Confidential BGM220P Wireless Gecko Bluetooth Module Data Sheet The BGM220P is a module designed and built to meet the per- formance, security, and reliability requirements of battery-powered IoT products running on Bluetooth networks. Based on the EFR32BG22 SoC, the BGM220P enables Bluetooth ® Low Energy connec- tivity while delivering best-in-class RF range and performance, future-proof capability for feature and OTA firmware updates, enhanced security features, and low energy con- sumption. BGM220P modules are a full solution that comes with fully-upgradeable, robust software stacks, world-wide regulatory certifications, advanced development and debugging tools, and support that will minimize and simplify the engineering and development of your end-products helping to accelerate their time-to-market. The BGM220P is intended for a broad range of applications, including: • Asset Tags and Beacons • Sports, Fitness, and Wellness devices • Portable Medical • Connected Home • Industrial and Building Automation • Bluetooth mesh Low Power Node KEY FEATURES • Bluetooth 5.2 • Bluetooth mesh Low Power Node • Built-in antenna • Up to 8 dBm TX power • -98.9 dBm BLE RX sensitivity at 1 Mbps • 32-bit ARM Cortex-M33 core at up to 76.8 MHz • 512/32 kB of Flash/RAM memory • Optimal selection of MCU peripherals • Up to 25 GPIO pins • 12.9 mm x 15.0 mm Lowest power mode with peripheral operational: EM4—Shutoff EM3—StopEM2—Deep SleepEM1—SleepEM0—Active Timers and Triggers 32-bit bus Peripheral Reflex System Serial Interfaces I/O Ports Analog I/F USART EUART External Interrupts General Purpose I/O Pin Reset Pin Wakeup ADC Energy Management Brown-Out Detector Voltage Regulator Power-On Reset SecurityClock Management HF Crystal Oscillator LF Crystal Oscillator LF RC Oscillator HF RC Oscillator Crypto Acceleration Ultra LF RC Oscillator Core / Memory ARM Cortex TM M33 processor with DSP extensions, FPU and TrustZone ETMDebug InterfaceRAM Memory LDMA Controller Flash Program Memory Real Time Capture Counter Timer/ Counter Low Energy Timer Watchdog Timer Protocol Timer True Random Number Generator Fast Startup RC Oscillator Back-Up Real Time Counter I 2 C PDM DC-DC Converter Temperature Sensor Radio Subsystem RFSENSE w/ OOK Detect RX/TX Frontend with Integrated +8 dBm PA Frequency Synthesizer ARM Cortex TM M0+ Radio Controller CRC BUFC RAM FRC DEMOD AGC IFADC MOD Crystals Antenna Chip Antenna Matching 38.4 MHz 32.768 kHz silabs.com | Building a more connected world.Preliminary Rev. 0.5 This information applies to a product under development. Its characteristics and specifications are subject to change without notice. Silicon Laboratories Confidential. Information contained herein is covered under non-disclosure agreement (NDA). Confidential 1. Feature List •Supported Protocols • Bluetooth Low Energy (Bluetooth 5.2) • Direction finding • 1M, 2M and LE Coded PHYs • Bluetooth mesh Low Power Node •Wireless System-on-Chip • 2.4 GHz radio • TX power up to +8 dBm • High-performance 32-bit ARM Cortex-M33 ® with DSP in- struction and floating-point unit for efficient signal process- ing • 512 kB flash program memory • 32 kB RAM data memory • Embedded Trace Macrocell (ETM) for advanced debugging •High-Receiver Performance • -106.7 dBm sensitivity (0.1% BER) at 125 kbps GFSK • -102.5 dBm sensitivity (0.1% BER) at 500 kbps GFSK • -98.9 dBm sensitivity (0.1% BER) at 1 Mbps GFSK • -96.2 dBm sensitivity (0.1% BER) at 2 Mbps GFSK •Low-Energy Consumption • 4.3 mA RX current at 1 Mbps GFSK • 4.8 mA TX current at 0 dBm output power • 10.8 mA TX current at 8 dBm output power • 26 μA/MHz in Active Mode (EM0) • 1.40 μA EM2 DeepSleep current (RTCC running from LFXO, Full RAM retention) • Regulatory Certifications 1 • FCC • CE • IC/ISEDC • MIC/TELEC • KCC •Wide Operating Range • 1.8 to 3.8 V • -40 to +105°C •Dimensions • 12.9 mm x 15.0 mm x 2.2 mm •Security Features • Secure Boot with Root of Trust and Secure Loader (RTSL) • Hardware Cryptographic Acceleration for AES128/256, SHA-1, SHA-2 (up to 256-bit), ECC (up to 256-bit), ECDSA, and ECDH • True Random Number Generator (TRNG) compliant with NIST SP800-90 and AIS-31 • ARM ® TrustZone ® • Secure Debug with lock/unlock •Wide Selection of MCU Peripherals • 12-bit 1 Msps SAR Analog to Digital Converter (ADC) • Up to 25 General Purpose I/O pins with output state reten- tion and asynchronous interrupts • 8 Channel DMA Controller • 12 Channel Peripheral Reflex System (PRS) • 4 × 16-bit Timer/Counter with 3 Compare/Capture/PWM channels • 1 × 32-bit Timer/Counter with 3 Compare/Capture/PWM channels • 32-bit Real Time Counter • 24-bit Low Energy Timer for waveform generation • 1 × Watchdog Timer • 2 × Universal Synchronous/Asynchronous Receiver/Trans- mitter (UART/SPI/SmartCard (ISO 7816)/IrDA/I 2 S) • 1 × Enhanced Universal Asynchronous Receiver/Transmit- ter (EUART) • 2 × I 2 C interface with SMBus support • Digital microphone interface (PDM) • RFSENSE with selective OOK mode 1.Available at the BGM220P Full-Production release. BGM220P Wireless Gecko Bluetooth Module Data Sheet Feature List silabs.com | Building a more connected world.Preliminary Rev. 0.5 | 2 Confidential 2. Ordering Information Table 2.1. Ordering Information Ordering CodeProtocol Stack TX Power RatingAntenna RF Shield Flash (kB) RAM (kB)LF ClockGPIOTemp Range BGM220PC22HNA2Bluetooth 5.2 • Direction finding 8 dBmBuilt-inYes51232Crystal24-40 to 105 °C BGM220PC22WGA2Bluetooth 5.28 dBmBuilt-inYes35232Precision LFRCO 25-40 to 85 °C Note: 1.LE Long Range (125 kbps and 500 kbps) PHYs are only supported on part numbers which include direction-finding capability. 2.End-product manufacturers must verify that the module is configured to meet regulatory limits for each region in accordance with the formal certification test reports. 3.Devices are pre-programmed with BGAPI UART DFU bootloader. 4.Throughout this document, the devices in the table above may be referred to by their product family name (e.g. BGM220P), by model name (BGM220…

