© 2005 Initium Co., Ltd. All rights reserved. by Bluetooth Enabling Wireless Serial Communications Promi- ESD01/ESD02™ User Manual Ver. 2.0 (2005.08.01) Promi-ESD User Manual – Products 2 © 2005 Initium Co., Ltd. All rights reserved. z Promi-SD/ESD Series Bluetooth Serial Adapter ESD01 ESD02 SD101 SD202 SD205 Part Number IP11-320 IP11-321 IP10-300 IP10-301 IP10-302 Description Board-type wireless serial adapter with MMCX antenna connector Board-type wireless serial adapter with on- board antenna External type wireless serial adapter with internal battery External type wireless serial adapter External type wireless serial adapter with dip switch Power Class Class1 Class2 Class2 Class1 Class1 RF Range Up to 100m Up to 30m Up to 30m Up to 100m Up to 100m Power Connector Header 2.54m Header 2.54m DC plug or 9 pin DC plug or 9 pin DC plug or 9 pin Power supply 3.3V 3.3V 5V 5V~12V 5V~12V Serial connector 2.54mm Header 2x6 2.54mm Header 1x4x2 Female DB9 Female DB9 Female DB9 Serial Interface UART UART RS-232 RS-232 RS-232 Dip switch No No No No Yes (4 slots) Battery No No Yes No No Profile Serial Port Profile Serial Port Profile Serial Port Profile Serial Port Profile Serial Port Profile Applicable Antenna Stub Antenna Dipole Antenna Patch Antenna Stub Antenna Dipole Antenna Patch Antenna Stub Antenna Dipole Antenna Patch Antenna Stub Antenna Dipole Antenna Patch Antenna Stub Antenna Dipole Antenna Patch Antenna Bluetooth Qualified Fully Fully Fully Fully Fully Type Approved FCC CE FCC CE TELEC MIC CE FCC TELEC MIC CE FCC MIC CE FCC Dimensions (H ̄W ̄D) 27x27x14 18x20x11.7 62.5x31.2x16.3 62.5x31.2x16.3 62.5x31.2x16.3 Includes Stub Antenna Antenna Cable (15cm) Stub Antenna DC power cable AC/DC power adapter Stub Antenna DC power cable Stub Antenna DC power cable Develop Board Set ESD01 or ESD02 use only DBS Jig Board + Power Adaptor + RS232 Cable Part Number: IP30-500 Promi-ESD User Manual – Products 3 © 2005 Initium Co., Ltd. All rights reserved. z Promi-MSP Series Wireless Multi- Serial Adapter MSP102A MSP102B ̈ Part Number IP20-400 IP20-401 Description Wireless multi-serial adapter COM port redirector supported Serial/IP Up to 7 links simultaneously Wireless multi-serial adapter COM port redirector supported Serial/IP Up to 14 links simultaneously Power Class Class1 Class1 RF Range Up to 100m Up to 100m Power Connector DC plug DC plug Power supply 5V 5V Serial connector Male DB9 Male DB9 Serial Interface RS-232 RS-232 Dip switch No No Battery No No Profile LAN Access Dial-up Serial Port Profile LAN Access Dial-up Serial Port Profile Applicable Antenna Stub Antenna Dipole Antenna Patch Antenna Stub Antenna Dipole Antenna Patch Antenna Bluetooth Qualified Fully Fully Type Approved MIC CE FCC MIC CE FCC Dimensions (H ̄W ̄D) 147x112x32 147x112x32 Includes Dipole Antenna AC/DC Power Adapter RS232 Cable LAN Cable Mounting Kit CD Dipole Antenna AC/DC Power Adapter RS232 Cable LAN Cable Mounting Kit CD Bluetooth USB Adapter Promi-ESD User Manual – Products 4 © 2005 Initium Co., Ltd. All rights reserved. z Accessories SAT DAT PAT EAT IA60-800 IA60-801 IA60-802 IA60-820 Antenna Stub (30mm) Dipole (120mm) Patch (130 ̄90 ̄65mm) Board type (18 ̄6 ̄7mm) ESD01 use only EPA OPA UPA DPA IA70-840 IA70-841 IA70-860 IA70-861 Power Supply External Power Adaptor Domestic use only External Power Adaptor International use USB power cable DC power cable RFC EEC SPC IA80-880 IA80-881 IA80-882 Extension Cable Antenna extension cable (1m) Antenna extension cable (15cm) ESD01 use only Serial power cable + Power adapter Ì For more information, please contact: Jinhyun Bae Marketing Manager Rm 901 Kins Tower 25-1 Jungja, Bundang Sungnam Kyunggi 463-120 South Korea +82 31 782-3234 (ext.111) +82 31 782-3230 Fax [email protected] [email protected] http://www.initium.co.kr Promi-ESD User Manual – Table of Contents 5 © 2005 Initium Co., Ltd. All rights reserved. Table of Contents Before Using the Product Welcome -------------------------------------------------------------7 Copyrights/Certification/Limited Liability ----------------- 7 Precautions and Safety ----------------------------------------- 7 General Terms and Conditions of Sale -------------------- 8 1. Getting Started Features of Promi-ESD --------------------------------------------- 11 Components -------------------------------------------------------- 12 Specifications ------------------------------------------------------------- 13 2. Configurations Operation Modes ------------------------------------------------- 15 Serial Ports ---------------------------------------------------------- 16 PromiWIN ™ -------------------------------------------------------- 18 Terminal Program ------------------------------------------------ 21 3. Connections Promi-ESD Pin Assignment ------------------------------------------------- 24 4. Trouble Shooting 5. Specifications Bluetooth ----------------------------------------------------------- 35 Serial Interface --------------------------------------------------- 35 Power ---------------------------------------------------------------- 35 Mechanical Dimensions ---------------------------------------- 36 Environmental --------------------------------------------------- 36 Default Antenna ------------------------------------------------- 37 Power Consumption -------------------------------------------- 37 Wireless Coverage ---------------------------------------------- 38 Appendix A. AT Commands Terminology ------------------------------------------------------- A-2 Command Category ----------------------------------------- A-3 Command Description --------------------------------------- A-4 Command Validity ------------------------------------------- A-12 Appendix B. S-Register Appendix C. How to make a RS232 interfaced Jig Board Appendix D. Technical Support Appendix E. Regulatory Information Promi-ESD User Manual – Before Using the Product 6 © 2005 Initium Co., Ltd. All rights reserved. Before Using the Product z Welcome z Copyrig…

