QRF-QSFNYON3Wireless Network Adapter

  Revision: 1.0 Firm ware: 2.10 Date: 7/06/06

    iiiiii This document is i ntended for Public Distributio n 19473 Fraser Way, Pitt Meadows, B .C. Canada V3Y 2V4 ii Document Revisions: Version 1.0 June 9, 2006 Tranzeo Wireless Technologies Inc. 19473 Fraser Way P itt Meadows, BC Canada V3Y 2V4 Toll Free Number: 1.866.872.6936 T echnical Support : 1.888.460.6366 General Inquiries: info@t ranzeo.com Local Number: 1.604.460.6002 Sales: sales@t ranzeo.com Fax Number: 1.604.460.6005 T echnical Support : support @t ranzeo.com iiiiiiiii This document is i ntended for Public Distributio n 19473 Fraser Way, Pitt Meadows, B .C. Canada V3Y 2V4 Safety Information iii TR-Multi Series Tranzeo Wireless Technologies This device has been t est ed and found t o comply wit h the limit s for a Class B digit al device pursuant to P art 15 of t he FCC rules. T hese limit s are designed to provide reasonable prot ect ion against harmful int erference when the device is operat ed in a resident ial environment. This device generat es, uses, and can radiat e radio frequency energy. If not inst alled and used in accordance wit h t he user guide, may cause harmful int erference t o radio communicat ion. In case of harmful interference, t he users will be required t o correct the interference at t heir own expense. The users should not modify or change t his device without writt en approval from T ranzeo Wireless. Modificat ion could void aut hority t o use the device. For safety reasons, people should not work in a sit uat ion where RF exposure limit s could be exceeded. T o prevent t his sit uat ion, t he users should consider the following rules: ∑ Install t he ant enna so that t here is a minimum of 81 cm of dist ance bet ween t he ant enna and people. ∑ Do not t urn on power to the device while inst alling t he ant enna. ∑ Do not connect t he antenna while t he device is in operat ion. ∑ Do not collocat e or operat e the ant enna used wit h the device in conjunct ion wit h any other ant enna or t ransmitt er. ∑ Use this product only wit h the following T ranzeo ant ennas of t he same or lower gain: ∑ In order to ensure compliance wit h local regulat ions, the inst aller MUST ent er t he gain of t he ant enna at the t ime of inst allat ion. See Chapt er 3, Wi reless Settings, for det ails. ∑ To reduce pot ent ial radio int erference to other users, the ant enna type and it s gain should be so chosen t hat t he equivalent isot ropically radiat ed power (EIRP) is not more t han that required for successful communicat ion. FCC and IC Compliance Safety Information T R-VA24-16 16 dBi Vagi antenna T R-GD-24-24 24 dBi Grid antenna T R-OD-24-12 12 dBi Vertical Omni T R-ODH24-13 13 dBi Horizontal Omi T R-24H-90-17 17 dBi Sector antenna T R-5.8-32DB-ANT 32 dBi Dish Antenna T R-GD58-26 26 dBi Grid antenna T R-HT Q-5.8-12 12 dBi Vertical Omni T R-58V-60-17 17 dBi Vertical Sector T R-58H-90-16 16 dBi Horizontal Sector iviviv This document is i ntended for Public Distributio n 19473 Fraser Way, Pitt Meadows, B .C. Canada V3Y 2V4 Safety Information iv TR-Multi Series Tranzeo Wireless Technologies You must read and understand t he following safety instruct ions before inst alling the device: ∑ This ant enna’s grounding syst em must be inst alled according to Art icles 810-15, 810-20, 810-21 of the Nat ional Elect ric Code, ANSI/NFP A No. 70-1993. If you have any quest ions or doubt s about your ant enna’s grounding syst em, cont act a local licensed electrician. ∑ Never attach the grounding wire while t he device is powered. ∑ If t he ground is t o be att ached t o an exist ing elect rical circuit , t urn off the circuit before att aching t he wire. ∑ Use the Tranzeo Power over Ethernet (P OE) adapt er only wit h approved T ranzeo models. ! Safety Instructions Light ning Protection The key to lightning prot ect ion is to provide a harmless route for lightning t o reach ground. The syst em should not be designed t o att ract lightning, nor can it repel lightning. Nat ional, st at e and local codes are designed to protect life, limb, and propert y, and must always be obeyed. When in doubt, consult local and nat ional elect rical codes or cont act an electrician or professional trained in t he design of grounding syst ems. The product requires professional inst allat ion. P rofessional inst allers ensure t hat the equipment is inst alled following local regulat ions and safety codes. Professional Installation Required vvv This document is i ntended for Public Distributio n 19473 Fraser Way, Pitt Meadows, B .C. Canada V3Y 2V4 Table of Contents v TR-Multi Series Tranzeo Wireless Technologies Chapter 1: Overview ................................................................. 1-1 Introduction....................................................................................................... 1-1 Product Kit........................................................................................................ 1-1 Product Description .......................................................................................... 1-2 LED Panel Indicators................................................................................... 1-2 Chapter 2: Hardware Installation ................................................ 2-1 Getting Ready ................................................................................................... 2-1 Tools Required............................................................................................. 2-1 Site Selection ............................................................................................... 2-1 Orientation of the Radio .............................................................................. 2-1 Power Supp ly............................................................................................... 2-1 Installing the Ethernet Cable ............................................................................ 2-2 M ounting the Radio …

