To: David Chernomordik ES-Mpk Subject: BeamReach FCC ID: QONBRU100 David, Review of this application is complete, and the following points are noted (earlier comments are repeated here for completeness): ADMINISTRATIVE A. Confidentiality request (this has been corrected) 1) Each application should have a separate request letter only referencing the applicable FCC ID. Do not cite two different FCC ID numbers in one letter. 2) The request letter does not reference the relevant FCC Rule parts applicable to confidentiality, namely, 0.457. This should be added. B. FCC Identifier 1) No FCC Identifier appears on the label drawing for FCC ID: QONBRU100. The FCC Identifier must appear on the product. TECHNICAL None. Regards, Roland

FCC ID: QONBRU100 FCC ID: QONBRU100

FCC ID: QONBRU100 Label location

FCC ID: QONBRU100 Figure 1. BRU-100 Open View, Electronics on Left, Antenna Ground Plane and EMI Gasket on Right. Figure 2. BRU-100 RF PWA, top view, no shields, no RF connector. Figure 3. BRU-100 RF PWA, Bottom View, No Shields. Figure 4. BRU-100 DC-DC Power Supply PWA Top View. Figure 5. BRU-100 DC-DC Po wer Supply PWA Bottom View. Figure 6. BRU-100 Digital PWA Top View. Figure 7. BRU-100 Digital PWA Bottom View. Figure 8. BRU-100 Peripherals, OTE AC/DC Pow er Supply, Power Supply AC Cord, and Power Injector Module. The Power Injector Pr ovides Interfaces between the BRU-100 Combined Power and Ethern et Cable, The DC Power Supply, and a Standard Ethernet Cable to Customer Computer or Ethernet LAN. Figure 9. BRU-100 Power Injector Module Open. Figure 10. BRU-100 Power Injector PWA, Bottom View.

