QSS-COX70ITDMCCoder working with 123kHz and 13.56 MHz keycards

Manual Coder CO x70i TDM/C Installation & Maintenance Instructions Coder CO x70i TDM/C Page 2 © SKIDATA AG, April 2003 SKIDATA AG Technical Documentation Untersbergstrasse 40 A-5083 Gartenau Telephone +43-(0)6246 888, Telefax +43-(0)06246 8887 Internet http://www.skidata.com e-mail [email protected] Copyright © 2003 by SKIDATA AG. All rights reserved. All information in the following document is protected by copyright law. No part of this document may be reproduced without the written consent of SKI- DATA AG. SKIDATA AG reserves the right to make any changes of specification and other information in this document without further notice. Please note During the compilation of this Technical Documentation, great care has been taken to ensure the accuracy of the information contained in it. However, despite our constant effort to ensure the highest degree of accuracy and comprehensiveness possible, the information provided cannot be guaranteed to be absolutely error-free. Trademarks This documentation may contain representations of registered product or service trademarks owned by SKIDATA AG or third parties, as well as references to proprietary know-how protected by copyright laws or other legal provisions. In any case the intel- lectual property rights remain exclusively with their respective owners. Declaration of Conformity The Coders of the CO x70i TDM/C product family have been de- veloped, designed and manufactured in accordance with the following EU directions: R&TTE (99/5/EC) 0408 List of EU countries where these Coders may be sold: AT, BE, DE, DK, ES, FI, FR, GB, GR, IE, IT, LU, NL, PT, SE Version April 2003 Coder models CO x70i TDM/C Installation & Maintenance instructions © SKIDATA AG, April 2003 Page 3 FCC 15.19 : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause un- desired operation. FCC 15.21 : IMPORTANT: Any changes to or modifications of CO x70i TDM/C unless expressly approved by SKIDATA™, may void the user's authority to operate this device. Installation & Maintenance Instructions Coder CO x70i TDM/C Page 4 © SKIDATA AG, April 2003 Coder CO x70i TDM/C 1 Document Management – Version Table Tab. 1: Document Version Table for Installation & Maintenance Instructions Section Document Pages Version Date 1 Coder CO x70i TDM/C 6 1.0 28-04-2003 Coder CO x70i TDM/C 1 1 Coder CO x70i TDM/C Version 1.1 4 pages Copyright 2003 by SKIDATA AG 1 Coder CO x70i TDM/C 1.1 Contents Page 2 © SKIDATA AG, Version 1.1 1.1 Contents 1.1 Contents 2 1.2 Electrical connections of the device 3 Coder CO x70i TDM/C 1 Electrical connections of the device 1.2 © SKIDATA AG, Version 1.1 Page 3 1.2 Electrical connections of the device „ Plug the D-sub connector of the power adapter into the power D-sub port of the printer. „ Use the supplied interface cable to connect the interface port on the printer to the COM 1 port on the PC. „ Plug in the power adapter Fig. 1: Back-View Fig. 2: Connection layput 1 Coder CO x70i TDM/C 1.2 Electrical connections of the device Page 4 © SKIDATA AG, Version 1.1

Coverletter: Skidata AG wants to get the FCC-Certification for the following product: Skidata Coder/Printer CO x70i TDM/C. The unit will get the following FCC-ID: QSS-COX70ITDMC List of documents:: Exhibit Thema File Exhibit 01 Label and placement Typelabel.pdf Type_label_placement.pdf Exhibit 02 Not needed -------------------- Exhibit 03 External Photos extern_03-163.pdf * Exhibit 04 Block Diagrams Block_diagram_COx70iTDMC.pdf * Exhibit 05 Schematic Diagrams sd537_7.pdf sd513_4.pdf Exhibit 06 Testreport 03-163.pdf Exhibit 07 Test Set-up Photos testsetup_03-163.pdf Exhibit 08 User Manual COx70iTDMC-1-1-en-man.pdf Exhibit 09 Internal Photos intern_03-163.pdf Exhibit 10 Not needed -------------------- Exhibit 11 Not needed -------------------- Exhibit 12 Operational Description COx70itdmc-1-0-en-fact.pdf Exhibit 13 Cover letter Request for confidentiality This file Request_for_Confidentialidity.pdf For the Exhibits marked with ‘*’ Skidata AG requested Confidentiality according to 47 CFR 0.457(d) of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos is not the actual status. The correct labelling you can see on the photo Typelabel.pdf in Exhibit 1.