Text truncated - open the document above for the full version.

19473 Fraser Way, Pitt Meadows, B.C. V3Y 2V4 T: 604.460.6002 F: 604-460.6005 Toll Free: 1-866-872-6936 Website: www.tranzeo.com January 30, 2008 Federal Communications Commission 445 12th Street SW Washington, DC 20554 Re: Confirmation of compliance FCC ID: QRF- QSFNYON3 This is to verify that the device with the referenced FCC ID is capable of operating in four frequency bands, namely 2400-2483.5 MHz, 5250-5350MHz, 5470-5725MHz, and 5725- 5850MHz. Operation in 2400-2483.5 MHz and 5725-5850MHz bands can be implemented using 5, 10 and 20 MHz bandwidths and has been certified under the FCC ID: QRF-NYYON23. Nonetheless, when operating in 5250-5350MHz and 5470-5725MHz bands, the device only uses 20MHz transmission bandwidth and the selection of other bandwidths is prohibited by the product’s firmware. Thank you for your attention in this matter. Bud Patterson VP Engineering Tranzeo Wireless Technologies 19473 Fraser Way Pitt Meadows, BC V3Y 2V4

19473 Fraser Way, Pitt Meadows, B.C. V3Y 2V4 T: 604.460.6002 F: 604-460.6005 Toll Free: 1-866-872-6936 Website: www.tranzeo.com February 12, 2008 Federal Communications Commission 445 12th Street SW Washington, DC 20554 Re: Request for Confidentiality FCC ID: QRF- QSFNYON3 In accordance with FCC Rules part 0.459, we hereby request confidential treatment for the above referenced certification application. The items to be held in confidence are: Confidential - Schematics “C_ZCOM AG-623C_Circuit Diagram_060831t.pdf” Confidential - Block Diagrams “C_ZCOM AG-623C_Block Diagram_060831.pdf” Confidential - Parts List “C_ZCOM AG-623C_Parts List_060831.pdf” The application contains technical information that which Tranzeo Wireless Technologies Inc. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention in this matter.

EMC LABS INC External Photos External PhotosExternal Photos External Photos QRF QRFQRF QRF- -- - QSFNYON3 QSFNYON3QSFNYON3 QSFNYON3 Series Series Series Series Wireless Network Adapter Tranzeo Wireless Technologies Inc. Date: 4 April, 2007 Report No.: 040407.1 Labs: 19473 Fraser Way, Pitt Meadows, BC, Canada V3Y 2V4 Cam Finnigan EMC Engineer Sam Zahed EMC Coordinator Supplemental Exhibit Tranzeo EMC Labs Inc. Page 2 of 5 A.1 External Photos Supplemental Exhibit Tranzeo EMC Labs Inc. Page 3 of 5 Supplemental Exhibit Tranzeo EMC Labs Inc. Page 4 of 5 Supplemental Exhibit Tranzeo EMC Labs Inc. Page 5 of 5

