QNU-VPSPIO-02USB External HDD KIT

User’s Manual 1. Product Introduction z Super slim & light mobile storage device using 2.5” HDD z Supporting both USB2.0 and IEEE1394 with lightning speed z One touch assembly without screws z Blue LED for operation indicator z No external power required z Plug & Play and Hot Plugging z Scheduling auto back-up software z Aluminum for heat management & deluxe case 2. Specification Interface USB 2.0 USB 2.0 + IEEE 1394 Model SPIO 252 SPIO 255 Transfer Rate 480Mbps 480Mbps / 400Mbps Hard Disk 2.5”, 9.5mm IDE Hard Disk Domension 128 x 75 x 145 (D x W x H) Weight 180g (HDD included) Power Source Bus Power Windows 98 / 98SE / ME / 2000 / XP (IEEE1394 is supported from Win98SE) OS Mac OS 8.6 Higher Contents SPIO, Cable, Driver & Auto backup Software CD, Manual, Leather Bag 3. System Environment [ Windows PC ] z USB 2.0 / 1.1 - System : Pentium or higher IBM compatible PC or Mac - Memory : Over 32MB - OS : Windows 98 / ME / 2000 / XP, Mac OS 8.6 & higher - Interface : USB2.0 / 1.1 port (For USB2.0 support, USB2.0 based main board or USB 2.0 PCI card, or PCMCIA cards are required) - CD Drive for driver installation or internet connection for download of installation driver z IEEE 1394 - System : Pentium or higher IBM compatible PC or Mac - Memory : Over 32MB - OS : Windows 98 / ME / 2000 / XP, Mac OS 8.6 & higher (IEEE1394 is not available under Win98) - Interface : IEEE1394 port (If the port is not exist in the PC, IEEE1394 PCI card, or PCMCIA cards are required) - CD Drive for driver installation or internet connection for download of installation driver [Macintosh] z USB 2.0/1.1 - System : PC that has USB port - Memory : Over 32MB - OS : Mac OS 8.6 & higher - CD Drive for driver installation or internet connection for download of installation driver z IEEE 1394 - System : iMAC, G3 higher (PC that has IEEE1394 port) - Memory : Over 32MB - OS: Mac OS 8.6 & higher - CD Drive for driver installation or internet connection for download of installation driver 4. Caution z New hard disk requires FDISK and Formatting. SPIO can’t be detected in the computer without this process. z Do not drop or aggressively handle the SPIO. It may cause damage to the hard disk. z Avoid exposing the SPIO to the magnetic like a speaker and humidity. It may cause damage to the hard disk.. z Do not remove or disconnect the SPIO from PC while the SPIO is transferring the data. It may cause damage to hard disk. <On the data loss resulted from ignoring above notes, Valueplus Inc. is not responsible for it.> 5. Name of each part Power / Blue LED for operation indicator IEEE1394 port Switch USB port 6. Hardware Installation 1) Please disassembly “SPIO” to insert Harddiskdrive. Step 1. Push the button. Tb Step2.Slidethecovertothearrowdirection. Step 1. Push the button. Step2.Slidethecovertothearrowdirection. * Warning. Do not lift up the top case over around 10 degrees. (Hook of aluminum cover in circle area can be broken due to excessive lift Top Case Disassembly BottomCaseDisassembly Push Button Step 3. Screw and fix the HDD with mid-frame. Step 1. Insert the Hard disk into HDD connector. Step 2. Put the board in the plastic mid-frame. 2) Assemble HDD into the mid-frame. 3) Assembly “SPIO” Step 2. Lock the case on a mid frame. BottomCaseAssembly TopCaseAssembly Step 1. Slide the cover to the arrow direction. Insert the hook of cover into the hole of mid frame. Step 2. Lock the case on a mid frame. Step 1. Slide the cover to the arrow direction. Insert the hook of cover into the hole of mid frame. 7. Installation Guide z USB (1) USB mode: Select the switch to “USB”(Left) USB(1394 POWER) USB 1394 USB USB (2) When the power is not enough from one USB port, please use USB DC Jack shown as below picture. USB DC Jack will provide extra power from another USB port. Switch should be “USB”(Left). USB USB USB USB(1394 POWER) USB 1394 z IEEE 1394 (1) 6pin to 6pin: Select the switch to “1394”(Right) USB(1394 POWER) USB 1394 1394 1394 (2) When the power is not enough from 6pin port, power can be provided from the USB port. Select the switch to “USB(1394 POWER)”(Middle) USB(1394 POWER) USB 1394 USB USB USB 1394 1394 (3) 6pin to 4pin: Power should be provided from the USB port. Select the switch to “USB(1394 POWER)”(Middle) USB(1394 POWER) USB 1394 1394 4Pin 1394 USB USB USB 8. Driver Installation z USB <Installation under Windows 98/ 98SE > 1) After connecting the SPIO to your computer, the Plug & play function will detect the SPIO. 2) When ‘Add New Hardware Wizard’ is shown, follow the installation process as below picture. (1) (2) (3) (4) (5) * After USB driver is installed completely, start installing IEEE1394 driver. (8) (7) (6) (9) (10) (11) < Driver Installation under Windows ME / 2000 / XP > SPIO is automatically detected without driver installation under Windows ME, 2000, XP. < Driver Installation under Mac OS 8.x ~ 9.x > SPIO is automatically detected without driver installation under Mac OS 8.6 higher. z IEEE 1394 < Driver Installation under Windows 98 SE > Driver installation is not required at Windows98SE. However, sometimes when you use at the Windows98 SE system, you can get the message “Insert Windows CD”. Please insert Windows 98SE CD in CD-Rom. Required driver will be installed automatically. * Windosw 98 does not support IEEE1394 interface. < Driver Installation under Windows ME / 2000 / XP > SPIO is automatically detected without driver installation under Windows ME, 2000, XP. < Driver Installation under Mac OS 8.6 ~ 9.0 > Please down load “Firewire enabler” at Macintosh Homepage (http://www.apple.com ) and install it. SPIO will be detected after rebooting the system. < Driver Installation under Mac OS 9.0 higher > SPIO is automatically detected without driver installation under Mac OS 9.0 higher. 9. Safe way to remove SPIO z Windows 1) Finish all operation of SPIO before removing. Click the left button of mouse on the USB icon in the system tray, and select the message “Stop – [DiskDrive]HDD Model name”. 2) When you get…

