QPY-6540UPI-ZWIRELESS MOTION DETECTOR

UTC. All Rights Reserved. 1 P/N 0000000 – Rev. A – 06 Nov 12 6540UPI W-OEM 100 lb Pet Immune Wireless Motion Detector Sensor Product Introduction The 6540PIW100 Pet Immune Wireless Motion Detector Sensor has a brand new range of volumetric motion sensor using a Fresnel lens, PIR element and digital signal processing. This product complies with UL639. It is suitable for indoor use in residential environments. For the consumer, it builds value in meeting security needs with respecting budgets. Quick to install and comes with a stylish low profile design. It provides detection for a variety of ranges, including up to 360 degrees of coverage for ceiling mount applications. It even has an option setting for smart pet immunity up to 100lbs / 45kg, making this product all the more attractive. This product delivers easy solutions for installers - being equipped with flexible installation heights and optional mounting bracket which are ideal for your security solution. This wireless product works in conjunction with your wireless Control Panel, providing a local indication. About This Guide This User Guide describes how to install, the operation and maintenance of this product. The User Guide is organized as you intent to use this product with step by step instructions. Keep this document in a handy location and refer to it when you have questions about this product and its functions and features. Reading this guide is the only way to learn how to use your product wisely and to know how to react in the event of an alarm. 1. General Information Passive infrared (PIR) motion sensor technology provides one of the most reliable and cost effective methods for protecting spaces in homes, offices, or industrial facilities. PIR motion sensors sense temperature contrasts between a relatively stable background and hotter or colder objects moving across their fields of view. The sensors emit no energy of their own, they merely see infrared images. This product uses a Fresnel lens, PIR sensor element and digital signal processing. The Fresnel lens focuses the 90 o viewing range onto the PIR sensor element through 24 lenses grouped into short, medium and long range viewing. See picture below. From a side view, the PIR detection range shows overlapping coverage to ensure complete range detection. As shown here. With all single lens Motion Detectors, it cannot see directly underneath the device. Therefore mounting the device higher and angling down maybe preferred. The digital signal processing translates the heat signatures into movement detection within the viewing range. Based on these signatures the electronics determines the different between pets and humans. To ensure a 100 lb / 45 kg pet can be detected versus a person of the same weight, the motion detector uses a 4-pulse algorithm, twice the industry norm. 2. Mounting Guideline The technology used in these detectors resists false alarm hazards. However, avoid potential causes of instability such as: o Direct sunlight on the detector. o Heat sources within the detector field of view. o Strong draughts onto the detector. o Large animals within the detector field of view. (except for pet immune version) o Obscuring the detector field of view with large objects, such as furniture. Not suitable for outdoor use. 3. Mounting the Sensor A. Unscrew the base screw on the detector until loose. The screw can be retained in the product to secure cover when complete with installation. B. Lift detector cover out from the base and off the lugs at the top. C. Loosen the PCB lock screw and remove the electronic assembly to gain access to the case mounting holes. Please use the battery terminals as a hand hold in removing the electronics. D. Locate the base on the wall between 4.1 and 10 ft (1.5 - 3.1 m) from the floor. Recommended height is 2 m / 6’ 7”. For flat wall mounting use a minimum of 2 screws in positions A. For corner 6’7”13’1”19’8” 26’2” 32’9” 40’0” 2m 6’7” 2m4m6m8m10m12m Long Range Medium Range Short Range 2 Top Cover UTC. All Rights Reserved. 2 P/N 0000000 – Rev. A – 06 Nov 12 mounting use screws in positions B and/or C. Drill holes in the base in provided screw locator. E. An optional swivel mount bracket is available, 6545-BP. The swivel bracket is used to adjust precisely the motion sensor’s viewing field. The swivel bracket mounts to the product on the top rear side for ceiling and wall mounts. For ceiling mount, (1) position the ceiling bracket base and secure properly to the ceiling. (2) Insert the swivel into the base and (3) secure with screw through the product’s swivel mount. With screw partially inserted make minor adjustments to sensor’s view angle and secure. For wall mount, (1) position the wall bracket base and secure properly to the ceiling material. First insert the top screw partially into the wall so the screw head can be inserted into the keyhole opening. Insert second screw into the lower mounting hole. (2) Insert the swivel into the base and (3) secure with screw through the product’s swivel mount. With screw partially inserted make minor adjustments to sensor’s view angle and secure. To complete the installation..... 1. Select the desired jumper settings. See the Jumper Adjustment (1) – switch settings section for more information. 2. Add masking labels if required (see next section for an example). 3. For ceiling mount applications that require a 90° coverage use the optional swivel-mount bracket (Part Number: 6545U-BP). 4. Replace cover and tighten the screw in the base. Note: ensure the battery is inserted properly and/or the battery pull tab is removed to activate the product. See the Installing / Replacing Batteries section for more information. 4. Sensor Setup & Jumper Selections This sensor has two mechanical adjustment and three jumper switches to aid in your application. After selecting your mounting location within the room, it’s time to optimize the sensor. Mechanical Adjustments (1) – Mounting Height Located on the left si…