Text truncated - open the document above for the full version.

Confidential MGM220P Wireless Gecko Bluetooth Module Data Sheet The MGM220P is a module designed and built to meet the per- formance, security, and reliability requirements of battery-powered IoT products for mesh networks. Based on the EFR32MG22 SoC, the MGM220P enables Zigbee Green Power ® and Bluetooth ® Low Energy connectivity while delivering best-in-class RF range and per- formance, future-proof capability for feature and OTA firmware updates, enhanced se- curity features, and low energy consumption. MGM220P modules are a full solution that comes with fully-upgradeable, robust soft- ware stacks, world-wide regulatory certifications, advanced development and debugging tools, and support that will minimize and simplify the engineering and development of your end-products helping to accelerate their time-to-market. The MGM220P is intended for a broad range of applications, including: • Connected Home • Building Automation and Security KEY FEATURES • Zigbee Green Power and Bluetooth 5.2 Connectivity • Bluetooth Low Energy • Built-in antenna • Up to 8 dBm TX power • -98.9 dBm BLE RX sensitivity at 1 Mbps • 32-bit ARM Cortex-M33 core at up to 76.8 MHz • 512/32 kB of Flash/RAM memory • Optimal selection of MCU peripherals • Up to 24 GPIO pins • 12.9 mm x 15.0 mm Lowest power mode with peripheral operational: EM4—Shutoff EM3—StopEM2—Deep SleepEM1—SleepEM0—Active Timers and Triggers 32-bit bus Peripheral Reflex System Serial Interfaces I/O Ports Analog I/F USART EUART External Interrupts General Purpose I/O Pin Reset Pin Wakeup ADC Energy Management Brown-Out Detector Voltage Regulator Power-On Reset SecurityClock Management HF Crystal Oscillator LF Crystal Oscillator LF RC Oscillator HF RC Oscillator Crypto Acceleration Ultra LF RC Oscillator Core / Memory ARM Cortex TM M33 processor with DSP extensions, FPU and TrustZone ETMDebug InterfaceRAM Memory LDMA Controller Flash Program Memory Real Time Capture Counter Timer/ Counter Low Energy Timer Watchdog Timer Protocol Timer True Random Number Generator Fast Startup RC Oscillator Back-Up Real Time Counter I 2 C PDM DC-DC Converter Temperature Sensor Radio Subsystem RFSENSE w/ OOK Detect RX/TX Frontend with Integrated +8 dBm PA Frequency Synthesizer ARM Cortex TM M0+ Radio Controller CRC BUFC RAM FRC DEMOD AGC IFADC MOD Crystals Antenna Chip Antenna Matching 38.4 MHz 32.768 kHz silabs.com | Building a more connected world.Preliminary Rev. 0.5 This information applies to a product under development. Its characteristics and specifications are subject to change without notice. Silicon Laboratories Confidential. Information contained herein is covered under non-disclosure agreement (NDA). Confidential 1. Feature List •Supported Protocols • Zigbee Green Power • Bluetooth Low Energy (Bluetooth 5.2) • Direction finding using Angle-of-Arrival (AoA) • LE Long Range (125 and 500 kbps PHYs) • Bluetooth Mesh •Wireless System-on-Chip • 2.4 GHz radio • TX power up to +8 dBm • High-performance 32-bit ARM Cortex-M33 ® with DSP in- struction and floating-point unit for efficient signal process- ing • 512 kB flash program memory • 32 kB RAM data memory • Embedded Trace Macrocell (ETM) for advanced debugging •High-Receiver Performance • -102.3 dBm sensitivity (1% PER) at 250 kbps O-QPSK DSSS • -106.7 dBm sensitivity (0.1% BER) at 125 kbps GFSK • -102.5 dBm sensitivity (0.1% BER) at 500 kbps GFSK • -98.9 dBm sensitivity (0.1% BER) at 1 Mbps GFSK • -96.2 dBm sensitivity (0.1% BER) at 2 Mbps GFSK •Low-Energy Consumption • 4.4 mA RX current at 250 kbps O-QPSK DSSS • 4.3 mA RX current at 1 Mbps GFSK • 4.8 mA TX current at 0 dBm output power • 10.8 mA TX current at 8 dBm output power • 26 μA/MHz in Active Mode (EM0) • 1.40 μA EM2 DeepSleep current (RTCC running from LFXO, Full RAM retention) • Regulatory Certifications 1 • FCC • CE • IC/ISEDC • MIC/TELEC • KCC •Wide Operating Range • 1.8 to 3.8 V • -40 to +105°C •Dimensions • 12.9 mm x 15.0 mm •Security Features • Secure Boot with Root of Trust and Secure Loader (RTSL) • Hardware Cryptographic Acceleration for AES128/256, SHA-1, SHA-2 (up to 256-bit), ECC (up to 256-bit), ECDSA, and ECDH • True Random Number Generator (TRNG) compliant with NIST SP800-90 and AIS-31 • ARM ® TrustZone ® • Secure Debug with lock/unlock •Wide Selection of MCU Peripherals • 12-bit 1 Msps SAR Analog to Digital Converter (ADC) • Up to 24 General Purpose I/O pins with output state reten- tion and asynchronous interrupts • 8 Channel DMA Controller • 12 Channel Peripheral Reflex System (PRS) • 4 × 16-bit Timer/Counter with 3 Compare/Capture/PWM channels • 1 × 32-bit Timer/Counter with 3 Compare/Capture/PWM channels • 32-bit Real Time Counter • 24-bit Low Energy Timer for waveform generation • 1 × Watchdog Timer • 2 × Universal Synchronous/Asynchronous Receiver/Trans- mitter (UART/SPI/SmartCard (ISO 7816)/IrDA/I 2 S) • 1 × Enhanced Universal Asynchronous Receiver/Transmit- ter (EUART) • 2 × I 2 C interface with SMBus support • Digital microphone interface (PDM) • RFSENSE with selective OOK mode 1.Available at the MGM220P Full-Production release. MGM220P Wireless Gecko Bluetooth Module Data Sheet Feature List silabs.com | Building a more connected world.Preliminary Rev. 0.5 | 2 Confidential 2. Ordering Information Table 2.1. Ordering Information Ordering CodeProtocol Stack TX Power RatingAntenna RF Shield Flash (kB) RAM (kB)LF ClockGPIOTemp Range MGM220PC22HNA2• Zigbee • Bluetooth 5.2 • Direction finding 8 dBmBuilt-inYes51232Crystal24-40 to 105 °C Note: 1.End-product manufacturers must verify that the module is configured to meet regulatory limits for each region in accordance with the formal certification test reports. 2.Devices are pre-programmed with UART XMODEM bootloader. 3.Throughout this document, the devices in the table above may be referred to by their product family name (e.g. MGM220P), by model name (MGM220P22A), or by full ordering code. MGM220P Wireless Gecko Bluetooth Module Data Sheet Ordering Information silabs.com | Building a m…

Text truncated - open the document above for the full version.

