QN8-MH100Telehealth Gateway

VA Test App Manual 2 COTENTS VA TEST APP MANUAL ..............................................................1 1. OVERVIEW ..............................................................................3 1.1 Test preparation ................................................................................... 3 2. APP ..........................................................................................3 2.1 Test App ................................................................................................. 3 3. TEST PROCEDURE .................................................................5 3.1 BT Connection ...................................................................................... 5 3.2 How to Perform the test .................................................................... 7 * Manual and actual contents may be different, and may be changed without prior notice for performance improvement. 3 Overview This manual describes how to use the test app to test MH100's firmware for VA. 1.1 Test preparation 1. FW : MH100 ver 1.0.1A 2. App : HubConnectSample.apk 2. App 2.1 Test App 1. Connect : Connect to MH100's modem control server 2. Disconnect : Terminate connection with server for modem control of MH100 3. State : Check the connection status of the MH100's modem control server 4. Login : Login to Hub's modem control server 4-1. Modem server ID 4-2. Modem Server Password 1. 2. 4. 3. 5. 7. 8. 6. 4-1. 4-2. 7-1 7-2 7-3 7-4 4 5. Get PPP Connection State: Check the modem connection status 6. Info : Check MH100 information, serial number, firmware version, etc 7. Call : Internet connection to the PPP server via modem If your PPP server connection is successful, provide your tablet with internet via Bluetooth 7-1 : PPP server phone number 7-2 : ID for PPP server authentication 7-3 : Password for PPP server authentication 7-4 : PPP Server Option Values 8. Hangup : Terminate modem connection 5 3. Test procedure 3.1 BT Connection 1. Turn off the tablet's WIFI 2. BT Search 3. When the serial of the MH100 you want to connect is displayed, pair with the device 6 4. When pairing is complete, select the device name again to connect the Bluetooth 7 3.2 How to Perform the test 1. Connect to MH100's modem control server 2. Log in to the modem control server 8 3. Check the connection status 4. Check MH100 information 9 5. Modem connection 6. Stop modem connection 7. Important Cautions This device comply with part15 of FCC rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. 10 • This device & its accessories must accept any interference received, including interference that may cause undesired operation. Part15.21 statement Changes or modifications not expressly approved by the manufacturer (or party responsible) for compliance could void the user’s authority to operate the equipment This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.

Seers Technology Co., Ltd. #1210, Tech Dong, SKn Technopark 190-1 Sangdaewon-dong, Jungwon-gu Sungnam-si South Korea Date: March 17, 2021 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Nam Taehyeon of BWS TECH Inc. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: QN8-MH100 including signing of all documents relating to these matters. Any and all acts carried out by Nam Taehyeon of BWS TECH Inc. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Seers Technology Co., Ltd. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Dae Yeop Kang / Direct

Seers Technology Co., Ltd. #1210, Tech Dong, SKn Technopark 190-1 Sangdaewon-dong, Jungwon-gu Sungnam-si South Korea Date: March 17, 2021 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA RE: Request of Confidentiality for FCCID: QN8-MH100 To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Seers Technology Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Seers Technology Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Operational Description 4 Part Lists SHORT-TERM 5 Internal Photos 7 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Dae Yeop Kang / Direct

FRONT BACK LEFT RIGHT TOP BOTTOM BOTTOM_OPEN

Label Information 1. Label Location 2. Label

Feeding point

INSIDE MAIN BOARD(TOP) MAIN BOARD(BOTTOM) SUB BOARD(TOP) SUB BOARD(BOTTOM)

Seers Technology Co., Ltd. Telehealth Gateway FCC ID : QN8-MH100 RF Exposure Report Issue Date : March 16, 2021 RF Exposure 1. Standard Requirement According to §15.247 (i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. 2. Limits : 3. EUT RF Exposure The max. power of channel, including tune-up tolerance is 3.76 dBm in High channel(2.480GHz); 3.76dBm logarithmic terms convert to numeric result is nearly 2.38 mW. According to the formula. Calculate the EIRP test result: [(max.power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] * [√f(GHz)] General RF Exposure = (2.38 mW / 5 mm) x √2.402GHz = 0.74 ... ① SAR requirement: S=3.0 ... ②; ① < ②. So the SAR report is not required.

