QHYHUBBUBC4500-RTFemtocell

911702 Rev. 51.12 AIRAVE 2.5 User Guide ©2012 Sprint. Sprint and the logo are trademarks of Sprint. Other marks are trademarks of their respective owners. 911702 Rev. 51.12 Important Messages IMPORTANT: Sprint’s policies often do not apply to third-party applications. Third-party applications may access your personal information or require Sprint to disclose your customer information to the third-party application provider. To find out how a third-party application will collect, access, use, or disclose your personal information, check the application provider’s policies, which can usually be found on their website. If you aren’t comfortable with the third- party application’s policies, don’t use the application. Important Messages c i Table of Contents Introduction ................................................................................................................................ 1 Getting Started........................................................................................................................... 2 Check What’s in the Box ........................................................................................................ 2 Set up at a glance .................................................................................................................. 2 Setting up Your AIRAVE™..................................................................................................... 3 External GPS Antenna Setup ................................................................................................. 5 When is Your AIRAVE Ready for Use? .................................................................................. 6 Setting up Optional Components ............................................................................................... 7 PC or LAN Router Setup ........................................................................................................ 7 Configuring AIRAVE™ Router ................................................................................................ 8 Adding Your ISP User Name and Password .............................................................................. 9 Using Your AIRAVE™...............................................................................................................12 How AIRAVE Works ..............................................................................................................12 Your Broadband Connection Speed...................................................................................12 How Calls and Data Go Over the Internet ..........................................................................13 Maintenance..........................................................................................................................13 Ventilation ..........................................................................................................................13 Cleaning ............................................................................................................................13 Troubleshooting ........................................................................................................................14 Troubleshooting Installation Problems ...................................................................................14 Resetting the AIRAVE ...........................................................................................................15 LED Quick Reference............................................................................................................16 Using LEDs ...........................................................................................................................17 FAQ.......................................................................................................................................21 Why does the AIRAVE™ need a GPS antenna?................................................................21 Why does the AIRAVE™ need an external GPS antenna? ................................................21 What happens to the AIRAVE™ if there is a power outage or if you lose Internet access? 21 Can you move the AIRAVE™ to another location? ............................................................21 How do I know if my phone is connecting through the AIRAVE?........................................21 Getting Help ..........................................................................................................................21 ii Safety Information.....................................................................................................................23 General Precautions..............................................................................................................23 FCC Information ....................................................................................................................24 ! FCC Radiation Exposure Statement ................................................................................24 FCC Part 15.......................................................................................................................24 iii 1 Introduction This User Guide introduces you to the SPRINT® AIRAVE™ service and all its features. It’s divided into four sections: ● Getting Started page 2 ● Setting up Optional Components page 7 ● Using Your AIRAVE™ page12 ● Troubleshooting page 14 ● Safety Information page 23 Throughout this guide, you’ll find tips and techniques that help you make the most of your new device and service. The Table of Contents and Index also help you quickly locate specific information. It is important that you read each section and note any special requirements. However, if you’d like to get right to a specific feature, simply locate that section in the Table of Contents and go directly to that page. Follow the instructions in that section, and you’ll be ready to use your AIRAVE in no time…

Text truncated - open the document above for the full version.

