QNX-BIO-007Reader w/ Keypad / Finger Print Recognition

Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 PROXIMTY READER PLUS KEYPAD PLUS FINGER PRINT RECOGNITION Model: BIO 007 Output formats: Prox. Card Wiegand 26 ( Factory Default ) Keypad 8 Bit Burst Power Supply 10 - 24 VDC Power Consumption: less than 100 mA in stand by Transmitter/Receiver frequency: 125Khz Mounting: Universal USA and EUROPE Environment: IP68 ; 100% relative humidity Operating Temperature: - 25 to + 70ºC ( -15 to 158 F ) Dimensions: 120 x 90 x 20 ( 4,72" / 3.54" /0.79" ) Antitamper Optical protection Certifications: Operation Modes: The BIO 007 is equipped with 3 electronically interlocked devices. The Proximity Reader, the Piezoelectric Keypad and the Finger Print Recognition. 1. Prox – Pin. Present Prox card. The unit will read the content and send it over the Data wires to the host. Enter PIN code. The unit will send each digit over the same Data wires to the host. The Keypad and the Prox reader are interlocked so that when one is functioning the other is inhibited until the data is transmitted. 2. Prox Only. The prox electronics is independently communicating via Data wires. 3. Prox-Pin-Finger_Print_Reader Verification Power up the unit. During the first 2 seconds the unit will activate the buzzer 3 times. In the same time the RED or the Green LED will come ON depending on the Central Computer setup. Present a valid HID encrypted card at 5 cm distance maximum. The unit will activate the Buzzer once. Each key press will activate the Buzzer and flash the Yellow LED . Wiring COLOR FUNCTION ELECTRICAL FUNCTION RED Input Voltage 10 – 24 VDC BLACK Ground GREEN Data 0 Open collector 1Kohm pull-up to internal +5V WHITE Data 1 Open collector 1Kohm pull-up to internal +5V BROWN LED Input 1 = Red LED ON 0 = Green LED ON GREY TX BLACK/ WHITE RX PINK GND Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 26 BIT WIEGAND SPECIFICATIONS When the LED control input is pulled low, the GREEN LED will be ON and the RED LED will be OFF. When the input goes high the RED LED is ON and the GREEN LED is OFF. The RED or GREEN LED will flash with each key press. The LED control input is pulled to the internal +5v with a 2.2K resistor. The data is sent at 2 millisecond. per bit with a pulse duration of 70 μsec. A Buzzer beeps with each key press. DATA FORMAT PIN data in 8 Bit burst output format: Each Key press generates the defined 8 bit Output as shown: KEY OUTPUT KEY Output 0 11110000 6 10010110 1 11100001 7 10000111 2 11010010 8 01111000 3 11000011 9 01101001 4 10110100 * 01011010 5 10100101 # 01001011 Card data 26 WIEGAND output format. P S S S S S S S S N N N N N N N N N N N N N N N N N P BIT 1 2 9 10 25 26 BIT 1 is an even parity for the following 12 bits. The sum of bits 1-13 is even. BITS 2-9 are the F/C the card presented from 000 to 255. BITS 10-25 this is the card number presented . Leading 0’s are added as required. Bit 10 is most significant. BIT 26 Odd parity over previous 12 bits. The sum of bits 14-26 is odd. EXAMPLE: A card code of 123 entered: 1 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 0 1 1 1 (F/C 004) The data is sent at 2 msec per bit with pulse duration of 70 μsec. A Buzzer beeps each time card is presented. 1. Orange Wire - When the Hold Line, Orange wire, is pulled “low”, any CARD PRESENTED DATA is stored in the buffer. When the Hold Line is released to logic “high” – the buffered data is sent NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by the party responsible for compliance Baran Advanced Technologies (86) LTD. could void the user’s authority to operate the equipment.

