QSHAIRRBCBluetooth Barcode Reader model: Baracoda RoadRunne

Baracoda RoadRunners User Guide © Baracoda 2005 Page 1/12 Table of content 1 Introduction ...................................................................................................2 2 PDA stylus ....................................................................................................2 3 Recharging the battery ..................................................................................2 4 Switching on the reader .................................................................................2 5 Installing / replacing batteries .........................................................................3 6 Quick Start up guide ......................................................................................4 6.1 How to read barcodes .............................................................................4 6.2 The different usage mode .......................................................................4 6.3 The different reading mode .....................................................................4 6.3.1 Trigger mode (default setting)...............................................................4 6.3.2 Autoscan mode...................................................................................4 6.4 The different ways to connect RoadRunners to a host ...........................5 7 Status Display Summary ...............................................................................7 8 Configuring your scanner...............................................................................8 8.1 Reset your scanner: ................................................................................8 8.2 Usage modes ..........................................................................................8 8.2.1 Real Time Mode (default setting)..........................................................8 8.2.2 Batch mode.........................................................................................8 8.2.3 Time Stamp........................................................................................9 8.3 Symbology ..............................................................................................9 8.4 Data format .............................................................................................9 8.4.1 Baracoda Header................................................................................9 8.4.2 No data loss mode:..............................................................................9 8.4.3 Prefix / suffix.......................................................................................9 8.4.4 Barcode Identifier................................................................................9 8.5 Beeps and LEDs ...................................................................................10 9 Other functions ...........................................................................................10 9.1 Power management ..............................................................................10 9.2 Sniff period ...........................................................................................10 9.3 Low battery ...........................................................................................10 9.4 Security .................................................................................................10 10 Safety / Regulatory. .....................................................................................10 Baracoda RoadRunners User Guide © Baracoda 2005 Page 2/12 1 Introduction The RoadRunners are easy to use. Just press the trigger in order to switch on the scanner and simply press it again to scan a barcode. The colours of the LEDs indicate the status of the device. A beep indicates when the scanner connects to the remote device and when a barcode is scanned successfully. Acknowledgement of a completed scan is configurable by the user. Barcodes are transmitted in real time to the remote host devices/terminals using Bluetooth wireless technology or can be stored in the scanner and later uploaded to a remote device/terminal always using Bluetooth wireless technology. You can download software updates as well as additional documentation from http://www.baracoda.com after registration. With the RS232 cable accessory the RoadRunners becomes a normal wired barcode reader. 2 PDA stylus In order to attach the PDA stylus to the RoadRunners, insert the stylus into the hole, as showed in Fig 1. Note that there are two holes, symmetric around the principal axe of RoadRunners. Push downwards, as shown by the arrow n° 2 in Fig. 1. till you will hear a clips There are two holes, one on both sides. Note that you will not be able to use the Protective boot and the PDA stylus simultaneously 3 Recharging the battery Recharge the internal battery by using the included AC adapter. The Adapter rating is 5V, 500mA. When the scanner is charging, the LED is red (solid or blinking according to the charging phase of the device). When the scanner is fully charged, the LED will shut off (no light). A full recharge (from completely drained batteries) takes approximately 4 hours. When the original batteries wear out, please contact your Baracoda reseller for replacements. The adapter is the disconnection device, the socket-outlet shall be installed near the equipment and shall be easily accessible 4 Switching on the reader Remember to fully charge the battery before first use. In order to switch on the scanner, please press the trigger. You can set up the scanner to be switched on only after keeping the trigger pressed for two seconds. The scanner will switch off alone after some period of inactivity (in its standard mode RoadRunners will switch off after 10 minutes of inactivity, if not connected. This value can be modified by the user) 1 2 Fig. 1 Baracoda RoadRunners User Guide © Baracoda 2005 Page 3/12 5 Installing / replacing batteries Only use Baracoda approved rechargeable batteries. The us…

Text truncated - open the document above for the full version.