Text truncated - open the document above for the full version.

BANDEDGE COMPLIANCE

Test Report Number 12F338B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 2 of 12 D I R E C T O R Y - EMISSIONS Page(s) A )Documentation Test report1 - 10 Directory2 Test Regulations3 General Remarks10 Test-setups (Photos)11 - 12 B)Test data Conducted emissions10/150 kHz - 30 MHz5, 9 Radiated emissions10 kHz - 30 MHz5, 9 Radiated emissions30 MHz - 1000 MHz6, 9 Interference power30 MHz - 300 MHz6, 9 Equivalent Radiated emissions1 GHz - 18 GHz7, 9 Antenna Disturbance Voltage30 MHz - 1,000 MHz7,9 C)Appendix A Test Data Sheets A2 - A4 D)Appendix B System Under Test DescriptionB1 - B1 E) Appendix C Measurement Protocol C1 - C2 Test Report Number 12F338B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 3 of 12 EMISSIONS TEST REGULATIONS : The emissions tests were performed according to following regulations: 9 - EN 61000-6-3:2007 9 - EN 61000-6-4:2007 9 - EN 55011 : 2009/A1:20109 - Group 19 - Group 2 9 - Class A9 - Class B 9 - EN 55013 : 2001 /A1:2003 /A2:2006 #- RSS-210 9 - EN 55014 -1: 20069 - Household appliances and similar 9 - Portable tools 9 - Semiconductor devices 9 - EN 55022:20109 - Class A9 - Class B 9 -AS/NZS CISPR 229 - Class A9 - Class B 9 - ICES-0039 - Class A9 - Class B 9 - CNS 134389 - Class A9 - Class B 9 - VCCI V-3/2010.49 - Class A9 - Class B # - FCC Part 15 (per ANSI C63.4)9 - Class A9 - Class B # - Certification 9 - Verification 9 - Declaration of Conformity 9 - FCC Part 18 Test Report Number 12F338B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 4 of 12 Environmental conditions during testing: LAB OATS T emperature: * _________: ________ Relative Humidity: ** _________: ________ * The ambient temperature during the testing was within the range of (50 o - 104 o F) unless indicted above. ** The humidity levels during the testing was within the range of (10% - 90%) relative humidity unless indicated above. Power supply system: Volts Hz SINGLE phase Internal Battery Sign Explanations: 9 - not applicable # - applicable Test Report Number 12F338B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 5 of 12 Emissions Test Conditions: CONDUCTED EMISSIONS ( Interference Voltage) The CONDUCTED EMISSIONS (INTERFERENCE VOLTAGE) measurements were performed at the following test location: # - Test not applicable 9 - Darby Test Site (Open Area Test Site) 9 - Darby Laboratory Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 - 8028-50Solar50 S LISN829012, 829022 9 - 8012Solar50 S LISN924840 9 - EMC-30Electro-MetricsEMI Receiver191 9 - 8566BHewlett-PackardSpectrum Analyzer2421A00526 9 -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 -85662AHewlett Packard Analyzer Display2403A07352 9 -8028-50Solar50 S LISN903725, 903726 9 -FCC-TLISN-T4-02Fisher Custom Com.Telecom ISN20454 9 - 9 - FCC-TLISN-T8-02 LI-125 Fisher Custom Com. Com-Power Telecom ISN 50 S LISN 20452 191080/191081 Emissions Test Conditions: RADIATED EMISSIONS (Magnetic Field) The R ADIATED EMISSIONS (MAGNETIC FIELD) measurements were performed