QPY-5XXNTT-ZWIRELESS SMOKE DETECTOR

UTC. All Rights Reserved. 1 P/N 0000000 – Rev. A – 06 Nov 12 562NSTT-OEM Smoke Alarm w/ Heat Detection Sensor Product Introduction This wireless photoelectric smoke alarm and heat detector (product) continually monitor operational status and provide a visual trouble condition if they drift out of the sensitivity range or fail internal diagnostics. This product meets NFPA 72 field sensitivity testing requirements without the need for external meters. The alarm sensitivity level can be determined at the product. Another feature is built-in drift compensation that allows the product to adjust sensitivity automatically as it becomes dirty over time. The drift compensation feature dramatically increases the time between cleanings, as well as reducing the chance of a nuisance alarm. Additional diagnostic information is activated by applying a magnet near the detector’s integral reed switch. This initiates a self-diagnostic routine and provides visual indication of sensitivity level, or if service is required. The product is powered by long life 3V Lithium batteries providing power to both the sensor and wireless transmitter. This wireless product works in conjunction with your wireless Control Panel, providing a local indication. About This Guide This User Guide describes how to install, the operation and maintenance of this product. The User Guide is organized as you intent to use this product with step by step instructions. Keep this document in a handy location and refer to it when you have questions about this product and its functions and features. Reading this guide is the only way to learn how to use your product wisely and to know how to react in the event of an alarm. 1. General Information Congratulations on purchasing your Smoke Alarm with Heat detection. The product is designed to be used with a Control Panel as part of the Fire and Life Safety signaling device. This product has an optical sensor capable of detecting smoke particles in the event of fire. It also contains an integrated heat sensor that is triggered if a room experiences a sharp rise in temperature in the event of fire. Parts List One Smoke Alarm Two CR123A lithium batteries Mounting Plate Mounting Screws and Anchors User Guide NFPA Guidelines NFPA 72, 2-1.4.2.1 Total (Complete) Coverage If required, total coverage shall include all rooms, halls, storage areas, basements, attics, lofts, spaces above suspended ceilings, and other subdivisions and accessible spaces; and the inside of all closets, elevator shafts, enclosed stairways, dumbwaiter shafts, and chutes. Inaccessible areas shall not be required to be protected by alarms. (For exceptions, see NFPA 72.) NFPA 72, 2-1.4.2.2 Partial Coverage If required, partial detection systems shall be provided in all common areas and work spaces, such as corridors, lobbies, storage rooms, equipment rooms, and other tenantless spaces in those environments suitable for proper alarm operation in accordance with this code. NFPA 72, 2-1.4.2.3 Selective Coverage Where codes, standards, laws, or authorities having jurisdiction require the protection of selected areas only, the specified areas shall be protected in accordance with this code. NFPA 72, 2-1.4.2.4 Supplementary (Non required) Coverage Where installed, detection that is not required by an applicable law, code, or standard, whether total (complete), partial, or selective coverage, shall conform to the requirements of this code. (For exceptions, refer to NFPA 72 Chapter 2 Spacing Requirements.) NFPA 72, 2-1.4.3 Where non-required detection devices are installed for a specific hazard, additional non-required detection devices shall not be required to be installed throughout an entire room or building. NFPA 72, 2-2 Heat-Sensing Fire Alarms Heat-sensing fire alarms shall be installed in all areas where required by the NFPA codes and standards or by the authority having jurisdiction. NFPA 72, 8-1.4.1.3.2 Detection in New Apartment Buildings Approved, single-station smoke alarms shall be installed in accordance with 7-6.2.10 of NFPA 101 outside every sleeping area in the immediate vicinity of the bedrooms and on all levels of the dwelling unit including basements. (101: 18-3.4.4.2) (For exceptions, refer to this section of NFPA 72.) NFPA 72, 8-1.4.1.4.2 Detection in Existing Apartment Buildings Approved, single-station smoke alarms shall be in-stalled in accordance with 7-6.2.10 of NFPA 101 outside every sleeping area in the immediate vicinity of the bedrooms and on all levels of the dwelling unit including basements. (101: 19-3.4.4.1) (For exceptions, refer to this section of NFPA 72.) 2. Mounting Guideline This product is a member of a reliable, high-quality product family using the latest technology available. Review the information in this section to ensure you get the most out of the product. The information in this User Guide is in accordance with NFPA 72 and/or CAN/ULC- S524, depending on country of installation. Pre-installation Considerations Install the smoke alarm in accordance with the National Fire Protection Association’s (NFPA) Standard 72, Chapters 2 and 8. Depending on the application, you may need to reference other chapters of NFPA 72 or NFPA 101. Choosing an Installation Location When choosing an installation location, consider: o Use of structure and type of construction o Contents you want to protect and their burning characteristics o Human occupancy o Total area to be monitored o Ceiling height and surface condition o Air movement and vent locations o Obstructions o Deflections After considering these factors, choose a location: o Where the temperature range is between 40° and 100° F (4.4° and 37.8° C). o Where the humidity is between 0 and 90% non-condensing. UTC. All Rights Reserved. 2 P/N 0000000 – Rev. A – 06 Nov 12 o Away from ventilation sources that can prevent smoke from reaching the smoke alarm. o That is at least 5 feet (1.5 m) from bathrooms. When placing the product on a ceiling, mount it in the…