Tranzeo Wireless Technologies, Inc. 19473 Fraser Way Pitt Meadows, B.C. Canada V3Y 2V4 Ph: +1-604-460-6002 www.tranzeo.com TR-Multi Wireless LAN Station Adapter The firmware supplied with this device is specific to Tranzeo Wireless Technologies Inc. and is the latest version. Only pre-approved and supplied upgrades are permitted. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. TR-Multi FCC ID: QRF- QSFNYON3 IC: 5181A- QSFNYON3 Manufactured: 28 March 2007 Serial #:TR-Multi-00001 F/W Version: 2.10 MAC Address: 00:60:B3:16:D9:DA EMC LABS INC Label Location Label LocationLabel Location Label Location QRF QRFQRF QRF- -- - QSFNYON3 QSFNYON3QSFNYON3 QSFNYON3 Series Series Series Series Wireless Network Adapter Tranzeo Wireless Technologies Inc. Date: 4 April, 2007 Report No.: 040407.1 Labs: 19473 Fraser Way, Pitt Meadows, BC, Canada V3Y 2V4 Cam Finnigan EMC Engineer Sam Zahed EMC Coordinator Supplemental Exhibit Tranzeo EMC Labs Inc. Page 2 of 2 A.1 Label Location Photo

19473 Fraser Way, Pitt Meadows, BC, Canada V3Y 2V4 T: 604.460.6002 • F: 604.460.6005 • Toll Free: 1.866.872.6936 • Website: www.tranzeo.com © Tranzeo Wireless Technologies. All rights reserved. E & OE. TR0090 5.8GHz 16dBi 90° Horizontal Sector Antenna Model Number TR-58H-90-16 Mechanical Specifications Dimensions (L x W x H) 19.7′′ x 6.7′′ x 4.6′′ Radome Material UV Protected PVC Wind Loading 100 mph 105 N 125 mph 164 N Electrical Specifications Antenna Patterns H-Plane E-Plane Tranzeo Wireless Technologies Frequency 5.875 GHz Plane H Beamwidth 81.5° Gain 16dBi Tranzeo Wireless Technologies Frequency 5.875 GHz Plane E Beamwidth 5.12° Gain 16dBi Frequency range 5150 - 5875 MHz Gain 16dB VSWR 1.7 Impedance 50Ω Elevation 6° Azimuth 90° Polarization Horizontal Maximum input power 20W Cross Polarization -20dB Connector N-Female 3dB Beamwidth Distributors North American Double Radius, Inc. 866 891 3602 [email protected] Electro-Comm Distributing, Inc. 1 800 525 0173 [email protected] RF Linx Corporation 513 777 2774 [email protected] Streakwave 408 294 8415 [email protected] WAV Wireless Outfitters 800 678 2419 [email protected] International AI Bridges Ireland +353 (0) 65 684 8768 [email protected] Alcadis Distributeur Netherlands (+31) 030 6585125 [email protected] BROADVOX GmbH Germany +49 (0) 40 1234 5678 Comnet Solutions Australia +61 2 9899 5700 [email protected] Nextmedia SRL Italy +39 0547 385611 [email protected] Orbitel Telecom.e Informática Ltda. Brazil +55 61 341 4100 [email protected] Pacific Net Mexico +52 800 633 9077 ZCOMAX (UK) Ltd England +44 (0)20 8982 8200 [email protected] Recommended Accessories Lightning Arrestors • 350V, 100MHz to 3GHz, N Fem to N Fem (p/n PAWSP3-350-FF) • 350V, 100MHz to 3GHz, N Fem to N Male (p/n SP3-90-6-FM) • 230V, DC to 6GHz, N Female to N Female (p/n PAWSP6-230-BFF) • 230V, DC to 6GHz, N Female to N Male (p/n PAWSP6-230-BFM)

