QRF-TR-CPE200WIRELESS NETWORKING DEVICE

20155 Stewart Crescent, Maple Ridge, B.C. Canada V2X 0T6 Phone (604) 460-6002 Fax (604) 460-6005 www.tranzeo.com Revision 7/26/04 Build 51 Page 1 of 10 TRANZEO WIRELESS QUICK START GUIDE FCC Information This equipment has been tested and found to comply with the limits for a Class A digital devices pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communication. Operation of this equipment in residential area is likely to cause harmful interference in which case the user will be required to correct the interference at this own expense. The user should not modify or change this equipment without written approval from company name. Modification could void authority to use this equipment. For the safety reason, people should not work in a situation which RF Exposure limits be exceeded. To prevent the situation happening, people who work with the antenna should be aware of the following rules 1. Install the antenna in a location where a distance of 32.5 cm from the antenna may be maintained. 2. While installing the antenna in the location, please do not turn on the power of wireless card. 3. While the device is working, please do not contact the antenna. 4. RF exposure: The antenna used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter” Copyright Copyright © 2004 all rights reserved. No part of this publication may be reproduced, adapted, stored in a retrieval system, translated into any language, or transmitted in any form or by any means without the written permission of the supplier. About This Manual The purpose of this manual is for the setup of the TRANZEO TR-CPE200. This manual, revised as version 1.0.0 in 2004, includes procedures assisting you in avoiding unforeseen problems. 20155 Stewart Crescent, Maple Ridge, B.C. Canada V2X 0T6 Phone (604) 460-6002 Fax (604) 460-6005 www.tranzeo.com Revision 7/26/04 Build 51 Page 2 of 10 TRANZEO WIRELESS QUICK START GUIDE TR-CPE Quick Start Guide Introduction This next-generation wireless LAN device – the TRANZEO TR-CPE200, brings Ethernet-like performance to the wireless realm. Fully compliant with the IEEE802.11b standard, the TRANZEO TR-CPE200 also provides powerful features such as the Internet-based configuration utility, and WEP security. Maximize network efficiency while minimizing your network investment and maintenance costs. TR-CPE Quick Start Guide Hardware Installation Product Kit Before installation, make sure that you have the following items: The TR CPE200 x 1 DC Power Adapter x 1 Power over Ethernet Adapter x 1 Ethernet Boot x 1 Ethernet Boot Tightening Bracket x 1 Mounting Bracket x 1 Ket Nuts (With Washer Attached) x 8 U-Bolt w/ 2 Nuts x 1 RJ-45 Patch Cable x 1 Spare Ethernet Boot Gasket x 1 If any of the above items is not included or damaged, please contact your local dealer for support. Mechanical Description LED panel of the Wireless LAN Smart Access Point: The following table provides an overview of each LED activity: LED Definition Activity Description Label Color Indicators POWER Amber On: Powered On Off: No Power LAN Amber/Green* On: Ethernet Link Flashing : Ethernet Traffic Off: No Ethernet Link Radio Red On: Radio Link Flashing Radio Activity Off: No Radio Link *Only one of the two colors will be shown. Actual color will vary between units. Power Supply: ONLY use the power adapter supplied with the TR- CPE200. Otherwise, the product may be damaged. 20155 Stewart Crescent, Maple Ridge, B.C. Canada V2X 0T6 Phone (604) 460-6002 Fax (604) 460-6005 www.tranzeo.com Revision 7/26/04 Build 51 Page 3 of 10 TRANZEO WIRELESS QUICK START GUIDE 2-4 Hardware Installations Take the following steps to set up your TR-CPE200. Site Selection: Before installation, determine the TR-CPE200 Units location. Proper placement of the unit is critical to ensure optimum radio range and performance. You should perform a Site Survey to choose a proper placement for your unit. Place your unit within the line of sight of the Access Point. Obstructions may impede performance of the unit. Tools Required to Install • One 3/8 wrench • One RJ-45 Crimper • A suitable length of Cat 5 Cable to bring the signal from the unit to the Power over Ethernet Adaptor • RJ-45 Jacks Before installing, you must determine if you will be installing the unit in a horizontal or vertical orientation. The TR-CPE200 model can be mounted in either orientation. The Ethernet boot should always be placed so that the cable runs toward the ground for maximum environmental protection. Vertical Orientation Horizontal Orientation 20155 Stewart Crescent, Maple Ridge, B.C. Canada V2X 0T6 Phone (604) 460-6002 Fax (604) 460-6005 www.tranzeo.com Revision 7/26/04 Build 51 Page 4 of 10 TRANZEO WIRELESS QUICK START GUIDE Connecting the Ethernet Cable Step 1 Place the Ethernet Boot Cover over the end of your Cat 5 Cable. Step 2 Step 3 Insert the Cat 5 Cable and tighten the Boot Cover. Be sure to pull enough cable through to reach the RJ-45 connector with an RJ-45 jack attached. Hand tighten only. DO NOT OVERTIGHTEN as you may damage the environment seal. Attach tightening bracket on top of the Ethernet Boot. This is easiest to do before you attach the CAT 5 cable. The Gasket must be attached to the Boot so that it sits between the radio and the boot. 20155 Stewart Crescent, Maple Ridge, B.C. Canada V2X 0T6 Phone (604) 460-6002 Fax (604) 460-6005 www.tranzeo.com Revision 7/26/04 Build 51 Page 5 of 10 TRANZEO WIRELESS QUICK START GUIDE Step 4 Place the Ethernet boot over the 4 Screw Posts. The screws should just barely clear the tightening bracket. Apply 4 Ket nuts to the screw posts and tighten until the metal plate makes…