Text truncated - open the document above for the full version.

Antenna UART 2.54mm 1x4 Header /RESET DC3.3V Status 2.54mm 1x4 Header Samsung BTKZ1702XX SPI UART PIO BPF Balun ANTENNA Port VDD 2.8V~3.6V 26MHz X-Tal INTERFACE BTKZ1702XX BC02 4Mbit Flash & ROM Memory PCM BTKZ1702XX Block Diagram 1,8V Regulator TX_RX (A) TX_RX(B)

SK TECH CO., LTD. Page 1 of 2 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 External Photographs of EUT <Photograph 1: Front View> SK TECH CO., LTD. Page 2 of 2 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 <Photograph 2: Rear View>

FCC ID Label Location & Sample LABEL LOCATION: Label is attached on the REAR of the module LABEL Drawing: FCC ID: QOCPROMI-ESD02 ESD Version XXXXXX 2005. 00 Instructions on how to attach the label in compliance with the modular approval guidelines developed by the FCC will be provided. LABEL LOCATION

SK TECH CO., LTD. Page 1 of 4 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 Internal Photographs of EUT <Photograph 1: Internal Front View – Shielding CAN removed> SK TECH CO., LTD. Page 2 of 4 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 <Photograph 2: TEST JIG, Model Promi-DBS Front View> SK TECH CO., LTD. Page 3 of 4 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 <Photograph 3: TEST JIG, Model Promi-DBS Rear View> SK TECH CO., LTD. Page 4 of 4 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 <Photograph 4: AC/DC Adaptor > For testing the power line conducted emissions

Operational Description This product, Promi-ESD02, is a Bluetooth module for OEM integrations. The product operates in 2400 to 2483.5 MHz band. The channel is represented by a pseudo-random hopping sequence through the 79 channels. The channel is divided into time slots, with a nominal slot length of 625μs, where each slot corresponds to different RF hop frequencies. The nominal hop rate is 1600 hops/s. The control signals and data in the Bluetooth Chipset are modulated and processed and then pass the PA in it. They will be transmitted from ANT through the BALUN FILTER to another Bluetooth device. The RF signal from other Bluetooth devices is received via ANT. And they go through BALUN FILTER into the chip. They are magnified by internal LNA in the chip. The power settings and crystal trim are stored in EEPROM. The product shall only be used with the tested antenna that is a permanently attached SMD chip antenna.