19473 Fraser Way, Pitt Meadows, BC, Canada V3Y 2V4 T: 604.460.6002 • F: 604.460.6005 • Toll Free: 1.866.872.6936 • Website: www.tranzeo.com © Tranzeo Wireless Technologies. All rights reserved. E & OE. TR0081 5.8GHz 17dBi 60° Vertical Sector Antenna Model Number TR-58V-60-17 Mechanical Specifications Dimensions (L x W x H) 21.8′′ x 3′′ x 2.1′′ Radome Material UV Protected PVC Wind Loading 100 mph 52 N 125 mph 81 N Weight of Antenna 1.6 lbs Electrical Specifications Antenna Patterns H-Plane E-Plane Frequency range 5150 - 5875 MHz Gain 17dB VSWR 1.7 Impedance 50Ω 3dB Beamwidth Azimuth 60° Elevation 5° Polarization Vertical Maximum input power 50W Connector N-Female Lightning Protection DC Grounded Tranzeo Wireless Technologies Frequency 5.875 GHz Plane H Beamwidth 64.6° Gain 16.3dBi Tranzeo Wireless Technologies Frequency 5.875 GHz Plane E Beamwidth 4.7° Gain 16.3dBi Distributors North American Double Radius, Inc. 866 891 3602 [email protected] Electro-Comm Distributing, Inc. 1 800 525 0173 [email protected] RF Linx Corporation 513 777 2774 [email protected] Streakwave 408 294 8415 [email protected] WAV Wireless Outfitters 800 678 2419 [email protected] International AI Bridges Ireland +353 (0) 65 684 8768 [email protected] Alcadis Distributeur Netherlands (+31) 030 6585125 [email protected] BROADVOX GmbH Germany +49 (0) 40 1234 5678 Comnet Solutions Australia +61 2 9899 5700 [email protected] Nextmedia SRL Italy +39 0547 385611 [email protected] Orbitel Telecom.e Informática Ltda. Brazil +55 61 341 4100 [email protected] Pacific Net Mexico +52 800 633 9077 ZCOMAX (UK) Ltd England +44 (0)20 8982 8200 [email protected] Recommended Accessories Lightning Arrestors • 350V, 100MHz to 3GHz, N Fem to N Fem (p/n PAWSP3-350-FF) • 350V, 100MHz to 3GHz, N Fem to N Male (p/n SP3-90-6-FM) • 230V, DC to 6GHz, N Female to N Female (p/n PAWSP6-230-BFF) • 230V, DC to 6GHz, N Female to N Male (p/n PAWSP6-230-BFM)

19473 Fraser Way, Pitt Meadows, BC, Canada V3Y 2V4 T: 604.460.6002 • F: 604.460.6005 • Toll Free: 1.866.872.6936 • Website: www.tranzeo.com © Tranzeo Wireless Technologies. All rights reserved. E & OE. TR0085-2 Tranzeo Wireless Technologies Inc., Tranzeo Wireless, Tranzeo and the Tranzeo logo are Registered Trademarks of Tranzeo Wireless Technologies Inc. 5.8GHz 12dBi Omnidirectional Antenna Model Number TR-HTQ-5.8-12 Frequency range 5725 - 5850 MHz Gain 12dBi VSWR ≤1.5 Impedance 50Ω Horizontal beamwidth 360° Vertical beamwidth 7° Polarization Vertical Maximum input power 100W Connector N-Female Mechanical Specifications Antenna Patterns Electrical Specifications Length 21.3′′ Weight of Antenna 9.5 lbs Rated Wind Speed 150 mph Radome Material Fiberglass Horizontal Pattern Vertical Pattern Recommended Accessories Lightning Arrestors • 350V, 100MHz to 3GHz, N Fem to N Fem (p/n PAWSP3-350-FF) • 350V, 100MHz to 3GHz, N Fem to N Male (p/n SP3-90-6-FM) • 230V, DC to 6GHz, N Female to N Female (p/n PAWSP6-230-BFF) • 230V, DC to 6GHz, N Female to N Male (p/n PAWSP6-230-BFM) About Tranzeo Tranzeo Wireless Technologies Inc. (TSX:TZT) leads the wireless broadband industry for value, by producing high- performance wireless network equipment with a low cost of ownership and unparalleled service, allowing communities and businesses to communicate without boundaries. Within its state-of-the-art manufacturing facility, Tranzeo designs and produces all of its equipment for quick installation, ease of use and minimal maintenance. Since the company’s inception in 2000, Tranzeo’s optimum cost effectiveness, premium quality and responsive support have attracted a growing and devoted worldwide following of more than 2,465 dealers and 18 distributors. Tranzeo’s full spectrum of point-to-point and point-to-multipoint radios, WiMAX equipment, and mesh network solutions are designed for wireless internet service providers, governments, campuses, military, carriers, enterprise customers, and systems integrators around the globe.