UNLESS OTHERWISE SPECIFIED -INTERPRET PER ASME Y14.5M 1994 -ALL DIMENSIONS IN INCHES -DO NOT SCALE DRAWING THIRD ANGLE PROJECTION LABEL; FCC PART 15; TRAIN7 THIS DOCUMENT CONTAINS INFORMATION WHICH IS THE EXCLUSIVE PROPERTY OF AIRVANA INC.. DISTRIBUTION, REPRODUCTION OR USE BY OTHERS IS NOT PERMITTED WITHOUT THE EXPRESS WRITTEN CONSENT OF AIRVANA INC. SIZEDRAWN BYPART NUMBERREV AK. CRAIG61014101 SCALE NONE CAD GENERATED DRAWINGSHEET 1 OF 2 TOLERANCES UNLESS OTHERWISE SPECIFIED X.X.XX.XXXANGLES INCHESN/A0.10.03 0.01 5 1° MATERIAL: FINISH: NOTE 1 REV.DESCRIPTIONDATEBY 01INITIAL ENGINEERING RELEASE01-24-2013KEC D C B A 4321 D C B A 4321 AIRVANA INC. 19 Alpha Rd. Chelmsford, MA 01824 (978) 250-4455 Notes: 1. Material: Label stock, Brady B483 Ribbon resin, R6007 2. Material and process used for fabrication of this part must be RoHS compliant Actual Size 1.125 0.400 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: QHYHUBBUBC4500-RT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: QHYHUBBUBC4500-RT SCALE 2/1 Model: HubBub C1-600-RT Rating: 12V 2A Made in China, Sep 2011 WARNING OF 911 LIMITATIONS: You may not be able to make phone calls, including to 911, in the event of an electrical power outage, broadband connection failure, termination of broadband service or other service disruption. 911 or enhanced 911 services may be limited in areas outside of Sprint’s wireless network coverage. Always be prepared to report your precise location. 800211-00-01 214357 SV This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: QHYHUBBUBC4500-RT

Part 22 BC0 Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at the antenna terminal:8.04(dBm) Max imum peak output power at the antenna terminal:6.367955209(mW) Antenna gain(typical):0 (dBi) Max imum antenna gain:1 (numeric) Pred iction distance:20(cm) Prediction frequency:879.6(MHz) MPE limit for uncontrolled exposure at prediction frequency:0.586400(mW/cm^2) Power density at prediction frequency:0.001267(mW/cm^2) 2 4R PG S π = Part 24 BC1 Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at the antenna terminal:17.00(dBm) Max imum peak output power at the antenna terminal:50.11872336(mW) Antenna gain(typical):0 (dBi) Max imum antenna gain:1 (numeric) Pred iction distance:20(cm) Prediction frequency:1931.25(MHz) MPE limit for uncontrolled exposure at prediction frequency:1.000000(mW/cm^2) Power density at prediction frequency:0.009971(mW/cm^2) 2 4R PG S π = Part 24 One-X Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at the antenna terminal:14.00(dBm) Max imum peak output power at the antenna terminal:25.11886432(mW) Antenna gain(typical):0 (dBi) Max imum antenna gain:1 (numeric) Pred iction distance:20(cm) Prediction frequency:1956.25(MHz) MPE limit for uncontrolled exposure at prediction frequency:1 (mW/cm^2) Power density at prediction frequency:0.004997(mW/cm^2) 2 4R PG S π = Part 24 EVD0 Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at the antenna terminal:22.70(dBm) Max imum peak output power at the antenna terminal:186.2087137(mW) Antenna gain(typical):0 (dBi) Max imum antenna gain:1 (numeric) Pred iction distance:20(cm) Prediction frequency:1988.7(MHz) MPE limit for uncontrolled exposure at prediction frequency:1.000000(mW/cm^2) Power density at prediction frequency:0.037045(mW/cm^2) 2 4R PG S π = Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at the antenna terminal:7.54(dBm) Max imum peak output power at the antenna terminal:5.675446054(mW) Antenna gain(typical):0 (dBi) Max imum antenna gain:1 (numeric) Prediction distance:20(cm) Pred iction frequency:867.9(MHz) MPE limit for uncontrolled exposure at prediction frequency:0.578600(mW/cm^2) Power density at prediction frequency:0.001129(mW/cm^2) 2 4R PG S π = [ Pd(1) / LPd(1) ] + [ Pd(2) / LPd(2) ] + ..... + [ Pd(n) / LPd(n) ] < 1, then device complies with FCC’s RF radiation exposure limit for general population for a mobile device. Where; Pd(n) = Power density of n th transmitter at 20cm LPd(n) = Power density limit for the n th transmitter The highest gain values were used for antenna gain. Radio TypePower DensityLimit (mW/cm 2 )(mW/cm 2 ) Part 22 (BC0)0.00126700 0.58640000 Part 24 (one- x)0.00499700 1.00000000 Part 24 (EVDO)0.03704500 1.00000000 Part 24 (BC1)0.00997100 1.00000000 Part 90 (BC10)0.00112900 0.57860000 0.0561249<1PASS FINAL COMBINED MPE