Text truncated - open the document above for the full version.

Timco Engineering, Inc. TCB Application Form 731 Rev 01 Mar 02 Shaded areas are REQUIRED Item 1. Applicant’s complete, legal business name: Tranzeo Wireless Technologies, Inc. Applicant’s FCC Registration Number (FRN): 0008001257 Item 2. Applicant’s mailing address: fill in fields, as appropriate Line 1: Line 2:20155 Stewart Crescent P.O. Box: City:Maple Ridge State: BC Country (if foreign address): Canada Zip/Postal Code: V2X 0T6 Item 3. FCC ID consisting of: Grantee Code: QRF Equipment Product Code (14 characters maximum): -TR-CPE200 include “dashes” (-) where appropriate Item 4. Person to receive grant: this is the APPLICANT’S contact person, NOT the Test Lab’s First Name:Damian Mail Stop: Last Name:Wallace Telephone:604-460-6002 Title:Product Manager Fax No.:604-460-6005 E-mail:[email protected] Item 5. Test Firm Contact (if different from applicant): fill in fields, as appropriate Firm Name: Tranzeo EMC Telephone: 604-460-6625 Ext: Fax: No.: First Name:Andrew Middle Initial: Last Name:Marles Address Line 1:2 - 11720 Stewart Cres P.O. Box: Address Line 2: City:Maple Ridge State:BC Country (if foreign address):Canada Zip/Postal Code: E-mail:[email protected] Item 6a. Name of Test Firm and Contact Person on file with the FCC: Tranzeo EMC, Andrew Marles Item 6b. FCC Registered Test Site Number. Required for Part 15 and 18 applications. 960532 Item 7. Non-Technical Contact if Different: Firm Name: Telephone: Ext.: Fax No.: First Name: Middle Initial: Last Name: Address Line 1: P.O. Box: Address Line 2: City: State: Country (if foreign address): Zip/Postal Code: E-mail: Item 8. * Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR 0.459 of the Commission Rules? Yes No Item 9. *Is this application for modular approval? Yes No If yes, please submit a cover letter addressing the modular approval requirements of DA 00-1407. Item 10. *Is this application for software defined radio authorization? Yes No Item 11. Equipment Class: 3-digits required DTS Description of Product as it is marketed: WIRELESS NETWORKING DEVICE For Timco Use Only Job Number Scope Date Filed Conf. # Grant Note Item 12. *Application is for: Original Equipment Change in identification of presently authorized equipment: Original FCC ID Grant Date (MM/DD/YYYY) Class II permissive change or modification of presently authorized equipment Class III permissive change to software defined radio Note: this may only be filed for applications pertaining to Software Defined Radio Item 13. Is the equipment in this application: * (a) a composite device subject to an additional equipment authorization? * (b) part of a system that operates with, or is marketed with, another device that requires an equipment authorization? If either of the above questions is answered “Yes” complete section 12 (c). Yes No Yes No (c) The related application: has been granted under the FCC ID listed to the right is in the process of being filed under the FCC ID listed to the right is pending with the FCC under the FCC ID listed to the right FCC ID * Equipment will be operated under FCC Rule Part(s): 15 Item 14. EQUIPMENT SPECIFICATIONS: Where applicable Frequency range in MHz Rated RF power output IN WATTS Frequency tolerance %, Hz, ppm Emission Designator (See 47 CFR 2.201 and 2.202) Microprocessor model number 2412 2462 0.150 Read each certification carefully before answering and signing this application WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND/OR IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTRUCTION PERMIT (U.S. CODE, TITLE 47, SECTION 312 (a) (1)), AND/OR FORFEITURE (U.S. TITLE 47, SECTION 503). Item 15. (This Section intentionally left blank) Item 16. APPLICANT/AGENT CERTIFICATION: I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization issued by the TCB, under the authority of the FCC, as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. Authorizing an agent to sign this application, is done solely at the applicant’s discretion; however, the applicant remains responsible for all statements in this application. If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above Section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time. *Signature of Authorized Applicant: Title of Authorized Signature: Complete items below if an agent signs the application Firm Name: Telephone: Ext.: Fax No.: First Name: Middle Initial: Last Name: Address Line 1: P.O. Box: Address Line 2: City: State: Country (if foreign address): Zip/Postal Code: NOTE: An asterisk ‘*’ preceding a field indicates it must be completed.

