QOQBLE112Bluetooth Low Energy Module

BLE112 PRELIMINARY DATA SHEET Friday, 19 August 2011 Version 1.0 Bluegiga Technologies Oy Copyright © 2000-2011 Bluegiga Technologies All rights reserved. Bluegiga Technologies assumes no responsibility for any errors which may appear in this manual. Furthermore, Bluegiga Technologies reserves the right to alter the hardware, software, and/or specifications detailed here at any time without notice and does not make any commitment to update the information contained here. Bluegiga’s products are not authorized for use as critical components in life support devices or systems. The WRAP is a registered trademark of Bluegiga Technologies The Bluetooth trademark is owned by the Bluetooth SIG Inc., USA and is licensed to Bluegiga Technologies. All other trademarks listed herein are owned by their respective owners. Bluegiga Technologies Oy VERSION HISTORY Version Comment 0.1 First draft 0.9 Preproduction information 0.91 Prerelease 0.92 Reference schematic added 0.93 Description updated 0.94 Design guide updates, characteristics updates, I/O descriptions updates 0.95 Layout fixes 0.96 Small updates 0.97 Figure 10 corrected 0.98 Recommended land pattern, land width added 0.99 Soldering recommendations added 1.0 Certification information updated. Layout guide for BLE112-N added. Bluegiga Technologies Oy TABLE OF CONTENTS 1 BLE112 Product numbering ......................................................................................................................... 6 2 Pinout and Terminal Description .................................................................................................................. 7 3 Electrical Characteristics ............................................................................................................................ 10 3.1 Absolute Maximum Ratings ................................................................................................................ 10 3.2 Recommended Operating Conditions ................................................................................................. 10 3.3 Antenna characteristics ....................................................................................................................... 10 4 Design Guidelines ...................................................................................................................................... 15 4.1 General Design Guidelines ................................................................................................................. 15 4.2 Layout Guide Lines ............................................................................................................................. 16 4.3 BLE112-A Layout Guide ..................................................................................................................... 16 4.4 BLE112-N Layout Guide ..................................................................................................................... 17 5 Soldering Recommendations ..................................................................................................................... 19 6 Block diagram ............................................................................................................................................. 20 7 Certifications ............................................................................................................................................... 23 7.1 Bluetooth ............................................................................................................................................. 23 7.2 FCC and IC ......................................................................................................................................... 23 7.3 CE ....................................................................................................................................................... 26 7.4 Qualified Antenna Types for BLE112-E and BLE112-N ..................................................................... 26 8 Contact Information .................................................................................................................................... 27 Bluegiga Technologies Oy BLE112 Bluetooth® low energy single mode module DESCRIPTION BLE112, Bluetooth low energy single mode module is a single mode device targeted for low power sensors and accessories. BLE112 offers all Bluetooth low energy features: radio, stack, profiles and application space for customer applications, so no external processor is needed. The module also provides flexible hardware interfaces to connect sensors, simple user interfaces or even displays directly to the module. BLE112 can be powered directly with a standard 3V coin cell batteries or pair of AAA batteries. In lowest power sleep mode it consumes only 400nA and will wake up in few hundred microseconds. APPLICATIONS:  Heart rate sensors  Pedometers  Watches  Blood pressure and glucose meters  Weight scales  Key fobs  Households sensors and collector devices  Security tags  Wireless keys (keyless go)  Proximity sensors  HID keyboards and mice  Indoor GPS broadcasting devices KEY FEATURES:  Bluetooth v.4.0, single mode compliant o Supports master and slave modes o 4+ simultaneous connection in master mode  Integrated Bluetooth low energy stack o GAP, GATT, L2CAP, SMP o Bluetooth low energy profiles  Radio performance o TX power: +3dBm to -23dBm o RX sensitivity: -87dBm to - 93dBm  Ultra low current consumption o Transmit: 27mA (0dBm) o Sleep mode 3: 0.4uA  Programmable 8051 processor for embedding full applications  Bluetooth end product, CE, FCC and IC and Telec qualified Bluegiga Technologies Oy Preliminary – information subject to change Page 6 of 27 1 BLE112 Product numbering BLE112-A-X Generation: 1 = 1st 2 = 2nd 3 = 3rd Firmware revision - 1.0 - 2.1 - 3.2 Antenna: A = Internal E = External N = RF pin Type: 1 = Single mode 2 = Dual mode 3 = Reseved Class:…

Text truncated - open the document above for the full version.