元件品號 品 名 規 格 組成用量 插件位置1 *PCBA AG-623C V0.5 ATHEROS WLAN MINI PCI CARD 0.000 01-200005-00N *R SMD 0Ω 5% 0402 0.063W 3.000 R45,R46,R48 01-201005-00N *R SMD 10Ω 5% 0402 0.063W 1.000 R51 01-202205-00N *R SMD 22Ω 5% 0402 0.063W 1.000 R50 01-204705-00N *R SMD 47Ω 5% 0402 0.063W 1.000 R31 01-204795-00N *R SMD 4.7Ω 5% 0402 0.063W 2.000 L2,R16 01-210025-00N *R SMD 10KΩ 5% 0402 0.063W 4.000 R1,R14,R15,R17 01-218701-00N *R SMD 187Ω 1% 0402 0.063W 2.000 R8,R9 01-243025-00N *R SMD 43KΩ 5% 0402 0.063W 1.000 R41 01-247005-00N *R SMD 470Ω 5% 0402 0.063W 1.000 R54 01-261911-00N *R SMD 6.19KΩ 1% 0402 0.063W 1.000 R42 01-300105-00N *R SMD 1Ω 5% 0603 0.1W 1.000 R40 01-500005-00N *R SMD 0Ω 5% 0805 0.125W 6.000 L13,R24,R59,R4,R5,R10 11-201018-01N *C SMD CER 1pF ±0.25pF 0402 NPO 50V 4.000 C17,C21,C51,C59 11-205917-01N *C SMD CER 0.5pF ±0.1pF 0402 NPO 50V 1.000 C16 11-210011-01N *C SMD CER 10pF ±5% 0402 NPO 50V 17.000 C2,C3,C4,C18,C19,C23,C52,C54,C60,C63,C67,C84,C103,C 1 05,C118,C119,C121 11-210111-00N *C SMD CER 100pF ±5% 0402 NPO 50V 5.000 C13,C14,C37,C50,C69 11-210222-00N *C SMD CER 1nF ±10% 0402 X7R 50V 1.000 C78 11-210432-00N *C SMD CER 100nF ±10% 0402 X5R 10V 9.000 C10,C36,C34,C72,C73,C75,C85,C93,C98 11-212011-00N *C SMD CER 12pF ±5% 0402 NPO 50V 2.000 C77,C25 11-212111-00N *C SMD CER 120pF ±5% 0402 NPO 50V 1.000 C22 11-215011-00N *C SMD CER 15pF ±5% 0402 NPO 50V 1.000 C117 11-218918-01N *C SMD CER 1.8pF ±0.25pF 0402 NPO 50V 2.000 L8,C12 11-222011-00N *C SMD CER 22pF ±5% 0402 NPO 50V 3.000 C11,C15,C120 11-222918-01N *C SMD CER 2.2pF ±0.25pF 0402 NPO 50V 2.000 C9,C56 11-233918-01N *C SMD CER 3.3pF ±0.25pF 0402 NPO 50V 3.000 C64,C65,C66 11-268918-01N *C SMD CER 6.8pF ±0.25pF 0402 NPO 50V 1.000 C45 11-347545-13N *C SMD CER 4.7uF +80-20% 0603 Y5V 6.3V 2.000 C95,C96 11-510672-00N *C SMD CER 10uF 10% 0805 X5R 6.3V 1.000 C80 11-522532-00N *C SMD 2.2uF ±10% 0805 X5R 6.3V 2.000 C71,C89 20-210012-08N *L SMD 10nH ±10% 0402 TOKO 100MHZ 300mA 0.46Ω Q=121.000 L4 20-210919-33N *L SMD 1nH±0.3nH 0402 ACX 100MHz 0.3A 120mΩ Q=8 3.000 R30,L11,L12 20-215917-06N *L SMD 1.5nH ±0.1nH 0402 Cyntec 100MHZ 930mA 0.10Ω Q=1 2.000 L3,R73 20-282912-08N *L SMD 8.2nH ±10% 0402 TOKO 100MHZ 300mA 0.39Ω Q=12 1.000 L5 23-070001-74N *BPF 5-6G BF2012 E5R5DAC ACX SMD IL=1.5dB 2.0×1.2mm1.000 FL3 23-A80003-BNN *Balun 4.9-5.9GHz BL138C IMT SMD 2012 IL=0.66dB 50/100 1.000 F1 23-B20001-BNN *BPF BP190B 2.4~2.5GHz 禾頻 SMD [email protected] 2.5X2X1.1mm 1.000 FL1 23-B20005-CFN *BPF LF22B2450P47-N24 浙江正原 2.45GHz IL≦1.7dbm 2.5*2*1.2 1.000 FL2 23-B50004-BNN *LPF LP284C 4.9~5.9GHz IL=0.3dB 5GHz 2.0*1.25*0.74mm 1.000 FL5 24-100001-75N *Crystal 40MHz (SIWARD) SMD ±20ppm 15pF 5×3.2×1 1.000 Y1 30-060001-06N *PIN SW DIODE SMP1321-079LF SC-79 DC-2GHz Ls=0.7nH 1.000 D1 32-A78000-00N *TR PNP 2SB1189 T100Q SMD SC-62 Ic=-0.7A 1.000 Q3 41-010001-87N *IC MAC&BBP AR5414A-001Atheros SMD BGA224 13×13mm 3.3V 1.000 U1 42-030001-38N *IC EEPROM M24C32-WDW6TP ST 2.5V 2-wire 1024×32bit TSSOP8 1.000 U3 46-030001-04N *5GHz LNA (ATF-55143) NF:0.6 Gain:17.7 SOT-343 1.000Q4 46-060001-22N *DPDT SW HWS410-6GHz Hexawave IL=0.8dB iso>29.5P1dB=33IP3=52 1.000 S1 46-A02001-B4N *IC 2.5/5G PA RF5824 RFMD SMD QFN-24 3.3V G=27dB Pout=18 1.000 U8 52-060001-26N *Connector U.FL-R-SMT-1(10) 6GHz VSWR< 1.3 HIROSE 2.000 J3,J2 56-090001-03N *3208 SN/Mac Label 32×8mm 80#白色銅版條碼貼紙 2.000 65-003001-37N *Shield Cover 48.91*26.69*1.7 t=0.15 SPTE 1.000 S3 65-020001-55N *Shield Frame 48.61*26.39*2.0 t=0.2 SPTE 1.000 S2 70-A06233-05N *PCB AG-623C V0.5 化金 FR4 4L H=1.0mm4連板59.6*38.5*1 1.000 11-282817-01N *C SMD CER 0.82pF ±0.1pF 0402 NPO 50V 1.000 C61 20-222919-08N *L SMD 2.2nH ±0.3nH 0402 TOKO 100MHZ 300mA 0.16Ω Q=10 1.000 L7 23-090001-06N *Diplexer 2.4&5GHz HMD888J-T [email protected] IL=0.8@5 SOSHIN 1.000 FL4 45-200001-03N *IC MC74VHC1G14DFT1G ON Schmidtt Inverter SC70 SOT-353 2.000 U9,U10 01-210011-00N *R SMD 1KΩ 1% 0402 0.063W 1.000 R32 01-247011-00N *R SMD 4.7KΩ 1% 0402 0.063W 1.000 R28 11-204917-01N *C SMD CER 0.4pF ±0.1pF 0402 NPO 50V 1.000 C58 01-233015-00N *R SMD 3.3KΩ 5% 0402 0.063W 1.000 R27 11-322545-00N *C SMD CER 2.2uF +80-20% 0603 Y5V 10V 1.000 C5 01-211011-00N *R SMD 1.1KΩ 1% 0402 0.063W 3.000 R52,R18,R63 52-H20000-00N *SMA EDGEMOUNT RECEPTACLE JACK 50Ω VSWR<1.5 2.000 J4,J8 11-227011-00N *C SMD CER 27pF ±5% 0402 NPO 50V 2.000 C47,L6 11-215918-01N *C SMD CER 1.5pF ±0.25pF 0402 NPO 50V 1.000 C48 01-249991-00N *R SMD 49.9Ω 1% 0402 0.063W 3.000 R35,R36