INSTRUCTIONS TCB SERVICE AGREEMENT For additional information on the TCB Program, contact MET Laboratories, Inc. at (410) 354-3300 or visit us at http://www.metlabs.com Enclosed is a copy of the MET TCB Service Agreement. Please complete the information on the Applicant and Manufacturer before making two copies of the agreement. The original and both copies of the agreement should be signed by your company and the product's manufacturer (if more than one manufacturer, additional agreements can be sent) before returning the executed original and copies of the agreement to MET. At the completion of the evaluation process for the product, fully executed copies of the agreement will be returned to your company and the manufacturer. The agreement allows MET access to the manufacturing facility during normal working hours to conduct any inspections that might be necessary to allow continued certification of the product. The agreement also indicates your intent to provide to MET Laboratories any product or information that might be required for reevaluation for continued surveillance. Additionally, the agreement specifies the conditions on how the product is to be identified as certified. This agreement in no way absolves the applicant or the manufacturer of any requirement or regulation of the Federal Communications Commission (FCC). 2 TCBF002 Rev.1MET Laboratories, Inc. TCB Service Agreement MET TCB SERVICE AGREEMENT THIS AGREEMENT is made at Baltimore, Maryland this 29 day of June 05 , 20 , by and between MET LABORATORIES, INC. (hereinafter referred to as MET) and the following: Applicant : Baracoda Wireless Technology Address : 30, Avenue de l'Amiral Lemonnier, 78160 Marly le Roi,FRANCE (Hereinafter referred to as the "Applicant") Manufacturer : (required for Part 68 only) Address : (Hereinafter referred to as the "Manufacturer") Only the product(s) designed and engineered by the Applicant and manufactured by the Manufacturer at the Manufacturer's facility at the above address, which have been certified by MET are covered by this service Agreement. NOW, THEREFORE, in consideration of the premises set forth in this agreement, the above mentioned parties agree that; Upon successful evaluation, MET will issue the Applicant a Grant of Equipment Authorization Certificate, granting the Applicant permission to market the certified product(s). At a minimum the product's identification plate or label will include the FCC ID Number or the Registration/Certification Number as well as any other information as might be required by statute. The FCC requires that MET perform post-certification surveillance. Surveillance for continued certification compliance can be accomplished by, one or all of the following methods depending on the specific FCC requirement and as notified by MET Labs; the Applicant providing recent test data as proof of continued compliance for production models of the product to MET at MET’s request, the applicant may either have MET perform the continued compliance testing, or provide test data from other locations as approved by MET for the purpose of compliance testing, or the Manufacturer agrees to allow free and unrestricted access to the Manufacturer's facility upon reasonable notice during normal working hours for the purpose of product review, or the Applicant or Manufacturer agrees to provide and deliver to MET or locations approved by MET models of the certified product at MET’s request. All costs associated with testing of the device will be borne by the Applicant or the Manufacturer and paid within 30 days of notice. If required the Applicant agrees to provide to MET for MET review certain identified technical documents or quality documents that provide for a review of product update and compliance. Acceptable Markings are found in 47 CFR 2.925, 2.926, 15.19, and part 68.300. Only products visually bearing the appropriate FCC identification label and identified as to model and type will be acknowledged as being an authorized product. The Applicant is responsible for applying the label to the product in accordance with current FCC requirements. An Applicant is required to submit to MET a sample of the label or plate showing the FCC ID Number or the Registration/Certification Number for approval prior to applying to the product. The Applicant is required to submit to MET a label location drawing or photograph showing the location of the mark on the product. Any reference to MET certification shall not be permitted on any non-eligible product(s), packaging, or literature. If the Applicant or the Manufacturer applies the FCC identification label to unauthorized products, then the Applicant and the Manufacturer shall save, indemnify, and hold harmless MET LABORATORIES, 3 TCBF002 Rev.1MET Laboratories, Inc. TCB Service Agreement INC. from any and all claims which may arise out of said unauthorized action. The label and/or references to MET are permitted on promotional, advertising, and packaging of Certified Product(s) provided that misrepresentation of results of the marking process and/or this agreement do not occur. Final judgment in the suitability of use of the label or the MET Laboratories name is reserved by MET. The Applicant shall maintain or require the manufacturer to maintain a record of all complaints made known to them relating to the product's compliance with the requirements of the relevant standard and agrees to make these records available to MET upon reasonable request. The applicant agrees to take appropriate action, or have the manufacturer take appropriate action with respect of such complaints and/or any deficiencies found in products or services that affect compliance with the requirements for certification. Compliance with all requirements and stipulations of the Certification Program and this agreement between MET and the Applicant is required for program compliance. Non-compliance with all or part of this agreement may result in termination of the agree…