Curtis-Straus LLC is accredited by the American Association for Laboratory Accreditation for the specific scope of accreditation under Certificate Number 1627-01. This report may contain data which is not covered by the A2LA accreditation. ____________________________________________________________ Curtis-Straus LLC, a wholly owned subsidiary of BV CPS One Distribution Center Circle, #1 • •• • Littleton, MA • •• • TEL (978) 486-8880 • •• • FAX (978) 486-8828 page 1 of 63 Test Report Curtis-Straus LLC, a wholly owned subsidiary of BV CPS Report No EM2419-1 Client Airvana Address 19 Alpha Road Chelmsford, MA 01824 Phone 978-250-2622 Item tested Femto Cell 750721 FCC ID QHYHUBBUBC4500-RT FRN 0021466594 Equipment Type PCS Licensed Transmitter Equipment Code PCB Emission Designator 1M27D7D FCC Rule Parts 47 CFR 22 Subpart H 47 CFR 24 Subpart E 47 CFR 90 Subpart S Test Dates October 29, 30, & 31, 2012 and November 1, 6, & 7, 2012 Results As detailed within this report Prepared by Arik Zwimer Authorized by Mairaj Hussain – EMC Supervisor Issue Date March 29, 2013 REPORT: EM2419-1 March 31, 2010 ______________________________________________________________________ ____________________________________________________________ Curtis-Straus LLC, a wholly owned subsidiary of BV CPS One Distribution Center Circle, #1 • •• • Littleton, MA • •• • TEL (978) 486-8880 • FAX (978) 486-8828 page 2 of 63 Contents Contents..................................................................................................................................2 Summary.................................................................................................................................3 Test Methodology ....................................................................................................................3 Product Tested - Configuration Documentation .......................................................................5 Statement of Conformity......................................................................................................6 Tests Specific to Part 22..........................................................................................................7 Bandwidth............................................................................................................................7 ERP...................................................................................................................................11 Band Edge Measurements.................................................................................................12 Conducted Spurious Emissions at Antenna Port................................................................15 Tests Specific to Part 24........................................................................................................18 Bandwidth..........................................................................................................................18 EIRP..................................................................................................................................28 Band Edge Measurements.................................................................................................30 Conducted Spurious Emissions at Antenna Port................................................................37 Tests Specific to Part 90........................................................................................................45 Occupied Bandwidth..........................................................................................................45 ERP...................................................................................................................................49 Emission Mask...................................................................................................................50 Conducted Spurious Emissions at Antenna Port................................................................53 Tests for Parts 22, 24, & 90 ...................................................................................................55 Radiated Spurious Emissions Measurements....................................................................55 Conducted AC Mains Spurious Emissions Measurements.................................................59 Frequency Stability............................................................................................................60 Test Equipment Used ............................................................................................................61 Conditions Of Testing ............................................................................................................62 Form Final Report REV 7-20-07 (DW) Release Control Record Issue No. Reason for change Date Issued 1 Original Release August 14, 2007 _____________________________________________________________ Curtis-Straus LLC, a wholly owned subsidiary of BV CPS One Distribution Center Circle, #1 • •• • Littleton, MA • •• • TEL (978) 486-8880 • •• • FAX (978) 486-8828 page 3 of 63 Summary This test report supports an application for certification of a transmitter operating pursuant to 47 CFR 22 Subpart H, 47 CFR 24 Subpart E, and 47 CFR 90 Subpart S. The product is the Femto Cell 750721. It is a transceiver that operates in the ranges 862- 869MHz, 869-894MHz, and 1930-1990MHz. We found that the product met the above requirements without modification. The test sample was received in good condition. Test Methodology Radiated emission testing was performed according to the procedures specified in ANSI C63.4 (2003) and TIA-603-C. Radiated Emissions were maximized by rotating the device around its upright axes as well as varying the test antenna’s height and polarity. Conducted measurements at the antenna port were performed. The EUT operating voltage is 120Vac 60Hz. The Femto Cell 750721 has five transmitters, identified as One-X, EVDO, Beacon BC0, Beacon BC1, and Beacon…
