QL4G2S7IRadar Detector

Head Office 2422 Dunwin Drive Mississauga, Ontario Canada L5L 1J9 Tel: (905) 828-1002 Fax: (905) 828-2951 wwwwww..bbeellttrroonniiccss..ccoomm This product is subject to one or more of the following patents: United States #4,571,593#4,625,210#4,630,054#4,939,521 #4,952,936#4,961,074#5,402,087#5,446,923 #5,587,916#5,600,132 Canada #1,187,586#1,187,602#1,295,714#1,295,715 Other Patents Pending Safety Warning System ® L.C.–Patents Pending Printed in Canada273004 - 13 ,Fundamental Mixer Technology, FMT and Shadow Technology are registered trademarks of BELTRONICS USA, Inc. VECTOR 990, Total Tracking Laser, TTL, AccuSweep and AutoScan are trademarks of BELTRONICS USA, Inc. Safety Warning System is a registered trademark of Safety Warning System L.C. VECTOR 990 VECTOR 990 Operating Instructions MOTOROLAMOTOROLA digital dna TM MOTOROLA Model V990 k International International Digital Voice and Text Messages 64 20 North American Driver Selectable Features International Driver Selectable Features 16 THE NEXT GENERATION IN DIGITAL PERFORMANCE THE NEXT GENERATION IN DIGITAL PERFORMANCE CONGRATULATIONS! SOFTWARE UPGRADABLE SHADOW TECHNOLOGY ® II Thank you for purchasing VECTOR 990International– the world’s only truly International Radar detector. VECTOR 990 International contains 10 Radar frequencies making it ideal for travel anywhere in the world. VECTOR 990International contains 16 North American Driver Selectable Features and 20 International Driver Selectable Features, 64 Digital Voice and Text Messages, and the best possible Radar sensitivity in the industry. Enjoy your new detector and be sure to obey all laws where ever you may travel. Remember, owning a Radar detector does not give you a license to speed. Alerts from a Radar detector serve as an effective reminder to check your speed. Laws vary throughout the USA and Europe governing the use of a Radar detector. It is your responsibility to follow these laws. VECTOR 990 International contains Flash Technology which provides the highest capability to be reprogrammed as the threat of new police traffic radar monitoring technologies emerge. Please ensure that you promptly send in your Consumer Information card. This will ensure you are notified about new traffic monitoring technologies as they emerge. VECTOR 990 Internationalcontains Shadow Technology ® IImaking it undetectable to the Interceptor VG-2 Radar Detector Detector. Shadow Technology is activated at all times – no button activity is required. The custom Anodized Aluminum Travel Case is designed to protect your unit and its accessories when not in use. Enjoy your new purchase and please drive safely. 2 Includes 16 Driver Selectable Features 5 Operating Modes11 General Features Normal Mode Modifications Mode Quick-StartX Band (10.525 GHz) On/Off Tech Mode Voltage Meter ModeK Band (24.125 GHz) On/Off Super Wideband Ka (33.4-36.0) AccuSweep™ Operating modes are Selected using PWR Button See page 00. AutoMute On/Off Radar/Laser Digital Voice Prompts On/Off Safety Warning System ™ On/Off Safety Warning System Digital Voice or Tone Audio/Visual Scroll Rate Fast/Slow Inverted Display Option AutoScan General Features selected by pressing CTY button followed by the PWR Button when the unit is off. Operating Modes are selected using the PWR button ( see page 5.) General Selectable Features are accessed by pressing the PWR and CTY buttons simultaneously, when the unit is off. (see page 11.) Note: for convenience AutoScan ™ is accessed using the CTY button (see page 9.) VECTOR 990Internationalprovides more user Selectable Features than any other detector on the market. Selectable Features allow you to “customize” how alerts will be presented to you. 5Operating Modes 1. NORMAL Mode A lengthy power up test sequence; text messages identify alerts received, i.e. “ XX BBaanndd ”. 2. MODIFICATIONS Mode Full Power-up test sequence; presents ONLY those General Selectable Features which you have altered from factory pre-set. Text messages identify alerts received. 3. QUICK START Mode No test sequence; unit immediately shows last used traveling mode:“ AAuuttooSSccaann ™ ”, “ HHiigghhwwaayy ”, “ CCiitt yy XX ” “ CCiitt yy AALLLL ”, Text messages identify alerts received. 4. TECH Mode Full Power-up text sequence. Text messages identify band received followed by ACTUAL police traffic radar or Laser frequency, i.e., “ 2244..115500 ” to confirm K band. 5. VOLTAGE METER Mode Full Power-up text sequence. Text Messages identify band received. Between alerts, display shows readout of your vehicle’s battery voltage. 11General Selectable Features 1. X Band (10.525 GHz) ONor OFF 2. K Band (24.150 GHz) ONor OFF 3. Super Wideband Ka (33.4 – 36.0 GHz) ONor OFF 4. AccuSweep ™ ONor OFF 5. AutoMute ONor OFF 6. Radar/Laser Digital Voice Prompts ONor OFF 7. Safety Warning System ™ ON/OFF 8. Safety Warning System ™ Digital Voice ONor OFF 9. Audio/Visual Scroll Rate: FA ST o r SLOW 10. Inverted Display Option ONor OFF 11. AutoScan ™ , “Highway”, “City X”or “City ALL.” 33 Table of Contents Profile of Features . . . . . . . . . . . . . . . . . . . . . . . . .4 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . .5 k Power-Up Test Sequence/Start-Up Mode . . . .5 k Tutorial Mode . . . . . . . . . . . . . . . . . . . . . . . . .7 k Set and Forget Memory . . . . . . . . . . . . . . . . . .8 k Reset to Factory Settings . . . . . . . . . . . . . . . . .8 k DRK (Bright/Dim/Dark) Button . . . . . . . . . . .8 k AUD (Auto-Mute/Volume Control) Button . . .9 k CTY (City/Highway) Button . . . . . . . . . . . . . .9 Selectable Features (North American Mode) . . . . . . . 11 k Travel Mode – What is it? . . . . . . . . . . . . . . . . 14 k Engaging Travel Mode . . . . . . . . . . . . . . . . . . . 14 k Entering Selectable Features . . . . . . . . . . . . . . 16 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 k General Guidelines . . . . . . . . . . . . . . . . . . . . . . 16 Understanding Radar, Laser…