Processor Oscillator frequency 3.579 MHz Power Suply Red& Black I/O Green,White,Brown,Blue,, Orange,Grey Violet Housing Ground Leds Red ,Green Keypad Voltage Regulator PROX&KEYPAD Buzzer Module MCM4025A Oscillator frequency 125 kHz Antenna Leds Yellow I/O Green,White Block diagram of -BIO-007 Finger print sensor Power Supply Step motor Finger Print Reader + Step Motor Driver Fiinger Print Module Power Suply Red& Black RS232 TX=GREY RX=ORANGE GND=BLACK

June 20, 2005 American TCB 6731 Whittier Ave Suite C110 McLean, VA 22101 USA Subject: Application for certification of a proximity reader with a keypad and finger print recognition, model BIO-007, FCC ID:QNX-BIO-007 Dear Gentlemen, Please find attached our application for certification of proximity reader with a keypad and finger print recognition, model BIO-007, FCC ID:QNX-BIO-007, prepared in accordance with FCC Rules, part 15, subpart C, section 15.209 and subpart B. The product testing and this application for certification were performed by Hermon Laboratories, which is listed by FCC, Registration Numbers 90623, 90624. Hermon Labs responsible person is Mr. Alex Usoskin, tel: 011 972 4628 8001, fax:011 972 4628 8277, e-mail:[email protected]. Please send an invoice to Hermon Labs. We hope this application satisfies your requirements. Sincerely yours Raul Kafka Project manager

Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 2 of 3 Photograph No.1 BIO-007 front view Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 3 of 3 Photograph No.2 BIO-007 rear side view

FCC ID:QNX-BIO-007 Label BIO 007 FCC ID: QNX-BIO-007 Manufacturer: Baran Advanced Technologies (1986) Ltd. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, 2) and this device must accept any interference received, including interference that may cause undesired operation. FCC ID:QNX-BIO-007 Label location on the rear side of BIO-007 Label with FCC ID:QNX-BIO-007 FCC ID:QNX-BIO-007 FCC ID:QNX-BIO-007

Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 1 of 14 INTERNAL PHOTOGRAPHS This document contains 13 photographs Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 2 of 14 Photograph No.1 BIO-007 internal view Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 3 of 14 Photograph No.2 BIO-007 internal view Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 4 of 14 Photograph No.3 BIO-007 PCB second side view Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 5 of 14 Photograph No.4 BIO-007 PCB front side view Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 6 of 14 Photograph No.5 BIO-007 internal view Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 7 of 14 Photograph No.6 BIO-007 second PCB view Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 8 of 14 Photograph No.7 BIO-007 second PCB view Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 9 of 14 Photograph No.8 Controller PCB front side Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 10 of 14 Photograph No.9 Controller PCB second side Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 11 of 14 Photograph No.10 Keypad PCB front side Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 12 of 14 Photograph No.11 Keypad PCB front side Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 13 of 14 Photograph No.12 Antenna view Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 14 of 14 Photograph No.13 Antenna rear side view

Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Page 1 of 2 Operational description The BIO-007 is intended to be used as a part of Access Control System. The unit transmits to a host via two wires (DATA0 , DATA1) Wiegand data input from Keypad PIN number or proximity card. The finger print module transmits and receives data through three RS232 wires. A buzzer is giving acoustic feedback to each key press or card recognition. The BIO-007 consists of the following components: 1. Piezoelectric Keypad 2. Proximity Reader. 3. Antenna 4. Finger print reader 5. Step motor 6. Power supply for the finger print reader and the motor + motor driver. The components are linked to an electronic board that takes care of the unit proper functioning. The BIO-007 functioning is as follows: It performs 3 functions: 1. Reads proximity card and sends the data. When an appropriate encoded Proximity Card is presented within the antenna’s sensing range (approx 5 cm) the data from the Card is transferred to the electronic board. The electronic board decodes the encryption into a Serial Protocol (for example Wiegand) and sends it to a Host computer. 2. Piezoelectric Keypad is used to KEY-In the PIN number. The PIN number is sent as a Serial Protocol (for example, Wiegand) and sends it to a Host computer. 3. The Finger Print Reader reads finger prints and sends to host via RS232. The Host may require one of this function ore more. After the host gets the data it opens the door if criteria are met. The BIO-007 is equipped with a Buzzer and LEDs to facilitate the Human Machine Interface. A drawing of an integral antenna, manufactured by STANDEX, is shown on the next page:

55 44 33 22 11 D D C C B B A A Do not populate R22 Do not populate C2,R10,D4 R13For 007 project leave AS ITFor all other projects where YELLOW led activatedfrom MCM4025A REMOVE R13 and short RS3 padsC1,C2,R10,D4 Do not populate R26 <Doc> A01 80091212 PROXIMITY 12_24V DC + 007 Custom 11 Tuesday, March 09, 2004 TitleSize Document Number Rev Date: Sheet of GL mdat0 Beep1 Buz hold RL BuzGLED RL RLED YL YL GL Khold mdat1 VCC VCC VCC VCC VCC VCC VCC VCC VCCVCC VCC RV1 CNR07D390K 12 D6BAS16-03W C1 1000 pF R8 100 + C922uF 50V 12 R6 10 Q1SMBTA42 3 1 2 R15 100 R30100K D4BZX84C5V6L 31 2 DN2 BAV70 32 1 D10BYG23M BZ1BUZZER 1 2 R1020K Q4 SMBTA42 3 1 2 C111000 pF Q3 SMBTA42 3 1 2 DN3 BAV70 3 2 1 R11K R24 2.2K Q5 SMBTA42 3 1 2 BLU1Cctv 1 R23 2.2K R22 5.11K 1% RS4 0 R22.2K R7 2.2K R18 2.2K R20 100 CN34 1 8 234 765 DD4 SMAJ15CA R11470 R17 100 CN34 1 8 234 765 DD3 SMAJ15CA TP1 1 R29 2.2K JP1ANT 12 C8 2400pF GRN1Dat0 1 U3 LM2594HVN-5.0 1237 6548 NCNC1NC3VIN GND ON/OFF FB OUTPUT RED1Vin_24V 1 R282.2K R16 10 C2 100 pF R192.2K RS2 0 + C12 100uF 16V-D 12 GRY1Tamper 1 D1 GREEN LED 12 D2 RED LED 12 RS3 0 BLK1Gnd 1 R32.2K R92.2K C5 33pF C101uF U2MCM4 025A 1 234 6 9 10 11 1215 161823 24 25 26 2728 3029 5 MCLR DATA0DATA1CP GLED MDATAAMP BEEP1 BEEP2Input TX RX Bctrl GLctrl RLctrl Hctrl VDD GND ANT+ANT- RLED C3 1000 pF BRN1Lctrl 1 U1 PIC16F872 12345 6 7 8 910111213 1415 16 17 18 19 20 2122232425262728 MCLR/VPP/THV RA0/AN0RA1/AN1RA2/AN2/VREF-RA3/AN3/VREF+ RA4/T0CKI RA5/SS/AN4 GND OSC1/CLKIN OSC2/CLKOUT RC0/T1OSO/T1CKI RC1/T1OSI/CCP2 RC2/CCP1 RC3/SCK/SCLRC4/SDI/SDA RC5/SDO RC6/TX/CK RC7/RX/DT GND VDD RB0/INT RB1RB2 RB3/PGM RB4RB5 RB6/PGCRB7/PGD Q6 SMBTA42 3 1 2 R21 10 DD5 SMAJ15CA C15 390pF DN1 BAV70 32 1 R25 1K D7 BAS16-03W J1 CON5 12345 X1 3.579MHz 1 2 RS1 0 R42.2K R13470 D5 MBR0540 21 ORN1Hold 1 L1UP2B_331 1 2 C14_U2 0.1uF R12470 R141K D3 AMBER LED 12 D11SS26 12 C7 1000 pF R261K D9 SS26 1 2 VIOLET1SHIELD 1 Q2 LTR-3208 BIN E C13_U10.1uF C6 33pF DD2 SMAJ15CA DD1 SMAJ15CA R27 10 C4 1000 pF R5150K J2 HEADER 7 1234567 DD6 SMAJ15CA D8 BAS16-03W WTE1Dat1 1

