/5/EC. •Benefon and Twig are registered trademarks of Benefon Oyj. •Bluetooth is a registered trademark of Bluetooth SIG, Inc. •eZiText ® is a registered trademark of ZI Corporation. 0700 Manufacturer: Benefon Oyj. P.O.Box 84, 24101, Salo, Finland website: www.benefon.com Copyright © 2006. All rights reserved. 3 SAR INFORMATION THIS MODEL PHONE MEETS THE GOVERNMENT'S RE- QUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your wireless phone is a radio transmitter and receiver. It is de- signed and manufactured not to exceed the emission limits for ex- posure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted lev- els of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientif- ic studies. The standards include a substantial safety margin de- signed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the phone transmitting at its high- est certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the max- imum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base sta- tion antenna, the lower the power output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as re- quired by the FCC for each model. The highest SAR value for this model phone when tested for use at the ear is 0.259 W/Kg and when worn on the body , as described in this user guide, is 0.588 W/Kg . (Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements). While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in com- pliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/ oet/fccid after search- ing on FCC ID: QFPTGP80EG. Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Asso-ciation (CTIA) web-site at http://www.wow-com.com. * In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a sub-stantial margin of safety to give additional pro- tection for the public and to account for any variations in measure- ments. U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful Interference in a residential installation This equipment generates, uses, and can radiate radio frequency energy and, if Not installed and used in accordance with the instructions, may cause ha…

Text truncated - open the document above for the full version.

BENEFON OYJ Postal address Telephone +358-2-77 400 P.O.Box 84 Telefax +358-2-733 2633 FIN-24101 SALO Domicile: SALO Trade reg. No. 415.722 Simon Button Chief Technology Officer Benefon 1 Victoria Street, Windsor Berkshire, United Kingdom, SL4 1YB Power of Attorney for 7 layers Commercial Power of Attorney for the type approval / registration of the TWIG DISCOVERY in several countries The company 7 layers, D-40880 Ratingen, has been contracted by Benefon to obtain „Radio Type Approvals“ for the following electronic components, manufactured and/or released by Benefon: TWIG DISCOVERY Unless future correspondence from Benefon directs otherwise, please extend your full cooperation to 7 layers regarding matters to the above mentioned products for the period beginning 12.06.06 through 31.12.06. Thank you. Simon Button – Chief Technology Officer (name and function of person signing) Benefon UK, Windsor, UK, 21 st June 2006 (place) (date) (signature)

