QQLC3310Dual Mode, Dual Channel Modem

P P i i n n P P o o i i n n t t C C D D M M A A User Guide Version 1.0 AirLink Communications, Inc. February 22, 2003 PinPoint CDMA User Guide Version 1.0 AirLink Communications, Inc. Page 1 February 22, 2003 Information in this document is subject to change without notice. © Copyright AirLink Communications, Inc, 1993-2003. All rights reserved. Please send comments to: email: [email protected] Fax: 510-226-4299 Phone: 510-226-4200 Post: AirLink Communications, Inc. Attention: Technical Publications Dept. 472 Kato Terrace Fremont, CA 94539 Preface AirLink Communications, Inc. Page i February 22, 2003 Important Notice Because of the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the AirLink Communications modem are used in a normal manner with a well-constructed network, the AirLink modem should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property. AirLink Communications, Inc., accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the AirLink Communications modem, or for failure of the AirLink Communications modem to transmit or receive such data. Safety and Hazards Do not operate the AirLink Communications modem in areas where blasting is in progress, where explosive atmospheres may be present, near medical equipment, near life support equipment, or any equipment which may be susceptible to any form of radio interference. In such areas, the AirLink Communications modem MUST BE POWERED OFF. The AirLink Communications modem can transmit signals that could interfere with this equipment. Do not operate the AirLink Communications modem in any aircraft, whether the aircraft is on the ground or in flight. In aircraft, the AirLink Communications modem MUST BE POWERED OFF. When operating, the AirLink Communications modem can transmit signals that could interfere with various onboard systems. The driver or operator of any vehicle should not operate the AirLink Communications modem while in control of a vehicle. Doing so will detract from the driver or operator's control and operation of that vehicle. In some states and provinces, operating such communications devices while in control of a vehicle is an offence. Limitation of Liability The information in this manual is subject to change without notice and does not represent a commitment on the part of AirLink Communications, Inc. AIRLINK COMMUNICATIONS, INC. SPECIFICALLY DISCLAIMS LIABILITY FOR ANY AND ALL DIRECT, INDIRECT, SPECIAL, GENERAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR EXEMPLARY DAMAGES INCLUDING, BUT NOT LIMITED TO, LOSS OF PROFITS OR REVENUE OR ANTICIPATED PROFITS OR REVENUE ARISING OUT OF THE USE OR INABILITY TO USE ANY AIRLINK COMMUNICATIONS, INC. PRODUCT, EVEN IF AIRLINK COMMUNICATIONS, INC. HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR THEY ARE FORESEEABLE OR FOR CLAIMS BY ANY THIRD PARTY. PinPoint CDMA User Guide Version 1.0 AirLink Communications, Inc. Page i February 22, 2003 Table of Contents 1 Introduction ..................................................................................... 1 1.1 CDMA2000 1X ............................................................................................... 1 1.2 Product Overview........................................................................................... 2 2 Network Connection ...................................................................... 3 2.1 Internet (TCP/IP) Connections via 1xRTT ................................................... 3 3 Windows 2000 Setup for 1xRTT Communications ................... 4 3.1 Windows 2000 Modem Configuration........................................................... 4 3.1.1 Prepare the Modem for Installation 4 3.1.2 Adding the Modem 4 3.2 Windows 2000 PPP Configuration................................................................ 6 3.3 Making a 1xRTT Data Connection ............................................................. 16 4 Low-power Mode ........................................................................... 17 5 PinPoint Vehicle Installation..................................................... 18 5.1 Overview....................................................................................................... 18 5.2 Mounting the PinPoint ................................................................................ 19 5.3 Installing the Antennas............................................................................... 20 Figure 2 – Optimum GPS antenna positioning on a vehicle................ 20 6 Using AT Commands .................................................................... 21 6.1 Terminology ................................................................................................. 22 6.2 PinPoint Serial Communication Modes...................................................... 22 6.2.1 AT Mode 23 6.2.2 PPP Mode 23 6.2.3 PassThru Mode 24 6.2.4 UDP PAD Mode 24 6.2.5 UDP Submodes 24 6.2.6 TCP PAD Mode 25 6.2.7 TCP Auto Answer 26 6.2.8 Hybrid Modes 26 6.2.9 SLIP Mode 26 6.3 AT Command Reference .............................................................................. 27 6.3.1 PinPoint Specific AT Commands 38 7 Technical Specifications ............................................................. 40 7.1 Quick Look: .................................................................................................. 40 PinPoint CDMA User Guide Version 1.0 AirLink Communications, Inc. Page ii February 22, 2003 7.2 Physical Characteristics: ............................................................................. 40 7.3 Power Specifications: .........................…

