QUPSAVERCALL-1000Wireless Security System - Main Unit

MCU RF RX Module RF TX Module CODEC & FILTER FLASH MEMORY Audio AMP Telephone Circuit KEYPAD SPEAKER Power Supply Circuit AC ADAPTER MAIN BLOCK DIAGRAM MODEL : SAVERCALL- 1000 Remote Controller (Necklace Type) Remote Controller Fire Sensor Door Sensor Motion Detector External Siren External Tx Unit Main Unit ANTENNA MIC [AC120V/60Hz] [ DC 9V/500mA] TEL. LINE MIC INTERFACE CIRCUIT Hyun Joung System Co., Ltd. LCD MODULE Data/Address Bus Backup Battery External Communication Port DTMF Receiver X-Tal 3.579545[MHz] X-Tal 4.096[MHz] 433.425[mhz] ~ 434.415[MHz]

Correspondence summary for FCC correspondence number 7340. 3/24/03 reply from test lab: The device was tested per Part 15.231(b) and the transmitter is activated when the transmitter of the main controls the remote siren(optional accessory not included in this category). The above is stated in the test report of main. 3/27/03 TCB question and answer from test lab: Please, kindly, answer the following question from the FCC: 1. The plot, also, does not indicate how the power line conducted measurements were made. Was the plot made while the EUT was transmitting, receiving, during audio communications, etc..?? Response : Yes, the plot was made while the EUT was transmitting and receiving so that power line has maximum load. But this device has no function of audio communications.

External Photo 1. Main Unit

Label Information Label is attached on the rear of main unit and packing box. The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. FCC ID: QUPSAVERCALL-1000 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS; (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED. INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

Internal Photo 1. Main Unit Internal Photo

Operation Manual This product informs emergency situation to user using wired te lephone line when produce invader, fire occur- rence using wireless sensors and emergency situation using wire less remote controller (include necklace style remote controller). And also it is a stand-alone radio alarm sy stem that can drive out invaders. Sensor part Main frame part Telephone listener part Sensor (include remote controller) transmits data by protocol predefined at in-vader, door open, occurrence of fire or emergency situation occurrence to main frame us-ing RF Transmitter. -> Main frame examines whether fit to protocol that receive RF signal that sensors (include re-mote controller) sends a letter through RF Receiver of main frame and is predefined. If is sensor or remote controller that is registered in main frame, main frame calls by stored telephone number beforehand. (At this time, according to user option or state of main frame, wired siren can act.) -> If listener receives telephone that is made from main frame, recorded beforehand user's ad-dress or message is played and manufacturing guidance voice is played continuously. This time, listener can do manufacturing such as tapping, arming side conversation, siren on/off, change main frame working mode and etc. using DTMF that happen by that press telephone button.