#13-11720 Stewart Crescent, Maple Ridge, BC, Canada V2X 9E7 T: 604.460.6002 F: 604-460.6005 Toll Free: 1-866-872-6936 Website: www.tranzeo.com 8/20/2004 Federal Communications Commission 445 12th Street SW Washington, DC 20554 Re: Request for Confidentiality FCC ID: QRF-TR-CPE200 In accordance with FCC Rules part 0.459, we hereby request confidential treatment for the above referenced Certification application. The items to be held in confidence are: Confidential – TR-CPE200 FCC Appendix A (Confidential).pdf This appendix contains internal photographs of the TR-CPE200. Confidential – All photographs Any photographs associated with the TR-CPE200 product family provided with this submission or those provided at a later date. Confidential – Technical schematics and information – Senao Internationals Any technical information or schematics provided by Senao International, including but not limited to block diagrams, schematics and materials list associated with the TR-CPE200 product family. The application contains technical information that which Senao International and Tranzeo Wireless Technologies Inc. deem to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Since the product is sealed and contains no user serviceable parts, the Interior Photos are only of use to the applicant’s competitors Thank you for your attention in this matter

EMC LABS INC Tranzeo EMC Labs Inc. #2 - 11720 Stewart Crescent Maple Ridge, BC Canada V2X 9E7 TR-CPE200 Test Report Appendix B – External Photos 29 July 2004 Report Number: TRL290704.1 Bruce Balston, EMC Lab Manager Andrew Marles, Technical Writer Report Number: TRL290704.1 Emissions Compliance Test Tranzeo EMC Labs Inc. Page 2 of 2 Appendix B B.1 External Photos Figure 1 – External, sealed front cover of unit Figure 2 – External, Back panel of unit.

Tranzeo Wireless Technologies, Inc. 20155 Stewart Crescent Maple Ridge, BC Canada V2X 0T6 Ph: +1-604-460-6002 www.tranzeo.com 11 Mbps Wireless LAN Station Adaptor The firmware supplied with the TR-CPE200-15 is specific to Tranzeo Wireless Technologies Inc. and is the latest version. Only pre-approved and supplied upgrades are permitted. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. TR CPE200-15 FCC ID: QRF-TR-CPE200 Manufactured: Aug 24/2004 Serial #:TR-CPE-II-202089 F/W Version: 59 MAC Address: 00:60:B3:16:D9:DA

Tranzeo Wireless Technologies, Inc. 20155 Stewart Crescent Maple Ridge, BC Canada V2X 0T6 Ph: +1-604-460-6002 www.tranzeo.com 11 Mbps Wireless LAN Station Adaptor The firmware supplied with the TR-CPE200-19 is specific to Tranzeo Wireless Technologies Inc. and is the latest version. Only pre-approved and supplied upgrades are permitted. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. TR CPE200-19 FCC ID: QRF-TR-CPE200 Manufactured: Aug 24/2004 Serial #:TR-CPE-II-202089 F/W Version: 59 MAC Address: 00:60:B3:16:D9:DA

EMC LABS INC Tranzeo EMC Labs Inc. #2 - 11720 Stewart Crescent Maple Ridge, BC Canada V2X 9E7 TR-CPE200 Test Report Appendix C – Label Location 29 July 2004 Report Number: TRL290704.1 Bruce Balston, EMC Lab Manager Andrew Marles, Technical Writer Report Number: TRL290704.1 Emissions Compliance Test Tranzeo EMC Labs Inc. Page 2 of 2 Appendix C C.1 FCC Label location Figure 1 – External back panel, FCC Label location..