Text truncated - open the document above for the full version.

B 4SPQ6 FILE NAME DRAWN BYCHECKERAPPROVEDAPPROVED MATERIALTREATMENT OR FINISH NEXT ASSY USED ON APPLICATION DATEDATEDATEDATE SCALE SHEET SIZE CAGE CODE DWG NO. REV A AB B 4 3 2 11 2 3 4 OF 1:1 - - - - - 1079555 1079555EN01.dft EN01 1 1 ASM, PRODUCT, SMOKE DETECTOR - - PRELIMINARY THIRD ANGLEPROJECTION UNLESS OTHERWISE SPECIFIED:MATERIAL TO BE COMPLIANT WITH RoHSDIRECTIVE 2002/95/ECDIMENSIONS ARE IN INCHESCAPACITANCE IS IN uFRESISTANCE IS IN OHMSTOLERANCES: .X = ±.03 .XX = ±. 01 .XXX = ±.0 05 ANGLES = ±0.5° -- DO NOT SCALE DRAWING-- EDWARDS, A UTC FIRE &SECURITY COMPANY8985 TOWN CENTER PARKWAYBRADENTON, FL 34202-5129(941) 739-4200 COPYRIGHT: CONFIDENTIAL COPYRIGHT © 2012 UTC FIRE & SECURITY, ALL RIGHTS RESERVED. UNAUTHORIZED ACCESS TO, COPYING, USE OF OR DISCLOSU RE OF THIS ARTIFACT, OR ANY OF ITS FEATURES, IS STRICTLY PROHI BITED. YOUR ACCESS TO OR POSSESION OF A COPY OF THIS ARTIFACT I S PURSUANT TO A LIMITED LICENSE; OWNERSHIP OF THE ARTIFACT AND ANY ASSOCIATED MEDIA REMAIN WITH UTC FIRE & SECURITY REVISIONS ZONE REV ECO DESCRIPTION BY DATE CK'D DATE Product Label Information Label