Text truncated - open the document above for the full version.

attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: LETTER OF AGENT AUTHORIZATION June 29, 2005 To Whom It May Concern: We, the undersigned, hereby authorize MET Laboratories, Inc. to act on our behalf in all matters relating to application for equipment authorizations (FCC ID: QSHAIRRBC), including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, P.A. Mr. Thierry Fortune Product Program Manager Baracoda Wireless Technology 30, Avenue de l'Amiral Lemonnier, 78160 Marly le Roi, FRANCE Phone: +33 1 30 08 89 06 E-mail: [email protected]

Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 June 29, 2005 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Baracoda Wireless Technology requests confidentiality for the following products: FCC ID Number Product Title/Model QSHAIRRBC Bluetooth Barcode Scanner / Baracoda RoadRunners For the product stated above, we request that the following information be held confidential: 1) Circuit diagrams 2) Block Diagrams 3) Bill of materials 4) Operational Description No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain Baracoda Wireless Technology trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our Bluetooth devices. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me at the address shown below. Sincerely, P.A. Mr. Thierry Fortune Product Program Manager Baracoda Wireless Technology 30, Avenue de l'Amiral Lemonnier, 78160 Marly le Roi, France Phone: +33 1 30 08 89 00 E-mail: [email protected]

Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 June 29, 2005 RE: 15.19 Statement (FCC ID: QSHAIRRBC) TO WHOM IT MAY CONCERN The statement: "This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation” Is not placed in the engraved label of the equipment due to the following reasons: - Type label is too small (No room for this writing). - Required text is already included in the user guide This statement is placed in a prominent location in the instruction manual. Please contact me if there is any information you may need. If you have any questions, please feel free to contact me at the address shown below. Sincerely, P.A. Mr. Thierry Fortune Product Program Manager Baracoda Wireless Technology 30, Avenue de l'Amiral Lemonnier, 78160 Marly le Roi, France Phone: +33 1 30 08 89 00 E-mail: [email protected]

RoadRunners– Labels TF Confidential 1 June 2005 For BRR-L RoadRunners– Labels TF Confidential 2 June 2005 For BRR-F

GENERAL INFORMATION 1 Applicant data: Baracoda Wireless Technology 30, Avenue de l’Amiral Lemonnier 78160 Marly le Roi, France Phone: +33 1 30 08 89 00 Fax: +33 1 30 08 89 98 Contact person: Mr. Thierry Fortune Phone: +33 1 30 08 89 06 Fax: +33 1 30 08 89 98 e-mail: [email protected] 2 Manufacturer data: Baracoda Wireless Technology 30, Avenue de l’Amiral Lemonnier 78160 Marly le Roi, France Phone: +33 1 30 08 89 00 Fax: +33 1 30 08 89 98 Contact person: Mr. Thierry Fortune Phone: +33 1 30 08 89 06 Fax: +33 1 30 08 89 98 e-mail: [email protected] 3 Equipment data: Brand name: Baracoda Model name: Baracoda RoadRunners FCC ID: QSHAIRRBC