EMC LABS INC Tranzeo EMC Labs Inc. #2 - 11720 Stewart Crescent Maple Ridge, BC Canada V2X 9E7 TR-CPE200 Test Report Appendix E – Operational Description 29 July 2004 Report Number: TRL290704.1 Bruce Balston, EMC Lab Manager Andrew Marles, Technical Writer Report Number: TRL290704.1 Emissions Compliance Test Tranzeo EMC Labs Inc. Page 2 of 2 Appendix E E.1 Operational Description The EUT is a Wireless Router with 11 channels. This device provided four kind of transmitting speed 1,2,5.5 and 11Mbps. The device of RF carrier is DQPSK, DB PSK and CCK. The device adapts direct sequence spread spectrum modulation. This Broadband Wireless Router is an IEEE 802.11b Wireless LAN adapter. It allows your computer to connect to a wireless network and to share resources, such as files or printers without being bound to the network wires. Operation in 2.4GHz Direst Sequence Spread Spectrum (DSSS) radio transmission, the Broadband Wireless Router transfers data at speeds up to 64/128-bit Wired Equivalent Protection (WEP) algorithm is used. In addition, its standard compliance ensures that it can communicate with any 802.11b network.

EMC LABS INC Tranzeo EMC Labs Inc. #2 - 11720 Stewart Crescent Maple Ridge, BC Canada V2X 9E7 TR-CPE200 Test Report 29 July 2004 Report Number: TRL290704.1 Bruce Balston, EMC Lab Manager Andrew Marles, Technical Writer Report Number: TRL290704.1 Emissions Compliance Test Tranzeo EMC Labs Inc. Page 2 of 30 Revision History Report TRL290704.1 1) Section 3.4 – Test Results a. Table column “Measurement” revised to read dBm TR-CPE200-15 Channel Frequency (MHz) Measurement (dBm) Limit (dBm) Result 1 2412 21.06 27.0 PASS 6 2437 21.34 27.0 PASS 11 2462 21.74 27.0 PASS TR-CPE200-19 Channel Frequency (MHz) Measurement (dBm) Limit (dBm) Result 1 2412 21.06 26.3 PASS 6 2437 21.34 26.3 PASS 11 2462 21.74 26.3 PASS 2) Section 2.5.2 – Test Data a. Typographical errors in “Limit” column corrected. TR-CPE200-19 – Neutral Frequency (MHz) Reading (dBμV) Correction (dB) Reading (dBμV) Limit (dBμV) Margin (dBμV) Polarity Reading type 0.191 21.8 0.0 21.8 54.0 -32.2 Neutral Ave 0.199 60.3 0.0 60.3 63.7 -3.4 Neutral Peak 0.546 33.7 0.2 33.9 46.0 -12.1 Neutral Ave 0.550 55.5 0.2 55.7 56.0 -0.3 Neutral Peak 0.571 13.3 0.2 13.5 46.0 -32.5 Neutral Ave 0.573 54.4 0.2 54.6 56.0 -1.4 Neutral Peak 0.667 16.4 0.2 16.6 46.0 -29.4 Neutral Ave 0.671 50.1 0.2 50.3 56.0 -5.7 Neutral Peak 0.731 30.9 0.2 31.1 46.0 -14.9 Neutral Ave 0.740 46.8 0.2 47.0 56.0 -9.0 Neutral Peak 25.258 51.3 0.6 51.9 60.0 -8.1 Neutral Peak 25.259 24.7 0.6 25.3 50.0 -24.7 Neutral Ave Report Number: TRL290704.1 Emissions Compliance Test Tranzeo EMC Labs Inc. Page 3 of 30 TR-CPE200-19 - Line Frequency (MHz) Reading (dBμV) Correction (dB) Reading (dBμV) Limit (dBμV) Margin (dBμV) Polarity Reading type 0.150 59.8 0.0 59.8 66.0 -6.2 Line Peak 0.197 21.5 0.0 21.5 53.8 -32.3 Line Ave 0.360 54.5 0.0 54.5 58.7 -4.2 Line Peak 0.544 30.2 0.1 30.3 46.0 -15.7 Line Ave 0.551 51.2 0.1 51.3 56.0 -4.7 Line Peak 0.582 7.3 0.1 7.4 46.0 -38.6 Line Ave 0.602 48.3 0.1 48.4 56.0 -7.6 Line Peak 0.667 11.2 0.1 11.3 46.0 -34.7 Line Ave 0.736 11.2 0.1 11.3 46.0 -34.7 Line Ave 24.826 48.5 0.6 49.1 60.0 -10.9 Line Peak 25.267 25.7 0.6 26.3 50.0 -23.7 Line Ave 25.532 48.4 0.6 49.0 60.0 -11.0 Line Peak TR-CPE200-15 - Neutral Frequency (MHz) Reading (dBμV) Correction (dB) Reading (dBμV) Limit (dBμV) Margin (dBμV) Polarity Reading type 0.150 63.0 0.0 63.0 66.0 -3.0 Neutral Peak 0.150 36.5 0.0 36.5 66.0 -29.5 Neutral QP 0.150 24.0 0.0 24.0 56.0 -32.0 Neutral Ave 0.240 36.5 0.0 36.5 62.1 -25.6 Neutral QP 0.243 19.9 0.0 19.9 52.0 -32.1 Neutral Ave 0.250 61.4 0.0 61.4 61.7 -0.3 Neutral Peak 0.310 36.5 0.1 36.6 60.0 -23.4 Neutral QP 0.316 30.5 0.1 30.6 49.8 -19.2 Neutral Ave 0.320 59.3 0.1 59.4 59.7 -0.3 