Text truncated - open the document above for the full version.

Redwing CDMA C3110 Theory of Operation Version 1.0 AirLink Communications, Inc. Page 3 February 25, 2003 Proprietary and Confidential 2 Block Diagram The AirLink PinPoint CDMA uses the Sierra Wireless embedded OEM module, the SB555, to implement the 1xRTT/CDMA modem functions. A GPS module is integrated with the SB555 and an ARM processor. AirLink mounts all the components in a rugged enclosure which provides physical and electrical protection, and a wide range power regulator. Serial Port DB9 Connector ESD Protection RS232 Signal Conversion Power Input 10 – 28 VDC Protection and Voltage Mit 3.3, 3.6, 5.0 VDC Voltage Regulators Status LEDs & Drivers SB555 1xRTT CDMA Modem Modem Antenna Connector GPS Antenna Connector GPS Module Dual UART ARM Processor NVRAM RTC

AirLink Communications, Inc. 472 Kato Terrace Fremont, CA 94539 Phone: 510-226-4200 Fax: 510-226-4299 February 26, 2003 Federal Communications Commission EQUIPMENT APPROVAL SERVICES P. O. Box 358315 Pittsburgh, PA 15251-5315 ATTN: Authorization & Evaluation Division PER: 47 CFR 0.457 and 0.459 RE: QQLC3310 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application as listed below, i.e. Schematics, Bills of materials, Theory of operation.. These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, AirLink Communications, Inc. Jim Baichtal Vice President of Engineering AirLink Communications

November 21, 2002 Federal Communications Commission Authorization and Standards Division 7435 Oakland Mills Rd. Columbia, M.D. 21046 Dear sir/madam: Re: Request for Confidentiality We hereby request that the documentation listed below, submitted with the application for certification, be withheld from public disclosure. This request is made under the provisions of Section 0.457(d) of the Commission’s Rules, and Section 552(b)(4) of the Freedom of Information Act. We cite trade secrets as the reason and purpose of the request. 1. SB555 modem schematics SB555SCH_S_3C.PDF 2. SB555 Bill of Materials SB555BOM_S_3C.PDF. 3. SB555 Detailed Circuit Description SB555DCD_S_3C.PDF 4. SB55 Block Diagram SB555BLK_S_3C.PDF Sincerely, Jit Roop Project Manager Sierra Wireless Inc

AirLink Communications, Inc. 472 Kato Terrace Fremont, CA 94539 Phone: 510-226-4200 Fax: 510-226-4299 Date: February 27, 2003 C3310 LABEL FOR 1-PART STATEMENT AirLink Communications, Inc. FCC ID: QQLC3310 Model: C3310 IC: xxx-yyyy Country Of Origin: USA This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. Label Size: 1” high x 4” long Label Location: Centered on bottom of unit AirLink Communications

AirLink Communications, Inc. 472 Kato Terrace Fremont, CA 94539 Phone: 510-226-4200 Fax: 510-226-4299 February 22, 2003 Gentlemen: The AirLink PinPoint CDMA Model C3310 modem does not require any tune-up procedures. The C3310 uses the embedded OEM modem module, the SB555 from Sierra Wireless, and is preset in the manufacturing process. AirLink Communications, Inc. Jim Baichtal Vice President of Engineering AirLink Communications

