QQGBT-3121CKBLUETOOTH HAND-FREE CAR KIT

Volume Up Volume Down Mic Connector Power Connector Switch Turn On/ OffPairing Speaker Operating manual: ◎Turn on the Car Kit Turn up the Power On/Off to switch on and an orange LED follows. An indication of music and LED off once the process of switch on is completed. For the first time pairing to blue tooth mobile, it automatically goes to pairing mode. For non-first time pairing, it automatically goes to standby mode. ◎Pairing Mode The twinkle of green & red LED indicates the Car Kit is in pairing mode, the pairing PIN is 0000. Once the Car Kit completes the pairing process, it stays in standby mode. Note: Under the pairing mode, you may select the music by pressing the Talk button. ◎Standby Mode. The Car Kit goes to standby mode under circumstances as below: 1. The Car Kit has successfully paired to your cell phone. 2. After disconnect calls.You are able to answer incoming calls under the standby mode. ◎Auto-answer incoming calls Under the standby mode, the Green LED shows auto-answer incoming calls function is on. The Red LED shows auto-answer incoming calls function is off. To set up the auto-answer function by press both Volume Up and Volume Down under the standby mode. ◎Answer incoming calls While an incoming call comes, the Car Kit displays by the music you previous set up, the incoming call will be answered after two rings under the auto-answer function is on. Press Talk button to answer the call OR Pair button to reject the call. Note: fast flash in Green to show the auto-answer is on OR in Red shows off. ◎Terminate calls Press Talk button to terminate the call, Car Kit LED in Green shows auto-answer function is on OR in Red shows off. ◎Transfer calls. An incoming call is transferable between cell phone and Car Kit. Transfer from Cell phone to Car Kit by pressing Talk button. Transfer from Car Kit to Cell phone, please refer you cell phone manual. ◎Adjust the volume Press the Volume Up button to increase the volume and Volume Down button to reduce the volume. The volume is adjustable during the communication process. ◎Re-enter to the pairing mode Press the Pair button to cancel the pairing record under standby mode and the Car Kit LED will be in orange. LED will be off after cancelled and to restart and pairing mode. ◎ Turn off the Car Kit Turn down the switch to turn off the power and follows the LED will be off.

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 1 of 12 Appendix A. Pictures ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 2 of 12 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 3 of 12 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 4 of 12

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 5 of 12 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 6 of 12 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 7 of 12 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 8 of 12 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 9 of 12

MPE Prediction FCC Rule: 15.247(b)(5) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See §1.1307(b)(1) of this Chapter. LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average time (minutes) (A)Limits For Occupational / Control Exposures 30-300 61.4 0.613 1.0 6 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 30-300 27.5 0.073 0.2 30 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 PG S = -------------- 4πR² where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 4.05 (dBm) Maximum peak output power at antenna input terminal: 2.542 (mW) Antenna gain(maximal): 2.5 (dBi) Prediction distance: 1 (cm) Prediction frequency: 2480 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1.0 (mW/cm²) Power density at prediction frequency: 0.505715 (mW/cm²) Maximum allowable antenna gain: 4.94 (dBi) The manual instruct the user to install and operate the device in a minimum distance of 20 cm between antenna and the users body.

ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH TEST - REPORT FCC RULES PART 15 / SUBPART C FCC ID: QQGBT-3121CK Test report no.: W6M20403-5091-P-15 FCC ELECTRONIC TECHNOLOGY SYSTEMSSTORKOWER STRASSE 38C, D-15526 REICHENWALDE B. BERLIN DR. GENZ GMBHPHONE +49-33631-888 00 FAX +49-33631-888 660 ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 1 of 28 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH TABLE OF CONTENTS 1General information 1.1Notes 1.2Testing laboratory 1.3Details of approval holder 1.4Application details 1.5Test item 1.6Test standards 2Technical test 2.1Summary of test results 2.2Test environment 2.3Test equipment utilized 2.4General Test Procedure 3Test Results ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 2 of 28 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1General Information 1.1Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has Passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH. Tester: 12.05.2004N. Kaspar DateETS-Lab.NameSignature Technical responsibility for area of testing: 12.05.2004Dr. Genz DateETSNameSignature ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 3 of 28 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.2 Testing laboratory 1.2.1Location ELECTRONIC TECHNOLOGY SYSTEM DR. GENZ GMBH (ETS) Storkower Straße 38c D-15526 Reichenwalde b. Berlin Germany Telefon : +49 33631 888 00 Telefax : +49 33631 888 66 1.2.2Details of accreditation status ACCREDITED TESTING LABORATORY DAR-REGISTRATION NUMBER: TTI-P-G 126/96 ACCREDITED COMPETENT BODY DAR-REGISTRATION NUMBER: BPT-ZE-026/96 FCC FILED TEST LABORATORY REG. NO. 96970 BLUETOOTH QUALIFICATION TEST FACILITY (BQTF) ACCREDITED BY BLUETOOTH QUALIFICATION REVIEW BOARD INDUSTRY CANADA FILED TEST LABORATORY REG. NO. IC 3470 A2LA A CCREDITED Certificate Number 1983-01 1.3Details of approval holder Name: J-Three International Holding Co., Ltd. Street: No. 23-7, Dungshyh 12 Lirn, Dungshyh Lii, Pingchien City Town: Taoyuan Hsien 324 Country: Taiwan, R.O.C. Telephone: +886-3-4606755 Fax: +886-3-4606761 Contact: Mr. Eric Wang E-mail: ./. ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 4 of 28 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.4Application details Date of receipt of application: 29.03.2004 Date of receipt of test item: 29.03.2004 Date of test: 01.04.2004 – 13.04.2004 1.5Test item Description of test item:Bluetooth Hand-Free Car Kit Type identification: BT-3121CK Hardware version: R1A Software version: R1A Serial number: without Photos: See Appendix A Technical data Frequency band: 2.4GHz – 2.4835GHz Frequency ( ch A): 2402 MHz Frequency (ch B): 2441 MHz Frequency (ch C): 2480 MHz TransmitterVnom Vnom Power (ch A): Conducted: 4.05 dBmRadiated: -0.47 dBm Power (ch B): Conducted: 3.03 dBmRadiated: -2.98 dBm Power (ch C): Conducted: 2.95 dBmRadiated: -4.24 dBm Power supply : 12 V Operating mode: duplex Type of modulation: FHSS Antenna type: Multilayer Ceramic Antenna Antenna gain: 2,5 dBi ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 5 of 28 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Host device: none Classification: Fixed Device Mobile Device (Human Body distance > 20cm) Portable Device (Human Body distance < 20cm) Manufacturer: (if applicable) Name: Street: Town: Country: Additional information:The test sample is designed as Bluetooth device. Its pseudorandom hopping scheme, authentication, receiver parameters, synchronization procedure and other parameters are determined by Bluetooth Core Specification. The color of the two samples: gray and black. ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 6 of 28 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.6Test standards Technical standard : FCC RULES PART 15 / SUBPART C § 15.247 2Technical test 2.1Summary of test results No deviations from the technical specification(s) were ascertained in the course
of the tests performed. or The deviations as specified in 2.5 were ascertained in the course of the tests  performed. 2.2Test environment Temperature: 23 o C Relative humidity content: 20 ...75 % Air pressure: 86 ...103 kPa Details of power supply: 12 V DC (120 V AC/DC Adaptor) Extreme conditions parameters:: test voltage - extrememin.:-- V max: -- V ETS Dr. Genz GmbH, GermanyRegistration number: W6M20403-5091-P-15Page 7 of 28 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 2.3Test equipment utilized No.Measurement device:Type:Manufacturer: ETS 0001Test receiverESHS 10Rohde&Schwarz ETS 0002Test receiverESVPRohde&Schwarz ETS 0003Test receiverESVS 10Rohde&Schwarz ETS 0004Spectrum- and Network-AnalyzerFSMS 26Rohde&Schwarz ETS 0005Test receiverSMV 11MEB ETS 0006Test receiver systemSME 12MEB ETS 0007Spectrum analyzerPSA-65AAvcom ETS 0008AntennaLoop antennaSiemens ETS 0009AntennaLoop antennaMEB ETS 0010AntennaLoop antennaMEB ETS 0011Antennavan Veen/ FrameETS ETS 0012AntennaHK 116Rohde&Schwarz ETS 0013AntennaHL 223Rohde&Schwarz ETS 0014AntennaHL 025Rohde&Schwarz ETS 0015AntennaHL 025Rohde&Schwarz ETS 0016AntennaVHAPSchwarzbeck ETS 0017An…