GENERAL INFORMATION 1 Applicant data: Baracoda Wireless Technology 30, Avenue de l’Amiral Lemonnier 78160 Marly le Roi, France Phone: +33 1 30 08 89 00 Fax: +33 1 30 08 89 98 Contact person: Mr. Thierry Fortune Phone: +33 1 30 08 89 06 Fax: +33 1 30 08 89 98 e-mail: [email protected] 2 Manufacturer data: Baracoda Wireless Technology 30, Avenue de l’Amiral Lemonnier 78160 Marly le Roi, France Phone: +33 1 30 08 89 00 Fax: +33 1 30 08 89 98 Contact person: Mr. Thierry Fortune Phone: +33 1 30 08 89 06 Fax: +33 1 30 08 89 98 e-mail: [email protected] 3 Equipment data: Brand name: Baracoda Model name: Baracoda RoadRunners FCC ID: QSHAIRRBC

Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 June 29, 2005 RE: RF exposure information FCC ID: QSHAIRRBC FCC ID Number Product Title / Model QSHAIRRBC Bluetooth Barcode Scanner / Baracoda RoadRunners TO WHOM IT MAY CONCERN The product stated above complies with the FCC limits for Human exposure to RF emissions. This handheld device is categorically excluded from routine environmental, because it operates at very low power level and it operates further than 2.5 cm from the body. The equipment is deemed to comply with the SAR or MPE limits without testing due to its very low power level (EIRP < 35 mW). Sincerely, P.A. Mr. Thierry Fortune Product Program Manager Baracoda Wireless Technology 30, Avenue de l'Amiral Lemonnier, 78160 Marly le Roi, France Phone: +33 1 30 08 89 00 E-mail: [email protected]