7 layers AG Aufsichtsratsvorsitzenderh Registergerichth registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Markus Becker USt-IdNr h VAT Nr: Phone: +49 (0) 2102 749 0 Vorstandh Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. Hans-Jürgen Meckelburg www.7Layers.com René Schildknecht InterLab ® is a registered trademark of 7 layers AG FCC Measurement/Technical Report on Bluetooth ® transceiver Included in a GSM Phone Twig DISCOVERY; TGP80EG Report Reference: 4_BENEF_0105_GSM_FCCc Test Laboratory: 7 layers AG Borsigstrasse 11 40880 Ratingen Germany email: [email protected] DAT-P-192/99-01 Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the testing laboratory. Test report Reference: 4_BENEF_0105_GSM_FCCc Page 2 of 56 Table of Contents 0 Summary 3 0.1 Technical Report Summary 3 0.2 Measurement Summary 4 1 Administrative Data 6 1.1 Testing Laboratory 6 1.2 Project Data 6 1.3 Applicant Data 6 1.4 Manufacturer Data 6 2 Product labeling 7 2.1 FCC ID label 7 2.2 Location of the label on the EUT 7 3 Test object Data 8 3.1 General EUT Description 8 3.2 EUT Main components 9 3.3 Ancillary Equipment 9 3.4 EUT Setups 9 3.5 Operating Modes 9 4 Test Results 10 4.1 Conducted emissions (AC power line) 10 4.2 Occupied bandwidth 12 4.3 Peak power output 14 4.4 Spurious RF conducted emissions 16 4.5 Spurious radiated emissions 18 4.6 Band edge compliance 23 4.7 Dwell time 25 4.8 Channel separation 27 4.9 Number of hopping frequencies 28 5 Test Equipment 29 6 Photo Report 32 7 Setup Drawings 35 8 Annex measurement plots 36 8.1 AC Mains conducted 36 8.2 Occupied bandwidth 37 8.3 Peak power output 40 8.4 Band edge compliance conducted and Spurious RF conducted emission43 8.5 Radiated emissions (f<30MHz) 50 8.6 Dwell time 52 8.7 Channel separation 55 8.8 Number of hopping frequencies 56 Test report Reference: 4_BENEF_0105_GSM_FCCc Page 3 of 56 0 Summary 0.1 Technical Report Summary Type of Authorization Certification for an Intentional Radiator (Frequency Hopping Spread Spectrum). Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 2 (10-1-05 Edition) and 15 (10-1-05 Edition). The following subparts are applicable to the results in this test report. Part 2, Subpart J - Equipment Authorization Procedures, Certification Part 15, Subpart C – Intentional Radiators § 15.201 Equipment authorization requirement § 15.207 Conducted limits § 15.209 Radiated emission limits; general requirements § 15.247 Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz Note: The tests were selected and performed with reference to the FCC Public Notice DA 00- 705, released March 30, 2000 Instead of applying ANSI C63.4-1992 which is referenced in the FCC Public Note, the newer ANSI C63.4-2003 is applied. Summary Test Results: The EUT complied with all performed tests as listed in chapter 0.2 Measurement Summary. Test report Reference: 4_BENEF_0105_GSM_FCCc Page 4 of 56 0.2 Measurement Summary FCC Part 15, Subpart C § 15.207 Conducted emissions (AC power line) The measurement was performed according to ANSI C63.4 2003 OP-Mode Setup Port Final Result op-mode 2 Setup_a01 AC Port (power line) passed FCC Part 15, Subpart C § 15.247 (a) (1) Occupied bandwidth The measurement was performed according to FCC § 15.31 10-1-05 OP-Mode Setup Port Final Result op-mode 1 Setup_b01 Temp.ant.connector passed op-mode 2 Setup_b01 Temp.ant.connector passed op-mode 3 Setup_b01 Temp.ant.connector passed FCC Part 15, Subpart C § 15.247 (b) (1) Peak power output The measurement was performed according to FCC § 15.31 10-1-05 OP-Mode Setup Port Final Result op-mode 1 Setup_b01 Temp.ant.connector passed op-mode 2 Setup_b01 Temp.ant.connector passed op-mode 3 Setup_b01 Temp.ant.connector passed FCC Part 15, Subpart C § 15.247 (d) Spurious RF conducted emissions The measurement was performed according to FCC § 15.31 10-1-05 OP-Mode Setup Port Final Result op-mode 1 Setup_b01 Temp.ant.connector passed op-mode 2 Setup_b01 Temp.ant.connector passed op-mode 3 Setup_b01 Temp.ant.connector passed FCC Part 15, Subpart C § 15.247 (d), § 15.35 (b), § 15.209 Spurious radiated emissions The measurement was performed according to ANSI C63.4 2003 OP-Mode Setup Port Final Result op-mode 1 Setup_a01 Enclosure passed op-mode 2 Setup_a01 Enclosure passed op-mode 3 Setup_a01 Enclosure passed FCC Part 15, Subpart C § 15.247 (d) Band edge compliance The measurement was performed according to FCC § 15.31 (10-1-05) / ANSI C63.4 (2003) 10-1-05 / 2003 OP-Mode Setup Port Final Result op-mode 1 Setup_b01 Temp.ant.connector passed op-mode 3 Setup_b01 Temp.ant.connector passed op-mode 3 Setup_a01 Enclosure passed Test report Reference: 4_BENEF_0105_GSM_FCCc Page 6 of 56 1 Administrative Data 1.1 Testing Laboratory Company Name: 7 Layers AG Address Borsigstr. 11 40880 Ratingen Germany This facility has been fully described in a report submitted to the FCC and accepted under the registration number 96716 . The test facility is also accredited by the following accreditation organisation: - Deutscher Akkreditierungs Rat DAR-Registration no. DAT-P-192/99-01 Responsible for Accreditation Scope: Dipl.-Ing. Bernhard Retka Dipl.-Ing. Robert Machulec Dipl.-Ing. Thomas Hoell Report Template Version: 2006-05-09 1.2 Project Data Responsible for testing and report: Dipl.-Ing. Robert Machulec Date of Test(s): 2006-05-11 to 2006-06-27 Date of Report: 2006-06-28 1.3 Applicant Data Company Name: Benefon Oyj Address: Meriniitynkatu 11 24101 Salo Finland Contact Person: Jari Pekka Savojoki 1.4 Manufacturer Data Company Name: please see applicant data Address: Contact Person: Test report Reference: 4_BENEF_0105_GSM_FCCc Page 7 of 56 2 Product labeling 2.1 FCC ID label At the time of the report there was no FCC label available. 2.2 Location of the l…