SILICON LABS Agency Authorization Letter Attn: To Whom it May Concern I Application Examiner / Review Engineer! Officer in Charge Re: Authority to Act as Agent for FCC application Dear Madam or Sir, We, Silicon Laboratories Finland Oy, a corporation validly organized and existing under the laws of Finland, having its principal place of business at Alberga Business Park, Bertel Jungin aukio 3, 02600 Espoo, Finland hereby authorize the following person: Andrea Hsia Supervisor of Bureau Veritas Consumer Products Services (H.K.) Ltd. Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf as our agent in all manners relating to the Federal Communication Commission (“FCC”) application for equipment authorization in connection with our multiprotocol Bluetooth Low Energy and Zigbee wireless radio modules with model names of M0M220P22A and BGM22OP22A and BGX22OP22A, having FCC ID: QOQ-GM22OP. Our authorization extends to any communication needed with the TCB and FCC, and includes signing of all documents relating to this matters. Any and all acts carried out on our behalf by Andrea Hsia, Supervisor of BV CPS Taoyuan, within the scope of the powers granted herein, shall have the same effect as acts of our own. Should there be any query regarding this authorization, please do not hesitate to contact the undersigned. Thank you for your attention to this matter. Senior Contact: Pasi Rahikkala Job Title: Staff Hardware Engineer, loT Radio Modules Email: [email protected] Silicon Laboratories Finland Oy Alberga Business Park, Bertel Jungin aukio 3 Fl-02600 Espoo, Finland Phone: +358 9435 5060 www.silabs.com Place and date of issue (of this letter): Espoo, 11 March2

FCC ID: QOQ-GM220P Report No.: RF190408C21, RF190408C21-1 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch April 8, 2020 Dear Application Examiner, Silicon Laboratories Finland Oy., Zigbee and Bluetooth Low Energy wireless radio modules, FCC ID: QOQ-GM220P would like to have your authorization as a modular approval specific to the mobile RF exposure condition. The requirements of KDB996369 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.” The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip EFR32MG22. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is EFR32MG22. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a USB extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: QOQ-GM220P Report No.: RF190408C21, RF190408C21-1 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, ________________ Andrea Hsia Supervisor Bureau Veritas Consumer Products Services (H.K.) Ltd., Hsinchu Branch

SILICON LABS Declaration of Identity Federal Communications Commission (Authorization and Evaluation Division) 7435 Oakland Mills Road, Columbia, MD 21046 FCC ID: 000-GM22OP Attn: To Whom it May Concern / Application Examiner / Review Engineer! Officer in Charge Re: Declaration of Identity / Attestation of Model Difference Dear Madam or Sir, We, Silicon Laboratories Finland Oy, a corporation validly organized and existing under the laws of Finland, having its principal place of business at Alberga Business Park, Bertel Jungin aukio 3, 02600 Espoo, Finland, hereby declare that the family of our radio modules includes 3 models with names and brand as listed below: Product description: Model names: Trademark! Brand: ZigBee and Bluetooth Low Energy wireless radio modules MGM22OP22A and BGM22OP22A and BGX22OP22A Silicon Labs As the manufacturers of the above-listed modules we declare that they are electrically and mechanically identical, and the only differences between models are described in the last row of the table below: Product Zigbee and Bluetooth Low Energy Bluetooth Low Energy wireless radio wireless radio modules modules Model MGM22OP22A BGM22QP22A and BGX22OP22A Spec. Low-Power, Zigbee and/or BLE Low-Power, BLE Antenna Type On board ceramic chip antenna with 1 .86dBi of gain Hardware-wise the modules are identical. These are fully internally regulated and Hardware shielded PCB modules with a single integral ceramic chip antenna. There are no separate variants with an RF pin or a connector for using external antennas. RF max TX power 8.2 dBm Model differences The only difference between these modules concerns the factory software configuration defining which wireless protocol are allowed: - The MGM22OP22A can run Zigbee and/or BLE and/or a simple proprietary protocol as a SRD (Short Range Device) - The BGM22OP22A can run BLE and/or a simple proprietary protocol as a SRD - The BGX22OP22A is identical to the 3GM220P22A, but with another name for marketing differentiation Should there be any query regarding this declaration, please do not hesitate to contact the undersigned. Thank you for your attention to this matter. Senior Contact: Pasi Rahikkala Job Title: Staff Hardware Engineer, loT Radio Modules Email: [email protected] Silicon Laboratories Finland Oy Alberga Business Park, Bertel Jungin aukio 3 Fl-02600 Espoo, Finland Phone: ÷358 9435 5060 www.silabs.com Place and date of issue (of this Espoo, 11 March