BANDEDGE COMPLIANCE

Test Report Number 12F335B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 2 of 12 D I R E C T O R Y - EMISSIONS Page(s) A )Documentation Test report1 - 10 Directory2 Test Regulations3 General Remarks10 Test-setups (Photos)11 - 12 B)Test data Conducted emissions10/150 kHz - 30 MHz5, 9 Radiated emissions10 kHz - 30 MHz5, 9 Radiated emissions30 MHz - 1000 MHz6, 9 Interference power30 MHz - 300 MHz6, 9 Equivalent Radiated emissions1 GHz - 18 GHz7, 9 Antenna Disturbance Voltage30 MHz - 1,000 MHz7,9 C)Appendix A Test Data Sheets A2 - A4 D)Appendix B System Under Test DescriptionB1 - B1 E) Appendix C Measurement Protocol C1 - C2 Test Report Number 12F335B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 3 of 12 EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: 9 - EN 61000-6-3:2007 9 - EN 61000-6-4:2007 9 - EN 55011 : 2009/A1:20109 - Group 19 - Group 2 9 - Class A9 - Class B 9 - EN 55013 : 2001 /A1:2003 /A2:2006 #- RSS-210 9 - EN 55014 -1: 20069 - Household appliances and similar 9 - Portable tools 9 - Semiconductor devices 9 - EN 55022:20109 - Class A9 - Class B 9 -AS/NZS CISPR 229 - Class A9 - Class B 9 - ICES-0039 - Class A9 - Class B 9 - CNS 134389 - Class A9 - Class B 9 - VCCI V-3/2010.49 - Class A9 - Class B # - FCC Part 15 (per ANSI C63.4)9 - Class A9 - Class B # - Certification 9 - Verification 9 - Declaration of Conformity 9 - FCC Part 18 Test Report Number 12F335B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 4 of 12 Environmental conditions during testing: LAB OATS T emperature: * _________: ________ Relative Humidity: ** _________: ________ * The ambient temperature during the testing was within the range of (50 o - 104 o F) unless indicted above. ** The humidity levels during the testing was within the range of (10% - 90%) relative humidity unless indicated above. Power supply system: Volts Hz SINGLE phase Internal Battery Sign Explanations: 9 - not applicable # - applicable Test Report Number 12F335B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 5 of 12 Emissions Test Conditions: CONDUCTED EMISSIONS ( Interference Voltage) The CONDUCTED EMISSIONS (INTERFERENCE VOLTAGE) measurements were performed at the following test location: # - Test not applicable 9 - Darby Test Site (Open Area Test Site) 9 - Darby Laboratory Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 - 8028-50Solar50 S LISN829012, 829022 9 - 8012Solar50 S LISN924840 9 - EMC-30Electro-MetricsEMI Receiver191 9 - 8566BHewlett-PackardSpectrum Analyzer2421A00526 9 -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 -85662AHewlett Packard Analyzer Display2403A07352 9 -8028-50Solar50 S LISN903725, 903726 9 -FCC-TLISN-T4-02Fisher Custom Com.Telecom ISN20454 9 - 9 - FCC-TLISN-T8-02 LI-125 Fisher Custom Com. Com-Power Telecom ISN 50 S LISN 20452 191080/191081 Emissions Test Conditions: RADIATED EMISSIONS (Magnetic Field) The R ADIATED EMISSIONS (MAGNETIC FIELD) measurements were performed at the following test location: # - Darby Test Site (Open Area Test Site) 9 - 9 - at a test distance of : # - 3 meters 9 - 30 meters 9 - Test not applicable Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 -3148EMCOLog Periodic Antenna00044783 9 -BIA-25Electro-MetricsBiconical Antenna4283 # -8566BHewlett-PackardSpectrum Analyzer2421A00526 # -85662AHewlett-PackardAnalyzer Display2403A07352 # -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 # -ALR-30MElectro-MetricsLoop Antenna824 # -8447DHewlett PackardPreamplifier2944A06832 9 - 9 - EMC-30 ALA-130/A Electro-Metrics Antenna Research EMI Receiver Loop Antenna 191 106 Test Report Number 12F335B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 6 of 12 Emissions Test Conditions: RADIATED EMISSIONS (Electric Field) The RADIATED EMISSIONS (ELECTRIC FIELD) measurements, in the frequency range of 30 MHz-1000 MHz, were tested in a horizontal and vertical polarization at the following test location : 9 99 9 - Test not applicable # - Darby Site (Open Area Test Site) 9 - Darby Lab 9 - at a test distance of : # - 3 meters 9 - 10 meters 9 - 30 meters T est equipment used : Model NumberManufacturerDescriptionSerial Number 9 -HLP 3003CE MC AutomationHybrid Periodic Antenna017501 # -8447DHewlett-PackardPreamplifier (26dB)1937A03247 # -8566BHewlett-PackardSpectrum Analyzer2421A00526 # -85662AHewlett-PackardAnalyzer Display2403A07352 # -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 -BIA 25 Electro-Metrics Biconical Antenna4283 9 -EMC-30E lectro-MetricsEMI Receiver191 9 - 9 - 9 - 9 - # - 8568B 85650A 85662A LPA30 3104C Hewlett Packard Hewlett Packard Hewlett Packard Electro-Metrics Emco Spectrum Analyzer Quasi-Peak Adapter Analyzer Display Log Periodic Biconical Antenna 2407A03213 2043A00358 2340A05806 2280 00075927 # - 9005 Eaton Log Periodic Antenna 1099 Emissions Test Conditions): INTERFERENCE POWER The INTERFERENCE POWER measurements were performed by using the absorbing clamp on the mains and in terface cables in the frequency range 30 MHz - 300 MHz at the following test location : # - Test not applicable 9 - Darby Lab 9 - Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 -MDS-21Rhode&SchwarzAbsorbing Clamp8608447020 9 -8566BH ewlett-PackardSpectrum Analyzer2421A00526 9 -85662AH ewlett-PackardAnalyzer Display2403A07352 9 -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 -8447DH ewlett-PackardAmplifier (26 dB)2944A06832 9 - EMC-30 Electro-Metrics EMI Receiver 191 Test Report Number 12F335B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 …

Text truncated - open the document above for the full version.

Test Report Number 12F335B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 12 of 12 Test-setup photo(s): Radiated emission 30 MHz - 1000 MHz Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 11 of 12 Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 12 of 12 Test-setup photo(s): Radiated emission 30 MHz - 1000 MHz