Bluegiga Technologies Sinikalliontie 5A, P.O. Box 120 02630 Espoo FINLAND Tel +358 9 435 5060 | Fax +358 9 435 50660 Co ID 0934238-1, VAT registered, domicile: Espoo www.bluegiga.com | [email protected] Picture 1: External top view, BLE112-A Picture 2: Internal top view, BLE112-A Bluegiga Technologies Sinikalliontie 5A, P.O. Box 120 02630 Espoo FINLAND Tel +358 9 435 5060 | Fax +358 9 435 50660 Co ID 0934238-1, VAT registered, domicile: Espoo www.bluegiga.com | [email protected] Picture 3: Bottom view

Bluegiga Technologies Sinikalliontie 5A, P.O. Box 120 02630 Espoo FINLAND Tel +358 9 435 5060 | Fax +358 9 435 50660 Co ID 0934238-1, VAT registered, domicile: Espoo www.bluegiga.com | [email protected] Label for BLE112-A 10.8mm 11.7mm 3.0mm FCC ID: QOQBLE112 IC : 5123A‐BGTBLE112 5.0mm Model: BLE112‐A Label for BLE112-E FCC ID: QOQBLE112 IC : 5123A‐BGTBLE112 Model: BLE112‐E Bluegiga Technologies Sinikalliontie 5A, P.O. Box 120 02630 Espoo FINLAND Tel +358 9 435 5060 | Fax +358 9 435 50660 Co ID 0934238-1, VAT registered, domicile: Espoo www.bluegiga.com | [email protected] Label for BLE112-N FCC ID: QOQBLE112 IC : 5123A‐BGTBLE112 Model: BLE112‐N

Bluegiga Technologies Sinikalliontie 5A, P.O. Box 120 02630 Espoo FINLAND Tel +358 9 435 5060 | Fax +358 9 435 50660 Co ID 0934238-1, VAT registered, domicile: Espoo www.bluegiga.com | [email protected] Picture 1: External top view, BLE112-A Picture 2: Internal top view, BLE112-A Bluegiga Technologies Sinikalliontie 5A, P.O. Box 120 02630 Espoo FINLAND Tel +358 9 435 5060 | Fax +358 9 435 50660 Co ID 0934238-1, VAT registered, domicile: Espoo www.bluegiga.com | [email protected] Picture 3: Bottom view