Reference No.: 191225C12-1 Page No. 1 / 3 CONSTRUCTION PHOTOS OF EUT Reference No.: 191225C12-1 Page No. 2 / 3 Reference No.: 191225C12-1 Page No. 3 / 3

Silicon Laboratories Finland Oy Alberga Business Park, Bertel Jungin aukio 3 FI-02600 Espoo, Finland Phone: +358 9 435 5060 Page 1 of 3 www.silabs.com Top Markings of the Zigbee and BLE wireless radio module with model name: MGM220P22A Figure 1: Label / Top Markings of MGM220P22A Silicon Laboratories Finland Oy Alberga Business Park, Bertel Jungin aukio 3 FI-02600 Espoo, Finland Phone: +358 9 435 5060 Page 2 of 3 www.silabs.com Top Markings of the BLE wireless radio module with model name: BGM220P22A Figure 2: Label / Top Markings of BGM220P22A Silicon Laboratories Finland Oy Alberga Business Park, Bertel Jungin aukio 3 FI-02600 Espoo, Finland Phone: +358 9 435 5060 Page 3 of 3 www.silabs.com Top Markings of the BLE wireless radio module with model name: BGX220P22A Figure 3: Label / Top Markings of BGX220P22A Label location

Reference No.: 191225C12-2 Page No. 1 / 2 CONSTRUCTION PHOTOS OF EUT Reference No.: 191225C12-2 Page No. 2 / 2

Report No.: SA191225C12 Page No. 1 / 6 Report Format Version: 6.1.1 RF Exposure Report (Mobile mode) Report No.: SA191225C12 FCC ID: QOQ-GM220P Test Model: MGM220P22A Series Model: BGM220P22A, BGX220P22A Received Date: Dec. 25, 2019 Test Date: Jan. 17 ~ Mar. 02, 2020 Issued Date: Mar. 05, 2020 Applicant: Silicon Laboratories Finland Oy Address: Alberga Business Park - Bldg D/Floor 5, Bertel Jungin aukio 3, 02600 ESPOO, FINLAND Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN FCC Registration / Designation Number: 788550 / TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: SA191225C12 Page No. 2 / 6 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 3 Calculation Result of Maximum Conducted Power ........................................................................... 6 Report No.: SA191225C12 Page No. 3 / 6 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SA191225C12 Original release Mar. 05, 2020 Report No.: SA191225C12 Page No. 4 / 6 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Zigbee and Bluetooth Low Energy wireless radio modules, Bluetooth Low Energy wireless radio modules Brand: Silicon Labs Test Model: MGM220P22A Series Model: BGM220P22A, BGX220P22A Sample Status: Engineering sample fully representing the production model Applicant: Silicon Laboratories Finland Oy Test Date: Jan. 17 ~ Mar. 02, 2020 Standards: FCC Part 2 (Section 2.1091) References Test Guidance: KDB 447498 D01 General RF Exposure Guidance v06 IEEE C95.3 -2002 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s RF characteristics under the conditions specified in this report. Prepared by : , Date:Mar. 05, 2020 Polly Chien / Specialist Approved by : , Date:Mar. 05, 2020 Bruce Chen / Senior Project Engineer Report No.: SA191225C12 Page No. 5 / 6 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA191225C12 Page No. 6 / 6 Report Format Version: 6.1.1 3 Calculation Result of Maximum Conducted Power Mode Frequency Band (MHz) Max. AV Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) BT LE Hopping LE 1M 2402~2480 8.82 1.86 20 0.002 1 LE 2M 8.78 1.86 20 0.002 1 DTS LE 1M 2402~2480 8.82 1.86 20 0.002 1 LE 2M 8.78 1.86 20 0.002 1 SRD - 2401 & 2481 8.76 1.86 20 0.002 1 Zigbee - 2405 ~ 2480 8.66 1.86 20 0.002 1 Note: 1. Determining compliance based on th…