verify No.591437628523 Seers Technology Co., Ltd. Telehealth Gateway FCC ID : QN8-MH100 Report No: BWS-21-RF-0003 FCC Test Report Page Number: Page 2 to 33 BWS TECH Inc. Data of Issue: March 15, 2021 F-LQP-15-43(2) Report Revision TEST REPORT NO. DATE DESCRIPTION BWS-21-RF-0003 March 15, 2021 - First Approval Report Seers Technology Co., Ltd. Telehealth Gateway FCC ID : QN8-MH100 Report No: BWS-21-RF-0003 FCC Test Report Page Number: Page 3 to 33 BWS TECH Inc. Data of Issue: March 15, 2021 F-LQP-15-43(2) TABLE OF CONTENTS 1. General Information .................................................................. 4 1.1 Applicant ................................................................................. 4 1.2 Manufacturer .............................................................................. 4 1.3 EUT Description ......................................................................................... 4 1.4 Other Information ....................................................................................... 4 2. Description of Test Facility ......................................................... 5 3. Test Methodology ..................................................................... 6 3.1 EUT Configuration ....................................................................... 6 3.2 EUT Exercise ............................................................................. 6 3.3 FCC Part 15.205 Restricted Bands of Operations ............................................. 6 3.4 Description of Test Modes .......................................................................... 6 4. Summary of Test Result ........................................................................ 7 5. Test Equipment ................................................................................. 8 6. Test Data .......................................................................................... 9 6.1 AC Power Line Conducted Emission ...................................................... 9 6.2 Peak Output Power Measurement............................................................... 12 6.3 Power Spectral Density .................................................................... 15 6.4 6 dB Bandwidth ...................................................................................... 18 6.5 Conducted Spurious Emission................................................................... 21 6.6 Band Edges Measurement ....................................................................... 24 6.7 Radiated Spurious Emission...................................................................... 27 6.8 Antenna Application ........................................................................... 33 Seers Technology Co., Ltd. Telehealth Gateway FCC ID : QN8-MH100 Report No: BWS-21-RF-0003 FCC Test Report Page Number: Page 4 to 33 BWS TECH Inc. Data of Issue: March 15, 2021 F-LQP-15-43(2) 1. General Information Scope – Measurement and determination of electromagnetic emission(EME) of radio frequency devices including intentional radiators and/or unintentional radiators for compliance with the technical rules and regulations of the U.S Federal Communications Commission(FCC) 1.1 Applicant ⚫ Company Name : Seers Technology Co., Ltd. ⚫ Company Address : #1210, Tech Dong, SKn Technopark 190-1 Sangdaewon-dong, Jungwon-gu Sungnam-si South Korea ⚫ Phone/Fax : Tel No. : +82-31-8023-9811 Fax No. : +82-31-8023-9812 1.2 Manufacturer ⚫ Company Name : Seers Technology Co., Ltd. ⚫ Company Address : #1210, Tech Dong, SKn Technopark 190-1 Sangdaewon-dong, Jungwon-gu Sungnam-si South Korea ⚫ Phone/Fax : Tel No. : +82-31-8023-9811 Fax No. : +82-31-8023-9812 1.3 EUT Description ⚫ Equipment : Telehealth Gateway ⚫ Model(s) : MH100 ⚫ Operation Frequency : 2402 MHz ~ 2480 MHz (Bluetooth) ⚫ Number of Channels : BLE Channel 40 ⚫ Modulation Method : 1Mbps GFSK ⚫ Power Tolerance : +/- 2dB ⚫ Input Voltage : DC 12 V ⚫ Antenna Peak Gain : 1.99 dBi 1.4 Other Information ⚫ FCC Rule Part(s) : Part 15 Subpart C §15.247 ⚫ FCC ID : QN8-MH100 ⚫ Test Procedure : ANSI C63.10-2013 KDB 558074 D01 DTS Meas Guidance v05r02 ⚫ Date of Test : January 19, 2021 to March 15, 2021 ⚫ Place of Test : BWS TECH Inc. (FCC Registration Number : 287786) #23, Gokhyeon-ro 480 Beon-gil, Mohyeon-eup, Cheoin-gu, Yongin-si, Gyeonggi-do 17031, South Korea TEL: +82 31 333 5997 FAX: +82 31 333 0017 Seers Technology Co., Ltd. Telehealth Gateway FCC ID : QN8-MH100 Report No: BWS-21-RF-0003 FCC Test Report Page Number: Page 5 to 33 BWS TECH Inc. Data of Issue: March 15, 2021 F-LQP-15-43(2) 2. Description of Test Facility Site Description Test Lab. : NRRA Designation Number is KR0017. The Certificate Designation Number is KR0017. The Certificate Accreditation Number is KT174. Name of Firm : BWS TECH Inc. Site Location : #23, Gokhyeon-ro 480 Beon-gil, Mohyeon-eup, Cheoin-gu, Yongin-si, Gyeonggi-do 17031, South Korea Seers Technology Co., Ltd. Telehealth Gateway FCC ID : QN8-MH100 Report No: BWS-21-RF-0003 FCC Test Report Page Number: Page 6 to 33 BWS TECH Inc. Data of Issue: March 15, 2021 F-LQP-15-43(2) 3. Test Methodology The tests documented in this report were performed in accordance with ANSI C63.10: 2013 and the requirements of FCC Rules Part 15.207, 15.209 and 15.247. Radio testing was performed according to KDB 558074 D01 DTS Meas Guidance v05r02. 3.1 EUT Configuration The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and is operated in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT Exercise The EUT was operated in the engineering mode to fix the TX frequency that was for the purpose of the measurements. According to its specifications, the EUT must comply with the requirements of the Section 15.207, 15.209 and 15.247 under the FCC Rules Part 15 Subpart C. 3.3 FCC Part 15.205 Restricted Bands of Operations (a) Except as shown in pa…
