QPY-263XCO-ZWIRELESS CARBON MONOXIDE ALARM

UTC. All Rights Reserved. 1 P/N 0000000 – Rev. A – 06 Nov 12 263B-CO-OEM Carbon Monoxide Alarm Product Introduction This wireless carbon monoxide (CO) Alarm (product) monitors the levels of CO gas and gives early warning when potentially dangerous levels exist. It does not detect fire, smoke, or any other gas. If a dangerous concentration of CO is detected by patented and field-proven electrochemical sensor, an LED indicator illuminates and an internal siren is activated in Temporal 4 pattern. The CO Alarm also transmits an alarm signal to the control panel within 15 seconds of detecting dangerous concentration of CO gas. The control panel activates its internal siren and reports the alarm condition to the central monitoring station (if the system is monitored). The CO Alarm also detects low battery, wall tamper, and sensor end-of-life. These trouble codes are transmitted to the control panel which reports the condition to the central monitoring station. The alarm automatically reset when CO is no longer detected. This wireless CO Alarm is Listed and compliant with the ANSI/UL 2034 standard for CO Alarms. It is intended for residential indoor dwelling unit applications and other areas approved by the authority having jurisdiction (AHJ). It is not intended for use in industrial applications. This wireless product works in conjunction with your wireless Control Panel, providing a local indication. Refer to the panel installation instructions for revision verification details. Please contact Technical Support for any questions regarding compatibility. About This Guide This User Guide describes how to install, the operation and maintenance of this product. The User Guide is organized as you intent to use this product with step by step instructions. Keep this document in a handy location and refer to it when you have questions about this product and its functions and features. Reading this guide is the only way to learn how to use your product wisely and to know how to react in the event of an alarm. Attention: Please take a few minutes to thoroughly read this guide which should be saved for future reference and passed on to any subsequent owner. 1. General Information Congratulations on purchasing your Carbon Monoxide Alarm. This product is designed to be used with a Control Panel as part of the Life Safety signaling device. This product has a chemical CO sensor capable of detecting CO gases in the event of dangerous CO gas exposure. WARNING: After seven years from initial power up, this alarm will beep two times every 30 seconds to indicate that it is time to replace the alarm. Replace the alarm immediately! It will not detect CO in this condition. To help identify the date to replace the alarm, an area has been reserved on the side of the alarm. Write the “replace by” date (seven years from power up) with a permanent marker in the area provided. Parts List One Carbon Monoxide Alarm Three AA alkaline batteries Mounting Plate Mounting Screws and Anchors User Guide 2. Mounting Guideline This product is a member of a reliable, high-quality product family using the latest technology available. Review the information in this section to ensure you get the most out of the product. Choosing an Installation Location CO Alarms should be mounted in or near bedrooms and living areas. We recommend that you install an alarm on each level of your home. When choosing your installation locations, make sure you can hear the alarm from all sleeping areas. If you install only one CO Alarm in your home, install it near bedrooms, not in the basement or furnace room. Place the alarm out of reach of children. Under no circumstances should children be allowed to handle the CO Alarm. Recommended locations Locations to avoid Improper location can affect the sensitive electronic components in this alarm. To avoid causing damage to the unit, to provide optimum performance, and to prevent unnecessary nuisance alarms: o Do not install in kitchens, garages, or furnace rooms that may expose the sensor to substances that could damage or contaminate it. o Do not install in areas where the temperature is colder than 40°F (4.4°C) or hotter than 100°F (37.8°C) such as crawl spaces, attics, porches, and garages. o Do not install within 5 ft. of heating or cooking appliances. (We recommend 15 ft. to prevent nuisance alarms.) UTC. All Rights Reserved. 2 P/N 0000000 – Rev. A – 06 Nov 12 o Do not install near vents, flues, chimneys, or any forced/unforced air ventilation openings. o Do not install on metal surfaces. o Avoid mounting in areas with a large quantity of metal or electrical wires. o Do not install near ceiling fans, doors, windows, or areas directly exposed to the weather. o Do not install in dead air spaces, such as peaks of vaulted ceilings or gabled roofs, where CO may not reach the sensor in time to provide early warning. o Do not install near deep-cell large batteries. Large batteries have emissions that can cause the alarm to perform at less than optimum performance. o Do not obstruct the vents located on the alarm. Do not place the alarm where drapes, furniture, or other objects block the flow of air to the vents. 3. Mounting the Sensor Note: Add the product to the Control Panel before physically mounting the product in the desired location. This verifies RF performance prior to permanently mounting the alarm. See “RF communication test”. The CO Alarm can be wall mounted or ceiling mounted. To mount the alarm: A. Slide the product body off of the mounting plate. Place the mounting plate in the desired location, and mark the location of the two mounting holes. Orient the mounting plate vertically or horizontally as shown in the following figures. Note: The product can also be directly mounted to a single gang box. Vertical Mounting Horizontal Mounting B. Insert the two screws provided and secure the mounting plate to the wall or ceiling surface. (If mounting in plasterboard or drywall, drill a 3/16 in. hole and use…

Text truncated - open the document above for the full version.

