QPISLROOMTMP01Sensor Link Room Temperature Transmitter

SENSOR LINK INSTALLATION/OPERATING INSTRUCTIONS The Sensor Link system consists of a Receiver and one or more Temperature or Pressure Transmitters. The Receiver is designed to intercept and decode the wireless information being emitted by the Transmitters and forward the data to the Heat-Timer panel (HWR, HWR-Q, MPC, MPC-Q, SRC, or Multi- MOD) via a wired connection. Instruction to User This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be deter- mined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: * Reorient or relocate the receiving antenna. * Increase separation between the equipment and receiver. * Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. * Consult the dealer or an experienced radio/TV technician for help. This equipment has been certified to comply with the limits for a class B computing device, pursuant to FCC Rules. In order to maintain compliance with FCC regulation, shielded cables must be used with this equipment. Operation with non-approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The user is cautioned that changes or modifications made to the equipment without the approval of the manufacturer could void the userís authority to operate this equipment. PROGRAM LOCK THERMAL LOCKOUT DIFFERENTIAL E PRESS TO DISPLAY MADE IN U.S.A. CONNECTED MUST CLOCKNEUTRAL LINE 132 OPTION READ INSTRUCTIONS BEFORE PROGRAMMING PROGRAM BER B OUTPUT W 12 34 56 AUX.OPTION 7 8 9 10121113 OUTPUT RELAY UNLOCK BY-PASS AUTO CLOCK AUX. 1 OPTION SUMMER WINTER RUN N C R ADJUSTMENT BOOST VARI OPTIONOPTION 17141516 MANUAL X WITH VARI SHUT DOWN Z ON I 3 OPTION 2 ADVANCE REVIEW PAIR SHOWN ERASE Y HEATING SYSTEM SENSOR A S E OFF FAST CYCLE FOR TESTING MORNING BOOST 120 SHUT DOWN CURVE Series (DAY) SYSTEM IN NORMAL AM TUE N HEAT ADJUSTMENT SYSTEM IN SAVE (NIGHT) OUTDOOR SENSOR SET POINTS SHIFT HOURS MON CURRENT STATUS INDICATORS E A L C B P O NORMAL H G F E S S D J K M L -DAY I THU CLOCK PROGRAM CONTROLS MINUTES PM DAY WEDSATFRI SUN TEMP 2 COPYDAY OFF MANUAL MINUTES VARI-BOOST / 1 20 OUT- SIDE40 3 60 4 80 BOOST K -NIGHT R E A L E C B SAVE F S S O M D E GJ H I R P E N O M O L M Gold SERIAL NO. 5 6 100 USE COPPER WIRE ONLY OUTPUTS: 120VAC, 6A RESISTIVE 1A PILOT DUTY 15A TOTAL FOR ALL CIRCUITS HEAT-TIMER PANEL HWR, HWRQ, MPC, MPCQ, SRC, Multi-MOD HEAT SOURCE ACTIVATED HEAT CIRCULATION ESTABLISHED SYSTEM IN CYCLE J1 X1 X2 X3 120 VAC Power Sensor Link Receiver Sensor Link Transmitter SENSOR LINK RECEIVER INSTALLATION Mount the enclosure ï In a location central to the various Transmitters. ï To prevent unauthorized tampering, the Receiver should be located in an inconspicuous area, or in an area with limited access. ï The Receiver must be located where the ambient temperature will not exceed 130∞F and away from any steam or moisture. ï Attach the Receiver to a flat surface by screwing through the mounting holes located on the top and bottom flange. ï If desired, the Receiver may also be installed inside a metal enclo- sure. Power Wiring ï Bring the 120VAC 60Hz power wires through the round opening in the enclosure. ï Class 1 voltages must enter the enclosure through a different opening from any Class 2 voltage wiring. ï Connect power to the terminals as shown at right. ï The GND terminals MUST be connected to earth ground. Network Wiring ï Use 2-wire unshielded twisted pair (see specification below). ï There is no polarity to observe. Either network wire from the Receiver can be attached to Heat-Timer panel (HWR, HWRQ, MPC, MPCQ, SRC, or Multi-MOD) Network terminals A or B. ï Bring the network wiring through the rectangular opening in the enclosure. ï Network wiring must enter the enclosure through a different opening from any Class 1 voltage wiring. ï Wire the network connections to the terminal block marked J1, terminals X1 and X2. ï The wires can be run in virtually any configuration back to the Heat- Timer panel. They can be wired sensor to sensor (daisy chained). They can be wired in a star configuration, with each sensor pair brought back to the panel. Finally, there can be any combination of the two. ï The Receiver has a specific ID number. The ID number is on the back of the Receiver, and is on the Network Identification card which is provided. Fill out the location of the Receiver on the Network Identification card and return it to the Heat-Timer network adminis- trator. GND Neutral Line WireType Belden 8471 Belden 85102 Unshielded Twisted Pair 16AWG GaugeMaximum Length (ft)Maximum Temp (°F) Unshielded Twisted Pair 16AWG 1200 1200 140 185 J1 X1 X2 X3 To Network Terminals A &B SENSOR LINK RECEIVER OPERATION Power Up Display ï When the receiver is first powered, 8 will be displayed in each of the digits in turn, moving from right to left. ï Next the display will briefly show the version number, and then go blank. ï During this period, the green LED (D1), yellow LED (D2), and red LED (D3) will flash or light. ï When the display goes blank, only the red LED (D3) will remain on to indicate the Receiver is powered. Display Modes ï Pressing the push button will set the display mode for the Receiver. ï Once a display mode is selected, the Receiver will remain in the selected display mode until the push button is pressed and a new mode is selec…