Text truncated - open the document above for the full version.

Test report Our reference : KEL02-F05069 Page : B1 of Appendix Issued date : 2003-06-03 Korea EMC Laboratory Appendix-B : External Photographs of E.U.T <FRONT VIEW OF EUT> <REAR VIEW OF EUT>

Test report Our reference : KEL02-F05069 Page : D1 of Appendix Issued date : 2003-06-03 Korea EMC Laboratory Appendix-D : FCC ID label location information and Sample - FCC ID label location information The label included following statement will be attached on the bottom side of product. - FCC ID label sample

Test report Our reference : KEL02-F05069 Page : C1 of Appendix Issued date : 2003-06-03 Korea EMC Laboratory Appendix-C : Internal Photographs of E.U.T <INTERNAL VIEW OF E.U.T> Test report Our reference : KEL02-F05069 Page : C2 of Appendix Issued date : 2003-06-03 Korea EMC Laboratory <FRONT VIEW OF MAIN BOARD> Test report Our reference : KEL02-F05069 Page : C3 of Appendix Issued date : 2003-06-03 Korea EMC Laboratory <REAR VIEW OF MAIN BOARD> Test report Our reference : KEL02-F05069 Page : C4 of Appendix Issued date : 2003-06-03 Korea EMC Laboratory <FRONT VIEW OF HDD> Test report Our reference : KEL02-F05069 Page : C5 of Appendix Issued date : 2003-06-03 Korea EMC Laboratory <REAR VIEW OF HDD>