B 4SPQ6 FILE NAME DRAWN BYCHECKERAPPROVEDAPPROVED MATERIALTREATMENT OR FINISH NEXT ASSY USED ON APPLICATION DATEDATEDATEDATE SCALE SHEET SIZE CAGE CODE DWG NO. REV A AB B 4 3 2 11 2 3 4 OF 1:1 - - - - - 21009057 21009057EN01.dft EN01 1 1 LBL, PRODUCT, CO SP 03/27/2012 PRELIMINARY THIRD ANGLEPROJECTION UNLESS OTHERWISE SPECIFIED:MATERIAL TO BE COMPLIANT WITH RoHSDIRECTIVE 2002/95/ECDIMENSIONS ARE IN INCHESCAPACITANCE IS IN uFRESISTANCE IS IN OHMSTOLERANCES: .X = ±.03 .XX = ±. 01 .XXX = ±.0 05 ANGLES = ±0.5° -- DO NOT SCALE DRAWING-- EDWARDS, A UTC FIRE &SECURITY COMPANY8985 TOWN CENTER PARKWAYBRADENTON, FL 34202-5129(941) 739-4200 COPYRIGHT: CONFIDENTIAL COPYRIGHT © 2012 UTC FIRE & SECURITY, ALL RIGHTS RESERVED. UNAUTHORIZED ACCESS TO, COPYING, USE OF OR DISCLOSU RE OF THIS ARTIFACT, OR ANY OF ITS FEATURES, IS STRICTLY PROHI BITED. YOUR ACCESS TO OR POSSESION OF A COPY OF THIS ARTIFACT I S PURSUANT TO A LIMITED LICENSE; OWNERSHIP OF THE ARTIFACT AND ANY ASSOCIATED MEDIA REMAIN WITH UTC FIRE & SECURITY REVISIONS ZONE REV ECO DESCRIPTION BY DATE CK'D DATE 01 XXXXXXX RELEASE TO PRODUCTION SP 03/27/2012   Notes: 1. All text on the label must be in "helvetica neue ltstd-bd" font, per artwork provided. The device complies with part 15 of the FCC Rules a s well as Industry Canada Rules and Regulations license-exemp t RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference receiv ed, including interference that may cause undesired operation. FCC ID: QPY-263XCO-Z Model: 263B-CO-OEM Date of Mfg: To replace batteries: Remove batteries and replace with 3 fresh AA batteries. Use only Duracell MN 1500 or MX 1500 or E91 Energizer from local hardware store. SPECIFIED. USE OF A DIFFERENT BATTERY MAY HAVE DETRIMENTAL EFFECT ON ALARM OPERATION. WARNING 21009057 Rev EN01 Alarm response time: 400 PPM within 4-15 minutes Single Station Carbon Monoxide Alarm conforms to UL 2034 Std. For servicing, return to: UTC – Climate, Controls & Security 325 N Main St, Pittsfield, ME 04967 USE ONLY BATTERIES 3 6 0 3 6 1 6 2 6 9 8 6 Shown for Reference Scale 2:1 1.450 1.900 The device complies with part 15 of the FCC Rules a s well as Industry Canada Rules and Regulations license-exemp t RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference receiv ed, including interference that may cause undesired operation. Date of Mfg: To replace batteries: Remove batteries and replace with 3 fresh AA batteries. Use only Duracell MN 1500 or MX 1500 or E91 Energizer from local hardware store. SPECIFIED. USE OF A DIFFERENT BATTERY MAY HAVE DETRIMENTAL EFFECT ON ALARM OPERATION. WARNING 21009057 Rev EN01 Alarm response time: 400 PPM within 4-15 minutes Single Station Carbon Monoxide Alarm conforms to UL 2034 Std. For servicing, return to: UTC – Climate, Controls & Security 325 N Main St, Pittsfield, ME 04967 USE ONLY BATTERIES 3 6 0 3 6 1 6 2 6 9 8 6 FCC ID: QPY-263XCO-Z Model: 263B-CO-OEM

Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 2 of 12 D I R E C T O R Y - EMISSIONS Page(s) A)Documentation Test report1 - 10 Directory2 Test Regulations3 General Remarks10 Test-setups (Photos)11 - 12 B)Test data Conducted emissions10/150 kHz - 30 MHz5, 9 Radiated emissions10 kHz - 30 MHz5, 9 Radiated emissions30 MHz - 1000 MHz6, 9 Interference power30 MHz - 300 MHz6, 9 Equivalent Radiated emissions1 GHz - 18 GHz7, 9 Antenna Disturbance Voltage30 MHz - 1,000 MHz7,9 C)Appendix A Test Data Sheets A2 - A4 D)Appendix B System Under Test DescriptionB1 - B1 E) Appendix C Measurement Protocol C1 - C2 Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 3 of 12 EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: 9 - EN 61000-6-3:2007 9 - EN 61000-6-4:2007 9 - EN 55011 : 2009/A1:20109 - Group 19 - Group 2 9 - Class A9 - Class B 9 - EN 55013 : 2001 /A1:2003 /A2:2006 #- RSS-210 9 - EN 55014 -1: 20069 - Household appliances and similar 9 - Portable tools 9 - Semiconductor devices 9 - EN 55022:20109 - Class A9 - Class B 9 -AS/NZS CISPR 229 - Class A9 - Class B 9 - ICES-0039 - Class A9 - Class B 9 - CNS 134389 - Class A9 - Class B 9 - VCCI V-3/2010.49 - Class A9 - Class B # - FCC Part 15 (per ANSI C63.4)9 - Class A9 - Class B # - Certification 9 - Verification 9 - Declaration of Conformity 9 - FCC Part 18 Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 4 of 12 Environmental conditions during testing: LAB OATS Temperature: * _________: ________ Relative Humidity: ** _________: ________ * The ambient temperature during the testing was within the range of (50 o - 104 o F) unless indicted above. ** The humidity levels during the testing was within the range of (10% - 90%) relative humidity unless indicated above. Power supply system: Volts Hz SINGLE phase Internal Battery Sign Explanations: 9 - not applicable # - applicable Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 5 of 12 Emissions Test Conditions: CONDUCTED EMISSIONS (Interference Voltage) The CONDUCTED EMISSIONS (INTERFERENCE VOLTAGE) measurements were performed at the following test location: # - Test not applicable 9 - Darby Test Site (Open Area Test Site) 9 - Darby Laboratory Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 - 8028-50Solar50 S LISN829012, 829022 9 - 8012Solar50 S LISN924840 9 - EMC-30Electro-MetricsEMI Receiver191 9 - 8566BHewlett-PackardSpectrum Analyzer2421A00526 9 -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 -85662AHewlett Packard Analyzer Display2403A07352 9 -8028-50Solar50 S LISN903725, 903726 9 -FCC-TLISN-T4-02Fisher Custom Com.Telecom ISN20454 9 - 9 - FCC-TLISN-T8-02 LI-125 Fisher Custom Com. Com-Power Telecom ISN 50 S LISN 20452 191080/191081 Emissions Test Conditions: RADIATED EMISSIONS (Magnetic Field) The R ADIATED EMISSIONS (MAGNETIC FIELD) measurements were performed at the following test location: # - Darby Test Site (Open Area Test Site) 9 - 9 - at a test distance of : # - 3 meters 9 - 30 meters 9 - Test not applicable Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 -3148EMCOLog Periodic Antenna00044783 9 -BIA-25Electro-MetricsBiconical Antenna4283 # -8566BHewlett-PackardSpectrum Analyzer2421A00526 # -85662AHewlett-PackardAnalyzer Display2403A07352 # -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 # -ALR-30MElectro-MetricsLoop Antenna824 # -8447DHewlett PackardPreamplifier2944A06832 9 - 9 - EMC-30 ALA-130/A Electro-Metrics Antenna Research EMI Receiver Loop Antenna 191 106 Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 6 of 12 Emissions Test Conditions: RADIATED EMISSIONS ( Electric Field) The RADIATED EMISSIONS (ELECTRIC FIELD) measurements, in the frequency range of 30 MHz-1000 MHz, were tested in a horizontal and vertical polarization at the following test location : 9 99 9 - Test not applicable # - Darby Site (Open Area Test Site) 9 - Darby Lab 9 - at a test distance of : # - 3 meters 9 - 10 meters 9 - 30 meters Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 -HLP 3003CEMC AutomationHybrid Periodic Antenna017501 # -8447DHewlett-PackardPreamplifier (26dB)1937A03247 # -8566BHewlett-PackardSpectrum Analyzer2421A00526 # -85662AHewlett-PackardAnalyzer Display2403A07352 # -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 -BIA 25 Electro-Metrics Biconical Antenna4283 9 -EMC-30Electro-MetricsEMI Receiver191 9 - 9 - 9 - 9 - # - 8568B 85650A 85662A LPA30 3104C Hewlett Packard Hewlett Packard Hewlett Packard Electro-Metrics Emco Spectrum Analyzer Quasi-Peak Adapter Analyzer Display Log Periodic Biconical Antenna 2407A03213 2043A00358 2340A05806 2280 00075927 # - 9005 Eaton Log Periodic Antenna 1099 Emissions Test Conditions): INTERFERENCE POWER The INTERFERENCE POWER measurements were performed by using the absorbing clamp on the mains and interface cables in the frequency range 30 MHz - 300 MHz at the following test location : # - Test not applicable 9 - Darby Lab 9 - Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 -MDS-21Rhode&SchwarzAbsorbing Clamp8608447020 9 -8566BHewlett-PackardSpectrum Analyzer2421A00526 9 -85662AHewlett-PackardAnalyzer Display2403A07352 9 -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 -8447DHewlett-PackardAmplifier (26 dB)2944A06832 9 - EMC-30 Electro-Metrics EMI Receiver 191 Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 7 of…

Text truncated - open the document above for the full version.

BANDEDGE COMPLIANCE

Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 12 of 12 Test-setup photo(s): Radiated emission 30 MHz - 1000 MHz Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 11 of 12 Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 12 of 12 Test-setup photo(s): Radiated emission 30 MHz - 1000 MHz