Preliminary Specification For LTCC Chip Antenna Model Name : RCA2450A2 RN2 Technologies co., Ltd. RN2 Technologies co., Ltd. 195-2, Soonam-ri, Sindoon-myeon, Icheon-si, Kyeongi-do, KOREA Phone : (+81) 31-638-0300 FAX : (+81) 31-638-3443 Customer : Title: Name : APPROVED By Date : Signature : Issued Date : C.H. Seok RN2 Technologies Preliminary Page 2 of 9 Bluetooth Chip Antenna Ver.02 May-2005 1. Description and Application MODEL : RCA2450A2 Description Surface mount, LTCC Chip Antenna Features - Multilayer LTCC( Low Temperature Cofired Ceramics) Technology - SMD ( Surface Mounted Device ) - Miniature Size - High Stability in Temperature/Humidity Change - Free Impedance Matching - Suitable for 2450MHz Working Frequency Operation Applications - Bluetooth device ( mobile Phone, headset, carkit, serial port, dongle, MP3 ) - WLAN ( Access Point, Notebook, PDA ) - DMB( receiver ) - HPi( High speed Portable internet) 2. Temperature Range Operating temperature range : -35 to +85 3. Properties 3.1 Electrical Specification : ITEM Specification Center frequency 2.45 GHz Bandwidth 100 MHz min. Gain 2 dBi Max VSWR 2 Max Polarization Linear Azimuth Beamwidth Omni Impedance 50 Ω RN2 Technologies Preliminary Page 3 of 9 Bluetooth Chip Antenna Ver.02 May-2005 3.2 Mechanical Specification Mechanical Outline & Feeding 3.3 Land Layout RN2 Technologies Preliminary Page 4 of 9 Bluetooth Chip Antenna Ver.02 May-2005 4. Electrical characteristics 4.1 Measurement Data ( S11 & Smith chart ) 4.2 Radiation pattern -40 -35 -30 -25 -20 -15 -10 -5 0 5 0 30 60 90 120 150 180 210 240 270 300 330 -40 -35 -30 -25 -20 -15 -10 -5 0 5 Azimuth 2400MHz 2450MHz 2500MHz AZIMUTH RN2 Technologies Preliminary Page 5 of 9 Bluetooth Chip Antenna Ver.02 May-2005 -50 -45 -40 -35 -30 -25 -20 -15 -10 -5 0 5 0 30 60 90 120 150 180 210 240 270 300 330 -50 -45 -40 -35 -30 -25 -20 -15 -10 -5 0 5 Elevation 2400MHz 2450MHz 2500MHz Elevation R.F. Anechoic Antenna Chamber (10.0m×6.0m×4.0m) Gain Units(dBi) Frequency (MHz) Average Min Max 2400 -0.67 -2.0 2.0 2450 -0.7 -3.31 1.71 Azimuth 2500 -1.35 -4.24 1.05 2400 -4.34 -27.66 3.95 2450 -4.78 -34.94 3.55 Elevation 2500 -5.65 -48.0 3.09 RN2 Technologies Preliminary Page 6 of 9 Bluetooth Chip Antenna Ver.02 May-2005 5. Test board and matching circuit for measurements 5.1 Test board 5.2 Matching Circuits for measurements Matching Circuit L C Inductor L : 3.9 nH Capacitor C : 0.5 pF GND GND In such case of internal SMD antenna, the resonant frequency is dependent on the GND size or other nearby active/passive components, and therefore can be different from what is measured on our test board. RN2 Technologies Preliminary Page 7 of 9 Bluetooth Chip Antenna Ver.02 May-2005 6. Soldering Conditions 6.1 Recommended Solder - A Sn/Pb/Ag ratio of 62/36/2 is recommended to inhibit dissolution of silver coating into molten solder - Do not allow the iron-tip to directly touch the ceramic element 6.2 Solder reflow Profile soaking condition: 230 , 20 sec. Max RN2 Technologies Preliminary Page 8 of 9 Bluetooth Chip Antenna Ver.02 May-2005 7. Packaging Dimension of the tape (Unit : mm) Dimension of the reel (Unit : mm) Marking Quantity per reel : 4000 pcs RN2 Technologies Preliminary Page 9 of 9 Bluetooth Chip Antenna Ver.02 May-2005 8. Environmental Specification. ITEM PROCEDURE REQUIREMENTS / RESULT Temperature Cycle (Thermal Shock) 1. One Cycle : Step1: 85 ± 5 °C for 10min Step2: -35 ± 5 °C for 10min 2. Cycle time : 5min 3. Number of Cycles : 100 4. Normal Condition in 1 hour 1. Meet the electrical specification after test Solderability 1. Solder : 230 ± 5°C for 5± 1 sec. 1. More than 85% of the electrode pad shall be covered with solder. Heat Resistance 1. Temperature : 85 ± 2 °C 2. Duration : 96 ± 2 hours 1. Meet the electrical specification after test Low Temperature Resistance 1. Temperature : -35 ± 5 °C 2. Duration : 96 ± 2 hours 1. Meet the electrical specification after test Vibration Resistance 1. Frequency: 10~ 55MHz 2. Acceleration : 10g 3. Sweep Time: 1.5 mm, 2hours/axis 4. Axis : X, Y and Z direction 1. No appearance damage 2. Meet the electrical specification after test Humidity Resistance 1. One Cycle : Step1: Temperature 85°C for 500 hours with humidity 95% Step2: Decrease Temperature 85°C to 25°C 2. Maintain for 1~2 hour after decreasing temperature 25°C 1. Meet the electrical specification after test Drop Shock 1. Dropped onto hard wood from height of 50 cm for 5 times; each x, y and z direction except I/O direction. 1. No appearance damage 2. Meet the electrical specification after test