Wireless External Antenna for 2.4 GHz Applications Pulse Part Number: W1030 © 2007 All Rights Reserved. W1030 Datasheet Version 1.1. September 2007 Feat ures - Shortest antennas in product lin e - For WLAN devices using WiFi (802.11b/g), Bluetooth® and ZigBee TM - Omni-directional radiation patte rn provides broad 360° coverage - One-quarter wavelength dipole confi guratio n - Connection options easily integrate with OEM designs Connector Option s - Reverse SMA (Male)* - SMA (Male) * Default Configuration – Please contact Pulse Applications Engineering for assistance in ordering connectors Weight........................................................6.3 grams Carton...........................................20/bag; 500/carton Dimensions: Inches mm Unless otherwise specified, a ll to lerances are ± .010 0.25 Frequency [GHz] VSWR Length Impedance [Nom] ≤ 2. 01/4, dipole50 Ω Electrical Specifications @ 25 ºC Note: This par t number is lead- free and RoHS compliant. N o additional suffix or identifier is required. Gain [dBi] 2.0 Radiatio n Omni Polarization Vertic al Antenna Part No. W1030 Pulse Antennas Takatie 6 90440 K empele Finland Tel: +358 207 935 500 www.pulseeng.com/antennas Exte rnal Antennas Sal es Contacts USA858 674 8100 UK44 1483 401 700 France33 3 84 35 04 04 Singapore65 6287 8998 Shanghai86 21 32181071 China86 769 5538070 Taiwan886 2 26980228 Electrical Wireless External Antenna for 2.4 GHz Applications Pulse Part Number: W1030 © 2007 All Rights Reserved. W1030 Datasheet Version 1.1. September 2007 Vertical Posi tion Horizontal Posi tion Gain Performance W1030 Omni-directional antennas provide a uniform, donut- shaped, 360° radiation pattern. The omni-directional pattern is suitable for point-to-multipoint broadcasting in all directions. This antenna is primarily used for WLAN applications. However, it can also be used for a variety of other applications within the specified frequency range. When used as an access point, th e antenna is ideally located at the center of the coverage ar ea. Application Notes Pulse Antennas Takatie 6 90440 K empele Finland Tel: +358 207 935 500 www.pulseeng.com/antennas Exte rnal Antennas Sales Contacts USA858 674 8100 UK44 1483 401 700 France33 3 84 35 04 04 Singapore65 6287 8998 Shanghai86 21 32181071 China86 769 5538070 Taiwan886 2 26980228

ACX Advanced Ceramic X AT3216 Series Multilayer Chip Antenna Features ™ Monolithic SMD with small, low-profile and light-weight type. ™ Wide bandwidth Applications ™Bluetooth/Wireless LAN/Home RF ™ISM band 2.4GHz applications Specifications Part Number Frequency Range (MHz) Peak Gain （XZ-V） Average Gain （XZ-V） VSWR Impedance AT3216 -B2R7HAA_ 2400 ~ 2500 0.5 dBi typ. -0.5 dBi typ.2 max. 50 Ω Q’ty/Reel (pcs) : 3,000pcs Operating Temperature Range : -40 ~ +85 o C Storage Temperature Range : -40 ~ +85 o C Power Capacity : 3W max. Part Number AT 3216 - B 2R7 HAA ‡ ‡ i ghfe dc c Type AT : Antenna d Dimensions ( L × W ) 3.2× 1.6 mm e Material Code B f Frequency Range 2R7=2700MHz g Specification Code HAA h Packaging T: Tape & Reel B: Bulk i Soldering =lead-containing /LF=lead-free Terminal Configuration No. Terminal Name No. Terminal Name c Feeding Point d NC d c ACX Advanced Ceramic X Dimensions and Recommended PC Board Pattern Unit : mm a W T L Mark L W T a Dimensions 3.2±0.2 1.6±0.2 1.3+ 0.1/-0.2 0.5±0.3 (a) Without Matching Circuits (b) With Matching Circuits 1.2pF 3.3nH 2.6 4.2 1.6 1.9 2.7nH 0.4 * *Line width should be designed to match 50Ω characteristic impedance, depending on PCB material and thickness. ACX Advanced Ceramic X Typical Electrical Characteristics (T=25 o C) ™Test Board Ground 13.5mm 6.5mm 39.5mm 4mm No Ground Matching Circuit 50Ω Feed Line 19mm Antenna 6.5mm ™Return Loss (a) Without Matching Circuits (b) With Matching Circuits ACX Advanced Ceramic X Radiation Patterns .... XZ cut @2.45GHz Vertical Horizontal YZ cut @2.45GHz Vertical Horizontal XZ-V/XZ-H YZ-V/YZ-H XY cut @2.45GHz Vertical Horizontal Z 270 o 0 o X Y XY-cut scanning direction Y 270 o 0 o X Z XZ-cut scanning direction Z X 0 o 270 Y YZ-cut scanning direction 180 180 180 o XY-V/XY-H 90 o 90 o 90 o Advanced Ceramic X Corp. 16 Tzu Chiang Road, Hsinchu Industrial District Hsinchu Hsien 303, Taiwan TEL:886-3-5987008 FAX:886-3-5987001 E-mail: [email protected] http://www.acxc.com.tw