FCC ID: QQLC3310 MFA p0310009, d0320010 T R A N S M I T T E R C E R T I F I C A T I O N of FCC ID: QQLC3310 MODEL: C3310 to FEDERAL COMMUNICATIONS COMMISSION Rule Part(s) 2, 22, 24E, 22.901d, Confidentiality DATE OF REPORT: February 7, 2003 ON THE BEHALF OF THE APPLICANT: AirLink Communications, Inc. AT THE REQUEST OF : P.O. 0020828 AirLink Communications, Inc. 472 Kato Terrace Fremont, CA 94539 Attention of: Jim Baichtal 510-226-4201; FAX: -4299 email: [email protected] SUPERVISED BY: Morton Flom, P. Eng. FCC ID: QQLC3310 MFA p0310009, d0320010 LIST OF EXHIBITS (FCC CERTIFICATION (CELLULAR TRANSMITTERS) - REVISED 9/28/98) APPLICANT: AirLink Communications, Inc. FCC ID: QQLC3310 BY APPLICANT: 1. LETTER OF AUTHORIZATION x 2. IDENTIFICATION DRAWINGS, 2.1033(c)(11) x LABEL x LOCATION OF LABEL x COMPLIANCE STATEMENT x LOCATION OF COMPLIANCE STATEMENT 3. PHOTOGRAPHS, 2.1033(c)(12) x 4. CONFIDENTIALITY REQUEST: 0.457 and 0.459 x 5. DOCUMENTATION: 2.1033(c) (3) USER MANUAL x (9) TUNE UP INFO x (10) SCHEMATIC DIAGRAM x (10) CIRCUIT DESCRIPTION x BLOCK DIAGRAM x PARTS LIST x ACTIVE DEVICES x 6. MPE REPORT x BY M.F.A. INC. A. TESTIMONIAL & STATEMENT OF CERTIFICATION B. STATEMENT OF QUALIFICATIONS FCC ID: QQLC3310 MFA p0310009, d0320010 THE APPLICANT HAS BEEN CAUTIONED AS TO THE FOLLOWING: 15.21 INFORMATION TO USER. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) SPECIAL ACCESSORIES. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. FCC ID: QQLC3310 MFA p0310009, d0320010 TABLE OF CONTENTS RULE DESCRIPTION PAGE . Test Report 1 2.1033(c) General Information Required 2 2.1033(c)(14) Rule Summary 5 . General Information 6 . Standard Test Conditions and Engineering Practices 6 2.1046(a) Carrier Output Power (Conducted) 7 2.1046(a) ERP Carrier Power (Radiated) 9 2.1049(c)(1), 22 Emission Masks (Occupied Bandwidth) 11 2.1051, 2.1049(c), 24, 24.238(b). . Transmitter Conducted Measurements 19 2.1051, 22.917 Spurious Emissions at Antenna Terminals 27 2.1053(a) Field Strength of Spurious Radiation 30 2.1055(a)(1) Frequency Stability (Temperature Variation) 34 2.1055(b)(1) Frequency Stability (Voltage Variation) 37 2.202(g) Necessary Bandwidth and Emission Bandwidth 38 FCC ID: QQLC3310 MFA p0310009, d0320010 PAGE NO. 1 of 38. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) TEST REPORT b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0320010 d) Client: AirLink Communications, Inc. 472 Kato Terrace Fremont, CA 94539 e) Identification: C3310 FCC ID: QQLC3310 Description: CDMA Modem f) EUT Condition: Not required unless specified in individual tests. g) Report Date: February 7, 2003 EUT Received: January 29, 2003 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. FCC ID: QQLC3310 MFA p0310009, d0320010 PAGE NO. 2 of 38. LIST OF GENERAL INFORMATION REQUIRED FOR CERTIFICATION IN ACCORDANCE WITH FCC RULES AND REGULATIONS, VOLUME II, PART 2 AND TO 2, 22, 24E, 22.901d, Confidentiality Sub-part 2.1033 (c)(1): NAME AND ADDRESS OF APPLICANT: AirLink Communications, Inc. 472 Kato Terrace Fremont, CA 94539 MANUFACTURER: Applicant (c)(2): FCC ID: QQLC3310 MODEL NO: C3310 (c)(3): INSTRUCTION MANUAL(S): PLEASE SEE ATTACHED EXHIBITS (c)(4): TYPE OF EMISSION: 1M25F9W (c)(5): FREQUENCY RANGE, MHz : 824.04 to 848 1850 to 1910 (c)(6): POWER RATING, Watts: 0.25 Switchable Variable x N/A FCC GRANT NOTE: BC - The output power is continuously variable from the value listed in this entry to 5%-10% of the value listed. (c)(7): MAXIMUM POWER RATING, Watts : 0.6 FCC ID: QQLC3310 MFA p0310009, d0320010 PAGE NO. 3 of 38. Subpart 2.1033 (continued) (c)(8): VOLTAGES & CURRENTS IN ALL ELEMENTS IN FINAL R. F. STAGE, INCLUDING FINAL TRANSISTOR OR SOLID STATE DEVICE: COLLECTOR CURRENT, A = 600 ma COLLECTOR VOLTAGE, Vdc = 3.3 SUPPLY VOLTAGE, Vdc = 12 (c)(9): TUNE-UP PROCEDURE: PLEASE SEE ATTACHED EXHIBITS (c)(10): CIRCUIT DIAGRAM/CIRCUIT DESCRIPTION: Including description of circuitry & devices provided for determining and stabilizing frequency, for suppression of spurious radiation, for limiting modulation and limiting power. P…