Hermon Laboratories Ltd. P.O.Box 23, Binyamina 30500, Israel Tel. +972 4628 8001 Fax. +972 4628 8277 E-mail: [email protected] Page 1 of 36 Report ID: BARRAD_FCC.16415.doc Date of Issue: 6/15/2005 Electrical TEST REPORT ACCORDING TO: FCC CFR 47 PART 15 Subpart C, section 15.209 and subpart B FOR: Baran Advanced Technologies Ltd. PROXIMITY READER WITH KEYPAD AND FINGER PRINT RECOGNITION Model: BIO-007 This report is in conformity with ISO/ IEC 17025. The A2LA logo endorsement applies only to the test methods and the standards that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report shall not be reproduced in any form except in full with the written approval of Hermon Laboratories Ltd. Report ID: BARRAD_FCC.16415.doc Date of Issue: 6/15/2005 Page 2 of 36 Table of contents 1 Applicant information..................................................................................................................................................... 3 2 Equipment under test attributes .................................................................................................................................... 3 3 Manufacturer information .............................................................................................................................................. 3 4 Test details.................................................................................................................................................................... 3 5 Tests summary.............................................................................................................................................................. 4 6 EUT description............................................................................................................................................................. 5 6.1 General information....................................................................................................................................................... 5 6.2 Ports and lines .............................................................................................................................................................. 5 6.3 Support and test equipment .......................................................................................................................................... 5 6.4 Changes made in the EUT ............................................................................................................................................ 5 6.5 Test configuration.......................................................................................................................................................... 6 7 Transmitter tests according to 47CFR part 15 subpart C requirements ........................................................................ 7 7.1 Field strength of fundamental and unwanted emissions................................................................................................ 7 7.2 Conducted emissions .................................................................................................................................................. 14 8 Emission tests according to 47CFR part 15 subpart B requirements .......................................................................... 19 8.1 Conducted emissions .................................................................................................................................................. 19 8.2 Radiated emission measurements .............................................................................................................................. 24 9 APPENDIX A Test equipment and ancillaries used for tests....................................................................................... 28 10 APPENDIX B Measurement uncertainties................................................................................................................... 29 11 APPENDIX C Test facility description ......................................................................................................................... 30 12 APPENDIX D Specification references ....................................................................................................................... 30 13 APPENDIX E Abbreviations and acronyms................................................................................................................. 31 14 APPENDIX F Test equipment correction factors ......................................................................................................... 32 Report ID: BARRAD_FCC.16415.doc Date of Issue: 6/15/2005 Page 3 of 36 1 Applicant information Client name: Baran Advanced Technologies Ltd. Address: Baran House, 8 Omarim Street, Industrial Zone, Omer, 84965, Israel Telephone: +972 8620 0020 Fax: +972 8620 0021 E-mail: [email protected] Contact name: Mr. Raul Kafka 2 Equipment under test attributes Product name: Proximity reader with a keypad and finger print recognition Product type: Transmitter Model(s): BIO-007 Serial number: 2004090005 Receipt date 5/4/2005 3 Manufacturer information Manufacturer name: Baran Advanced Technologies Ltd. Address: Baran House, 8 Omarim Street, Industrial Zone, Omer, 84965, Israel Telephone: +972 8620 0020 Fax: +972 8620 0021 E-Mail: [email protected] Contact name: Mr. Raul Kafka 4 Test details Project ID: 16415 Location: Hermon Laboratories Ltd. P.O.Box 23, Binyamina 30500, Israel Test started: 5/4/2005 Test completed: 6/14/2005 Test specification(s): FCC Part 15, subpart C, §15.209; subpart B, §15.109 Test suite: FCC_15.225 (5/3/2004 5:43:04 PM, modified) Report ID: BARRAD_FCC.16415.doc Date of Issue: 6/15/2005 Page 4 of 36 5 Tests summary Test Status Transmitter characteristics Section 15.209 (a), Fundamental radiated emissions Pass Section 15. 209 (c), Unwanted radiated emissions Pass Section 15.2…

Text truncated - open the document above for the full version.

Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 1 of 5 SETUP PHOTOGRAPHS This document contains 4 photographs Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 2 of 5 Photograph No.1 Radiated emissions measurement setup in the anechoic chamber with loop antenna Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 3 of 5 Photograph No.2 Spurious radiated emissions measurement setup in the anechoic chamber with biconilog antenna Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 4 of 5 Photograph No.3 Spurious radiated emissions measurement setup in the anechoic chamber close view Baran Advanced Technologies (86) Ltd. FCC ID:QNX-BIO-007 Date: June 2005 Page 5 of 5 Photograph No.4 Conducted emissions test setup