1 (1) SGS Fimko Ltd Särkiniementie 3, PO Box 30 FI-00211 Helsinki, Finland t. +358 9 696 361 f. +358 9 692 5474 www.fi.sgs.com Business ID 0978538-5 Member of the SGS Group (SGS SA) RF EXPOSURE ANALYSIS Product FCC ID _IC number Bluetooth module QOQBLE112 5123A-BGTBLE112 The product is a Bluetooth low energy single mode module to be used in a various kind of low power applications. This evaluation cover all three models BLE112-A, BLE112-E and BLE112-N presented in the test reports 264152-7, -8 and -9. The evaluation value is the highest output power generated by the device. It is designed to be used 20 cm distance from the persons. Analysis for FCC The equipment transmits in the 2402 – 2480 MHz frequency range and therefore the applicable threshold is calculated as stated in FCC document KDB 447498 by using the formula f 60 (where f is a highest frequency in used) mW19.24 48.2 60 = Output power considerations: Max. E.I.R.P value: 4.89 dBm = 3.08 mW (Value is taken from the test report number: 264152-8. Value contains conducted output power and antenna gain.) Analysis for FCC Since the Max. E.I.R.P value is below the 24.19mW product fulfils FCC requirements without further testing. Analysis for IC According to standard RSS-102 RF exposure analysis is required for devices operating abowe 1.5 GHz if the maximum E.I.R.P. of the device is 5.0 W or more. Therefore RF exposure analysis is not required for this device. Result: Equipment complies with the requirements of FCC and IC to RF exposure