Neutral Peak 0.345 36.5 0.1 36.6 59.1 -22.5 Neutral QP 0.346 28.5 0.1 28.6 49.1 -20.5 Neutral Ave 0.355 57.7 0.1 57.8 58.8 -1.0 Neutral Peak 0.451 36.5 0.2 36.7 56.9 -20.2 Neutral QP 0.453 16.9 0.2 17.1 46.8 -29.7 Neutral Ave 0.461 52.2 0.2 52.4 56.7 -4.3 Neutral Peak 25.228 23.5 0.6 24.1 50.0 -25.9 Neutral Ave 25.237 53.1 0.6 53.7 60.0 -6.3 Neutral Peak 25.361 48.6 0.6 49.2 60.0 -10.8 Neutral QP Report Number: TRL290704.1 Emissions Compliance Test Tranzeo EMC Labs Inc. Page 4 of 30 TR-CPE200-15 - Line Frequency (MHz) Reading (dBμV) Correction (dB) Reading (dBμV) Limit (dBμV) Margin (dBμV) Polarity Reading type 0.190 58.1 0.0 58.1 64.0 -5.9 Line QP 0.200 63.8 0.0 63.8 -- -- Line Peak 0.204 21.8 0.0 21.8 53.5 -31.7 Line Ave 0.240 57.0 0.0 57.0 62.1 -5.1 Line QP 0.250 62.7 0.0 62.7 -- -- Line Peak 0.253 15.6 0.0 15.6 51.6 -36.0 Line Ave 0.313 55.2 0.0 55.2 59.9 -4.7 Line QP 0.323 61.2 0.0 61.2 -- -- Line Peak 0.326 10.4 0.0 10.4 49.6 -39.2 Line Ave 0.486 50.7 0.1 50.8 56.2 -5.4 Line QP 0.487 8.4 0.1 8.5 46.2 -37.7 Line Ave 0.496 55.3 0.1 55.4 56.1 -0.7 Line Peak 0.515 50.3 0.1 50.4 56.0 -5.6 Line QP 0.525 53.8 0.1 53.9 56.0 -2.1 Line Peak 0.535 10.1 0.1 10.2 46.0 -35.8 Line Ave 24.944 40.8 0.6 41.4 50.0 -8.6 Line Ave 24.949 54.4 0.6 55.0 60.0 -5.0 Line Peak 24.950 48.4 0.6 49.0 60.0 -11.0 Line QP Report Number: TRL290704.1 Emissions Compliance Test Tranzeo EMC Labs Inc. Page 5 of 30 Table of Contents 1.0 General Information........................................................................................................................6 1.1 EUT Description.....................................................................................................................6 1.2 Operational Description..........................................................................................................7 1.3 EUT Testing Configuration....................................................................................................7 1.4 EUT Modifications.................................................................................................................7 1.5 Test Facilities..........................................................................................................................8 1.6 Test Equipment.......................................................................................................................8 1.7 Test System Details.................................................................................................................8 1.8 Test Results.............................................................................................................................8 2.0 Conducted Emissions......................................................................................................................9 2.1 Test Standard...........................................................................................................................9 2.2 Test Limits..............................................................................................................................9 2.3 Test Setup................................................................................................................................9 2.4 Test Results..........................................................................................…

Text truncated - open the document above for the full version.

EMC LABS INC Tranzeo EMC Labs Inc. #2 - 11720 Stewart Crescent Maple Ridge, BC Canada V2X 9E7 TR-CPE200 Test Report Appendix D – Test Setup Photos 29 July 2004 Report Number: TRL290704.1 Bruce Balston, EMC Lab Manager Andrew Marles, Technical Writer Report Number: TRL290704.1 Emissions Compliance Test Tranzeo EMC Labs Inc. Page 2 of 2 Appendix D D.1 Test Setup Photos