Text truncated - open the document above for the full version.

FCC ID: QQLC3310 MFA p0310009, d0320012 ENVIRONMENTAL ASSESSMENT for MOBILES/FIXED BASE STATION for FCC ID: FCC ID: QQLC3310 Model:C3310 to FEDERAL COMMUNICATIONS COMMISSION 47 CFR 1.1310 (MPE) Radiofrequency Radiation Exposure Limits DATE OF REPORT: February 7, 2003 ON THE BEHALF OF THE APPLICANT: AirLink Communications, Inc. AT THE REQUEST OF: P.O. 0020828 AirLink Communications, Inc. 472 Kato Terrace Fremont, CA 94539 Attention of: Jim Baichtal 510-226-4201; FAX: -4299 email: [email protected] SUPERVISED BY: Morton Flom, P. Eng. FCC ID: QQLC3310 MFA p0310009, d0320012 TABLE OF CONTENTS RULE DESCRIPTION PAGE . Test Report 1 . Identification of the Equipment Under Test 2 . Standard Test Conditions and Engineering Practices 4 1.1310 Environmental Assessment 5 FCC ID: QQLC3310 MFA p0310009, d0320012 PAGE NO. 1 of 5. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) TEST REPORT (SUPPLEMENTAL) b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0320012 d) Client: AirLink Communications, Inc. 472 Kato Terrace Fremont, CA 94539 e) Identification: C3310 FCC ID: QQLC3310 Description: CDMA Modem f) EUT Condition: Not required unless specified in individual tests. g) Report Date: February 7, 2003 EUT Received: 2003-Jan-29 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. FCC ID: QQLC3310 MFA p0310009, d0320012 PAGE NO. 2 of 5. IDENTIFICATION OF THE EQUIPMENT UNDER TEST (EUT) NAME AND ADDRESS OF APPLICANT: AirLink Communications, Inc. 472 Kato Terrace Fremont, CA 94539 MANUFACTURER: AirLink Communications, Inc. 472 Kato Terrace Fremont, CA 94539 FCC ID: QQLC3310 MODEL NO: C3310 DESCRIPTION: CDMA Modem TYPE OF EMISSION: 1M25F9W FREQUENCY RANGE, MHz: 824.04 to 848 1850 to 1910 POWER RATING, Watts: 0.25 Switchable Variable x N/A MODULATION: AMPS TDMA x CDMA OTHER ANTENNA: HELICAL MONOPOLE WHIP x OTHER NOTE: For RF Safety test antenna gain taken at the upper range of expected gain (i.e. 0 dBd) and RF Power set to highest nominal power across all channels. FCC ID: QQLC3310 MFA p0310009, d0320012 PAGE NO. 3 of 5. M. Flom Associates, Inc. is accredited by the American Association for Laboratory Association (A2LA) as shown in the scope below. "This laboratory is accredited by the American Association for Laboratory Accreditation (A2LA) and the results shown in this report have been determined in accordance with the laboratory's terms of accreditation unless stated otherwise in the report." Should this report contain any data for tests for which we are not accredited, or which have been undertaken by a subcontractor that is not A2LA accredited, such data would not covered