C H A P T E R 5 Remote Unit In This Chapter: Overview Architecture Remote Unit Components Subscriber LAN Architectures This chapter provides descriptions of the BRU-100 and BRU- 150 Remote Unit (RU). Overview BeamPlex remote units operate cost-effectively in non-line-of-sight environments and provide high speed, near-symmetric connections to broadband customers. Two models of the remote unit are available: BRU-100 – Outdoor, service provider installation. Includes the outdoor unit (ODU), power supply, power injector, associated cabling and software. A RIT Interface Box is optional. The ODU typically attaches to an exterior wall or roof. BRU-150 – Indoor, subscriber self-installation. Includes the transceiver (indoor unit), window-mount antenna, power supply, and software. Both models use the same electronics and function in the same manner. The remote unit provides the wireless termination point for the BeamPlex system at the subscriber’s location. It connects to the subscriber's terminal equipment (computer) across a LAN, or directly by Ethernet 10/100 BaseT. The airlink serves as the connection between the subscriber’s computer and the base station. It utilizes the BeamReach-developed Adaptive MultiBeam OFDM technology. Depending on the airlink signal strength, different data rates are possible. See Appendix B "Remote Unit Specifications” for reference. BRU-100 A BRU-100 remote unit consists of the following major components: Outdoor Unit – RF assembly; digital assembly with ASICs and microprocessors; DC/DC power supply; 16-element array antenna with 20° beamwidth and 18 dBi gain Power Adapter – 110/220 VAC input; 48 VDC output for the RF and digital circuitry in the outdoor unit Power Injector – 8-lead Ethernet from computer plus power and return from Power Adapter; 6-lead output to outdoor unit RIT Interface Box (RIB) – Optional device; mounts to outside wall; 10- pin RJ-45 for connecting to outdoor unit RU Installation Tool (RIT) – Software application in handheld PC to facilitate the installation process BRU-150 A BRU-150 remote unit consists of the following major components: Transceiver – This indoor unit has the same electronics as the BRU-100’s outdoor unit, except that it does not have an integrated antenna. Antenna – A window-mount, directional antenna with approximately 90° beamwidth housed in a transparent enclosure. Power supply – Connects to standard 120 VAC and outputs 48 VDC to the transceiver. Future versions of the remote unit are planned to include the following models and added capabilities: BRU-450 – High capacity business model HPNA – Home Phone Network Alliance support (in Version 1.0) VoIP – Voice over IP support BRU-100 Features and Benefits The BRU-100 is a fully integrated remote unit suitable for professional installation in outdoor environments. Using a high gain antenna, the BRU-100 maximizes cell coverage and range in challenging propagation environments. The outdoor unit provides for simple, fast, low cost installations and high operational reliability. Ethernet connectivity makes it compatible with all types of subscriber LAN equipment. Features • Fully integrated outdoor unit • Single drop cable for power and subscriber interface • Non-line-of-sight operation (NLOS) • Sustained throughput up to 1.5 Mbps (downlink) and 1.2 Mbps (uplink) • Multi-level QoS and SLA support • Ethernet user interface • PPP/Bridged Ethernet networking model • Automatic link quality measurements • Remote configuration and management • 2.3 GHz (WCS) band operationand 2.5–2.7 GHz (MMDS/ITFS) Benefits • Reduced installation time and cost – NLOS, below the roof line – One piece outdoor unit, simple cabling • Reduced operational costs – Over the air service management and configuration – Over the air software upgrades • Flexible service offerings – Variable service rates – 64 kbps to 1.5 Mbps downlink, up to 1.2 Mbps uplink – Multi level QoS via DiffServ, service provider defined SLAs – Service transparency using bridged Ethernet model • High quality voice services, file swapping and streaming media • Increased cell coverage in comparison to the BRU-150 • Subscriber equipment compatibility – Standard Ethernet LAN interface – Compatible with standard NICs, hubs, routers, firewalls and 802.11 WLANs BRU-150 Features and Benefits The BRU-150 is a fully integrated remote unit designed for subscriber selfinstallation. The high gain, wide beamwidth antenna minimizes the need for pointing to establish an airlink with a base station. The installation process is automated, requiring minimal user actions. Features • Fully integrated transceiver packaged in an aesthetic housing for indoor use • Simple wiring and automated process for ease of installation • Diagnostic software on subscriber’s computer to assist customer support calls • Non-line-of-sight operation (NLOS) • Sustained throughput up to 1.5 Mbps (downlink) and 1.2 Mbps (uplink) • Ethernet user interface • PPP/Bridged Ethernet networking model • Remote configuration and management • 2.3 GHz (WCS) Benefits • Subscriber self-installation, no truck roll required • Reduced operational costs – Over the air service management and configuration – Over the air software upgrades • Flexible service offerings – Variable service rates – 64 Kbps to 1.5 Mbps downlink, up to 1.2 Mbps uplink – Multi level QoS via DiffServ, service provider defined SLAs – Service transparency using bridged Ethernet model • High quality voice services, file swapping and streaming media • Subscriber equipment compatibility – Standard Ethernet LAN interface – Compatible with standard NICs, hubs, routers, firewalls and 802.11 WLANs Remote Unit Interfaces For both models of the RU there are two basic interfaces: The airlink to the base station. The Ethernet data interface to the Customer Premise Equipment (CPE). All CPE connects to the RU through an Ethernet data interface. Network equipment can be used to connect multiple CPE to the RU. Future versions of the BRU-100 wil…

Text truncated - open the document above for the full version.

Computation of Distance to Center of Radiation of Antenna vs Power into Antenna, Antenna Gain, and Allowed Power Density BEAMREACH NETWORKS MAXIMUM PERMISSIBLE EXPOSURE CALCULATIONS Calculation of mpe distance per product specifications Unit Average Power into Antenna during Tx Interval (dBm) Tx Duty Cycle (dB) Average Power into Antenna, P (dBm) Antenna Gain, G (dBi) Power Density, S (mW/cm^2) Distance to Center of Radiation of Antenna, R (cm) ODU CPE30-3.8926.1118520.24 IDU CPE30-3.8926.1111120.22 Base (5W)37-2.9234.0817545.16 Base (10W)40-2.9237.0817563.78 S = P*G/(4*pi*R^2), far field calculation R = SQRT(P*G/(4*pi*S)) Note: 1. FCC limit for general population/uncontrolled exposure is 1mW/cm^2. 2. FCC limit for occupation/controlled exposure is 5mW/cm^2. Unit Average Power into Antenna during Tx Interval (dBm) Tx Duty Cycle (dB) Average Power into Antenna, P (dBm) Antenna Gain, G (dBi) Power Density, S (mW/cm^2) Distance to Center of Radiation of Antenna, R (cm) ODU CPE28.5-3.8924.6118517.03 IDU CPE27-3.8923.1111114.31 Calculation of mpe distance per product average power measurements

EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 1 of 76 TEST REPORT Report Number: 30408641 Project Number: 3040864 & 3030973 June 10, 2003 Testing performed on the Wireless Outdoor Remote Unit Model: BRU-100 FCC ID: QONBRU100 to FCC Part 27 for BeamReach Networks Test Performed by: Test Authorized by: Intertek Testing Services 1365 Adams Court Menlo Park, CA 94025 BeamReach Networks 755 North Mathilda Avenue Sunnyvale, CA 94086 Prepared by: Date: 6/10/03 Arkadi Kaplan Reviewed by: Date: 6/17/03 David Chernomordik This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. This report must not be used to claim product endorsement by A2LA, NIST nor any other agency of the U.S. Government. EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 2 of 76 TABLE OF CONTENTS 1.0 Summary of Tests .......................................................................................................................... 3 2.0 General Description ....................................................................................................................... 4 2.1 Product Description ............................................................................................................4 2.2 Related Submittal(s) Grants ................................................................................................ 5 2.3 Test Facility ........................................................................................................................ 5 3.0 System Test Configuration............................................................................................................ 5 3.1 Support Equipment ............................................................................................................. 5 3.2 Block Diagram of Test Setup.............................................................................................. 6 4.0 RF Power Output, Radiated Power.............................................................................................. 8 4.1 Requirements ...................................................................................................................... 8 4.2 Test Procedure .................................................................................................................... 8 4.3 Test Results......................................................................................................................... 8 5.0 Occupied Bandwidth ..................................................................................................................... 9 5.1 Test Procedure .................................................................................................................... 9 5.2 Test Results......................................................................................................................... 9 6.0 Spurious Emissions at Antenna Terminal ................................................................................. 12 6.1 Requirements ....................................................................................................................12 6.2 Test Procedure ..................................................................................................................12 6.3 Test Results....................................................................................................................... 12 7.0 Field Strength of Spurious Radiation......................................................................................... 13 7.1 Requirements ....................................................................................................................13 7.2 Test Procedure ..................................................................................................................13 7.3 Test Result ........................................................................................................................ 14 8.0 Line Conducted Emissions .......................................................................................................... 16 8.1 Test Procedure ..................................................................................................................16 8.2 Test Results....................................................................................................................... 17 9.0 Frequency Stability vs Temperature and Voltage .................................................................... 31 9.1 Test Procedure ..................................................................................................................31 9.2 Test Results....................................................................................................................... 31 10.0 List of Test Equipment ................................................................................................................ 33 11.0 Document History ........................................................................................................................ 34 12.0 Appendix A ....................................................................…

Text truncated - open the document above for the full version.

EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 35 of 76 12.0 Appendix A Sub band A1 (operating center frequencies: 2306.25 and 2351.25 MHz) Plot Number Description 1.1 Scan 10 MHz – 1 GHz 1.2 Scan 1 GHz – 2.300 GHz 1.3 Scan 2.300 GHz – 2.310 GHz 1.4 Scan 2.315 GHz – 2.320 GHz 1.5 Scan 2.320 GHz – 2.345 GHz 1.6 Scan 2.450 GHz – 2.355 GHz 1.7 Scan 2.360 GHz – 2.370 GHz 1.8 Scan 2.370 GHz – 6.4 GHz 1.9 Scan 6.4 GHz – 24 GHz Sub band A3 (operating center frequencies: 2308.75 and 2353.75 MHz) Plot Number Description 2.1 Scan 10 MHz – 1 GHz 2.2 Scan 1 GHz – 2.300 GHz 2.3 Scan 2.300 GHz – 2.310 GHz 2.4 Scan 2.315 GHz – 2.320 GHz 2.5 Scan 2.320 GHz – 2.345 GHz 2.6 Scan 2.450 GHz – 2.355 GHz 2.7 Scan 2.360 GHz – 2.370 GHz 2.8 Scan 2.370 GHz – 6.4 GHz 2.9 Scan 6.4 GHz – 24 GHz EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 36 of 76 Sub band B1 (operating center frequencies: 2311.25 and 2356.25 MHz) Plot Number Description 3.1 Scan 10 MHz – 1 GHz 3.2 Scan 1 GHz – 2.300 GHz 3.3 Scan 2.300 GHz – 2.310 GHz 3.4 Scan 2.315 GHz – 2.320 GHz 3.5 Scan 2.320 GHz – 2.345 GHz 3.6 Scan 2.450 GHz – 2.355 GHz 3.7 Scan 2.360 GHz – 2.370 GHz 3.8 Scan 2.370 GHz – 6.4 GHz 3.9 Scan 6.4 GHz – 24 GHz Sub band B3 (operating center frequencies: 2313.75 and 2358.75 MHz) Plot Number Description 3.1 Scan 10 MHz – 1 GHz 3.2 Scan 1 GHz – 2.300 GHz 3.3 Scan 2.300 GHz – 2.310 GHz 3.4 Scan 2.315 GHz – 2.320 GHz 3.5 Scan 2.320 GHz – 2.345 GHz 3.6 Scan 2.450 GHz – 2.355 GHz 3.7 Scan 2.360 GHz – 2.370 GHz 3.8 Scan 2.370 GHz – 6.4 GHz 3.9 Scan 6.4 GHz – 24 GHz EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 37 of 76 Plot 1.1 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 38 of 76 Plot 1.2 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 39 of 76 Plot 1.3 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 40 of 76 Plot 1.4 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 41 of 76 Plot 1.5 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 42 of 76 Plot 1.6 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 43 of 76 Plot 1.7 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 44 of 76 Plot 1.8 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 45 of 76 Plot 1.9 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 46 of 76 Plot 2.1 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 47 of 76 Plot 2.2 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 48 of 76 Plot 2.3 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 49 of 76 Plot 2.4 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 50 of 76 Plot 2.5 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 51 of 76 Plot 2.6 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 52 of 76 Plot 2.7 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 53 of 76 Plot 2.8 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 54 of 76 Plot 2.9 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 55 of 76 Plot 3.1 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 56 of 76 Plot 3.2 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 57 of 76 Plot 3.3 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 58 of 76 Plot 3.4 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 59 of 76 Plot 3.5 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 60 of 76 Plot 3.6 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 61 of 76 Plot 3.7 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 62 of 76 Plot 3.8 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 63 of 76 Plot 3.9 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 64 of 76 Plot 4.1 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 65 of 76 Plot 4.2 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 66 of 76 Plot 4.3 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 67 of 76 Plot 4.4 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 68 of 76 Plot 4.5 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 69 of 76 Plot 4.6 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 70 of 76 Plot 4.7 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 71 of 76 Plot 4.8 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 72 of 76 Plot 4.9 EMC Report for BeamReach Networks on the model: BRU-100 File: 30408641 Page 73 of 76 13.0 Appendix B Radiated Emissions Model: BRU 100 Test Mode: Tx at Sub Band A1, Band 3/39 Fundamental frequencies: 2306.25 MHz & 2351.25 MHz LO frequencies: 1956.25 MHz & 2001.25 MHz Engineer: AK Frequency Antenna Antenna Average Antenna Preamp D.C. Cable Field Strength Location Polariz. SA Reading Factor correction Factor Loss @ 3m GHz m H/V dB(uV) dB(1/m)dB dB dB dB(uV/m) 3.913 3.0 H 33.0 34.2 -36.0 0.0 6.6 37.8 4.003 3.0 H 32.7 34.2 -36.0 0.0 6.8 37.7 4.613 3.0 H 38.7 34.2 -36.0 0.0 8.0 44.9 4.703 3.0 H 36.0 34.5 -36.0 0.0 8.3 40.8 5.869 3.0 H 24.5 36.1 -35.5 0.0 8.4 42.8 6.004 3.0 H 28.3 36.6 -35.0 0.0 8.5 38.4 6.919 3.0 H 29.2 37.0 -35.3 0.0 6.6 37.5 7.054 3.0 H 30.0 37.3 -35.4 0.0 6.6 38.5 7.825 3.0 H 28.3 37.9 -35.3 0.0 6.5 37.4 8.005 3.0 H 30.7 37.7 -36.0 0.0 6.6 39.0 9.225 3.0 H 31.2 39.6 -35.3 0.0 5.3 40.8 9.405 3.0 H 34.5 39.1 -35.3 0.0 5.5 43.8 9.781 1.0 H 31.2* 39.0 -36.7 -9.5 4.8 28.8 10.006 1.0 H 29.3* 39…

Text truncated - open the document above for the full version.

FCC ID: QONBRU100 Setup Photos FCC ID: QONBRU100 Setup Photos FCC ID: QONBRU100 Setup Photos FCC ID: QONBRU100 Setup Photos FCC ID: QONBRU100 Setup Photos