at the following test location: # - Darby Test Site (Open Area Test Site) 9 - 9 - at a test distance of : # - 3 meters 9 - 30 meters 9 - Test not applicable Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 -3148EMCOLog Periodic Antenna00044783 9 -BIA-25Electro-MetricsBiconical Antenna4283 # -8566BHewlett-PackardSpectrum Analyzer2421A00526 # -85662AHewlett-PackardAnalyzer Display2403A07352 # -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 # -ALR-30MElectro-MetricsLoop Antenna824 # -8447DHewlett PackardPreamplifier2944A06832 9 - 9 - EMC-30 ALA-130/A Electro-Metrics Antenna Research EMI Receiver Loop Antenna 191 106 Test Report Number 12F338B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 6 of 12 Emissions Test Conditions: RADIATED EMISSIONS (Electric Field) The RADIATED EMISSIONS (ELECTRIC FIELD) measurements, in the frequency range of 30 MHz-1000 MHz, were tested in a horizontal and vertical polarization at the following test location : 9 99 9 - Test not applicable # - Darby Site (Open Area Test Site) 9 - Darby Lab 9 - at a test distance of : # - 3 meters 9 - 10 meters 9 - 30 meters T est equipment used : Model NumberManufacturerDescriptionSerial Number 9 -HLP 3003CE MC AutomationHybrid Periodic Antenna017501 # -8447DHewlett-PackardPreamplifier (26dB)1937A03247 # -8566BHewlett-PackardSpectrum Analyzer2421A00526 # -85662AHewlett-PackardAnalyzer Display2403A07352 # -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 -BIA 25 Electro-Metrics Biconical Antenna4283 9 -EMC-30E lectro-MetricsEMI Receiver191 9 - 9 - 9 - 9 - # - 8568B 85650A 85662A LPA30 3104C Hewlett Packard Hewlett Packard Hewlett Packard Electro-Metrics Emco Spectrum Analyzer Quasi-Peak Adapter Analyzer Display Log Periodic Biconical Antenna 2407A03213 2043A00358 2340A05806 2280 00075927 # - 9005 Eaton Log Periodic Antenna 1099 Emissions Test Conditions): INTERFERENCE POWER The INTERFERENCE POWER measurements were performed by using the absorbing clamp on the mains and in terface cables in the frequency range 30 MHz - 300 MHz at the following test location : # - Test not applicable 9 - Darby Lab 9 - Test equipment used : Model NumberManufacturerDescriptionSerial Number 9 -MDS-21Rhode&SchwarzAbsorbing Clamp8608447020 9 -8566BH ewlett-PackardSpectrum Analyzer2421A00526 9 -85662AH ewlett-PackardAnalyzer Display2403A07352 9 -85650AHewlett-PackardQuasi-Peak Adapter2043A00209 9 -8447DH ewlett-PackardAmplifier (26 dB)2944A06832 9 - EMC-30 Electro-Metrics EMI Receiver 191 Test Report Number 12F338B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 …

Text truncated - open the document above for the full version.

Test Report Number 12F338B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 12 of 12 Test-setup photo(s): Radiated emission 30 MHz - 1000 MHz Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 11 of 12 Test Report Number 12F317B Product Safety Engineering, Inc 12955 Bellamy Brothers Blvd. Dade City, FL 33525 Tel (352) 588-2209 Fax (352) 588-2544 Page 12 of 12 Test-setup photo(s): Radiated emission 30 MHz - 1000 MHz