by this laboratory's A2LA accreditation. FCC ID: QQLC3310 MFA p0310009, d0320012 PAGE NO. 4 of 5. STANDARD TEST CONDITIONS and ENGINEERING PRACTICES Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.4-1992/2000, section 6.1.9, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104 °F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Prior to testing, the EUT was tuned up in accordance with the manufacturer's alignment procedures. All external gain controls were maintained at the position of maximum and/or optimum gain throughout the testing. Measurement results, unless otherwise noted, are worst case measurements. FCC ID: QQLC3310 MFA p0310009, d0320012 PAGE NO. 5 of 5. Name of test: R.F. Radiation Exposure FCC Rules: 1.1307, 1.1310, 1.1311, 2.1091 Description, EUT: See page 2 of Test Report 0.3-1.234 MHz: Limit [mW/cm 2 ] = 100 1.34-30 MHz: Limit [mW/cm 2 ] = (180/f 2 ) 30-300 MHz: Limit [mW/cm 2 ] = 0.2 LIMITS: Uncontrolled Exposure 47 CFR 1.1310 Table 1, (B) 300-1500 MHz Limit [ mW/cm 2 ] = f/1500 1500-100,000 MHz: Limit [mW/cm 2 ] = 1.0 Frequency Range, MHz Limits, mW/cm 2 824 – 849 0.549 to 0.566 1850 – 1910 1.0 to 1.0 MHz Measured Maximum Power Density, mW/cm 2 824.73 0.025 836.40 0.010 849.19 0.001 1851.25 0.020 1880.00 0.019 1908.75 0.019 FCC ID: QQLC3310 MFA p0310009, d0320012 (The following will be placed in the Instruction Manual) MANDATORY SAFETY INSTRUCTIONS TO INSTALLERS & USERS Use only manufacturer or dealer supplied antenna. Antenna Minimum Safe Distance: 20 cm. Antenna Gain: zero dBd referenced to a dipole. The Federal Communications Commission has adopted a safety standard for human exposure to RF (Radio Frequency) energy which is below the OSHA (Occupational Safety and Health Act) limits. Antenna Mounting: The antenna supplied by the manufacturer or radio dealer must not be mounted at a location such that during radio transmission, any person or persons can come closer than the above indicated minimum safe distance to the antenna i.e. 20 cm . To comply with current FCC RF Exposure limits, the antenna must be installed at or exceeding the minimum safe distance shown above, and in accordance with the requirements of the antenna manufacturer or supplier. Base Station Installation: The antenna should be fixed-mounted on an outdoor permanent structure. RF Exposure compliance must be addressed at the time of installation. Antenna Substitution: Do not substitute any antenna for the one supplied or recommended by the manufacturer or radio dealer. You may be exposing person or persons to excess radio frequency radiation. You may contact your ra…

Text truncated - open the document above for the full version.