Reference number: 264152-7 Page 2 of 28 Table of Contents PRODUCT DESCRIPTION 3 Equipment Under Test (EUT) 3 Description of the EUT 3 Ratings and declarations 3 P ower Supply 3 Mechanical Size of the EUT 4 Peripherals 4 Samples 4 GENERAL REMARKS 5 Disclaimer 5 SUMMARY OF TESTING 6 EUT Test Conditions During Testing 6 TEST RESULTS 7 Transmitter Radiated Emissions 30 – 1000 MHz 7 Transmitter Radiated Emissions 1 000 – 26 500 MHz 11 Receiver Radiated Emissions 30 – 26 500 MHz 22 Conducted emissions 26 LIST OF TEST EQUIPMENTS 28 Reference number: 264152-7 Page 3 of 28 Product Description PRODUCT DESCRIPTION Equipment Under Test (EUT) Bluetooth module Model: BLE112-A Type: - Serial no: - HW version: SW version: 1.0 FCC ID number: QOQBLE112 Industry Canada number: 5123A-BGTBLE112 Description of the EUT The EUT is a Bluetooth low energy single mode module targeted for low power sensors and accessories. Device can be used with batteries or from DC power supply. Classification of the device Fixed device Mobile Device (Human body distance > 20cm) Portable Device (Human body distance < 20cm) Modifications Incorporated in the EUT No modifications were applied to the EUT during testing Ratings and declarations Operating Frequency Range (OFR): 2402 – 2480 MHz Channels: 40 Transmission technique: Digital transmission Modulation: GFSK Antenna connector type Internal Antenna gain: 0.5 dBi Power Supply Battery operated Operating voltage range 2,0 – 3,6 VDC Normal input voltage: 3.0 V coin battery or 2 x 1,5V AAA batteries Tested by using external power supply and 3.0 VDC voltage level Reference number: 264152-7 Page 4 of 28 Product Description Mechanical Size of the EUT Height: 2,03 mm Width:12,05 mm Depth: 18,10 mm Peripherals Peripheral DC power supply Thandar TS3021S. Samples All tests were performed to one sample. No modifications were done during the tests. Reference number: 264152-7 Page 5 of 28 General remarks GENERAL REMARKS Disclaimer This test report is issued under SGS Fimko general terms of delivery (available on request and accessible at www.fi.sgs.com ). Attention is drawn to the limitations of liability, indemnification and jurisdictional issues defined therein. Unless otherwise stated: (a) the results shown in this document refer only to the sample(s) tested and (b) such sample(s) are retained for three months. This document cannot be reproduced except in full, without prior approval of SGS Fimko. Any unauthorized alteration, forgery or falsification of the content or appearance of this report is unlawful and offenders may be prosecuted to the fullest extent of the law Reference number: 264152-7 Page 6 of 28 Summary of Testing SUMMARY OF TESTING Test SpecificationDescription of TestResult §15.209(a) §15.247(d) / RSS-210 A8.5 Radiated Emissions Within The Restricted Bands PASS §15.109 RSS-GEN 7.2.3.2 Unintentional Radiated Emissions PASS §15.207 RSS-GEN 7.2.2 Conducted emissions PASS EUT Test Conditions During Testing The EUT was in continuous transmit mode during all the tests. The hopping was stopped and the EUT was configured into the wanted channel. Normal modulation and duty cycle was applied in all the tests. Following channels were used during the tests when the hopping was stopped: Channel LOW (CH 0) = 2402 MHz Channel MID (CH 20) = 2442 MHz Channel HIGH (CH 39) = 2480 MHz Test Facility Testing Location / address: FCC registration number: 90598 SGS Fimko Ltd Särkiniementie 3 FI-00210, HELSINKI FINLAND Testing Location / address: FCC registration number: 178986 Industry Canada registration number: 8708A-2 SGS Fimko Ltd Karakaarenkuja 4 FI-02610, ESPOO FINLAND Reference number: 264152-7 Page 7 of 28 Radiated Emission Test TEST RESULTS Transmitter Radiated Emissions 30 – 1000 MHz Standard: ANSI C63.10 (2009) Tested by: JJM Date: 25.5.2011 Humidity: 35 % Temperature: 22.0 °C Measurement uncertainty ±4.51 dB Level of confidence 95 % (k = 2) FCC Rule: 15.247(d), 15.209(a) In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement, provided the transmitter demonstrates compliance with the peak conducted power limits. If the transmitter complies with the conducted power limits based on the use of RMS averaging over a time interval, as permitted under paragraph (b)(3) of this section, the attenuation required under this paragraph shall be 30 dB instead of 20 dB. Attenuation below the general limits specified in Section 15.209(a) is not required. In addition, radiated emissions which fall in the restricted bands, as defined in Section 15.205(a), must also comply with the radiated emission limits specified in Section 15.209(a) . The correction factor in the final result table contains the sum of the transducers (antenna + amplifier + cables). The QuasiPeak value is the measured value corrected with the correction factor. Reference number: 264152-7 Page 8 of 28 Radiated Emission Test Measured Peak Values In The Frequency Range 30 MHz - 1000 MHz. 0 10 20 30 40 50 60 70 80 30M 5060 80100M200300400500 8001G L e v e l i n d B M V / m Frequency in Hz FCC Part 15 Class B Electric Field Strenght FCC Part 15 Class B Electric Field Strength QPMaxPeak-ClearWrite-PK+MaxPeak-ClearWrite-PK+ Final Result 1-QPKFinal Result 2-PK+ Figure 1. Measured curve with peak-detector. Channel LOW. Final measurements from the worst frequencies Frequency (MHz) QuasiPeak (dBAV/m) Meas. Time (ms) Bandwidth (kHz) Height (cm) PolAzimuth (deg) Corr. (dB) Margin (dB) 30.34000015.515000.0120.000130.0H195.019.024.5 36.798750 11.7 15000.0 120.000 128.0 H 48.0 15.3 28.3 490.245000 17.0 15000.0 120.000 250.0 H 104.0 21.6 29.0 696.85625022.015000.0120.000100.0V226.025.524.0 869.425000 23.8 15000.0 120.…

Text truncated - open the document above for the full version.

