QSS-COX70ITXBCCoder working with 123 kHz and 13.56 MHz keycards

Installation & Maintenance Instructions Coder Models CO x70 TX, CO x70 TX/BC and CO x70i TX, CO x70i TX/BC Installation & Maintenance Instructions Coder models COx70TX Page 2 © SKIDATA AG, February 2003 SKIDATA AG Technical Documentation Untersbergstrasse 40 A-5083 Gartenau Telephone +43-(0)6246 888, Telefax +43-(0)06246 8887 Internet http://www.skidata.com e-mail [email protected] Copyright © 2003 by SKIDATA AG. All rights reserved. All information in the following document is protected by copyright law. No part of this document may be reproduced without the written consent of SKI- DATA AG. SKIDATA AG reserves the right to make any changes of specification and other information in this document without further notice. Please note During the compilation of this Technical Documentation, great care has been taken to ensure the accuracy of the information contained in it. However, despite our constant effort to ensure the highest degree of accuracy and comprehensiveness possible, the information provided cannot be guaranteed to be absolutely error-free. Trademarks This documentation may contain representations of registered product or service trademarks owned by SKIDATA AG or third parties, as well as references to proprietary know-how protected by copyright laws or other legal provisions. In any case the intel- lectual property rights remain exclusively with their respective owners. Declaration of Conformity The Coders of the COx70TX product family have been devel- oped, designed and manufactured in accordance with the following EU directives: R&TTE (99/5/EC) Machinery (98/37/EC) 0408 Version February 2003 Coder models COx70TX Installation & Maintenance instructions © SKIDATA AG, February 2003 Page 3 List of EU countries where these Coders may be sold: AT, BE, DE, DK, ES, FI, FR, GB, GR, IE, IT, LU, NL, PT, SE FCC 15.19 : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause un- desired operation. FCC 15.21 : IMPORTANT: Any changes to or modifications of COx70TX (all variants) unless expressly approved by SKIDATA™, may void the user's authority to operate this device. Installation & Maintenance Instructions Coder models COx70TX Page 4 © SKIDATA AG, February 2003 Main Table of Contents 1 Introduction, Safety Requirements 2 Operation & Maintenance Coder models 3 Document Management – Version Table Tab. 1: Document Version Table for Installation & Maintenance Instructions Section Document Pages Version Date 1 Main Table of Contents 4 1.0 17-02-2003 2 Introduction, Safety Requirements 6 1.0 17-02-2003 3 Operation & Maintenance of Coder Models 24 1.0 17-02-2003 Contents 1 1 Contents Version 1.0 4 Pages Copyright 2003 by SKIDATA AG 1 Contents 1.1 Content Page 2 © SKIDATA AG, Version 1.0 1.1 Contents Contents 1 1.1 Contents 2 Introduction, Safety requirements 2 2.1 Contents 2 2.2 About this Documentation 3 2.2.1 Structure of this Document 3 2.3 Typographical Conventions 4 2.3.1 Text 5 2.3.2 Important product safety notice 5 2.4 Safety instructions 5 2.4.1 Danger of injury by rotating parts 5 2.4.2 Environmental conditions 5 2.4.3 Power cord 6 2.4.4 Warranty and liability 6 Operation & Maintenance 3 3.1 Contents 2 3.2 Installation 4 3.2.1 Space Requirements 4 3.2.2 Placement 4 3.2.3 Unpacking and Set-Up 5 3.2.4 Installing a Single-Hopper Module 6 3.2.5 Installing a Triple-Hopper Module 8 3.2.6 Installing the hopper attachment 8 3.3 Coder Components 10 3.4 Safety Notes 12 3.5 Preparing the Coder for usennnn 13 3.5.1 Inserting Cards 13 3.5.2 Connecting the Coder and Power Supply 15 3.5.3 Connection of Coder and CashComputer 15 3.6 Maintenance 16 3.6.1 Removing the Housing Cover 16 3.6.2 Cleaning the Transport Path 17 Contents vvvvc 1 Content 1.1 © SKIDATA AG, Version 1.0 Page 3 3.6.3 Cleaning or replacing the Thermal print head / Barcode Reader 18 3.6.4 Cleaning the Transport Rollers 19 3.6.5 Cleaning the Separating Roller 21 3.7 Troubleshooting 22 3.7.1 Cards are not issued 22 3.7.2 Card stuck in mechanism 22 3.7.3 Cards are not Drawn In 23 3.7.4 Poor Print Quality 23 3.8 Technical characteristics 24 3.8.1 Data Carriers 24 3.8.2 Devices 24 1 Contents 1.1 Content Page 4 © SKIDATA AG, Version 1.0 Introduction, Safety Requirements 2 2 Introduction, Safety Require- ments Version 1.0 6 Pages Copyright 2003 by SKIDATA AG 2 Introduction, Safety Requirements 2.1 Contents Page 2 © SKIDATA AG, Version 1.0 2.1 Contents 2.1 Contents 2 2.2 About this Documentation 3 2.2.1 Structure of this Document 3 2.3 Typographical Conventions 4 2.3.1 Text 4 2.3.2 Important product safety notice 4 2.4 Safety Instructions 5 2.4.1 Danger of injury by rotating parts 5 2.4.2 Environmental conditions 5 2.4.3 Power cord 6 2.4.4 Warranty and liability 6 Introduction, Safety Requirements, 2 About this Documentation 2.2 © SKIDATA AG, Version 1.0 Page 3 2.2 About this Documentation This manual contains a description of the Series CO x70 TX and CO x70 TX/BC as well as the Series CO x70i TX and CO x70i TX/BC coding units, as well as instructions for the correct installation and connection of the device, and details on operation and main- tenance. NOTE: Throughout this documentation, Coder models CO x70 TX (or KeyPrinter), CO x70i TX, CO x70 TX/BC and CO x70i TX/BC are uniformly referred to as “COx70TX”, disregard- ing any distinction between 1-hopper and 3-hopper models. 2.2.1 Structure of this Document Chapter 1 contains the main table of contents of this manual. Chapter 2 (i.e. the chapter you are just reading) provides some general information about this documentation and its use, as well as a number of important safety instructions. In Chapter 3 you will find instructions on how to install and con- nect the coding units, as well as details on its operation and maintenance. 2 Introduction, Safety Requirements 2.3 Typographical Convention…