-35-30-25-20-15-10 -5 0 180 160 140 120 100 80 60 40 20 0 20 40 60 80 100 120 140 160 180 Angle(deg) dB MA-WS2455-20T 2.4-5.5GHz DUAL-BAND Antenna Frequency 5.5 GHz Plane/Pol H-plane Beamwidth 10.5 deg Gain 19.6 dBi

1.02.03.0 4.9 5.0 5.0 5.1 5.1 5.2 5.3 5.3 5.4 5.4 5.5 5.6 5.6 5.7 5.7 5.8 5.9 5.9 6.0 Frequency range GHz MA-WS2455-20T 4.9-6GHz DUAL-BAND Antenna VSWR MAX-5.67GHz 1.38

EMC LABS INC RF Exposure Evaluation RF Exposure EvaluationRF Exposure Evaluation RF Exposure Evaluation FCCID: QRF FCCID: QRFFCCID: QRF FCCID: QRF- -- - QSFNYON3 QSFNYON3QSFNYON3 QSFNYON3 Wireless Network Adapter Tranzeo Wireless Technologies Inc. Date: 4 April, 2007 Report No.: 040407.1 Labs: 19473 Fraser Way, Pitt Meadows, BC, Canada V3Y 2V4 Cam Finnigan EMC Engineer Sam Zahed EMC Coordinator Supplemental Exhibit Tranzeo EMC Labs Inc. Page 2 of 2 RF Exposure Evaluation FCC 1.1310 states the criteria listed in the table below shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Section 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Section 2.1093 of this chapter. Further information on evaluating compliance with these limits can be found in the FCC's OST/OET Bulletin Number 65, “Evaluating Compliance with FCC-Specified Guidelines for Human Exposure to Radiofrequency Radiation”. Frequency Range (MHZ) Electric Field Strength (V/m) Magnetic Field Strength (A/M) Power Density (mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 EUT Operating Condition The maximum antenna gain is 20 dBi at 5.2 and 5.4 GHz. RF exposure evaluation distance calculation EUT with 20 dBi antenna Mode OFDM/ Channel BW = 20MHz Freq (MHz) Output Power to Antenna (dBm) Antenna Gain (dBi) r (cm) 5260 8.54 20 7.5 5300 8.87 20 8.0 5320 8.70 20 7.5 5500 8.66 20 7.5 5600 9.76 20 8.5 5700 9.60 20 8.5 As shown above, the minimum distance where the MPE limit is reached is 8.5 cm for the EUT.

EMC LABS INC RF Exposure Evaluation RF Exposure EvaluationRF Exposure Evaluation RF Exposure Evaluation FCCID: QRF FCCID: QRFFCCID: QRF FCCID: QRF- -- - QSFNYON3 QSFNYON3QSFNYON3 QSFNYON3 Wireless Network Adapter Tranzeo Wireless Technologies Inc. Date: 4 April, 2007 Report No.: 040407.1 Labs: 19473 Fraser Way, Pitt Meadows, BC, Canada V3Y 2V4 Cam Finnigan EMC Engineer Sam Zahed EMC Coordinator Supplemental Exhibit Tranzeo EMC Labs Inc. Page 2 of 2 RF Exposure Evaluation FCC 1.1310 states the criteria listed in the table below shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Section 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Section 2.1093 of this chapter. Further information on evaluating compliance with these limits can be found in the FCC's OST/OET Bulletin Number 65, “Evaluating Compliance with FCC-Specified Guidelines for Human Exposure to Radiofrequency Radiation”. Frequency Range (MHZ) Electric Field Strength (V/m) Magnetic Field Strength (A/M) Power Density (mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 EUT Operating Condition The maximum antenna gain is 20 dBi at 5.2 and 5.4 GHz. RF exposure evaluation distance calculation EUT with 20 dBi antenna Mode OFDM/ Channel BW = 20MHz Freq (MHz) Output Power to Antenna (dBm) Antenna Gain (dBi) r (cm) 5260 8.54 20 7.5 5300 8.87 20 8.0 5320 8.70 20 7.5 5500 8.66 20 7.5 5600 9.76 20 8.5 5700 9.60 20 8.5 As shown above, the minimum distance where the MPE limit is reached is 8.5 cm for the EUT. Note that for fixed location transmitters such as an access point, the minimum separation distance is 20 cm even if the calculations indicate that the MPE distance may be less.