Text truncated - open the document above for the full version.

Modifications not expressly approved by the manufacturer could void the user’s FCC granted authority to operate the equipment. Printed in Canada153003-00 11263_FCC card insert 8/28/02 5:06 PM Page 1 11263_FCC card insert 8/28/02 5:06 PM Page 2

Curtis-Straus LLC 527 Great Road Littleton, Massachusetts 01460 Tel: 978.486.8880 Fax: 978.486.8828 Web: www.curtis-straus.com Worldwide Regulatory Approvals Experts ® Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with 47 CFR 0.457(d)(2) pertaining to confidential material. Beltronics USA, Inc. requests that the following documents regarding this submission for FCC ID: QL4G2S7I be kept confidential: 1. Block Diagram 2. Circuit Description 3. Schematic 4. Model Groupings The material above contains technical data, which would customarily be guarded from competitors. We at Curtis-Straus LLC are acting as an Agent on behalf of Beltronics USA, Inc. in requesting confidentiality with regards to the preceding documents. Sincerely, Michael Buchholz Senior EMC Manager Curtis-Straus LLC 527 Great Road Littleton, MA 01460

External Photos Model: Vector 990 FCC ID: QL4G2S7I Model: Vector 990 FCC ID: QL4G2S7I Model: Vector 990 FCC ID: QL4G2S7I

Internal Photos Model: Vector 990 FCC ID: QL4G2S7I Model: Vector 990 FCC ID: QL4G2S7I