Text truncated - open the document above for the full version.

Coverletter: Skidata AG wants to get the FCC-Certification for the following product: Skidata Coder CO x70i TX/BC. The unit will get the following FCC-ID: QSS-COX70ITXBC List of documents:: Exhibit Thema File Exhibit 01 Label and placement Type-label_COx70iTXBC.pdf Type_label_placement.pdf Exhibit 02 Not needed -------------------- Exhibit 03 External Photos 02-223extern.pdf * Exhibit 04 Block Diagrams Block_diagram_COx70iTX.pdf * Exhibit 05 Schematic Diagrams sd487_5V2.pdf sd537_7.pdf sd538_2.pdf sd556_1.pdf Exhibit 06 Testreport 02-223.pdf Exhibit 07 Test Set-up Photos 02-223testsetup.pdf Exhibit 08 User Manual InstAndMaintenance-COx70TX-1-0-en-man.pdf Exhibit 09 Internal Photos 02-223intern.pdf Exhibit 10 Not needed -------------------- Exhibit 11 Not needed -------------------- Exhibit 12 Operational Description cox70itx-1-1-en-fact.pdf Exhibit 13 Cover letter Request for confidentiality This file Confidentialidity.pdf For the Exhibits marked with ‘*’ Skidata AG requested Confidentiality according to 47 CFR 0.457(d) of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos is not the actual status. The correct labelling you can see on the photo Type-label_COx70iTXBC.pdf in Exhibit 1.

Fa. SKIDATA AG Untersbergstrasse 40 A-5183 Gartenau Austria, Europe Tel.: +43 / 62 46 / 888 – 0 Fax: +43 / 62 46 / 888 – 7 TÜV Austria (TUEV Austria) Deutschstrasse 10 A-1230 Wien Austria, Europe Tel.: +43 / 1 / 610 91 - 0 Request for CONFIDENTIALITY Pursuant to 47 CFR 0.457(d) of the FCC Rules, we have request for confidentiality of the following parts of our documentation regarding the Coder CO x70 iTX/BC (FCC-ID: QSS-COX70ITXBC): • Schematic Diagrams: - sd487_5V2.pdf - sd537_7.pdf - sd538_2.pdf - sd556_1.pdf • Block Diagram: - Block_diagram_COx70iTX.pdf This information is owned by our company and put into public is prohibited. We further certify that the applicant nor any party to the application subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C Section 862. Christoph Sonderegger Standard Compliance Coordinator SKIDATA AG