Report No.: 22281RET.101 Date: 2005-06-21 Page: 2 of 8 FDT08_04 INDEX 1. COMPETENCE AND GUARANTEES..........................................................................................3 2. GENERAL CONDITIONS..............................................................................................................3 3. CHARACTERISTICS OF THE TEST............................................................................................3 3.1 TEST REQUESTED.................................................................................................................3 3.2 REQUIREMENTS AND METHOD........................................................................................3 4. IDENTIFICATION DATA SUPPLIED BY THE APPLICANT.....................................................4 4.1 APPLICANT.............................................................................................................................4 4.2 REPRESENTATIVE................................................................................................................4 4.3 TEST SAMPLES SUPPLIER...................................................................................................4 4.4 IDENTIFICATION OF ITEM/ITEMS TESTED.....................................................................5 5. USAGE OF SAMPLES, PERIOD OF TESTING AND ENVIRONMENTAL CONDITIONS.....5 5.1 USAGE OF SAMPLES............................................................................................................5 5.2 PERIOD OF TESTING............................................................................................................6 5.3 ENVIROMENTAL CONDITIONS..........................................................................................6 6. TEST RESULTS..............................................................................................................................8 7. REMARKS AND COMMENTS......................................................................................................8 8. SUMMARY......................................................................................................................................8 ANNEXES ANNEX A. TEST RESULTS ANNEX B. PHOTOGRAPHS Report No.: 22281RET.101 Date: 2005-06-21 Page: 3 of 8 FDT08_04 1. COMPETENCE AND GUARANTEES Centro de Tecnología de las Comunicaciones (CETECOM), S.A. is a laboratory with a measurement facility in compliance with the requirements of Section 2.948 of the FCC rules and has been added to the list of facilities whose measurements data will be accepted in conjuction with applications for Certification under Parts 15 or 18 of the Commission's Rules. Registration Number: 905266. Centro de Tecnología de las Comunicaciones (CETECOM), S.A. is a laboratory with a measurement site in compliance with the requirements of RSS 212, Issue 1 (Provisional) and has been added to the list of filed sites of the Canadian Certification and Engineering Bureau. Reference File Number: IC 4621. In order to assure the traceability to other national and international laboratories, CETECOM has a calibration and maintenance programme for its measuring equipment. CETECOM guarantees the reliability of the data presented in this report, which is the result of measurements and tests performed to the item under test on the date and under the conditions stated on the report and is based on the knowledge and technical facilities available at CETECOM at the time of execution of the test. CETECOM is liable to the client for the maintenance by its personnel of the confidentiality of all information related to the item under test and the results of the test. 2. GENERAL CONDITIONS 1. This report only refers to the item that has undergone the test. 2. This report does not constitute or imply by its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without written approval of CETECOM. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of CETECOM and the Accreditation Bodies. 3. CHARACTERISTICS OF THE TEST 3.1 TEST REQUESTED Measurements for frequency hopping spread spectrum equipment (Bluetooth) operating in the 2400 MHz -2483.5 MHz band and using, according to FCC Part 15.247. 3.2 REQUIREMENTS AND METHOD The test has been carried out according to FCC parts 15.33, 15.35, 15.109, 15.207, 15.205, 15.209, 15.247 and the document DA 00-705:"Filing and Measurement Guidelines for Frequency Hopping Spread Spectrum Systems". The testing was performed according to the procedure in ANSI C63.4. Radiated testing was performed in Cetecom's semi-anechoic chamber. This site has been fully described in a report submitted to the FCC and was accepted in a letter dated July 25, 2002. Report No.: 22281RET.101 Date: 2005-06-21 Page: 4 of 8 FDT08_04 The instrumentation used to perform the testing is listed below: 1. Semianechoic Absorber Lined Chamber IR 11. BS. 2. Control Chamber IR 12.BC. 3. Antenna mast EM 1072 NMT. 4. Rotating table EM 1084-4. ON. 5. Multi device controller ETS 2090. 6. Bilog antenna CHASE CBL6111. 7. Antenna tripod EMCO 11968C. 8. Double-ridge Guide Horn antenna 1-18 GHz HP 11966E. 9. Double-ridge Guide Horn antenna 18-40 GHz Agilent 119665J. 10. RF pre-amplifier Miteq JS4-12002600-30-5A. 11. Semianechoic Absorber Lined Chamber IR 11. BS. 12. RF pre-amplifier Miteq AFS5-04001300-15-10P-6. 13. Spectrum analyzer R&S ESIB 26. 14. Spectrum analyzer R&S FSM. 15. Transient limiter. HP 11947ª 16. Line Impedance Stabilization Network (L.I.S.N.) R&S. ESH2-Z5 4. IDENTIFICATION DATA SUPPLIED BY THE APPLICANT Identification data in this section has been supplied by the client. 4.1 APPLICANT Name or Company: BARACODA WIRELESS TECHNOLOGY V.A.T.: --- Address: 30, Avenue de l’Amiral Lemonnier City: Marly le Roi Postal code: 78160 Country: FRANCE Telephone: +33 1 300889…

Text truncated - open the document above for the full version.

Report No.: 22281RET.101 Date: 2005-06-21 Page: 1 of 7 Annex B FET18_00.DOC ANNEX B PHOTOGRAPHS (Number of photographs: 6) Report No.: 22281RET.101 Report No.: 22281RET.101 Date: 2005-06-21 Page: 2 of 7 Annex B FET18_00.DOC 1. Equipment (external view) Report No.: 22281RET.101 Date: 2005-06-21 Page: 3 of 7 Annex B FET18_00.DOC 2. Equipment for conducted measurements. Report No.: 22281RET.101 Date: 2005-06-21 Page: 4 of 7 Annex B FET18_00.DOC 3. General test set-up for radiated measurements. Report No.: 22281RET.101 Date: 2005-06-21 Page: 5 of 7 Annex B FET18_00.DOC 4. Test set-up for radiated measurements below 1 GHz. Report No.: 22281RET.101 Date: 2005-06-21 Page: 6 of 7 Annex B FET18_00.DOC 5. Test set-up for radiated measurements above 1 GHz. Report No.: 22281RET.101 Date: 2005-06-21 Page: 7 of 7 Annex B FET18_00.DOC 6. Test set-up for RF conducted measurements.