Text truncated - open the document above for the full version.

Sensor Link Transmitter FCC Label 20 New Dutch Lane ® Fairfield, NJ 07004 Tel: (973) 575-4004 ® Fax: (973) 575-4052 HTC Product # Doc # Rev. Date Prepared by WWW.Heat-Timer.com EDR068 A 7/7/04 Oron Brokman EDR068A FCC label for Sensor Link Transmitter Room Temp 070704.doc 7/7/2004 Page 1 of 1 Purpose This document illustrates the FCC label used on the Sensor Link Transmitter. Ro o m T e m p e r a t u r e Se n s o r T RA N SM I T T ER (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND Operation is subject to the following two conditions: This device complies with Part 15 of the FCC Rules. FCC ID: QPISLROOMTMP01 SEN SOR-L I N K Note: All dimensions are in Inches.

Report Number: B40625A1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Sensor Link Room Temperature Transmitter Model: 904710-00 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 14 FCC PART 15, SUBPART B and C TEST REPORT for SENSOR LINK ROOM TEMPERATURE TRANSMITTER MODEL: 904710-00 Prepared for HEAT-TIMER CORPORATION 20 NEW DUTCH LANE FAIRFIELD, NEW JERSEY 07004 Prepared by:_____________________ JAMES ROSS Approved by:____________________ MICHAEL CHRISTENSEN COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: JULY 8, 2004 REPORT APPENDICES TOTAL BODY A B C D E PAGES 14 2 2 2 10 11 41 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B40625A1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Sensor Link Room Temperature Transmitter Model: 904710-00 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 14 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description Of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 Radiated Emissions (Spurious and Harmonics) Test 13 8. CONCLUSIONS 14 Report Number: B40625A1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Sensor Link Room Temperature Transmitter Model: 904710-00 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 14 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of 3 Meter Radiated Test Site Report Number: B40625A1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Sensor Link Room Temperature Transmitter Model: 904710-00 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 14 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Sensor Link Room Temperature Transmitter Model: 904710-00 S/N: N/A Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Manufacturer: Heat-Timer Corporation 20 New Dutch Lane Fairfield, New Jersey 07004 Test Dates: June 23 and 25, 2004 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.209 and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz This test was not performed because the EUT operates on DC power only and cannot be plugged into the AC public mains. 2 Radiated RF Emissions, 10 kHz – 9.2 GHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B40625A1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Sensor Link Room Temperature Transmitter Model: 904710-00 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 14 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Sensor Link Room Temperature Transmitter Model: 904710-00. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B; and Subpart C, sec…