Typenschild Grundgerät 50,8 x 25,4 mm Model SeriaI no. Prod.date Tech.spec. MADE IN AUSTRIA SKIDATA AG A-5083 Gartenau · Phone +43 6246 888-0 CO x70i TX/BC XXXXXXXXXX YYYY 24.5 V 4A QSS-COX70ITXBC For indoor use 0408 FCC-ID

:-):-) :-):-) :-) SKIDATA AG • Untersbergstraße 40 • A-5083 Gartenau [t] +43 (0) 62 46/8 88-0 • [f] +43 (0) 62 46/8 88-7 • [e] [email protected] • [w] www.skidata.com Version 1.1 • 03.03.2003 • Copyright © 2003 by SKIDATA AG This documentation may contain representations of registered product or service trademarks owned by SKIDATA or third parties, as well as references to proprietary know-how protected by copyright laws or other legal provisions. In any case the intellectual property rights remain exclusively with their respective owners. This document is subject to change without notice. It cannot form part of a binding contract. Picture may vary from actual product KeyPrinterPage 1/2 CO x70i TX The CO x70i TX is a fast and compact universal ticket printer and coder. Coding units read, print and code ISO-format tickets. The CO x70i TX applies supplementary visual imprints to colored, preprinted blank tickets, e.g. authorizations or a bar code or personalizing. A built-in bar-code reader module (optional) can be employed for checking freshly printed bar codes. In addition to these features, the CO x70i TX can process ThermoReWrite KeyCards. These tickets can be reused a number of times, as they are equipped with a thermo sensitive coating for receiving visual imprints which can be erased at any time. Features •Compatible with the data carriers used in all SkiData systems •Flexibility by way of economical, speedy printing of uniform blank cards •Direct thermoprinting •Standard parallel interface (IEEE 1284) •Safe from manipulation because tickets are printed and coded in a single step •Contactless data carriers such as Swatch Access can be coded via the integrated groove antenna •Simple handling due to the omission of colour ribbons and ink cartridges •Electronic coding for 122.88 KHz and 13.56 MHz •ISO 15693-compatible •For erasing and printing ThermoReWrite KeyCards •Top printing quality by using a 300 dpi thermal head •Extremely high output speed Versions, Accessories 937100020 ............................... CO x70i TX. For coding contactless data carriers, 122.88 kHz and 13.56-MHz KeyCards and Swatch Access on built- in antenna, erase function for ThermoReWrite KeyCards, manual insertion into front 937100025 ............................... CO x70i TX/BC. For coding contactless data carriers, 122.88 kHz and 13.56-MHz KeyCards and Swatch Access on built- in antenna, erase function for ThermoReWrite KeyCards, can be used to issue barcode tickets, manual insertion into front 937100810 ...............................COx70TX/1S: Single Tray. Ticket hopper for 150 to 450 tickets, for attachment to the rear of CO x70 TX 937100820 ...............................COx70TX/3S: Multiple Tray. Multiple-tray (three) ticket hopper for 150 to 450 tickets, for attachment to rear of CO x70i TX CPZUBEHÖR4113 ................... Cleaning set for KeyPrinter Technical Characteristics Data Carriers ............................Barcode card (optional), KeyCard, Swatch Access, KeyBand, GORE-TEX® Glove Tickets ...................................... 84 x 54 mm, thickness: 0.3 - 1.2 mm Input voltage ............................ 85 - 132 V or 170 - 265 V, 47 - 63 Hz Power consumption ................. 200 W max. Standards ................................. CE symbol, FTV 525, ETS 300 330, ISO 9001 Ambient conditions................... +10° - +35°C, 25% - 85% humidity Dimensions [in mm] ................. Printer Multiple Tray: 365 x 250 x 330 (w x h x d); Single Tray: 210 x 250 x 330 (w x h x d); Power supply: 120 x 70 x 240 (w x h x d) Weight ......................................Printer: 8.2 kg; power supply: 1.7 kg Printing area............................. 81.5 x 48 mm, edge: 2 mm (l) or 2.5 mm (w) Resolution................................ 300 dpi Chassis base colors ................. Gray RAL 6009, Blue RELIUS E-14-45, Orange (PANTONE 151 C) KeyPrinterPage 2/2 CO x70i TX