TEST REPORT Date : 2003-02-13 No. : BRF-0212001 Page 1 of 9 BARO Approval Tech Co. #402, Sewang Building, 127-18, Nonhyun-Dong, Gangnam-Gu, Seoul, 135-010, Korea TEL : 82 2 546 9607, FAX : 82 2 546 9608 APPLICANT : Hyun Joung System Co., Ltd. No. 302, 2 nd ACE Techno Tower, 197-7, Guro-dong, Guro-gu, Seoul, Korea DATE OF SMAPLES RECEIVED : Dec. 06, 2002 TEST DURATION : Dec. 16, 2002 ∼ Feb. 7, 2003 DESCRIPTION OF SAMPLE (S) : A sample of product said to be : Product : Wireless Security System Manufacturer : Hyun Joung System Co., Ltd. Model Number : SAVERCALL-1000 Type of Modulation : FSK Frequency Range : 433.425MHz – 434.415MHz High Frequency 4.096MHz(CPU/CODEC Clock) Tx/Rx Antenna Type : Whip No. of Units : 1 Tx/Rx Rating : Tx/Rx : Main : AC/DC Adaptor 9V 500mA Origin : Korea INVESTIGATIONS REQUESTED : Measurement to the relevant clauses of F.C.C. Rules and Regulations Part15 Subpart B – Unintentional Radiator and Subpart C – Intentional Radiator. TEST PROCEDURE : ANSI C63.4-2000 RESULT / REMARK : Please see attached sheet(s). TEST REPORT Date : 2003-02-13 No. : BRF-0212001 Page 2 of 9 BARO Approval Tech Co. #402, Sewang Building, 127-18, Nonhyun-Dong, Gangnam-Gu, Seoul, 135-010, Korea TEL : 82 2 546 9607, FAX : 82 2 546 9608 CONCLUSION : From the measurement data obtained, the tested sample was considered to have COMPLIED with the clause 15.231 for the Transmitter Section of Federal Communications Commission Rules, Clause 15.231 (a), (b) & (c) and clause 15.109 for the Receiver Section of Part 15 and ANSI C63.4-2000 Section 12.1.1.1 The receiver portion of the main unit is subject to verification per Part 15.101(b), the receiver portion of this transceiver is not part of this application for certification and the receiver was tested and found compliant with Part 15. TEST EQUIPMENT AUDIT : 2003. 2. 13 2003. 2. 13 Testing by M.J. Byun Approval by C.A.Kwon TEST SUMMARY (1) Measurement of Emission of RF energy on the carrier frequency...................... Satisfactory Measurement of the out-of band emissions including harmonics........................ Satisfactory (2) Measurement of Emission Within Band Edges............................................... Satisfactory (3) Measurement of Radiated Emissions........................................................... Satisfactory (4) Measurement of Line-Conducted Voltage onto AC Power Line.......................... Satisfactory (5) FCC rule clause 15.231 (a), (b) and (c) subpart C– Intentional-radiator................. Satisfactory TEST DATA Please refer to the attached result sheets. TEST REPORT Date : 2003-02-13 No. : BRF-0212001 Page 3 of 9 BARO Approval Tech Co. #402, Sewang Building, 127-18, Nonhyun-Dong, Gangnam-Gu, Seoul, 135-010, Korea TEL : 82 2 546 9607, FAX : 82 2 546 9608 INTENTIONAL RADIATOR (Main) (1) Measurement of Radiated Interference TEST REFERENCE : FCC Rule Part 15 Section 15.231 (433.92MHz) TEST CONDITION : Normal TEST DATE : 2002. 12. 16 ∼ 12. 18 Emission of RF energy on the carrier frequency –433.92MHz Emission Frequency Reading (Peak Value) Polarization Antenna Factor & Cable Loss Amp Gain Average Factor Field Strength (at 3m) FCC Limit MHz dB() H-V dB dB dB dB(/m) dB(/m) 433.92 71.2 H 21.7 -27.3 -4.4 61.2 80.825 Calculation of the field strength limits by linear interpolation (F=433.92) Field strength limit of the fundamental frequency: Limit = (F-260)*(12500-3750)/(470-260) + 3750 = 10996.6/m = 80.825 dB/m Field strength limit of spurious emissions: Limit = (F-260)* (1250-375)/(470-260) + 375 = 1099.6/m = 60.825 dB/m Field strength of spurious emissions Emission Frequency Reading (Peak Value) Polarization Antenna Factor & Cable Loss Amp Gain Average Factor Field Strength (at 3m) FCC Limit MHz dB() H-V dB dB dB dB(/m) dB(/m) 867.82 20 V 30.6 -26.7 -4.4 19.5 60.825 *1301.76 < 10 31.7 -26.7 -4.4 < 10.6 54 1735.68 < 10 35.3 -26.6 -4.4 < 14.3 60.825 2169.6 < 10 36.6 -26.4 -4.4 < 15.8 60.825 2603.52 < 10 36.9 -26.4 -4.4 < 16.1 60.825 3037.44 < 10 37.6 -26.3 -4.4 < 16.0 60.825 3471.36 < 10 38.7 -26.3 -4.4 < 18.0 60.825 *3905.28 < 10 39.3 -26.2 -4.4 < 18.7 54 *4339.2 < 10 40.5 -26.2 -4.4 < 19.9 54 Remark: *-Denotes restricted band of operation. TEST REPORT Date : 2003-02-13 No. : BRF-0212001 Page 4 of 9 BARO Approval Tech Co. #402, Sewang Building, 127-18, Nonhyun-Dong, Gangnam-Gu, Seoul, 135-010, Korea TEL : 82 2 546 9607, FAX : 82 2 546 9608 Measurement were made using a peak detector. Any emission less than 1000MHz and falling within the restricted bands of FCC Rules Part 15 Section 15.205 were not adjusted for averaging and the limit of FCC Rules Part15 Section 15.209 were applied. ========== SUMMARY========== Data is within limits Broad-band Antennas were used and both polarizations of emissions were measured. Polarizations at highest reading indicated as; H—Horizontal V--Vertical INTENTIONAL RADIATOR(Main) TEST REPORT Date : 2003-02-13 No. : BRF-0212001 Page 5 of 9 BARO Approval Tech Co. #402, Sewang Building, 127-18, Nonhyun-Dong, Gangnam-Gu, Seoul, 135-010, Korea TEL : 82 2 546 9607, FAX : 82 2 546 9608 (2) Measurement of Emissions Within Band Edges. TEST REFERENCE : FCC Rules Part 15 Section 15.231 (433.92MHz) TEST CONDITION : Normal TEST DATE : 2003. 2. 7 ∼ 2. 7 RESULTS AND NOTES The bandwidth of the emission shall be no wider than 0.25% of the center frequency for devices operating above 70MHz and below 900MHz. The bandwidth is determined at the points 20dB down from the modulated carrier. @433.92MHz 433.92 MHz x 0.0025 =1084.8 KHz 1084.8 KHz / 2 =542.4 KHz The bandwidth at 20dB down is 37.41kHz which is within the allowable limit of 542.4KHz at 433.92MHz. ========== SUMMARY========== ALL data is within limits UNINTENTIONAL RADIATOR(Main) TEST REPORT Date : 2003-02-13 No. : BRF-0212001 Page 6 of 9 BARO Approval Tech Co. #402, Sewang Building, 127-18, Nonhyun-Dong, Gangnam-Gu, Seoul, 135-010, Korea TEL : 82 2 546 9607, FAX : 82 2 546 9608 (3) Measurement of Radiated Interference TEST REFERENCE : FCC Rule…

Text truncated - open the document above for the full version.

Test Photo