Reference number: 264152-8 Page 2 of 58 Table of Contents PRODUCT DESCRIPTION 3 Equipment Under Test (EUT) 3 Description of the EUT 3 Ratings and declarations 3 P ower Supply 3 Mechanical Size of the EUT 4 Peripherals 4 Samples 4 GENERAL REMARKS 5 Disclaimer 5 SUMMARY OF TESTING 6 EUT Test Conditions During Testing 6 TEST RESULTS 7 Maximum Peak Conducted Output Power 7 Transmitter Radiated Emissions 30 – 1000 MHz 11 Transmitter Radiated Emissions 1 000 – 26 500 MHz 15 Transmitter Band Edge Measurement and Conducted Spurious Emissions 26 6 dB Bandwidth of the Channel 41 Power Spectral Density 45 99% Occupied Bandwidth 49 Receiver Radiated Emissions 30 – 26 500 MHz 53 Conducted emissions 56 LIST OF TEST EQUIPMENTS 58 Reference number: 264152-8 Page 3 of 58 Product Description PRODUCT DESCRIPTION Equipment Under Test (EUT) Bluetooth module Model: BLE112-E Type: - Serial no: - HW version: SW version: 1.0 FCC ID number: QOQBLE112 Industry Canada number: 5123A-BGTBLE112 Description of the EUT The EUT is a Bluetooth low energy single mode module targeted for low power sensors and accessories. Device can be used with batteries or from DC power supply. Classification of the device Fixed device Mobile Device (Human body distance > 20cm) Portable Device (Human body distance < 20cm) Modifications Incorporated in the EUT No modifications were applied to the EUT during testing Ratings and declarations Operating Frequency Range (OFR): 2402 – 2480 MHz Channels: 40 Channel separation: 2 MHz Channel bandwidth: 1.25 MHz Effective conducted power: 2.59 dBm Transmission technique: Digital Transmission Modulation: GFSK Antenna connector type RF pin connector Antenna gain: 2.14 dBi Power Supply Battery operated Operating voltage range 2,0 – 3,6 VDC Normal input voltage: 3.0 V coin battery or 2 x 1,5V AAA batteries Tested by using external power supply and 3.0 VDC voltage level Reference number: 264152-8 Page 4 of 58 Product Description Mechanical Size of the EUT Height: 2,03 mm Width:12,05 mm Depth: 18,10 mm Peripherals Peripheral DC power supply Thandar TS3021S. Samples All tests were performed to one sample. No modifications were done during the tests. Reference number: 264152-8 Page 5 of 58 General remarks GENERAL REMARKS Disclaimer This test report is issued under SGS Fimko general terms of delivery (available on request and accessible at www.fi.sgs.com ). Attention is drawn to the limitations of liability, indemnification and jurisdictional issues defined therein. Unless otherwise stated: (a) the results shown in this document refer only to the sample(s) tested and (b) such sample(s) are retained for three months. This document cannot be reproduced except in full, without prior approval of SGS Fimko. Any unauthorized alteration, forgery or falsification of the content or appearance of this report is unlawful and offenders may be prosecuted to the fullest extent of the law Reference number: 264152-8 Page 6 of 58 Summary of Testing SUMMARY OF TESTING Test SpecificationDescription of TestResult §15.247(b)(3) / RSS-210 A8.4 Maximum Peak Conducted Output Power PASS §15.247(a)(2) / RSS-210 A8.2 6 dB Bandwidth PASS §15.247(e) / RSS-210 