Fa. SKIDATA AG Untersbergstrasse 40 A-5183 Gartenau Austria, Europe Tel.: +43 / 62 46 / 888 – 0 Fax: +43 / 62 46 / 888 – 7 TÜV Österreich (TUEV Austria) Deutschstrasse 10 A-1230 Wien Austria, Europe Tel.: +43 / 1 / 610 91 - 0 Request for CONFIDENTIALITY Pursuant to 47 CFR 0.457(d) of the FCC Rules, we have request for confidentiality of the following parts of our documentation regarding the Coder CO x70i TDM/C (FCC-ID: QSS-COX70ITDMC): • Schematic Diagrams: - sd513_4.pdf - sd537_7.pdf • Block Diagram: - Block_diagram_COx70iTDMC.pdf This information is owned by our company and put into public is prohibited. We further certify that the applicant nor any party to the application subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C Section 862. Christoph Sonderegger Standard Compliance Coordinator SKIDATA AG

:-):-) :-):-) :-) SkiData AG • Untersbergstraße 40 • A-5083 Gartenau [t] +43 (0) 62 46/8 88-0 • [f] +43 (0) 62 46/8 88-7 • [e] [email protected] • [w] www.skidata.com Version 1.0 • 08.10.2002 • Copyright © 2002 by SkiData AG This documentation may contain representations of registered product or service trademarks owned by SkiData or third parties, as well as references to proprietary know-how protected by copyright laws or other legal provisions. In any case the intellectual property rights remain exclusively with their respective owners. This document is subject to change without notice. It cannot form part of a binding contract. Picture may vary from actual product KeyPrinterPage 1/2 CO x70i TDM/C The CO x70i TDM/C is a compact and inexpensive ticket printer and coder. Coding units read, print and code ISO-format tickets. In addition to these features, the CO x70i TDM/C can process ThermoReWrite KeyCards. These tickets can be reused a number of times, as they are equipped with a thermosenstive coating for receiving visual imprints which can be erased at any time. The CO x70i TDM/C is a printer, which was especially designed for the advance ticket sale in hotels or other points of sale via internet for connection to existing PCs. Features •Compatible with the data carriers used in all SkiData systems •Flexibility by way of economical printing of uniform blank cards •Direct thermoprinting (thermosensitive coating on the ticket is turned black) •Standard interface (RS232) •Safe from manipulation because tickets are printed and coded in a single step •Contactless data carriers such as Swatch Access can be coded via the integrated groove antenna •Simple handling due to the omission of colour ribbons and ink cartridges •Electronic coding for 122.88 KHz and 13.56 MHz •ISO 15693-compatible •For erasing and printing ThermoReWrite KeyCards 153 128 85 116 Models, accessories 937100035 ............................... CO x70i TDM/C thermodirect coding unit with manual ticket insertion and erase function. For coding contactless data carriers, 122.88 kHz and 13.56-MHz KeyCards and Swatch Access on built-in antenna. Can be used to issue bar-code tickets, manual insertion into front. Technical features Data Carriers ............................Barcode card, KeyCard, Swatch Access, KeyBand, GORE- TEX ® Glove Tickets ...................................... 84 x 54 mm, thickness of 0.3 - 1.2 mm Input voltage ............................ 85 – 132 or 170 – 265 V, 47 – 63 Hz Power consumption ................. 200 Watt max. Norms ....................................... CE symbol, ETS 300 330 Ambient conditions................... +10° – +35 °C, 25 % – 85 % humidity, (non condense) Dimensions (mm) ..................... printer: 168 x 164 x 132, power unit: 250 x 100 x 55 Weight ...................................... printer: 1.55 kg, power unit: 1.7 kg Printing area............................. 45 x 48 mm Resolution................................ 200 dpi Printing speed.......................... 3.5 s. Total time required for issue 7 s. Ticket insertion......................... manual Color .........................................Bue RELIUS E-14-45, Orange (PANTONE 151 C) KeyPrinterPage 2/2 CO x70i TDM/C