CERTIFICATE OF COMPLIANCE 352 Youngduk-Ri, Kihung-Eup, Yongin-City, Kyunggi-Do, Korea 449-908 TEL : (82)31-206-4693 FAX : (82)31-206-3051 http://www.kesilab.com [email protected] http://www.koreaemc.co.kr [email protected] (CLASS B) CERTIFICATION OF COMPLIANCE is hereby issued to the named Applicant and is VALID ONLY for the equipment identified below: Date of Tested : May. 30. 2003 Applicant’s Name : ValuePlus, Inc. Applicant’s Address : 8F, Hyundai Office Bldg., Sunae dong, Bundang ku, Seongnam, Kyungki-, Korea Manufacturer’s Name : ValuePlus, Inc. Manufacturer’s Address : 8F, Hyundai Office Bldg., Sunae dong, Bundang ku, Seongnam, Kyungki-, Korea Declares that the product Product Description : USB External HDD KIT Brand Name : SPIO Model Number : spio 255 FCC ID : QNU-VPSPIO-02 Conforms to FCC Rules and Regulations Part 15 Subpart B requirements. This product herewith complies with the requirements of the FCC Rules and Regulations as listed below: Part 15.107: Conducted Emissions. Part 15.109: Radiated Spurious Emissions. TESTED and CERTIFIED by: KOREA EMC LABORATORY 352 Youngduk-Ri, Kihung-Eup, Yongin-Si, Kyunggi-Do, 449-908, KOREA Date : June. 03. 2003 Report No : KEL02-F05069 Authorized Signature : M. S. CHO / President Test report Our reference : KEL02-F05069 Page : 2 of 13 Issued date : 2003-06-03 Korea EMC Laboratory TABLE OF CONTENTS DESCRIPTION Page 0. VERIFICATION OF COMPLIANCE 3 1. GENERAL INFORMATION 1.1 Product Description 4 1.2 Related Submittal(s)/Grant(s) 4 1.3 Tested System Details 4 1.4 System Configuration 4 1.5 General Setup of the test Shield room 5 1.6 Test Facility 5 2. Measurement Procedure 2.1 System test configuration 6 2.1.1 Video mode Justification 6 2.1.2 EUT Exercise S/W 6 2.2 Special Accessories 6 2.3 Equipment Modification 6 2.4 Connected Cable 6 2.5 System Configuration Diagram 6 2.6 Preliminary testing 7 2.7 Shielded Enclosure 7 2.8 Data Reporting Format 7 2.9 Operating Condition 7 2.10 Conditioning of the EUT 7 2.11 Power Line Conducted Emissions 8 2.12 Open field Radiated Emissions Tests 8 3. Measurement Data 3.1 Conducted Emission Data 9 3.2 Conducted Emission Graph 10 3.3 Radiated Emission Data 11 3.4 Summary 12 4. Labeling Requirement 13 Appendix - A : Test set-up Photographs (Conducted and Radiated) - B : External Photographs of E.U.T - C : Internal Photographs of E.U.T - D : FCC ID label location information and sample - E : Block Diagram - F : User’s Manual Test report Our reference : KEL02-F05069 Page : 3 of 13 Issued date : 2003-06-03 Korea EMC Laboratory 0 . VERIFICATION OF COMPLIANCE Equipment Under Test : USB External HDD KIT Model Number : spio 255 Serial Number : Prototype Manufacturer : ValuePlus, Inc. 8F, Hyundai Office Bldg., Sunae dong, Bundang ku, Seongnam, Kyungki-, Korea Type of Test : FCC CLASS B Report Number : KEL02-F05069 Date Tested : May. 30. 2003 Tested By : S. J. LEE The results show that the sample equipment tested as described in this reports is in compliance with the CLASS B conducted and radiated emission limits of FCC Rules Part 15, Subpart B. Test report Our reference : KEL02-F05069 Page : 4 of 13 Issued date : 2003-06-03 Korea EMC Laboratory 1. GENERAL INFORMATION 1.1 PRODUCT DESCRIPTION The spio 255 is a USB External HDD KIT made by ValuePlus, Inc. in Korea. Refer to the user's manual for more information. ITEM SPECIFICATION Interface USB 2.0 + IEEE1394 Transfer rate: 