DFS PORTION OF FCC CFR47 PART 15 SUBPART E CERTIFICATION TEST REPORT FOR ACCESS POINT MODEL NUMBER: TR-Multi FCC ID: QRF-QSFNYON3 REPORT NUMBER: 07U11088-1 ISSUE DATE: JUNE 27,2007 Prepared for TRANZEO 19473 FRASER WAY PITT MEADOWS, BC, V3Y 2V4, CANADA Prepared by COMPLIANCE CERTIFICATION SERVICES 47173 BENICIA STREET FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 07U11088-1 DATE: JUNE 27, 2007 EUT: ACCESS POINT FCC ID: QRF-QSFNYON3 Page 2 of 46 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Issue Date Revisions Revised By -- 06/27/07 Initial Issue M. Heckrotte REPORT NO: 07U11088-1 DATE: JUNE 27, 2007 EUT: ACCESS POINT FCC ID: QRF-QSFNYON3 Page 3 of 46 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS............................................................................................. 4 2. TEST METHODOLOGY .................................................................................................................. 5 3. FACILITIES AND ACCREDITATION .......................................................................................... 5 4. CALIBRATION AND UNCERTAINTY.......................................................................................... 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 5 4.2. MEASUREMENT UNCERTAINTY ............................................................................................... 5 5. DYNAMIC FREQUENCY SELECTION ........................................................................................ 6 5.1. LIMITS .......................................................................................................................................... 6 5.2. TEST AND MEASUREMENT SYSTEM ........................................................................................ 9 5.3. DESCRIPTION OF EUT ............................................................................................................ 13 5.4. TEST CHANNEL AND METHOD .............................................................................................. 14 5.5. PLOTS OF RADAR WAVEFORM, AND WLAN TRAFFIC........................................................ 14 5.6. CHANNEL AVAILABILITY CHECK TIME ................................................................................ 21 5.7. CHANNEL MOVE TIME AND CHANNEL CLOSING TRANSMISSION TIME ........................ 26 5.8. NON-OCCUPANCY PERIOD .................................................................................................... 31 5.9. DETECTION BANDWIDTH....................................................................................................... 32 5.10. IN-SERVICE MONITORING .................................................................................................. 34 5.11. SLAVE DEVICE CONFIGURATION - CHANNEL MOVE TIME AND CHANNEL CLOSING TRANSMISSION TIME ........................................................................................................................... 41 6. SETUP PHOTOS .............................................................................................................................. 45 REPORT NO: 07U11088-1 DATE: JUNE 27, 2007 EUT: ACCESS POINT FCC ID: QRF-QSFNYON3 Page 4 of 46 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: TRANZEO 19473 FRASER WAY PITT MEADOWS, BC, V3Y 2V4, CANADA EUT DESCRIPTION: ACCESS POINT MODEL: TR-Multi SERIAL NUMBER: 0060B30B8BA2 (Device configured as Master) 0060B30B8B98 (Device configured as Slave) DATE TESTED: JUNE 13-14, 2007 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 15 SUBPART E (DFS REQUIREMENTS) NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Approved & Released For CCS By: Tested By: MIKE HECKROTTE YOBI ZHOU ENGINEERING MANAGER EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 07U11088-1 DATE: JUNE 27, 2007 EUT: ACCESS POINT FCC ID: QRF-QSFNYON3 Page 5 of 46 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of CCS. 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with FCC CFR 47 Part 15 and FCC 06-96 APPENDIX “COMPLIANCE MEASUREMENT PROCEDURES FOR UNLI…