Company: Beltronics USA, Inc. FRN: 0007600588 Models: Vector 990 FCC ID: QL4G2S7I Equipment Code: CRD Report prepared for: Report prepared by: Beltronics USA, Inc. Evan D. Gould 5442 West Chester Road Curtis-Straus LLC West Chester, OH 45069 527 Great Road Phone: (513)-870-8535 Phone: (978)-486-8880 FAX: (513)-870-8523 FAX: (978)-486-8828 EMC Manager Worldwide Regulatory Approvals Experts (A2LA Certificate Number 1627-01) Technical Report REPORT:C0610-2 FCC ID:QL4G2S7I Page 2 of 8 Introduction This report is an application for Certification of Radar Detectors operating pursuant to 47 CFR 15.109, as amended by ET Docket No. 01-278; FCC 02-211, published in the Federal Register Vol. 67, No. 145 on Monday July 29, 2002. REPORT:C0610-2 FCC ID:QL4G2S7I Page 3 of 8 Statement of Conformity 47 CFR 15.109(h) states that “Radar detectors shall comply with the emissions limits...of [section 15.109(a)] over the frequency range of 11.7 – 12.2GHz.” The applicable limit being 500μV/m measured at a distance of 3m. The Beltronics Vector 990 has been tested and found to comply with this requirement. REPORT:C0610-2 FCC ID:QL4G2S7I Page 4 of 8 Test Methodology Radiated emission testing was performed according to the procedures in ANSI C63.4 (2001). The testing was performed at an antenna to EUT distance of 1 meter. Performance was investigated in the range 11.7-12.2GHz. The Vector 990 was powered by a R.O.C. SPN4025A 12VDC 400mA power supply. Since the device is a hand-held unit, the emissions were maximized around the three orthogonal axes and the maximum reading was recorded. The integrated antenna cannot be maximized separately. REPORT:C0610-2 FCC ID:QL4G2S7I Page 5 of 8 Test Equipment SPECTRUM ANALYZERS x Analyzer Model No. Company Serial No. Calibration Due X ORANGE 9kHz-26.5GHz E4407B HP US39440975 07-JUN-2003 OPEN AREA TEST SITES (OATS) x Site FCC Code IC Code VCCI Code Calibration Due X “T” Texas 93448 IC 2762-T R-905/ C-480 04-FEB-2004 ANTENNAS x Antenna Model No. Company Serial No. Calibration Due X BLACK Horn: 1-18GHz 3115 EMCO 9703-5148 12-JUN-2003 PREAMPLIFIERS / ATTENUATORS x Preamplifier Model No. Company Serial No. Calibration Due X ORANGE-BLACK 1-20GHZ SMC-12A MITEQ 690639 06-SEP-2002 Unless otherwise noted the calibration interval is one year. All equipment is calibrated using standards traceable to NIST or other nationally recognized calibration standard. All Open Area Test Sites are located at 527 Great Road, Littleton, MA 01460. REPORT:C0610-2 FCC ID:QL4G2S7I Page 6 of 8 Setup Photo Model: Vector 990 REPORT:C0610-2 FCC ID:QL4G2S7I Page 7 of 8 Measurement Results All measurements taken were peak detector readings of the noise floor. There were no emissions detected from the EUTs. Radiated Emissions Table Curtis-Straus LLC Date:08-Aug-02Company:BeltronicsTable1 Engineer:Evan GouldEUT Desc:various radar detector modelsWork Order:C0610 Frequency Range:11.7-12.2GHzMeasurement Distance:1 m Notes:Emissions maximized Horizontally and Vertically. All measurements are noise floor readings. AntennaPreampAntennaCableAdjusted47 CFR 15.209(a) PolarizationFrequencyReadingFactorFactorFactorReadingLimitMarginResult (H / V)(MHz)(dBμV)(dB)(dB/m)(dB)(dBμV/m)(dBμV/m)(dB)(Pass/Fail) V99012190.031.420.038.94.755.063.5-8.5Pass Test Sites:"T"Pre-Amp:Or-BlkCable:3m MicroflexAnalyzer:OrangeAntennas:Black Horn REPORT:C0610-2 FCC ID:QL4G2S7I Page 8 of 8 Emission Plot

REPORT:C0610-2 FCC ID:QL4G2S7I Page 6 of 8 Setup Photo Model: Vector 990