480Mbps / 400Mbps Dimension 128 mm x 75 mm x 14.5 mm 1.2 Related Submittal(s)/Grant(s) N/A 1.3 Tested System Details Type Model Name FCC ID Serial NO Manufacturer USB External HDD KIT spio 255 QNU-VPSPIO-02 Prototype ValuePlus, Inc. PC VECTRA VL400MT DoC SG05005352 HP Monitor TGIC-LC1710P DoC FHUJ350009149 PROVIEW Keyboard SK-2502C DoC M011208657 HP Mouse M-S48a DoC HCA21509514 LOGITECH Adapter LSE9901B1250 Verification NONE LI SHIN USB Mouse U813I-O DoC K020803612 HP Serial Mouse M-CE15 DZLMCE15 LT292R00295 LOGITECH Speaker ST-40 - NONE TRIGEM MIC RM-1000 - NONE HANIL Printer 2225C DSI6XU2225 3119S96116 HP Adapter 0912-TY Verification NONE HANSUNG 1.4 System Configuration Type Model Name Serial NO Manufacturer Remark Main B/D HDD SPIO 255 MHS2030AT NONE NL02T2A12RC1 ValuePlus, Inc. Fujitsu(Thailand)Co., Ltd. Korea Thailand Test report Our reference : KEL02-F05069 Page : 5 of 13 Issued date : 2003-06-03 Korea EMC Laboratory 1.5 General Set-up of the Test Shielded Room The EUT was set up in accordance with the suggested configuration given in FCC measurement Procedure ANSI C63.4 2000. The measurement are performed in the shielded room which dimension is 3.0*7.0*2.5(m). The EUT was placed on a non conductive table which is 1.0*1.5(m), 80 cm above an earthed ground plane and is kept at least 1m from any other earthed ground plane except the rear of table top being removed 40 cm from a vertical conducting plane. Power to the EUT was provided through the LISN(ESH3-Z5, Rohde & Schwarz) which has the Impedance vs Frequency Characteristic in accordance with the conducted setup photographs in Appendix-A Impedance Characteristic of LISN. Peripheral equipment required to provide a functional system(support equipment) for EUT testing was powered through another LISN(KNW-407, KYORITSU). Power to the LISN was filtered to eliminate ambient signal interference. A coaxial type connector which provides a 50 Ohm terminating impedance was provided for the test instrument. The excess length of the power cord was wrapped in the two non metallic pegs attached to the top of the LISN. The two pegs are 9 cm high, approximately 2.0 cm in diameter and that are spaced 6 cm on the center apart. 1.6 Test Facility Location: Korea EMC Laboratory 352 Yungduck-Ri Kihung-Eup,Yongin-City Kyungki-Do,Korea Site : - 3/10m Open Fielded Radiated - Indoor Line Conducted Room(Shielded) The Open Field Radiated and Indoor Line Conducted sites are constructed and calibrated to meet the FCC requirements in documents ANSI C63.4 2000. Korea EMC Lab. was refiled in FCC in Feb. 2001. INSTRUM…

Text truncated - open the document above for the full version.

Test report Our reference : KEL02-F05069 Page : A1 of Appendix Issued date : 2003-06-03 Korea EMC Laboratory Appendix-A : Test Setup Photographs - Conducted Setup Photographs LINE CONDUCTED SETUP PHOTOGRAPH - FRONT VIEW LINE CONDUCTED SETUP PHOTOGRAPH - REAR VIEW Test report Our reference : KEL02-F05069 Page : A2 of Appendix Issued date : 2003-06-03 - Radiated Setup Photograph RADIATED EMISSION SETUP PHOTOGRAPH - FRONT VIEW ( 30 - 300 MHz ) RADIATED EMISSION SETUP PHOTOGRAPH - REAR VIEW ( 30 - 300 MHz ) Test report Our reference : KEL02-F05069 Page : A3 of Appendix Issued date : 2003-06-03 Korea EMC Laboratory RADIATED EMISSION SETUP PHOTOGRAPH - FRONT VIEW ( 300- 1000 MHz ) RADIATED EMISSION SETUP PHOTOGRAPH - REAR VIEW ( 300 - 1000 MHz )
