Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|
| 37 | 27 | 1.72 GHz - 1.77 GHz | 190.11 mW | 17M9W7D | 0.008
ppm |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesOutput Power is EIRP and ERP for above and below 1 GHz, respectively, except for Part 90 LTE Band 26 emissions, which are conducted. Single Modular Approval for mobile RF Exposure condition. The Antenna(s) used for this transmitter must not exceed a maximum gain as described in the filing. This module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. Integration not consistent with these conditions will entail additional testing and authorization process. Co-location of this module with other transmitters that operate simultaneously are required to be evaluated using the FCC multi-transmitter procedures. Approved for OEM integration only. The grantee must provide OEM integrators with installation and operating instructions for satisfying FCC multi-transmitter product guidelines. This grant is valid only when the device is sold to OEM integrators. This device supports LTE of 1.4, 3, 5, 10, 15 and 20 MHz bandwidth modes for FDD LTE Bands 2, 4 and 66; LTE of 5, 10, 15 and 20 MHz bandwidth modes for FDD LTE Band 7; LTE of 1.4, 3, 5 and 10 MHz bandwidth modes for FDD LTE Bands 5 and 12; LTE of 5 and 10 MHz bandwidth modes for FDD LTE Band 13; LTE of 1.4, 3, 5, 10 and 15 MHz bandwidth modes for FDD LTE Band 26; and LTE of 5, 10, 15 and 20 MHz bandwidth modes for TDD LTE Bands 38 and 41. This device contains functions that are not operational in U.S. Territories; this filing is applicable only for U.S. operations.