SK TECH CO., LTD. Page 1 of 41 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 Certificate of Compliance Test Report No.: SKTTRT-060112-001 NVLAP CODE: 200220-0 Applicant: INITIUM Co., Ltd. Applicant Address: # 901, Kins Tower, 25-1 Jungja, Bundang, Sungnam, Kyunggi, 463-811 Korea Manufacturer: INITIUM Co., Ltd. Manufacturer Address: # 901, Kins Tower, 25-1 Jungja, Bundang, Sungnam, Kyunggi, 463-811 Korea Device Under Test: Bluetooth Serial Adapter FCC ID: QOCPROMI-ESD02 Model No.: Promi-ESD02 Receipt No.: SKTEU06-0001 Date of receipt: January 2, 2006 Date of Issue: January 12, 2006 Location of Testing: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Procedure: ANSI C63.4, FCC Public Notice DA 00-705 (March 2000) Test Specification: 47CFR, Part 15 Rules Equipment Class: DSS - Part 15 Spread Spectrum Transmitter Test Result: The above-mentioned device has been tested and passed. Tested & Reported by: Jong-Soo, Yoon 2006.01.12 Approved by: Jae-Kyung, Bae 2006.01.12 Signature Date Signature Date Other Aspects: - Abbreviations: · OK, Pass = passed · Fail = failed · N/A = not applicable ☞ •This test report is not permitted to copy partly without our permission. •This test result is dependent on only equipment to be used. •This test result is based on a single evaluation of one sample of the above mentioned. •This test report must not be used to claim product endorsement by NVLAP or any agency of the U.S Government. • We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. NVLAP Lab. Code: 200220-0 SK TECH CO., LTD. Page 2 of 41 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 >> CONTENTS << 1. GENERAL ············································································································· 4 2. TEST SITE ············································································································ 4 2.1 Location ········································································································· 4 2.2 List of Test and Measurement Instruments ···················································· 5 2.3 Test Date ········································································································ 5 2.4 Test Environment ··························································································· 5 3. DESCRIPTION OF THE EQUIPMENT UNDER TEST ········································· 6 3.1 Rating and Physical Characteristics ······························································ 6 3.2 Equipment Modifications ················································································ 6 3.3 Submitted Documents ···················································································· 6 4. MEASUREMENT CONDITIONS ··········································································· 7 4.1 Description of test configuration ···································································· 7 4.2 List of Peripherals ·························································································· 7 4.3 Uncertainty ····································································································· 7 5. TEST AND MEASUREMENTS ············································································· 8 5.1 ANTENNA REQUIREMENT ·········································································· 8 5.1.1 Regulation ······························································································· 8 5.1.2 Result ······································································································ 8 5.2 MAXIMUM PEAK OUTPUT POWER ···························································· 9 5.2.1 Regulation ······························································································· 9 5.2.2 Test Procedure ························································································ 9 5.2.3 Test Results ····························································································· 9 Table 1: Measured values of the Maximum Peak Output Power (Conducted) ····· 9 Figure 1: Plot of the Maximum Peak Output Power (Conducted) ······················10 5.3 CARRIER FREQUENCY SEPARATION ····················································· 12 5.3.1 Regulation ····························································································· 12 5.3.2 Test Procedure ······················································································ 12 5.3.3 Test Results ··························································································· 12 Table 2: Measured values of the Carrier Frequency Separation (Conducted) ···12 Figure 2: Plot of the Carrier Frequency Separation (Conducted) .....................13 5.4 20dB CHANNEL BANDWIDTH ·································································· 15 5.4.1 Regulation ····························································································· 15 5.4.2 Test Procedure ······················································································ 15 5.4.3 Test Results ··························································································· 15 Table 3: Measured values of the 20dB Channel Bandwidth (Conducted) ··········15 Figure 3: Plot of the 20dB Channel Bandwidth (Conducted) ···························16 SK TECH CO., LTD. Page 3 of 41 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 5.5 NUMBER OF HOPPING CHANNELS ························································ 18 5.5.1 Regulation ····························································································· 18 5.5.2 Test Procedure ······················································································ 18 5.5.3 Test Results ······························································…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 5 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 Test set up photos <Conducted RF power measurement> SK TECH CO., LTD. Page 2 of 5 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 <Radiated Emissions – Front View> SK TECH CO., LTD. Page 3 of 5 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 <Radiated Emissions – Rear View>

SK TECH CO., LTD. Page 4 of 5 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 <Conducted Emissions – Front View> SK TECH CO., LTD. Page 5 of 5 SKT SKTTRT-060112-001 FCC ID: QOCPROMI-ESD02 <Conducted Emissions – Rear View>