A8.2 Power Spectral Density PASS RSS-GEN 4.6.1 99% Occupied Bandwidth PASS §15.247(d) / RSS-210 A8.5 100 kHz Bandwidth of Frequency Band Edges and Conducted Spurious Emissions PASS §15.209(a), §15.247(d) / RSS-210 A8.5 Radiated Emissions Within The Restricted Bands PASS §15.109 / RSS-GEN 7.2.3.2 Unintentional Radiated Emissions PASS §15.207 / RSS-GEN 7.2.2 Conducted emissions PASS EUT Test Conditions During Testing The EUT was in continuous transmit mode during all the tests. The hopping was stopped and the EUT was configured into the wanted channel. Normal modulation and duty cycle was applied in all the tests. Following channels were used during the tests when the hopping was stopped: Channel LOW (CH 0) = 2402 MHz Channel MID (CH 20) = 2442 MHz Channel HIGH (CH 39) = 2480 MHz Test Facility Testing Location / address: FCC registration number: 90598 SGS Fimko Ltd Särkiniementie 3 FI-00210, HELSINKI FINLAND Testing Location / address: FCC registration number: 178986 Industry Canada registration number: 8708A-2 SGS Fimko Ltd Karakaarenkuja 4 FI-02610, ESPOO FINLAND Reference number: 264152-8 Page 7 of 58 Conducted Output Power Test TEST RESULTS Maximum Peak Conducted Output Power Standard: ANSI C63.10 (2009) Tested by: JJM Date: 25.5.2011 Humidity: 22 % Temperature: 35 °C Measurement uncertainty ±2,87dB Level of confidence 95 % (k = 2) FCC Rule: 15.247(b)(3) For systems using digital modulation in the 2400-2483.5 MHz bands the limit is 1 Watt. As an alternative to a peak power measurement, compliance with the one Watt limit can be based on a measurement of the maximum conducted output power. Results: ChannelConducted Power [dBm] Limit [dBm]Margin [dBm]Result Low 1.94 30 28.06 PASS Mid 2.44 30 27.56 PASS High 2.59 30 27.41 PASS The attenuation of the measurement cable and the attenuator was added as an offset 10.5 dB to correct the measurement result. Reference number: 264152-8 Page 8 of 58 Conducted Output Power Test Att 5 dB * A Offset10.5 dB LVL Ref 5 dBm Center 2.402 GHzSpan 7 MHz700 kHz/ * 3DB RBW 2 MHz SWT 2.5 ms * VBW 3 MHz 1 PK MAXH -90 -80 -70 -60 -50 -40 -30 -20 -10 0 1 Marker 1 [T1 ] 1.96 dB m 2.401988782 GHz Date: 25.MAY.2011 08:45:08 Figure 1. Channel LOW. Reference number: 264152-8 Page 9 of 58 Conducted Output Power Test Att 5 dB * A Offset10.5 dB LVL Ref 5 dBm 1 PK MAXH Center 2.442 GHzSpan 7 MHz700 kHz/ * * 3DB RBW 2 MHz VBW 3 MHz SWT 2.5 ms -90 -80 -70 -60 -50 -40 -30 -20 -10 0 1 Marker 1 [T1 ] 2.44 dB m 2.442011218 GHz Date: 25.MAY.2011 08:53:34 Figure 2. Channel MID. Reference number: 264152-8 Page 10 of 58 Conducted Output Power Test Att 5 dB * A Offset10.5 dB LVL Ref 5 dBm 1 PK MAXH Center 2.48 GHzSpan 7 MHz700 kHz/ * * 3DB RBW 2 MHz VBW 3 MHz SWT 2.5 ms -90 -80 -70 -60 -50 -40 -30 -20 -10 0 1 Marker 1 [T1 ] 2.59 dB m 2.480246795 GHz Date: 25.MAY.2011 09:06:40 F…

Text truncated - open the document above for the full version.

1 (4) 9.8.2011 Test setup photographs. Bluegiga Oy Project number: 264152-7, -8, -9 Conducted emissions test setup. 2 (4) 9.8.2011 Radiated emission test setup. 3 (4) 9.8.2011 Radiated emission test setup. 4 (4) 9.8.2011 Radiated emission test setup.
